Siemens SIMATIC NET SCALANCE XP-200 User manual

SIMATIC NET
Industrial Ethernet switches
SCALANCE XP-200
Operating Instructions
03/2021
C79000-G8976-C428-08
Introduction 1
Safety notices 2
Recommendations on
network security 3
Description of the device 4
Installation 5
Connecting up 6
Upkeep and maintenance 7
Technical speci󹪝cations 8
Dimension drawings 9
Approvals A

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage
to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices
referring only to property damage have no safety alert symbol. These notices shown below are graded according to
the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may
be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this
publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C428-08
Ⓟ 03/2021 Subject to change
Copyright © Siemens AG 2017 - 2021.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 5
2 Safety notices ........................................................................................................................................ 9
3 Recommendations on network security.............................................................................................. 11
4 Description of the device..................................................................................................................... 17
4.1 Product overview ............................................................................................................... 17
4.2 Device views...................................................................................................................... 24
4.2.1 SCALANCE XP208 and SCALANCE XP208EEC ...................................................................... 24
4.2.2 SCALANCE XP208PoE EEC .................................................................................................. 25
4.2.3 SCALANCE XP216 and SCALANCE XP216EEC ...................................................................... 26
4.2.4 SCALANCE XP216PoE EEC .................................................................................................. 27
4.3 LED display ........................................................................................................................ 28
4.3.1 Overview........................................................................................................................... 28
4.3.2 "RM" LED............................................................................................................................ 28
4.3.3 "SB" LED............................................................................................................................. 29
4.3.4 "F" LED............................................................................................................................... 29
4.3.5 LEDs "DM1" and "DM2"....................................................................................................... 29
4.3.6 LEDs "L1" and "L2".............................................................................................................. 30
4.3.7 Port LEDs ........................................................................................................................... 31
4.4 RESET button ..................................................................................................................... 33
4.5 SELECT / SET button ........................................................................................................... 35
4.6 C-PLUG .............................................................................................................................. 37
4.6.1 Function of the C-PLUG ...................................................................................................... 37
4.6.2 Replacing the C-PLUG......................................................................................................... 38
4.7 Power over Ethernet (PoE).................................................................................................. 41
5 Installation........................................................................................................................................... 45
5.1 Safety notices for installation ............................................................................................. 45
5.2 Types of installation ........................................................................................................... 48
5.3 Wall mounting................................................................................................................... 49
5.4 Wall mounting................................................................................................................... 50
5.5 Rack mounting................................................................................................................... 51
6 Connecting up ..................................................................................................................................... 53
6.1 Safety when connecting up................................................................................................ 53
6.2 Industrial Ethernet ............................................................................................................. 56
6.2.1 Industrial Ethernet ............................................................................................................. 56
6.3 24 VDC power supply......................................................................................................... 59
6.4 54 VDC power supply......................................................................................................... 62
SCALANCE XP-200
Operating Instructions, 03/2021, C79000-G8976-C428-08 3

6.5 Signaling contact ............................................................................................................... 64
6.6 Serial interface................................................................................................................... 66
6.7 Functional ground ............................................................................................................. 68
7 Upkeep and maintenance.................................................................................................................... 71
7.1 Downloading new 󹪝rmware using TFTP without WBM and CLI............................................. 71
7.2 Restoring the factory settings............................................................................................. 72
8 Technical speci󹪝cations ....................................................................................................................... 75
8.1 Technical speci󹪝cations SCALANCE XP208 and SCALANCE XP208EEC.................................. 75
8.2 Technical speci󹪝cations of the SCALANCE XP208PoE EEC .................................................... 77
8.3 Technical speci󹪝cations SCALANCE XP216 and SCALANCE XP216EEC.................................. 79
8.4 Technical speci󹪝cations of the SCALANCE XP216PoE EEC .................................................... 81
8.5 Cable lengths..................................................................................................................... 83
8.6 Switching properties.......................................................................................................... 84
9 Dimension drawings............................................................................................................................ 85
A Approvals............................................................................................................................................. 89
Index .................................................................................................................................................... 95
Table of contents
SCALANCE XP-200
4Operating Instructions, 03/2021, C79000-G8976-C428-08

Introduction 1
Purpose of the Operating Instructions
These operating instructions support you when installing and connecting up devices of the
SCALANCE XP-200 product group.
The con󹪝guration and the integration of the devices in a network are not described in these
operating instructions.
Validity of the Operating Instructions
These operating instructions apply to the following devices:
• SCALANCE XP208
• SCALANCE XP208EEC
• SCALANCE XP208PoE EEC
• SCALANCE XP216
• SCALANCE XP216EEC
• SCALANCE XP216PoE EEC
Unless mentioned otherwise, the descriptions in these operating instructions refer to all devices
of the SCALANCE XP-200 product group named above in the section on validity.
There are two variants of some devices, refer to the section "Product overview (Page 17)".
Designations used
Classi󹪝cation Description Terms used
Product line The product line includes all devices and variants of all product
groups.
If information applies to all product groups within the product
line, the term SCALANCE X-200 is used.
SCALANCE X-200
Product group If information applies to all devices and variants of a product
group, the term SCALANCE XP-200 is used.
SCALANCE XP-200
Device If information relates to a speci󹪝c device, the device name is used. e.g. SCALANCE XP208PoE EEC
Documentation on con󹪝guration
You will 󹪝nd detailed information on con󹪝guring the devices in the following con󹪝guration
manuals:
• SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Web Based Management
• SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Command Line Interface
SCALANCE XP-200
Operating Instructions, 03/2021, C79000-G8976-C428-08 5

You will 󹪝nd the con󹪝guration manuals here:
• on the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
• On the Internet pages of Siemens Industry Online Support (https://
support.industry.siemens.com/cs/ww/en/ps/21869/man).
Further documentation
In the system manuals "Industrial Ethernet / PROFINET Industrial Ethernet" and "Industrial
Ethernet / PROFINET passive network components", you will 󹪝nd information on other SIMATIC
NET products that you can operate along with the devices of this product line in an Industrial
Ethernet network.
There, you will 󹪝nd among other things optical performance data of the communications
partner that you require for the installation.
You will 󹪝nd the system manuals here:
• On the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
• On the Internet pages of Siemens Industry Online Support:
– Industrial Ethernet / PROFINET Industrial Ethernet System Manual (https://
support.industry.siemens.com/cs/ww/en/view/27069465)
– Industrial Ethernet / PROFINET Passive Network Components System Manual (https://
support.industry.siemens.com/cs/ww/en/view/84922825)
SIMATIC NET manuals
You will 󹪝nd the SIMATIC NET manuals here:
• On the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
• On the Internet pages of Siemens Industry Online Support (https://
support.industry.siemens.com/cs/ww/en/ps/15247).
SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
Introduction
SCALANCE XP-200
6Operating Instructions, 03/2021, C79000-G8976-C428-08

You will 󹪝nd the SIMATIC NET glossary here:
• SIMATIC NET Manual Collection or product DVD
The DVD ships with certain SIMATIC NET products.
• On the Internet under the following address:
50305045 (https://support.industry.siemens.com/cs/ww/en/view/50305045)
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is necessary
to implement – and continuously maintain – a holistic, state-of-the-art industrial security
concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected to
an enterprise network or the internet if and to the extent such a connection is necessary and only
when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation) are in place.
For additional information on industrial security measures that may be implemented, please visit
https://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity)
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends that product updates are applied as soon as they are available
and that the latest product versions are used. Use of product versions that are no longer
supported, and failure to apply the latest updates may increase customers’ exposure to cyber
threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS Feed
under
https://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity)
Catalogs
You will 󹪝nd the article numbers for the Siemens products of relevance here in the following
catalogs:
• SIMATIC NET Industrial Communication / Industrial Identi󹪝cation, catalog IK PI
• SIMATIC Products for Totally Integrated Automation and Micro Automation, catalog ST 70
• Industry Mall - catalog and ordering system for automation and drive technology, Online
catalog (https://mall.industry.siemens.com/goos/WelcomePage.aspx?regionUrl=/
en&language=en)
You can request the catalogs and additional information from your Siemens representative.
Device defective
If a fault develops, send the device to your SIEMENS representative for repair. Repairs on-site are
not possible.
Introduction
SCALANCE XP-200
Operating Instructions, 03/2021, C79000-G8976-C428-08 7

Decommissioning
Shut down the device properly to prevent unauthorized persons from accessing con󹪝dential
data in the device memory.
To do this, restore the factory settings on the device.
Also restore the factory settings on the storage medium.
Recycling and disposal
The products are low in pollutants, can be recycled and meet the requirements of the WEEE
directive 2012/19/EU for the disposal of electrical and electronic equipment.
Do not dispose of the products at public disposal sites.
For environmentally friendly recycling and the disposal of your old device contact a certi󹪝ed
disposal company for electronic scrap or your Siemens contact (Product return (https://
support.industry.siemens.com/cs/ww/en/view/109479891)).
Note the di󹪜erent national regulations.
Trademarks
The following and possibly other names not identi󹪝ed by the registered trademark sign ® are
registered trademarks of Siemens AG:
SIMATIC NET, SCALANCE, C-PLUG, OLM
Electrostatic discharge
NOTICE
Electrostatic sensitive devices (ESD)
Electronic modules contain electrostatic sensitive components
These components can easily be destroyed if handled incorrectly.
Note the following instructions to avoid damage.
• Touch electronic modules only when you absolutely need to work on them.
• If electronic modules need to be touched, the body of the person involved must 󹪝rst be
electrostatically discharged and grounded.
• Do not bring electronic modules in contact with electrically isolating materials such as
plastic 󹪝lm, isolating table top pads or clothing made of synthetic 󹪝bers.
• Place the modules only on conductive surfaces.
• Pack, store and transport electronic modules and components only in conductive packaging
such as metalized plastic or metal containers, conductive foam or household aluminum foil.
Introduction
SCALANCE XP-200
8Operating Instructions, 03/2021, C79000-G8976-C428-08

Safety notices 2
Read the safety notices
Note the following safety notices. These relate to the entire working life of the device.
You should also read the safety notices relating to handling in the individual sections,
particularly in the sections "Installation" and "Connecting up".
CAUTION
To prevent injury, read the manual before use.
NOTICE
Loss of water and dust protection
If you open the device, it loses its water and dust protection.
• Do not open the device.
If the is not adhered to, the manufacturer's guarantee is lost.
Safety notices on use in hazardous areas
General safety notices relating to protection against explosion
WARNING
EXPLOSION HAZARD
Do not open the device. There are no serviceable parts inside of the device.
WARNING
EXPLOSION HAZARD
Do not open the device when the supply voltage is turned on.
Safety notices when using the device according to Hazardous Locations (HazLoc)
If you use the device under HazLoc conditions you must also keep to the following safety notices
in addition to the general safety notices for protection against explosion:
This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or non-hazardous
locations only.
This equipment is suitable for use in Class I, Zone 2, Group IIC or non-hazardous locations only.
SCALANCE XP-200
Operating Instructions, 03/2021, C79000-G8976-C428-08 9

Safety notices
SCALANCE XP-200
10 Operating Instructions, 03/2021, C79000-G8976-C428-08

Recommendations on network security 3
NOTICE
Information security
Connect to the device and change the standard password for the user set in the factory "admin"
and "" before you operate the device.
To prevent unauthorized access, note the following security recommendations.
General
• You should make regular checks to make sure that the device meets these recommendations
and/or other security guidelines.
• Evaluate your plant as a whole in terms of security. Use a cell protection concept with suitable
products (https://www.industry.siemens.com/topics/global/en/industrial-security/pages/
default.aspx).
• When the internal and external network are disconnected, an attacker cannot access internal
data from the outside. Therefore operate the device only within a protected network area.
• For communication via non-secure networks use additional devices with VPN functionality to
encrypt and authenticate the communication.
• No product liability will be accepted for operation in a non-secure infrastructure.
• Terminate management connections correctly (WBM. Telnet, SSH etc.).
Physical access
• Restrict physical access to the device to quali󹪝ed personnel because the plug-in data medium
can contain sensitive data.
• Lock unused physical interfaces on the device. Unused interfaces can be used to gain access
to the plant without permission.
Software (security functions)
• Keep the 󹪝rmware up to date. Check regularly for security updates for the device. You can
󹪝nd information on this at the Industrial Security (https://www.siemens.com/
industrialsecurity) website.
• Inform yourself regularly about security recommendations published by Siemens
ProductCERT (https://www.siemens.com/cert/en/cert-security-advisories.htm).
• Only activate protocols that you require to use the device.
• Restrict access to the management of the device with rules in an access control list (ACL).
SCALANCE XP-200
Operating Instructions, 03/2021, C79000-G8976-C428-08 11

• The option of VLAN structuring provides protection against DoS attacks and unauthorized
access. Check whether this is practical or useful in your environment.
• Use a central logging server to log changes and accesses. Operate your logging server within
the protected network area and check the logging information regularly.
Passwords
•De󹪝ne rules for the assignment of passwords.
• Regularly change your passwords to increase security.
• Use passwords with a high password strength.
• Make sure that all passwords are protected and inaccessible to unauthorized persons.
• A password must be changed if it is known or suspected to be known by unauthorized
persons.
• Do not use the same password for di󹪜erent users and systems.
Certi󹪝cates and keys
• The device contains a pre-installed certi󹪝cate with key. Replace this certi󹪝cate with a self-
made certi󹪝cate with key. We recommend that you use a certi󹪝cate signed either by a reliable
external or by an internal certi󹪝cation authority. You can install the certi󹪝cate via the WBM
(System > Load and Save).
• Use the certi󹪝cation authority including key revocation and management to sign the
certi󹪝cates.
• Make sure that user-de󹪝ned private keys are protected and inaccessible to unauthorized
persons.
• Verify certi󹪝cates and 󹪝ngerprints on the server and client to prevent "man in the middle"
attacks.
• It is recommended that you use password-protected certi󹪝cates in the PKCS#12 format.
• It is recommended that you use certi󹪝cates with a key length of at least 2048 bits.
• Change keys and certi󹪝cates immediately if there is a suspicion of compromise.
Recommendations on network security
SCALANCE XP-200
12 Operating Instructions, 03/2021, C79000-G8976-C428-08

Secure/non-secure protocols and services
• Avoid or disable non-secure protocols and services, for example HTTP, Telnet and TFTP. For
historical reasons, these protocols are available, however not intended for secure
applications. Use non-secure protocols on the device with caution.
• Check whether use of the following protocols and services is necessary:
– Non authenticated and unencrypted ports
– MRP, HRP
– IGMP snooping
– LLDP
– Syslog
– RADIUS
– DHCP Options 66/67
– TFTP
– GMRP and GVRP
• The following protocols provide secure alternatives:
– HTTP → HTTPS
– Telnet → SSH
– SNMPv1/v2c → SNMPv3
Check whether use of SNMPv1/v2c. is necessary. SNMPv1/v2c is classi󹪝ed as non-secure.
Use the option of preventing write access. The device provides you with suitable setting
options.
If SNMP is enabled, change the community names. If no unrestricted access is necessary,
restrict access with SNMP.
Use the authentication and encryption mechanisms of SNMPv3.
• Use secure protocols when access to the device is not prevented by physical protection
measures.
• If you require non-secure protocols and services, operate the device only within a protected
network area.
• Restrict the services and protocols available to the outside to a minimum.
• For the DCP function, enable the "Read Only" mode after commissioning.
• If you use RADIUS for management access to the device, activate secure protocols and
services.
Interfaces security
• Disable unused interfaces.
• Use IEEE 802.1X for interface authentication.
• Use the function "Locked Ports" to block interfaces for unknown nodes.
• Use the con󹪝guration options of the interfaces, e.g. the "Edge Type".
•Con󹪝gure the receive ports so that they discard all untagged frames ("Tagged Frames Only").
Recommendations on network security
SCALANCE XP-200
Operating Instructions, 03/2021, C79000-G8976-C428-08 13

Available protocols
The following list provides you with an overview of the open protocol ports.
The table includes the following columns:
•Protocol
•Port
•Default port status
– Open
The factory setting of the port is "Open".
– Closed
The factory setting of the port is "Closed".
•Con󹪝gurable port
– ✓
The port status can be changed.
– --
The port status cannot be changed.
•Authentication
Speci󹪝es whether the communication partner is authenticated.
•Encryption
Speci󹪝es whether or not the transfer is encrypted.
List of available protocols (local access via a local network)
The following is a list of all available protocols and their ports through which the device can be
accessed.
Protocol Protocol/
Port number
Default port sta‐
tus
Con󹪝gurable
port
Authentication Encryption
DHCPv4 Server UDP/67 Closed ✓ No No
DHCPv4 Client UDP/68 Open ✓ No No
Discard TCP/9 Open, 󹪝ltered -- No No
Echo IP UPD/TCP/9 Open -- No No
EtherNet/IP TCP/44818
UDP/2222
UDP/44818
Closed
(Open with
EtherNetIP var‐
iants)
✓ No No
HTTP TCP/80 Open ✓ Yes No
HTTPS TCP/443 Open ✓ Yes Yes
Kerberos TCP/464 Open, 󹪝ltered -- No No
NTP
SNTP
UDP/123 Closed ✓ No No
NTP (secure) UDP/123 Closed ✓ Yes No
Recommendations on network security
SCALANCE XP-200
14 Operating Instructions, 03/2021, C79000-G8976-C428-08

Protocol Protocol/
Port number
Default port sta‐
tus
Con󹪝gurable
port
Authentication Encryption
PROFINET UDP/34964
UDP/49151 … 49159 1)
Open ✓ No No
RADIUS UPD/1812,1813 Closed ✓ Yes Yes
SMTP TCP/25
TCP/465
Closed ✓ Yes Yes
SNMP UDP/161 Open ✓ Yes Yes (when con‐
󹪝gured)
SSH TCP/22 Open ✓ Yes Yes
Syslog UPD/514
TCP/6514
Closed ✓ Yes Yes
TELNET TCP/23 Open ✓ Yes No
TFTP UDP/69 Open ✓ No No
1) Port number can be con󹪝gured via the WBM.
Recommendations on network security
SCALANCE XP-200
Operating Instructions, 03/2021, C79000-G8976-C428-08 15

Recommendations on network security
SCALANCE XP-200
16 Operating Instructions, 03/2021, C79000-G8976-C428-08

Description of the device 4
4.1 Product overview
Article numbers
There are two variants of some devices with di󹪜erent article numbers. These variants di󹪜er only
in their factory settings. All other properties are identical.
Device Description Article number
(Ethernet/IP)
Article number
(PROFINET)
SCALANCE XP208 8 x 10/100 Mbps M12 connector technol‐
ogy electrical
6GK5 208-0HA00-2TS6 6GK5 208-0HA00-2AS6
SCALANCE XP208EEC 8 x 10/100 Mbps M12 connector technol‐
ogy electrical, varnished circuit board
- 6GK5 208-0HA00-2ES6
SCALANCE XP208PoE EEC 8 x 10/100 Mbps M12 connector technol‐
ogy electrical, varnished circuit board,
Power over Ethernet on 4 ports
- 6GK5 208-0UA00-5ES6
SCALANCE XP216 12 x 10/100 Mbps and 4 x 10/100/1000
Mbps M12 connector technology electri‐
cal
6GK5 216-0HA00-2TS6 6GK5 216-0HA00-2AS6
SCALANCE XP216EEC 12 x 10/100 Mbps and 4 x 10/100/1000
Mbps M12 connector technology electri‐
cal, varnished circuit board
- 6GK5 216-0HA00-2ES6
SCALANCE XP216PoE EEC 12 x 10/100 Mbps und 4 x
10/100/1000 Mbps M12 connector tech‐
nology electrical, varnished circuit board,
Power over Ethernet on 8 ports
- 6GK5 216-0UA00-5ES6
Factory settings
EtherNet/IP variants
• Industrial Ethernet protocol: EtherNet/IP
• Base bridge mode: 802.1Q VLAN Bridge
• Redundancy mechanism: RSTP
• Trust mode: Trust CoS-DSCP
• IGMP Snooping/IGMP Querier: On
• IPv4 Address Collision Detection: Attempt to defend
PROFINET variants
• Industrial Ethernet protocol: PROFINET
• Base bridge mode: 802.1D transparent bridge
SCALANCE XP-200
Operating Instructions, 03/2021, C79000-G8976-C428-08 17

• Redundancy mechanism: Ring redundancy
Device Factory setting ring ports
SCALANCE XP208, XP208EEC and XP208PoE EEC P0.1 and P0.2
SCALANCE XP216, XP216EEC and XP216PoE EEC P0.10 and P0.12
• Trust mode: Trust CoS
• IGMP Snooping/IGMP Querier: O󹪜
• IPv4 Address Collision Detection: Never give up
Type designation
The type designation of a SCALANCE XP-200 is made up of several parts that have the following
meaning:
[ - ]
EEC
Number of electrical connectors
[ - ]
PoE
XP2
Property Description
EEC Enhanced Environmental Conditions
PoE Power over Ethernet
Unpacking and checking
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to the
speci󹪝cation.
If you use damaged parts, this can lead to the following problems:
• Injury to persons
• Loss of the approvals
• Violation of the EMC regulations
• Damage to the device and other components
Use only undamaged parts.
Description of the device
4.1 Product overview
SCALANCE XP-200
18 Operating Instructions, 03/2021, C79000-G8976-C428-08

1. Make sure that the package is complete.
2. Check all the parts for transport damage.
Components of the product
The following components are supplied with a SCALANCE XP-200:
• One device
• One product DVD with documentation and software
• Protective caps for all connectors
• 4 screws for mounting on a rack
• Grounding screw
Accessories
The following accessories are available for SCALANCE XP-200:
C-PLUG
Component Description Article number
C-PLUG Con󹪝guration plug, exchangeable stor‐
age medium for con󹪝guration data, 32
MB
6GK1 900-0AB00
Con󹪝guration plug, exchangeable stor‐
age medium for con󹪝guration data, 32
MB, varnished (conformal coating)
6GK1 900-0AQ00
M12 data plug-in connector
Component Description Article number
IE FC M12 PLUG PRO 2x2 M12 data plug-in con‐
nector for IE FC TP ca‐
bles 2x2, IP65/67, D-co‐
ded, axial cable outlet
1 connector
per package
6GK1 901-0DB20-6AA0
8 connectors
per package
6GK1 901-0DB20-6AA8
IE FC M12 PLUG PRO 4x2 M12 data plug-in con‐
nector for IE FC TP ca‐
bles 4x2, IP65/67, X-co‐
ded, axial cable outlet
1 connector
per package
6GK1 901-0DB30-6AA0
8 connectors
per package
6GK1 901-0DB30-6AA8
IE FC M12 CABLE CONNEC‐
TOR PRO 4X2
M12 plug-in connector
(X-coded) can be assem‐
bled in the 󹪝eld, 8-pin,
metal housing, FC fast
connection technology,
socket insert
1 connector
per package
6GK1 901-0DB40-6AA0
8 connectors
per package
6GK1 901-0DB40-6AA8
Description of the device
4.1 Product overview
SCALANCE XP-200
Operating Instructions, 03/2021, C79000-G8976-C428-08 19

Data line
Component Description Article number
Connecting cable (M12/RS-232) Preassembled, serial cable with
M12 and RS-232 plug,
Length: 3 m
pack of 1
6GK5 980-3BC00-0AA5
IE FC TP STANDARD CABLE
GP2X2
(PROFINET type A)
Standard bus cable, TP installation
cable for connection to FC OUTLET
RJ-45, for universal use, 4-wire,
shielded, CAT 5E
Sold by the meter
6XV1 840-2AH10
IE FC TP ROBUST STANDARD CA‐
BLE GP 2X2
(PROFINET type A)
Standard bus cable, ATPE outer jack‐
et for connection to FC RJ45 PLUG
and FC OUTLET RJ45, 󹪝xed installa‐
tion, for universal use, 4-wire, shiel‐
ded, CAT 5
Sold by the meter
6XV1 841-2A
IE FC TP ROBUST FLEXIBLE CA‐
BLE GP 2X2
(PROFINET type B)
Flexible bus cable, TPE outer jacket
for connection to FC RJ45 PLUG and
FC OUTLET RJ45, 󹪞exible wires, 4-
wire, shielded, CAT 5
Sold by the meter
6XV1 841-2B
IE FC TP FLEXIBLE CABLE GP 2X2
(PROFINET type B)
Flexible bus cable, TP installation
cable, 󹪞exible wires, shielded, CAT 5
Sold by the meter
6XV1 870-2B
IE FC TP TRAILING CABLE 2X2
(PROFINET type C)
Highly 󹪞exible bus cable, TP instal‐
lation cable for connection to FC
OUTLET RJ45, for use in drag chains,
4-wire, shielded, CAT 5
Sold by the meter
6XV1 840-3AH10
IE TP TORSION CABLE 2X2
(PROFINET type C)
Highly 󹪞exible bus cable, TP instal‐
lation cable for use in highly 󹪞exible
applications (torsion), 4-wire
Sold by the meter
6XV1 870-2F
IE FC TP STANDARD CABLE GP
4X2
Shielded TP installation cable for
connection to IE FC RJ45 PLUG 4X2,
CAT 6, AWG 24
Sold by the meter
6XV1 878-2A
IE FC TP FLEXIBLE CABLE GP 4X2 Shielded TP installation cable for
connection to IE FC RJ45 PLUG 4X2,
󹪞exible wires, CAT 6, 24 AWG
Sold by the meter
6XV1 878-2B
IE CONNECTING CABLE
M12-180/IE RJ45
Flexible IE connecting cable, 4-wire,
preassembled with a 4-pin M12
plug (D-coded) and an IE FC RJ-45
Plug 145
6XV1 871-5T*
IE CONNECTING CABLE
M12-180/M12-180
Flexible IE connecting cable, 4-wire,
preassembled with two 4-pin M12
plugs (D-coded)
6XV1 870-8A*
Description of the device
4.1 Product overview
SCALANCE XP-200
20 Operating Instructions, 03/2021, C79000-G8976-C428-08
