Siemens SIMATIC NET RUGGEDCOM i801 User manual

Edition 01/2021
Installation Manual
SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM i801
https://www.siemens.com

SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM i801
Installation Manual
Preface
Introduction 1
Installing the Device 2
Device Management 3
Communication Ports 4
Technical Specifications 5
Certification 6
01/2021
C79000-G8976-1003-06

Legal Information
Warning Notice System
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety
alert symbol, notices referring only to property damage have no safety alert symbol. These notices shown
below are graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger
will be used. A notice warning of injury to persons with a safety alert symbol may also include a warning
relating to property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the
specific task in accordance with the relevant documentation, in particular its warning notices and safety
instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper Use of Siemens Products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant
technical documentation. If products and components from other manufacturers are used, these must be
recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning,
operation and maintenance are required to ensure that the products operate safely and without any
problems. The permissible ambient conditions must be complied with. The information in the relevant
documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of
the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Digital Industry
Process Automation
Postfach 48 48
90026 NÜRNBERG
GERMANY
© 01/2021 Subject to Change Copyright © Siemens 2021
All rights reserved

Table of Contents
Preface ............................................................................................................................................ v
Related Documents ................................................................................................................. v
Accessing Documentation ....................................................................................................... v
Registered Trademarks ............................................................................................................ v
Warranty ................................................................................................................................. v
Training .................................................................................................................................. vi
Customer Support .................................................................................................................. vi
Contacting Siemens ............................................................................................................... vii
1 Introduction ........................................................................................................................... 1
1.1 Feature Highlights ................................................................................................. 1
1.2 Description ............................................................................................................ 2
1.3 Required Tools and Materials ................................................................................. 3
1.4 Decommissioning and Disposal ............................................................................. 4
1.5 Supported Fiber Optic Cables ................................................................................ 4
2 Installing the Device ............................................................................................................. 5
2.1 General Procedure ................................................................................................. 6
2.2 Unpacking the Device ........................................................................................... 6
2.3 Mounting the Device ............................................................................................. 6
2.4 Connecting the Failsafe Alarm Relay (If Equipped) ................................................. 8
2.5 Connecting Power ................................................................................................. 9
3 Device Management ........................................................................................................... 11
3.1 Connecting to the Device .................................................................................... 11
3.2 Configuring the Device ........................................................................................ 12
3.3 Inserting/Removing the MicroSD/MicroSDHC Card ................................................ 12
4 Communication Ports .......................................................................................................... 15
4.1 Copper Ethernet Ports ......................................................................................... 15
4.2 Fiber Optic Ethernet Ports ................................................................................... 17
5 Technical Specifications ...................................................................................................... 19
5.1 Power Supply Specifications ................................................................................ 19
5.2 Failsafe Alarm Relay Specifications ...................................................................... 19
5.3 Copper Ethernet Port Specifications ..................................................................... 19
5.4 Fiber Optic Ethernet Port Specifications ............................................................... 20
5.5 Operating Environment ....................................................................................... 20
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06 iii

Table of Contents
5.6 Mechanical Specifications .................................................................................... 20
5.7 Dimension Drawings ........................................................................................... 21
6 Certification ......................................................................................................................... 23
6.1 Approvals ............................................................................................................ 23
6.1.1 CSA ..................................................................................................................... 23
6.1.2 ATEX/IEC Ex ......................................................................................................... 24
6.1.3 European Union (EU) .......................................................................................... 24
6.1.4 FCC ..................................................................................................................... 25
6.1.5 FDA/CDRH ........................................................................................................... 25
6.1.6 ISED .................................................................................................................... 25
6.1.7 ISO ...................................................................................................................... 26
6.1.8 ACMA .................................................................................................................. 26
6.1.9 RoHS ................................................................................................................... 26
6.1.10 Other Approvals .................................................................................................. 27
6.2 EMC and Environmental Type Tests ..................................................................... 27
iv RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06

Preface
This guide describes the RUGGEDCOM i801 (i-Series) product line. It describes the
major features, installation, commissioning and important technical specifications.
It is intended for use by network technical support personnel who are responsible
for the installation, commissioning and maintenance of the device. It is also
recommended for use by network and system planners, system programmers, and
line technicians.
Related Documents
Other documents that may be of interest include:
Document Title Link
RUGGEDCOM ROS Configuration Manual https://support.industry.siemens.com/cs/ww/en/
view/109737193
Accessing Documentation
The latest user documentation for RUGGEDCOM i801 is available online at https://
support.industry.siemens.com . To request or inquire about a user document,
contact Siemens Customer Support.
Registered Trademarks
RUGGEDCOM ™ and ROS™ are trademarks of Siemens AG.
Other designations in this manual might be trademarks whose use by third parties
for their own purposes would infringe the rights of the owner.
Warranty
Siemens warrants this product for a period of five (5) years from the date of
purchase, conditional upon the return to factory for maintenance during the
warranty term. This product contains no user-serviceable parts. Attempted service by
unauthorized personnel shall render all warranties null and void. The warranties set
forth in this article are exclusive and are in lieu of all other warranties, performance
guarantees and conditions whether written or oral, statutory, express or implied
(including all warranties and conditions of merchantability and fitness for a particular
purpose, and all warranties and conditions arising from course of dealing or usage
or trade). Correction of nonconformities in the manner and for the period of time
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06 v

Preface
Training
provided above shall constitute the Seller’s sole liability and the Customer’s exclusive
remedy for defective or nonconforming goods or services whether claims of the
Customer are based in contract (including fundamental breach), in tort (including
negligence and strict liability) or otherwise.
For warranty details, visit https://www.siemens.com or contact a Siemens customer
service representative.
Training
Siemens offers a wide range of educational services ranging from in-house training
of standard courses on networking, Ethernet switches and routers, to on-site
customized courses tailored to the customer's needs, experience and application.
Siemens' Educational Services team thrives on providing our customers with the
essential practical skills to make sure users have the right knowledge and expertise
to understand the various technologies associated with critical communications
network infrastructure technologies.
Siemens ' unique mix of IT/Telecommunications expertise combined with domain
knowledge in the utility, transportation and industrial markets, allows Siemens to
provide training specific to the customer's application.
For more information about training services and course availability, visit https://
www.siemens.com or contact a Siemens Sales representative.
Customer Support
Customer support is available 24 hours, 7 days a week for all Siemens customers.
For technical support or general information, contact Siemens Customer Support
through any of the following methods:
Online
Visit http://www.siemens.com/automation/support-request to submit a
Support Request (SR) or check on the status of an existing SR.
Telephone
Call a local hotline center to submit a Support Request (SR). To locate a
local hotline center, visit https://w3.siemens.com/aspa_app/?lang=en.
Mobile App
Install the Industry Online Support app by Siemens AG on any Android,
Apple iOS or Windows mobile device and be able to:
• Access Siemens' extensive library of support documentation,
including FAQs and manuals
• Submit SRs or check on the status of an existing SR
• Contact a local Siemens representative from Sales, Technical Support,
Training, etc.
vi RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06

Preface
Contacting Siemens
• Ask questions or share knowledge with fellow Siemens customers
and the support community
Contacting Siemens
Address Siemens AG
Industry Sector
300 Applewood Crescent
Concord, Ontario
Canada, L4K 5C7
Telephone Toll-free: 1 888 264 0006
Tel: [phone]
Fax: [phone]
E-Mail [email protected]
Web https://www.siemens.com
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06 vii

Preface
Contacting Siemens
viii RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06

Introduction 1
The RUGGEDCOM i801 is a compact, fully managed Ethernet switch designed to
operate reliably in harsh industrial environments. The flexibility of the RUGGEDCOM
i801 allows the user to choose from managed or unmanaged, regular or extended
temperature, fiber optical or copper interfaces, and fast or Gigabit Ethernet. With
up to nine Ethernet ports, the RUGGEDCOM i801 is the perfect choice for a wide
variety of demanding industrial environments such as those found in process control
applications (oil and gas, petro-chemical, metals and mining, wind farms).
The RUGGEDCOM i801 is packaged in a compact, die cast aluminum, DIN mountable
enclosure for efficient use of cabinet space. Dual 24 VDC power inputs increase
reliability in case of primary power supply faults. The i800 provides a high level of
immunity to electromagnetic interference and heavy electrical surges typical of
environments found in industrial applications. An operating temperature range of
-20 to 60 °C (-4 to 140 °F) or optionally -40 to 85 °C (-40 to 185 °F), coupled with
hazardous location certification (Class 1 Division 2) allows the RUGGEDCOM i801 to
be placed in almost any location.
The RUGGEDCOM i801 features a full array of intelligent functionality for high
network availability and manageability. The embedded Rugged Operating System
(ROS) provides advanced Layer 2 and Layer 3 networking functions, and advanced
cyber security features. The Enhanced Rapid Spanning Tree Protocol (eRSTP) provides
very fast network recovery in case of failures, guaranteeing a high availability
network, and allows any topology from ring to mesh. Numerous other features
like VLANs and QoS make the RUGGEDCOM i801 an enterprise class switch in an
industrial class package.
1.1 Feature Highlights
Ethernet Ports
• Up to 8 x 10/100Base-TX ports
• 1 x 1000Base-LX or 10/100/1000Base-TX port
• Industry standard LC fiber optical connectors
• Multi-mode and single-mode optical transceivers
Cyber Security Features
• Multi-level user passwords
• SSH/SSL (128-bit encryption)
• Enable/disable ports, MAC based port security
• Port based network access control (802.1x)
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06 1

Introduction
1.2Description
• VLAN (802.1Q) to segregate and secure network traffic
• RADIUS centralized password management
• SNMPv3 authentication and 56-bit encryption
Rated for Reliability in Harsh Environments
• Immunity to EMI and heavy electrical surges
• Hazardous Location Certification: Class I, Division 2
• -20 to +60 °C (-4 to 140 °F) operating temperature (optional -40 to +85°C or -40
to 185 °F)
• Conformal coated printed circuit boards (optional)
• Die cast aluminum enclosure
Memory Options
• Removable microSD/microSDHC card
Power Supply
• Dual low-voltage DC inputs: 24 VDC (9-32 VDC)
• Compression fit connections
• CSA/UL 60950 safety approved to 85 °C (185 °F)
1.2 Description
The RUGGEDCOM i801 features various ports, controls and indicator LEDs on the
front panel for connecting, configuring and troubleshooting the device.
4
7
9
10
8
2
1
3
5
6
1 Failsafe Alarm Relay
2 Power Supply Terminal Block
3 Chassis Ground Terminal
4 POWER LEDs
5 ALARM LED
6 Fiber Optic or Copper Gigabit Ethernet Port
7 Port Status LED
8 Copper Ethernet Ports
2RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06

Introduction
1.3Required Tools and Materials
9 Access Plate
10 RS-232 Console Port (RJ-45)
Figure1.1 RUGGEDCOM i801
Failsafe Alarm Relay Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
•"Connecting the Failsafe Alarm Relay (If Equipped) (Page
8)"
•"Failsafe Alarm Relay Specifications (Page 19)"
Power Supply Terminal Block A pluggable terminal block. For more information, refer to:
•"Connecting Power (Page 9)"
•"Power Supply Specifications (Page 19)"
POWER LEDs Illuminate when power is being supplied to the device by the
respective power source.
Color Description
Green Device ready
Red Device booting up
Off No power
ALARM LED Illuminates when an alarm condition exists.
Port Status LED Indicates the status of the associated port.
State Description
Solid Link
Blinking Activity
Off No link/activity
Communication Ports Receive and transmit data, as well as provide access to the
RUGGEDCOM i801 Web interface. For more information about
the various ports available for the RUGGEDCOM i801, refer to
"Communication Ports (Page 15)".
Access Plate The removable access plate provides access to the microSD/
microSDHC slot. Use a microSD/microSDHC card to load/store the
firmware and configuration for the device. For information about
using a microSD/microSDHC card, refer to "Inserting/Removing the
MicroSD/MicroSDHC Card (Page 12)".
RS-232 Console Port The serial console port is for interfacing directly with the device
and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page 11)".
1.3 Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM i801:
Tools/Materials Purpose
AC or DC power cord (16 AWG) For connecting power to the device.
CAT-5 Ethernet cables For connecting the device to the network.
Flathead screwdriver For mounting the device to a DIN rail.
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06 3

Introduction
1.4Decommissioning and Disposal
Tools/Materials Purpose
Phillips screwdriver For mounting the device to a panel.
4 x #8-32 screws For mounting the device to a panel.
1.4 Decommissioning and Disposal
Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of
service, either permanently or for maintenance by a third-party, make sure it has
been fully decommissioned.
For more information, refer to the associated Configuration Manual.
Recycling and Disposal
For environmentally friendly recycling and disposal of this device and related
accessories, contact a facility certified to dispose of waste electrical and electronic
equipment. Recycling and disposal must be done in accordance with local
regulations.
1.5 Supported Fiber Optic Cables
The following fiber optic cable types are supported under the stated conditions.
Distance (m)Cable Type Wavelength (nm) Modal Bandwidth
(MHz·km) 100Base-FX 1000Base-SX 10GBase-SR
850 200 — 275 33OM1 (62.5/125)
1300 500 2000 — —
850 500 — 550 82OM2 (50/125)
1300 500 2000 — —
850 1500 — 550 300OM3 (50/125)a
1300 500 2000 — —
850 3500 — 550 400OM4 (50/125)a
1300 500 2000 — —
aLaser optimized.
4RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06

Installing the Device 2
This section describes how to install the device, including mounting the device,
installing/removing modules, connecting power, and connecting the device to the
network.
DANGER
Electrocution hazard – risk of serious personal injury and/or damage to
equipment.
Before performing any maintenance tasks, make sure all power to the device has
been disconnected and wait approximately two minutes for any remaining energy
to dissipate.
WARNING
Radiation hazard – risk of serious personal injury.
This product contains a laser system and is classified as a CLASS 1 LASER PRODUCT.
Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
NOTICE
This product contains no user-serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void.
Changes or modifications not expressly approved by Siemens AG could invalidate
specifications, test results, and agency approvals, and void the user's authority to
operate the equipment.
NOTICE
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use
of a tool, lock and key, or other means of security, and controlled by the authority
responsible for the location.
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06 5

Installing the Device
2.1General Procedure
2.1 General Procedure
The general procedure for installing the device is as follows:
NOTICE
The user is responsible for the operating environment of the device, including
maintaining the integrity of all protective conductor connections and checking
equipment ratings. Make sure to review all operating and installation instructions
before commissioning or performing maintenance on the device.
1. Review the relevant certification information for any regulatory requirements.
For more information, refer to "Approvals (Page 23)".
2. Mount the device.
3. Connect the failsafe alarm relay.
4. Connect power to the device and ground the device to safety Earth.
5. Connect the device to the network.
6. Configure the device.
2.2 Unpacking the Device
When unpacking the device, do the following:
1. Inspect the package for damage before opening it.
2. Visually inspect each item in the package for any physical damage.
3. Verify all items are included.
IMPORTANT
If any item is missing or damaged, contact Siemens for assistance.
2.3 Mounting the Device
The RUGGEDCOM i801 can be ordered with a DIN rail adapter pre-installed on the
back of the chassis. Use the adapter to latch the mount the device to a standard 35
mm (1.4 in) by 15 mm (0.6 in) IEC/EN 60715 or TS35 DIN rail.
NOTICE
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a
reduction of ambient temperature and improve the long-term reliability of all
equipment mounted in the rack space.
6RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06

Installing the Device
2.3Mounting the Device
Note
For detailed dimensions of the device with the DIN rail adapter installed, refer to
"Dimension Drawings (Page 21)".
Mounting the Device
To mount the device to a DIN rail, do the following:
1. Hook the top teeth of the adapter onto the DIN rail.
1
2
2
3
1
1
1 DIN Rail
2 DIN Rail Adapter
Figure2.1 Mounting the Device to a DIN Rail
2. Insert a flathead screw driver into the slot of the sliding release and move it
down.
3. Push the device against the bottom of the DIN rail, then let go of the sliding
release to latch the device.
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06 7

Installing the Device
2.4Connecting the Failsafe Alarm Relay (If Equipped)
Removing the Device
To remove the device from a DIN rail, do the following:
1. Insert a flathead screwdriver into the slot of the sliding release and move it
down.
1 DIN Rail
2 DIN Rail Adapter
Figure2.2 Removing the Device from a DIN Rail
2. Swing the bottom of the device away from the DIN rail.
3. Lift the device off the DIN rail.
2.4 Connecting the Failsafe Alarm Relay (If Equipped)
The failsafe relay can be configured to latch based on alarm conditions. The NO
(Normally Open) contact is closed when the unit is powered and there are no active
alarms. If the device is not powered or if an active alarm is configured, the relay
opens the NO contact and closes the NC (Normally Closed) contact.
Note
Control of the failsafe relay output is configurable through RUGGEDCOM i801 . One
common application for this relay is to signal an alarm if a power failure occurs.
For more information, refer to the RUGGEDCOM ROS Configuration Manual for the
RUGGEDCOM i801.
The following shows the proper relay connections.
1
3
2
1 Normally Open
2 Common
3 Normally Closed
Figure2.3 Failsafe Alarm Relay Wiring
8RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06

Installing the Device
2.5Connecting Power
2.5 Connecting Power
The RUGGEDCOM i801 supports a single low DC power supply with reverse polarity
and dual independent inputs. This allows for two redundant DC power sources with
the same nominal voltage to be connected.
To connect power to the device, do the following:
NOTICE
• Terminals P1-, P2- and GND are connected together internally. As such, if
redundant power supplies are connected, their negative terminals must be at
the same potential.
• Do not field wire the DC power supply on the DC mains or Battery mains.
• Use minimum #16 gage wiring when connecting terminal blocks.
• Equipment must be installed according to applicable local wiring codes and
standards.
1. Connect the positive wire from the power source to the positive terminal (P1+ or
P2+) on the terminal block.
1
2
3
4
1 Positive Terminal
2 Negative Terminal
3 GND Terminal
4 Chassis Ground Terminal
Figure2.4 Terminal Block Wiring – Single DC Power Supply Input
2. Connect the negative wire from the power source to the negative terminal (P1-
or P2-) on the terminal block.
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06 9

Installing the Device
2.5Connecting Power
3. [Optional] If connecting a second redundant power source, repeat Step 1 and
Step 2, making sure to connect the power supply to the P2 ports.
1
2
1
2
3
4
1 Positive Terminal
2 Negative Terminal
3 GND Terminal
4 Chassis Ground Terminal
Figure2.5 Terminal Block Wiring – Dual DC Power Supply Inputs
4. Connect the chassis ground terminal to protective Earth.
10 RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06

Device Management 3
This section describes how to connect to and manage the device.
3.1 Connecting to the Device
The following describes the various methods for accessing the RUGGEDCOM i801
console and Web interfaces on the device. For more detailed instructions, refer to the
RUGGEDCOM ROS Configuration Manual for the RUGGEDCOM i801.
RS232 Console Port
Connect a PC or terminal directly to the RS232 console port to access the boot-
time control and RUGGEDCOM i801 interfaces. The console port provides access to
RUGGEDCOM i801's console and Web interfaces.
NOTICE
The console port is intended to be used only as a temporary connection during initial
configuration or troubleshooting.
Connection to the console port is made using an RJ45-to-DB9 console cable. The
following is the pin-out for the console port:
18
Figure3.1 RJ45 Console Port Pin Configuration
Pin
RJ45 Male DB9 Female
Name Description Comment
1a6 DSR Data Set Ready 
2 1 DCD Carrier Detect Reserved (Do Not Connect)
3a4 DTR Data Terminal Ready 
4 5 GND Signal Ground 
5 2 RxD Receive Data (to DTE) 
6 3 TxD Transmit Data (from DTE) 
7 8 CTSbClear to Send 
RUGGEDCOM i801
Installation Manual, 01/2021, C79000-G8976-1003-06 11
