Siemens Pointek CLS200 Instruction manual

Capacitance Switches
Quick Start Manual 09/2010
Pointek CLS200/CLS300 (Digital)

7ML19985XA82 Pointek CLS200/300 (Digital) – QUICK START MANUAL Page EN-1
mmmmm
English
Note: Information in boxes 1 through 7 changes based on customer order.
CLS200 (Digital)
CLS300 (Digital)

Page EN-2 Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA82
mmmmm
English
Pointek CLS200/300 (Digital) Quick Start
Manual
This manual outlines the essential features and functions of the Pointek CLS200/300. We strongly
advise you to acquire the detailed version of the manual so you can use your instrument to its
fullest potential. The complete manual is available at: www.siemens.com/level. The printed
manual is available from your Siemens Milltronics representative.
Questions about the contents of this manual can be directed to:
Siemens Milltronics Process Instruments Inc.
1954 Technology Drive, P.O. Box 4225
Peterborough, Ontario, Canada, K9J 7B1
Email: techpubs.smp[email protected]
MILLTRONICS is a registered trademark of Siemens Milltronics Process Instruments Inc.
Safety Guidelines
Warning notices must be observed to ensure personal safety as well as that of others, and to
protect the product and the connected equipment. These warning notices are accompanied by
a clarification of the level of caution to be observed:
1
Copyright Siemens Milltronics
Process Instruments Inc. 2010.
All Rights Reserved
Disclaimer of Liability
We encourage users to purchase authorized
bound manuals, or to view electronic
versions as designed and authored by
Siemens Milltronics Process Instruments
Inc. Siemens Milltronics Process
Instruments Inc. will not be responsible for
the contents of partial or whole
reproductions of either bound or electronic
versions.
While we have verified the contents of this manual for
agreement with the instrumentation described,
variations remain possible. Thus we cannot guarantee
full agreement. The contents of this manual are
regularly reviewed and corrections are included in
subsequent editions. We welcome all suggestions for
improvement.
Technical data subject to change.
WARNING: relates to a caution symbol on the product, and means that failure to
observe the necessary precautions can result in death, serious injury, and/or
considerable material damage.
WARNING1: means that failure to observe the necessary precautions can result
in death, serious injury, and/or considerable material damage.
CAUTION: means that failure to observe the necessary precautions can result in
considerable material damage.
Note: means important information about the product or that part of the operating manual.
1. This symbol is used when there is no corresponding caution symbol on the product.

7ML19985XA82 Pointek CLS200/300 (Digital) – QUICK START MANUAL Page EN-3
mmmmm
English
Pointek CLS200/300 (Digital)
Pointek CLS200/300 is a versatile capacitance
switch with a high level of chemical
resistance; ideal for level detection of
interfaces, solids, liquids, slurries, and foam,
and for simple pump control.
Approvals (verify against
device nameplate)
•CE,CSA
C/US, FM, ATEX
•VlaremII,WHG
• Lloyd’s Register of Shipping, categories
ENV1, ENV2, and ENV5
Process connections
Compact (std.) configuration R ¾", 1", 1 1/4", 1 ½" BSPT; ¾", 1", 1 1/4", 1 ½" NPT; G ¾", 1",
1 ½" BSPP
Sanitary configuration 1", 1 ½", 2", 2 ½"and 3" tri-clamp
Cable and slide coupling R ¾", 1", 1 1/4", 1 ½" BSPT; ¾", 1", 1 1/4", 1 ½" NPT (Taper);
configuration G ¾", 1", 1 ½" BSPP
Ambient temperature
• General applications -40 to +85 °C (-40 to +185 °F)
- local display -30 to +85 °C (-22 to +185 °F)
- storage temperature -40 to +85 °C (-40 to +185 °F)
• In potentially explosive atmospheres (check temperature class shown on device
nameplate)
Process Conditions
• relative dielectric constant (r1.5 minimum
• CLS200 temperature1:
- without thermal isolator -40 to +85 °C (-40 to +185 °F)
- with thermal isolator -40 to +125 °C (-40 to +257 °F)
Note: Pointek CLS200/300 is to be used only in the manner outlined in this manual, otherwise
protection provided by the equipment may be impaired.
This product is intended for use in industrial areas. Operation of this equipment in a
residential area may cause interference to several frequency based communications.
Note: The use of approved watertight conduit hubs/glands is required for Type 4 / NEMA 4,
Type 6 / NEMA 6, IP68 (outdoor applications). For CE requirements, the use of EMC-rated
cable entries is required.
Note: Please see full Operating Instructions for Process Pressure/Temperature De-
rating Curves.
1. At process connection.
Digital version
lid with window
integral digital display
optional M12 plug
available
device
nameplate

Page EN-4 Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA82
mmmmm
English
• CLS200 pressure (vessel):
- rod version -1 to 25 bar g/-14.6 to 365 psi g
- cable version -1 to 10 bar g/-14.6 to 150 psi g
• CLS300 temperature1:
- rod/cable version -40 to +200 °C (-40 to +185 °F)
- high-temperature version -40 to +400 °C (-40 to +752 °F)
• CLS300 pressure (vessel):
-1 to 35 bar g/-14.6 to 511 psi g
Power
Bus voltage
• General purpose 12 to 30 V DC, 12.5 mA
• Intrinsically Safe 12 to 24 V DC, 12.5 mA
Installation
Mounting Location
• Do: provide a sun shield to protect the transmitter from direct heat radiation.
• Do not: exceed the permissible ambient temperature limits.
• Do not: mount Pointek CLS200/300 in locations subject to strong vibrations (if it can be
avoided).
Pointek CLS200/300 (standard probe length): top or side mounting
High level alarm
• normally mounted into the vessel top, or
• through the tank wall at the detection level
1. At process connection.
Notes:
• Installation shall only be performed by qualified personnel and in accordance with local
governing regulations.
• This product is susceptible to electrostatic shock. Follow proper grounding procedures.
• The housing may only be opened for maintenance, local operation, or electrical
installation.
• Before installing the instrument, verify that the environment complies with any restrictions
specified on the device nameplate.
Notes:
• Keep the sensor at least 50 mm (2") away from any nozzle or tank wall.
• If multiple units are used, allow at least 100 mm (4") between them, to prevent interference
(mount diagonally if space is restricted).
normal process
level
normal process
level
vertical
horizontal

7ML19985XA82 Pointek CLS200/300 (Digital) – QUICK START MANUAL Page EN-5
mmmmm
English
Low level alarm
• mounted through the tank wall at the detection level
Standard configuration with extensions: top mounting
• Designed for top mounting, for high or low level alarm. Suspend the probe vertically so
that it reaches into the process at the desired detection level.
Process Cautions
• The maximum allowable torque on a horizontally installed rod is 15 Nm.
• Keep unit out of path of falling material, or protect probe from falling material.
• Avoid areas where material build up occurs.
• Take into account material surface configuration when installing unit.
• Ensure tensile load does not exceed probe or vessel ratings.
Mounting Instructions
Pointek CLS200/300 is available in three thread types: NPT or BSPT (R) or BSPP (G)1. Make
sure the mounting connection threads are of the same type, then simply screw Pointek
CLS200/300 into the process connection, and hand tighten.
Wiring: standalone unit
Electrical Connection
1. Asanitary connection is also available.
WARNING:
• Observe the specifications of the examination certificate valid in your country.
• Observe the laws and regulations valid in your country for electrical installations in
potentially explosive atmospheres.
• Ensure that the available power supply complies with the power supply specified on
the product nameplate and specified in the examination certificate valid in your
country.
• Dust-proof protection caps in the cable inlets must be replaced by suitable screw-
type glands or dummy plugs, which are appropriately certified for transmitters with
explosion-proof protection.
• The lid must not be opened in wet locations while the unit is powered. (A wet
location is location where water or another conductive fluid may be present and is
likely to increase the risk of electric shock.)
• For CE installations use a cable with a braided metallic shield (or armoured cable
where applicable).
50 mm
(2") min

Page EN-6 Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA82
mmmmm
English
Power connection to screw terminals (standalone unit)
1. Loosen the lid clip and unscrew the lid
of the enclosure.
2. Unscrew and lift up the digital display.
3. Connect the wires to the terminals:
polarity is not important. (Terminal is
removable.)
4. To use the Alarm Output, connect the
wires of an optional input to the Alarm
Output terminals: polarity is not
important. (Terminal is removable.)
5. Ground the instrument according to
local regulations1.
6. Tighten the gland to form a good seal.
7.
Replace the digital display.
8. To adjust the transmitter locally,
use the keypad. (See
Setup using 3-
button keypad
on page 7 and the
Quick Reference table on page 8).
After adjustment, replace the
enclosure lid and secure the lid clip.
Operation
Digital display
Selected in Mode 13: displays either the measured value, logical level, mode number and
numerical value for the selected mode, or electronics temperature.
Measured value display
• default display at startup
• value (in counts2) when Sensor (2) selected3
1. The usual PROFIBUS PA recommendation is to ground the shield on both the device side and the cable
side. In some cases it may be preferable to ground one side only, to avoid ground loops.
2. A dimensionless value generated from the inverse of frequency.
3. Switch function (open/closed) depends on setting at Mode 24.
lid clip
digital display
removable
terminal block:
for PROFIBUS
PA/power
connection
removable
terminal block
for alarm output/
solid-state
switch
gland
power
cable
white
power cable
reed
contact
white
red(+)
black (–)
orange (f)
PROFIBUS PA
PA+ PA–
sensor
alarm output
solid-state switch test
input
bar graph
sensor uncovered
down arrow
(switch open3)

7ML19985XA82 Pointek CLS200/300 (Digital) – QUICK START MANUAL Page EN-7
mmmmm
English
Logical level display (output status)
• value when OUT parameter of Discrete
input function block (0) selected
Bar graph
• represents extent to which sensor is covered
• displayed when one of the three following options is selected in Mode 13: the OUT
parameter of the Discrete input function block; or the Primary Value of the Transducer
Block; or the Sensor Value discrete of the Transducer Block1,
Setup using 3-button keypad
Initial setup can be carried out prior to mounting into the process, but it is extremely important
to calibrate the unit and adjust the sensitivity on the product itself.
• Flashing digit indicates cursor position.
• Press M to select a mode. Hold Mand tap to move
backwards.
• To increment or decrement a value, press or .
• To move cursor to the right, press 
• After editing the least-significant digit, press to
store the value.
• To enter a selection (not a numerical value) press M.
Magnet-activated sensor test
Bring the bar magnet supplied close to the test area on the housing. After
approximately 10 seconds, SENSOR TEST SUCCESSFUL, or SENSOR TEST FAILED,
is displayed as rolling text.
Error message display
Please see the full manual for details.
1. Switch function (open/closed) depends on setting at Mode 24.
WARNING: It is essential to check settings during the process itself, and confirm
that they are correct, before regular operation commences.
Notes:
• See Quick Reference table on next page for Modes of Operation.
• Ensure HW Write Protection is disabled (Mode 10, page 8).
sensor covered
active
communications symbol
up arrow
(switch closed1)
Rising Edge
(Switch Point 1)
Falling Edge
(Switch Point 2)
100% Application
Range setting
0% Application
Range setting
M
mode
indicator
added indicator
(Mode 4)
auxiliary
reading
primary
reading

Page EN-8 Pointek CLS200/300 (Digital) – QUICK START MANUAL Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA02
Appendix C: menu chart
Quick Reference: operating functions using input keypad
Function,
(parameter in PDM) Mode Key function Display/ explanation
M 1
1. Press to store numerical values; press Mto store a selection (indicated by asterisk *).
and 
Measured value display2
2. Lappears in Mode indicator field if HW Write Protection is enabled.
Default startup display; or if Sensor selected in Mode 13
Error display Error, if transmitter is disturbed
Sensor test 2 * Either key activates test Displays GOOD or FAIL D
Rise Time 4Open Edit mode, or
increment digit.
Move cursor to right, or decrement digit, or
store edited value.
and value (seconds)
Range: 0.0 to 100.0 s
Fall Time 5Open Edit mode, or
increment digit.
Move cursor to right, or decrement digit, or
store edited value.
and value (seconds)
Range: 0.0 to 100.0 s
HW Write Protection 10 * Either key enables Write Protection2Hold for 5
seconds to
disable3
3. If Lor LA appear after disabling HW Write Protection, local operation is locked via the bus. Use PDM to disable this lock.
– – = disabled (parameter changes permitted)
L= enabled (parameter changes inhibited)
Display Source 13 * Increment or decrement value to make selection 0= OUT parameter; 1= primary value;
2= sensor; 3= electronics temperature
Unit 14 * Increment or decrement value to make selection. Select oC; oF; oR, or K (if 3 selected in Mode 13).
Node address (PROFIBUS
only) 15 Open Edit mode, or
increment digit.
Move cursor to the right, or decrement digit, or
store edited value. Assign slave address on the PROFIBUS-line (0 to 126)
PROFIBUS Ident Number 16 * Increment or decrement value to make selection. Select device mode: according to profile; or, according to profile with full device
specific support.
M1and 
0% Application Range
setting 19 Open Edit mode, or
increment digit.
Move cursor to the right, or decrement digit, or
store edited value. Adjust lower limit of application range.
100% Application Range
setting 20 Open Edit mode, or
increment digit.
Move cursor to the right, or decrement digit, or
store edited value. Adjust upper limit of application range.
Alarm output trigger 23 * Increment or decrement value to make selection. Select diagnostic interrupt (dIAG); process interrupt (OUt_d); disabled (OFF): or
diagnostic alarm limit (set in PDM) exceeded (ALErt)
Contact type 24 * Increment or decrement value to make selection. Set contact functionality in case of event: (logical inversion of alarm output switch)
- Make contact (CLOSE) / Break contact (OPEn)
Switch Point 1
(Rising Edge)
OFF to ON
25 Open Edit mode, or
increment digit.
Move cursor to the right, or decrement digit, or
store edited value.
Set % of range at which switch will change from OFF to ON. (Hysteresis is a
difference in value between Switch Point 1 and 2).
Switch Point 2
(Falling Edge)
ON to OFF
26 Open Edit mode, or
increment digit.
Move cursor to the right, or decrement digit, or
store edited value.
Set % of range at which switch will change from ON to OFF.
(Hysteresis is a difference in value between Switch Point 1 and 2).
Local Status Text 27 * Increment or decrement value to make selection. Select presentation of the status text.

Page EN-9 Pointek CLS200/300 (Digital) – QUICK START MANUAL Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA02
Appendix C: menu chart

Page EN-10 Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA82
mmmmm
English
Pointek CLS200/300 Digital unit on a PROFIBUS
network
Wiring: connection to a PROFIBUS PA network
PROFIBUS PA connection to screw terminals
Connect the PROFIBUS cable to the screw terminals, following the instructions on page 6.
.
PROFIBUS PA connection via M12 plug
If an M12 plug is installed on thePointek
CLS200/300 enclosure, a female M12 receptacle
is required on the end of the cable, to complete
the bus connection to PROFIBUS PA.
The usual PROFIBUS PA recommendation is to
ground the shield on both the device side and
the cable side. In some cases (for example, on
cathodically protected tanks), it may be
preferable to ground one side only, to avoid
ground loops.
WARNING: The requirements listed under WARNINGS on page 5 must be fulfilled.
Notes:
• Lay PA cable separately from power cable with voltages greater than 60 V AC.
• Avoid locating Pointek CLS200/300 near large electrical equipment wherever possible.
• Connect the cable shield to earth (for example, to the housing by means of a metallic
screwed gland).
M12 plug
(device side)
M12receptacle
(cable side)
digital display
lid with window
Pin assignment: device side Pin assignment: cable side
PIN PROFIBUS PA
1PA+
2 not connected
3PA–
4 shield, connected to ground
thread M12 x 1
positioning lug positioning nut
PIN PROFIBUS PA
1PA+
2 not connected
3PA–
4 shield, connected to ground
12
43
21
34
Front view of pin
insert and pins
Front view of
sleeve insert and
sleeves
Follow the instructions
accompanying the
female receptacle.

7ML19985XA82 Pointek CLS200/300 (Digital) – QUICK START MANUAL Page EN-11
mmmmm
English
Communications via PROFIBUS PA: Pointek CLS200/300
Digital model
Pointek CLS200/300 is a Class B, Profile Version 3.0, PA device. It supports Class 1 Master for
cyclic data exchange, and Class 2 for acyclic services.
To configure Pointek CLS200/300 we recommend SIMATIC Process Device Manager (PDM) by
Siemens. (For more information go to > www.siemens.com/simatic-pdm.)
Device Description
To use PDM with PROFIBUS PA, you will need the Device Description (DD) for Pointek CLS200/
300. Go to > Device Catalog > Sensors/Level/Capacitive/Siemens Milltronics, or download it
from: www.siemens.com/level under Downloads on the Pointek CLS200/300 product page.
After downloading the DD file, you need to execute DeviceInstall.
Configuration
To configure a PROFIBUS Class 1 Master (for example, a PLC), you will need the GSD file,
SIEM80E9.GSD. It can be downloaded from the Pointek CLS200/300 product page at:
www.siemens.com/level, under Downloads.
Setting the PROFIBUS address
The factory setting for the PROFIBUS address is 126. Reset it locally using Mode 15 (see page 8),
or remotely via the bus, using a parameterization tool such as SIMATIC PDM or HW Config.
When cyclic data transfer with a Class 1 Master is in process, the address can only be
changed via the bus.
Bus Termination
Transmission of user data via PROFIBUS PA
The user data is the OUT parameter of the discrete input function block and is composed of the
Logical Level and Status bytes.
Logical Level
Status
• the usability of the measured value in the user program
• the device status (self-diagnosis/system diagnosis)
• additional process information (process alarms)
Please see the full manual for tables listing the codes for the Status byte.
Notes:
• The following instructions assume that the user is familiar with PROFIBUS PA.
• For more detail, please see the full manual.
Note: PROFIBUS PA line must be terminated at both extreme ends of the cable for it to work
properly. Please refer to the PROFIBUS PA User and Installation Guidelines (order number
2.092), available from www.profibus.com.
Inversion Sensor Status Logical Level
OFF uncovered = 0(zero)
OFF covered = 1

Page EN-12 Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA82
mmmmm
English
Configuring the user data
The Discrete input function block supplies the content of the OUT parameter.
Diagnosis
Pointek CLS200/300 can actively report information on its own status. Please see the full
manual for a list of diagnostic messages.
Remote Operation via PROFIBUS PA
To use PROFIBUS PA, you will need a PC configuration tool: we recommend SIMATIC PDM. You
can download an application guide from the product page at www.siemens.com/pointek. Also
see the proprietary operating instructions or online help for details.
Functions
Open the device menu (top left side of screen) for access to the following functions: upload
from/download to the device; set address; master reset; write locking; sensor test via
PROFIBUS PA; and simulation.
Changing parameter settings
• First launch SIMATIC PDM, connect to Pointek CLS200/300, and upload data from the
device.
• Adjust parameter values in the parameter view field (right side of screen).
• When you have completed the adjustments, open the Device menu, download data to the
device, then save parameter settings offline.
•GotoView – Display to track the effects.
Notes:
• To configure STEP 7, use HW Config.

7ML19985XA82 Pointek CLS200/300 (Digital) – QUICK START MANUAL Page EN-13
mmmmm
English
Quick Setup
Initial setup can be carried out prior to mounting into the process, but it is extremely important
to calibrate the unit and adjust the sensitivity on the product itself.
Adjust 0 % application range setting
CLS200 Digital
1. Install the device in the process.
2. Open the menu View – Display and select the tab Transducer Block: Discrete Input
(Part 1). Make a note of the Sensor Value (digits) when the device is in the setup
condition that most closely represents the process (refer to table above).
3. Subtract 300 counts from the Sensor Value noted in step 2 and enter this new value in the
parameter view field: > Input > Transducer Block: Discrete Input > Range of Application>
0%.
CLS300 Digital
1. Install the device in the process.
1. Open the menu View – Display and select the tab Transducer Block: Discrete Input
(Part 1). Make a note of the Sensor Value (digits) when the device is in the setup
condition that most closely represents the process (refer to table above).
2. Enter the sensor value in the parameter view field: > Input > Transducer Block: Discrete
Input > Range of Application> 0%.
WARNING: It is essential to check settings during the process itself, and confirm
that they are correct, before regular operation commences.
Note: After adjusting values, download data to the device, then go to View – Display to track
the effects.
Application Material Setup conditions
General
applications
dry solids
low viscosity liquids
Sensor uncovered and a minimum of 100 mm (4")
free space all around
Demanding
applications
hygroscopic / wet solids
high viscosity and high
conductivity liquids
Sensor immersed and then uncovered, but
retaining as much build up of material as possible
on the sensor.
Interface
detection
liquid A / liquid B
foam / liquid
Immerse the sensor in the material that has the
lowest dielectric constant.

Page EN-14 Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA82
mmmmm
English
Adjust 100 % application range setting
CLS200 Digital
1. Open the menu View – Display and select the tab Transducer Block: Discrete Input
(Part 1). Make a note of the Sensor Value (digits) when the device is in the setup
condition that most closely represents the process (refer to table above).
2. Add 1000 counts to the Sensor Value noted in step 1and enter this new value in the
parameter view field: > Input > Transducer Block: Discrete Input > Range of Application >
100%.
CLS300 Digital
1. Open the menu View – Display and select the tab Transducer Block: Discrete Input
(Part 1). Make a note of the Sensor Value (digits) when the device is in the setup
condition that most closely represents the process (refer to table above).
2. Enter the sensor value in the parameter view field: > Input > Transducer Block: Discrete
Input > Range of Application > 100%.
Switch Point adjustment
CLS200 Digital
1. Define the application range (from tables above).
2. Open the menu View–Display, and select the tab Transducer Block: Discrete Input
(Part 1), to view the actual Sensor Value, the Sensor Value Discrete, the actual valid
Switch Point and Hysteresis
3. Go to Input > Transducer Block: Discrete Input > Switch behavior.
- Edit the value of Switch Point 1 (default 55%).
- Edit the value of Switch Point 2 (default 45%) to adjust the Hysteresis.
CLS300 Digital
1. Define the application range (from tables above).
2. Open the menu View–Display, and select the tab Transducer Block: Discrete Input
(Part 1), to view the actual Sensor Value, the Sensor Value Discrete, the actual valid
Switch Point and Hysteresis
3. Go to Input > Transducer Block: Discrete Input > Switch behavior.
- Edit the value of Switch Point 1 (default 55%).
- Edit the value of Switch Point 2 (default 45%) to adjust the Hysteresis.
Application Material Setup conditions
General applications dry solids
low viscosity liquids
Sensor fully covered
Demanding
applications
hygroscopic / wet solids
high viscosity and high
conductivity liquids
Sensor fully covered
Interface detection liquid A / liquid B
foam / liquid
Immerse the sensor in the material that
has the highest dielectric constant.
Note: A minimum hysteresis (difference between the Off to On switch point and the On to
Off switch point) of 10% must be maintained for reliable operation. In some situations it may
be desirable to increase the hysteresis between the two switch points to prevent false
tripping (e.g. turbulence in the process).

7ML19985XA82 Pointek CLS200/300 (Digital) – QUICK START MANUAL Page EN-15
mmmmm
English
Delay
•Rise Time (Off to On) determines the delay of the signal flow from the moment the sensor
becomes covered until the Primary Value is set.
•Fall Time (On to Off) determines the delay of the signal flow from the moment the sensor
becomes uncovered until the Primary Value is reset.
The delay timers have a range of values from 0.0 to 100.0 seconds.
•GotoInput > Transducer Block: Discrete Input > Delay > Rise Time (Off to On) and set the
value from 0 to 100 seconds.
•GotoFall Time (On to Off), and set the value from 0 to 100 seconds.
Inversion
When Inversion Output = On, the level status undergoes a logical inversion.
•GotoOutput > Function Block: Discrete Input > Inversion Output > Off or On
Failsafe Mode
Go to Output > Function Block: Discrete Input > Fail Safe Mode > Fail Safe Mode and select
one of the three options:.
Resetting
Open the Device Menu Master Reset and select one of the three options:
Factory Reset (restart/cold startup)
Recreates the delivery status. It resets most parameters to the factory setting.
Warm start (new start-up)
Disconnects then restarts Pointek CLS200/300. Communication is interrupted and re-
established. Use it if, for example, the PROFIBUS address has been changed.
Resetting the PROFIBUS address to 126
Please see the full manual for details.
Note: If the sensor status changes before the delay interval is complete, the timer is reset to
its initial value and restarted.
Failsafe Mode Description
The default value is used as the output
value.
The predefined preset safety value is output (status code
U_075).
Store the last valid output value. The last valid output value is output (status code U_071).
The calculated output value is incorrect. The bad output value is accompanied by the status which
the Transducer block assigns to it (B_0xx).

Page EN-16 Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA82
mmmmm
English
Local display and operation
1. Go to Local Display and Operation > Local Operation:
Locking functions can be combined:
2. Go to Local Display and Operation > Display source:
select either Output Value, Primary Value, Sensor Value, or Electronics Temperature.
3. Go to Local Display and Operation > Local Status Text:
select a language, or numeric option.
Sensor Test
Open the Device Menu to find and activate Sensor Test via PDM, and to see the results:
(test successful, or test failed).
Error Messages and References: PROFIBUS PA
Lock
options Effect Turn on/off Digital display
HW Write
Protection
Parameter changes using SIMATIC PDM and
settings via local operation are both disabled.
Independent of the other lock functions.
Keypad
Mode 10
L
Write locking Prevents parameter changes via the bus. Local
operation is possible.
SIMATIC PDM
(via Device Menu)
Lc
Local
Operation
When disabled, no access is possible via the
keypad. After a communication failure, local
operation is automatically enabled 30 s later. Once
communication is reestablished, the original
setting for Local Operation is restored.
SIMATIC PDM LA
HW Write Protection Write locking Local Operation Digital display
Off Off enabled
On On or Off enabled or disabled L
Off Off disabled LA
Off On disabled LL
Off On enabled Lc
Note: For more detail, please consult the PROFIBUS PA User and Installation Guideline
(order number 2.092), available for download from www.profibus.com.

7ML19985XA82 Pointek CLS200/300 (Digital) – QUICK START MANUAL Page EN-17
mmmmm
English
Instructions specific to hazardous area installations (Reference
European ATEX Directive 94/9/EC, Annex II, 1/0/6)
The following instructions apply to equipment covered by certificate number KEMA
03ATEX1007X , KEMA 03ATEX1008X, KEMA 03ATEX1010X, KEMA 00ATEX2039X and KEMA
00ATEX2040X:
1. For use and assembly, refer to the main instructions.
2. The equipment is certified for use as Category 1G, 1/2G, 3G, 1/2D, 2D. Refer to appropriate
certificate.
3. Refer to appropriate certificate for application in specific hazardous environment.
4. Refer to appropriate certificate for ambient temperature range.
5. The equipment has not been assessed as a safety related device (as referred to by
Directive 94/9/EC Annex II, clause 1.5).
6. Installation and inspection of this equipment shall be carried out by suitably trained
personnel in accordance with the applicable code of practice (EN 60079-14 and EN 60079-
17 in Europe).
7. Repair of this equipment shall be carried out by suitably trained personnel in accordance
with the applicable code of practice (e.g. EN 60079-19 within Europe).
8. Components to be incorporated into or used as replacements in the equipment shall be
fitted by suitably trained personnel in accordance with the manufacturer's
documentation.
9. The certificate numbers have an 'X' suffix, which indicates that special conditions for
safe use apply. Those installing or inspecting this equipment must have access to the
certificates.
10. If the equipment is likely to come into contact with aggressive substances, then it is the
responsibility of the user to take suitable precautions that prevent it from being adversely
affected, thus ensuring that the type of protection is not compromised.
Aggressive substances: e.g. acidic liquids or gases that may attack metals, or solvents
that may affect polymeric materials.
Suitable precautions: e.g. establishing from the material's data sheet that it is resistant to
specific chemicals.
Maintenance
Pointek CLS200/300 requires no maintenance or cleaning.
Unit Repair and Excluded Liability
For detailed information, please see the inside back cover.
Note: Please see www.siemens.com/pointek for the latest approval certificates.

Page EN-18 Pointek CLS200/300 (Digital) – QUICK START MANUAL 7ML19985XA82
mmmmm
English
Notes

7ML19985XA82 Pointek CLS200/300 (Digital) – KVIKSTART MANUAL Side DA-1
mmmmm
Dansk
Bemærk: Oplysningerne i boksene 1 til 7 ændres på basis af kundens ordre.
CLS200 (Digital)
CLS300 (Digital)
