1: Introduction
The Sierra Wireless EM7355 Embedded Module is an M.2 modem
that provides LTE, DC-HSPA+, HSPA+, HSDPA, HSUPA, WCDMA,
GSM, GPRS, EDGE, CDMA, and GNSS connectivity for notebook,
ultrabook, and tablet computers over several radio frequency bands.
The device also supports 2G/3G roaming.
Accessories
A hardware development kit is available for AirPrime M.2 modules.
The kit contains hardware components for evaluating and developing
with the module, including:
•Development board
•Cables
•Antennas
•Other accessories
For over-the-air LTE testing, ensure that suitable antennas are used.
Required connectors
Table 1-1 describes the connectors used to integrate the EM7355
Embedded Module into your host device.
Table 1-1: Required host-module connectors
Connector type Description
RF cables •Mate with M.2-spec connectors
•Three connector jacks
EDGE (67 pin) •Slot B compatible—Per the M.2 standard (PCI Express NGFF
(M.2) Electromechanical Specification Revision 0.7), a generic
75 pin position EDGE connector on the motherboard uses a
mechanical key to mate with the 67 pin notched module
connector.
•Manufacturers include LOTES (part #APCI0018-P001A01),
Kyocera, JAE, Tyco, and Longwell.
SIM •Industry-standard connector.

Hardware Integration Guide
8 Proprietary and Confidential - Contents subject to change 4112880

Rev 2 Feb.13 Proprietary and Confidential - Contents subject to change 9
2
2: Power
Power supply
The host provides power to the EM7355 through multiple power and
ground pins. The host must provide safe and continuous power (via
battery or a regulated power supply) at all times; the module does not
have an independent power supply, or protection circuits to guard
against electrical issues.
For detailed pinout and voltage/current requirements of this module,
see the AirPrime EM7355 Product Technical Specification &
Customer Design Guidelines.
Module power states
The module has five power states, as described in Ta b l e 2-1.
Table 2-1: Module power states
State Details
Host is powered Module is powered USB interface active RF enabled
Normal
(Default
state)
•Module is active
•Default state. Occurs when VCC is first applied, Full_Card_Power_Off# is
deasserted (pulled high), and W_DISABLE#1 is deasserted
•Module is capable of placing/receiving calls, or establishing data connections on the
wireless network
•Current consumption is affected by several factors, including:
•Radio band being used
•Transmit power
•Receive gain settings
•Data rate
   
Low power
(‘Airplane
mode’)
•Module is active
•Module enters this state:
•Under host interface control:
·Host issues AT+CFUN=0 ([1] AT Command Set for User Equipment (UE)
(Release 6) (Doc# 3GPP TS 27.007))), or
·Host asserts W_DISABLE#1, after AT!PCOFFEN=0 has been issued.
•Automatically, when critical temperature or voltage trigger limits have been
reached))
   

Hardware Integration Guide
10 Proprietary and Confidential - Contents subject to change 4112880
Sleep •Normal state of module between calls or data connections
•Module cycles between wake (polling the network) and sleep, at network provider-
determined interval.
   
Off •Host keeps module powered off by asserting Full_Card_Power_Off# (signal pulled
low or left floating)
•Module draws minimal current
  
Disconnected •Host power source is disconnected from the module and all voltages associated with
the module are at 0 V.    
Table 2-1: Module power states (Continued)
State Details
Host is powered Module is powered USB interface active RF enabled

Rev 2 Feb.13 Proprietary and Confidential - Contents subject to change 11
3
3: RF Specifications
The EM7355 operates on the frequency bands listed below.
Table 3-1: LTE frequency band support
Band Frequencies
Band 2 Tx: 1850–1910 MHz
Rx: 1930–1990 MHz
Band 4 (AWS) Tx: 1710–1755 MHz
Rx: 2110–2155 MHz
Band 5 Tx: 824–849 MHz
Rx: 869–894 MHz
Band 13 Tx: 777–787 MHz
Rx: 746–756 MHz
Band 17 Tx: 704–716 MHz
Rx: 734–746 MHz
Band 25 Tx: 1850–1915 MHz
Rx: 1930–1995 MHz
Table 3-2: WCDMA frequency band support1
1. WCDMA channel spacing is 5 MHz, but this can be adjusted to
optimize performance in a particular deployment scenario.
Band Frequencies
Band 1
WCDMA 2100 Tx: 1920–1980 MHz Rx: 2110–2170 MHz
Band 2
WCDMA 1900 Tx: 1850–1910 MHz Rx: 1930–1990 MHz
Band 4
AWS 1700/2100 Tx: 1710–1755 MHz Rx: 2110–2155 MHz
Band 5
WCDMA 850 Tx: 824–849 MHz Rx: 869–894 MHz
Band 8
WCDMA 900 Tx: 880–915 MHz Rx: 925–960 MHz
Table 3-3: GSM frequency band support
Band Frequencies
GSM 850 Tx: 824–849 MHz
Rx: 869–894 MHz
EGSM 900 Tx: 880–915 MHz
Rx: 925–960 MHz

Hardware Integration Guide
12 Proprietary and Confidential - Contents subject to change 4112880
RF connections
When attaching antennas to the module:
•Use any of the following (or compatible) 2x2 mm 
RF receptacle connectors to attach antennas to the module’s connection
points
•Match coaxial connections between the module and the antenna to 50 .
•Minimize RF cable losses to the antenna; the recommended maximum cable
loss for antenna cabling is 0.5 dB.
•To ensure best thermal performance, if possible use the mounting hole to
attach (ground) the device to a metal chassis.
Note: If the antenna connection is shorted or open, the modem will not sustain permanent
damage.
Shielding
The module is fully shielded to protect against EMI and must not be removed.
GSM 1800 Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
GSM 1900 Tx: 1850–1910 MHz
Rx: 1930–1990 MHz
Table 3-4: CDMA frequency band support
Band Frequencies
Band Class 0
(Cellular 800 MHz) Tx: 824–849 MHz Rx: 869–894 MHz
Band Class 1
(PCS) Tx: 1850–1910 MHz Rx: 1930–1990 MHz
Band Class 10
(Secondary 800 MHz)1Tx: 817–824 MHz Rx: 862–869 MHz
1. BC10 subclasses 2 and 3 (system designator C and D) are sup-
ported
Table 3-5: GNSS frequency band support
Band Frequencies
Narrow-band GPS Rx: 1575.42 MHz
Wide-band GPS + GLONASS Rx: 1565–1606 MHz
Table 3-3: GSM frequency band support (Continued)
Band Frequencies

RF Specifications
Rev 2 Feb.13 Proprietary and Confidential - Contents subject to change 13
Antenna and cabling
When selecting the antenna and cable, it is critical to RF performance to match
antenna gain and cable loss.
Choosing the correct antenna and cabling
When matching antennas and cabling:
•The antenna (and associated circuitry) should have a nominal impedance of
50 with a return loss of better than 10 dB across each frequency band of
operation.
•The system gain value affects both radiated power and regulatory (FCC, IC,
CE, etc.) test results.
Designing custom antennas
Consider the following points when designing custom antennas:
•A skilled RF engineer should do the development to ensure that the RF
performance is maintained.
•If both UMTS and CDMA modules will be installed in the same platform, you
may want to develop separate antennas for maximum performance.
Determining the antenna’s location
When deciding where to put the antennas:
•Antenna location may affect RF performance. Although the module is
shielded to prevent interference in most applications, the placement of the
antenna is still very important—if the host device is insufficiently shielded,
high levels of broadband or spurious noise can degrade the module’s perfor-
mance.
•Connecting cables between the module and the antenna must have 50 
impedance. If the impedance of the module is mismatched, RF performance
is reduced significantly.
•Antenna cables should be routed, if possible, away from noise sources
(switching power supplies, LCD assemblies, etc.). If the cables are near the
noise sources, the noise may be coupled into the RF cable and into the
antenna.
Disabling the diversity antenna
•For LTE /UMTS bands, use the AT command !RXDEN=0 to disable receive
diversity or !RXDEN=1 to enable receive diversity.
•For CDMA bands, use the AT command !DIVERSITY to enable or disable
receive diversity.
Note: A diversity antenna is used to improve connection quality and reliability through
redundancy. Because two antennas may experience difference interference effects (signal
distortion, delay, etc.), when one antenna receives a degraded signal, the other may not be
similarly affected.

Hardware Integration Guide
14 Proprietary and Confidential - Contents subject to change 4112880
Ground connection
When connecting the module to system ground:
•Prevent noise leakage by establishing a very good ground connection to the
module through the host connector.
•Connect to system ground using the module’s mounting hole.
•Minimize ground noise leakage into the RF.
Depending on the host board design, noise could potentially be coupled to
the module from the host board. This is mainly an issue for host designs that
have signals traveling along the length of the module, or circuitry operating at
both ends of the module interconnects.
Interference and sensitivity
Several interference sources can affect the module’s RF performance
(RF desense). Common sources include power supply noise and device-
generated RF.
RF desense can be addressed through a combination of mitigation techniques
(Methods to mitigate decreased Rx performance on page 15) and radiated
sensitivity measurement (Radiated sensitivity measurement on page 16).
Note: The EM7355 is based on ZIF (Zero Intermediate Frequency) technologies. When
performing EMC (Electromagnetic Compatibility) tests, there are no IF (Intermediate
Frequency) components from the module to consider.
Interference from other wireless devices
Wireless devices operating inside the host device can cause interference that
affects the module.
To determine the most suitable locations for antennas on your host device,
evaluate each wireless device’s radio system, considering the following:
•Any harmonics, sub-harmonics, or cross-products of signals generated by
wireless devices that fall in the module’s Rx range may cause spurious
response, resulting in decreased Rx performance.
•The Tx power and corresponding broadband noise of other wireless devices
may overload or increase the noise floor of the module’s receiver, resulting in
Rx desense.
The severity of this interference depends on the closeness of the other antennas
to the module’s antenna. To determine suitable locations for each wireless
device’s antenna, thoroughly evaluate your host device’s design.
Host-generated RF interference
All electronic computing devices generate RF interference that can negatively
affect the receive sensitivity of the module.

RF Specifications
Rev 2 Feb.13 Proprietary and Confidential - Contents subject to change 15
Proximity of host electronics to the antenna in wireless devices can contribute to
decreased Rx performance. Components that are most likely to cause this
include:
•Microprocessor and memory
•Display panel and display drivers
•Switching-mode power supplies
Device-generated RF interference
The module can cause interference with other devices. Wireless devices such as
AirPrime embedded modules transmit in bursts (pulse transients) for set durations
(RF burst frequencies). Hearing aids and speakers convert these burst
frequencies into audible frequencies, resulting in audible noise.
Methods to mitigate decreased Rx performance
It is important to investigate sources of localized interference early in the design
cycle. To reduce the effect of device-generated RF on Rx performance:
•Put the antenna as far as possible from sources of interference. The
drawback is that the module may be less convenient to use.
•Shield the host device. The module itself is well shielded to avoid external
interference. However, the antenna cannot be shielded for obvious reasons.
In most instances, it is necessary to employ shielding on the components of
the host device (such as the main processor and parallel bus) that have the
highest RF emissions.
•Filter out unwanted high-order harmonic energy by using discrete filtering on
low frequency lines.
•Form shielding layers around high-speed clock traces by using multi-layer
PCBs.
•Route antenna cables away from noise sources.
Radiated Spurious Emissions (RSE)
When designing an antenna for use with AirPrime embedded modules, the host
device with an AirPrime embedded module must satisfy the radiated spurious
emission (RSE) test cases described in:
•(CDMA) Refer to CDMA standards for receive-only mode, and local
regulatory bodies for transmit mode (transmitter is operating).
•CE/ETSI EN 301 908 (WCDMA), test numbers 5.3.1 (‘Radiated Emissions
(UE)’)
•CE/ETSI EN 301 511 (GSM), test 5.2.16 (‘Radiated Spurious Emissions - MS
allocated a channel’). This test uses the procedure and requirement outlined
in 3GPP 51.010 (GSM) section 12.2.1 of the same test name.
Note that antenna impedance affects radiated emissions, which must be
compared against the conducted 50-ohm emissions baseline. (AirPrime
embedded modules meet the 50-ohm conducted emissions requirement.)

Hardware Integration Guide
16 Proprietary and Confidential - Contents subject to change 4112880
Note: GSM spurious emissions are most likely to have RSE issues, but in general, RSE
requirements must be met on all models with user-designed antennas.
Radiated sensitivity measurement
A wireless host device contains many noise sources that contribute to a reduction
in Rx performance.
To determine the extent of any receiver performance desensitization due to self-
generated noise in the host device, over-the-air (OTA) or radiated testing is
required. This testing can be performed by Sierra Wireless or you can use your
own OTA test chamber for in-house testing.

Rev 2 Feb.13 Proprietary and Confidential - Contents subject to change 17
4
4: Regulatory Compliance and Industry
Certifications
This module is designed to meet, and upon commercial release, will
meet the requirements of the following regulatory bodies and
regulations, where applicable:
•Federal Communications Commission (FCC) of the United States
•The Certification and Engineering Bureau of Industry Canada
(IC)
•The National Communications Commission (NCC) of Taiwan,
Republic of China
Upon commercial release, the following industry certifications will
have been obtained, where applicable:
•GCF-CC (For Verizon 2G/3G approval)
•PTCRB
•CDG2
Additional certifications may be obtained upon customer request—
contact your Sierra Wireless account representative for details.
Additional testing and certification may be required for the end
product with an embedded EM7355 modem and are the
responsibility of the OEM. Sierra Wireless offers professional
services-based assistance to OEMs with the testing and certification
process, if required.
Important notice
Because of the nature of wireless communications, transmission and
reception of data can never be guaranteed. Data may be delayed,
corrupted (i.e., have errors) or be totally lost. Although significant
delays or losses of data are rare when wireless devices such as the
Sierra Wireless modem are used in a normal manner with a well-
constructed network, the Sierra Wireless modem should not be used
in situations where failure to transmit or receive data could result in
damage of any kind to the user or any other party, including but not
limited to personal injury, death, or loss of property. Sierra Wireless
and its affiliates accept no responsibility for damages of any kind
resulting from delays or errors in data transmitted or received using
the Sierra Wireless modem, or for failure of the Sierra Wireless
modem to transmit or receive such data.
Safety and hazards
Do not operate your EM7355 modem:
•In areas where blasting is in progress

Hardware Integration Guide
18 Proprietary and Confidential - Contents subject to change 4112880
•Where explosive atmospheres may be present including refuelling points, fuel
depots, and chemical plants
•Near medical equipment, life support equipment, or any equipment which
may be susceptible to any form of radio interference. In such areas, the
EM7355 modem MUST BE POWERED OFF. Otherwise, the EM7355 modem
can transmit signals that could interfere with this equipment.
In an aircraft, the EM7355 modem MUST BE POWERED OFF. Otherwise, the
EM7355 modem can transmit signals that could interfere with various onboard
systems and may be dangerous to the operation of the aircraft or disrupt the
cellular network. Use of a cellular phone in an aircraft is illegal in some
jurisdictions. Failure to observe this instruction may lead to suspension or denial
of cellular telephone services to the offender, or legal action or both.
Some airlines may permit the use of cellular phones while the aircraft is on the
ground and the door is open. The EM7355 modem may be used normally at this
time.
Important compliance information for
North American users
Note: Details are preliminary and subject to change.
The EM7355 modem has been granted modular approval for mobile applications.
Integrators may use the EM7355 modem in their final products without additional
FCC/IC (Industry Canada) certification if they meet the following conditions.
Otherwise, additional FCC/IC approvals must be obtained.
1. At least 20 cm separation distance between the antenna and the user’s body
must be maintained at all times.
2. To comply with FCC/IC regulations limiting both maximum RF output power
and human exposure to RF radiation, the maximum antenna gain including
cable loss in a mobile-only exposure condition must not exceed:
·6.5 dBi in Cellular band
·3.0 dBi in PCS band
·3.0 dBi in LTE Band 2
·6.0 dBi in LTE Band 4
·6.5 dBi in LTE Band 5
·9.0 dBi in LTE Band 13 (Note: LTE Band 13 is not permitted in Canada.)
·9.0 dBi in LTE Band 17 (Note: LTE Band 17 is not permitted in Canada.)
·3.0 dBi in LTE Band 25
3. The EM7355 modem may transmit simultaneously with other collocated radio
transmitters within a host device, provided the following conditions are met:
·Each collocated radio transmitter has been certfied by FCC/IC for mobile
application.
·At least 20 cm separation distance between the antennas of the collocated
transmitters and the user’s body must be maintained at all times.

Regulatory Compliance and Industry Certifications
Rev 2 Feb.13 Proprietary and Confidential - Contents subject to change 19
·The output power and antenna gain must not exceed the limits and configu-
rations stipulated in the following table.
4. A label must be affixed to the outside of the end product into which the
EM7355 modem is incorporated, with a statement similar to the following:
· This device contains FCC ID: N7NEM7355
Contains transmitter module IC: 2417C-EM7355 where 2417C-EM7355
is the module’s certification number.
5. A user manual with the end product must clearly indicate the operating
requirements and conditions that must be observed to ensure compliance
with current FCC/IC RF exposure guidelines.
Device Technology Band Frequency
(MHz) Maximum conducted power
(dBm)
Maximum
antenna gain
(dBi)
EM7355
Embedded
Module
LTE 21850–1910 24 3
41710–1755 24 6
5824–849 24 3
13 777–787 24 6
17 704–716 24 6
25 1850–1915 24 3
UMTS 21850–1910 24 3
41710–1755 24 6
5824–849 24 3
GSM 850 824–849 33 3
1900 1850–1910 30 3
CDMA BC0 824–849 25 3
BC1 1850–1910 25 3
BC10 817–824 25 3
Collocated
transmitters1WLAN 2400–2500 29 5.0
5150–5850 29 5.0
WiMAX 2300–2400 29 5.0
2500–2700 29 5.0
3300–3800 29 5.0
BT 2400–2500 15 5.0
1. Valid collocated transmitter combinations: WLAN+BT; WiMAX+BT.
(WLAN+WiMAX+BT is not permitted.)

Hardware Integration Guide
20 Proprietary and Confidential - Contents subject to change 4112880
The end product with an embedded EM7355 modem may also need to pass the
FCC Part 15 unintentional emission testing requirements and be properly
authorized per FCC Part 15.
Note: If this module is intended for use in a portable device, you are responsible
for separate approval to satisfy the SAR requirements of FCC Part 2.1093 and IC
RSS-102.
