Sierra Wireless AirLink GL7 00 Series User manual

Product Technical Specification
and User Guide
AirLink GL7x00
41110590
6.1
January 28, 2019

41110590 Rev 6.1 January 28, 2019 2
Product Technical Specification and
User Guide
Important Notice
Due to the nature of wireless communications, transmission and reception of data can never be
guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant
delays or losses of data are rare when wireless devices such as the Sierra Wireless modem are used
in a normal manner with a well-constructed network, the Sierra Wireless modem should not be used
in situations where failure to transmit or receive data could result in damage of any kind to the user or
any other party, including but not limited to personal injury, death, or loss of property. Sierra Wireless
accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or
received using the Sierra Wireless modem, or for failure of the Sierra Wireless modem to transmit or
receive such data.
Safety and Hazards
Do not operate the Sierra Wireless modem in areas where cellular modems are not advised without
proper device certifications. These areas include environments where cellular radio can interfere such
as explosive atmospheres, medical equipment, or any other equipment which may be susceptible to
any form of radio interference. The Sierra Wireless modem can transmit signals that could interfere
with this equipment. Do not operate the Sierra Wireless modem in any aircraft, whether the aircraft is
on the ground or in flight. In aircraft, the Sierra Wireless modem MUST BE POWERED OFF. When
operating, the Sierra Wireless modem can transmit signals that could interfere with various onboard
systems.
Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door
is open. Sierra Wireless modems may be used at this time.
The driver or operator of any vehicle should not operate the Sierra Wireless modem while in control of
a vehicle. Doing so will detract from the driver or operator’s control and operation of that vehicle. In
some states and provinces, operating such communications devices while in control of a vehicle is an
offence.
Limitations of Liability
This manual is provided “as is”. Sierra Wireless makes no warranties of any kind, either expressed or
implied, including any implied warranties of merchantability, fitness for a particular purpose, or
noninfringement. The recipient of the manual shall endorse all risks arising from its use.
The information in this manual is subject to change without notice and does not represent a
commitment on the part of Sierra Wireless. SIERRA WIRELESS AND ITS AFFILIATES
SPECIFICALLY DISCLAIM LIABILITY FOR ANY AND ALL DIRECT, INDIRECT, SPECIAL,
GENERAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES INCLUDING,
BUT NOT LIMITED TO, LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS OR
REVENUE ARISING OUT OF THE USE OR INABILITY TO USE ANY SIERRA WIRELESS
PRODUCT, EVEN IF SIERRA WIRELESS AND/OR ITS AFFILIATES HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY
THIRD PARTY.
Notwithstanding the foregoing, in no event shall Sierra Wireless and/or its affiliates aggregate liability
arising under or in connection with the Sierra Wireless product, regardless of the number of events,
occurrences, or claims giving rise to liability, be in excess of the price paid by the purchaser for the
Sierra Wireless product.

41110590 Rev 6.1 January 28, 2019 3
Product Technical Specification and
User Guide
Patents
This product may contain technology developed by or for Sierra Wireless Inc.
This product includes technology licensed from QUALCOMM®.
This product is manufactured or sold by Sierra Wireless Inc. or its affiliates under one or more patents
licensed from MMP Portfolio Licensing.
Copyright
© 2019 Sierra Wireless. All rights reserved.
Trademarks
Sierra Wireless®, AirPrime®, AirLink®, AirVantage®, WISMO®, ALEOS®and the Sierra Wireless and
Open AT logos are registered trademarks of Sierra Wireless, Inc. or one of its subsidiaries.
Watcher®is a registered trademark of NETGEAR, Inc., used under license.
Windows®and Windows Vista®are registered trademarks of Microsoft Corporation.
Macintosh®and Mac OS X®are registered trademarks of Apple Inc., registered in the U.S. and other
countries.
QUALCOMM®is a registered trademark of QUALCOMM Incorporated. Used under license.
Other trademarks are the property of their respective owners.
Contact Information
Sales information and technical support, including
warranty and returns Web: sierrawireless.com/company/contact-us/
Global toll-free number: 1-877-687-7795
6:00 am to 5:00 pm PST
Corporate and product information Web: sierrawireless.com

41110590 Rev 6.1 January 28, 2019 4
Product Technical Specification and
User Guide
Document History
Version Date Updates
1.0 April 27, 2017 Creation
1.1 May 08, 2017 Updated 8.2 Reliability Prediction Model
2.0 June 27, 2017
Added:
•5 Last Gasp Configuration
•9 Regulatory Information
Updated:
•2.2.1.1 Power Supply
•2.2.3.1 RF Performances
•6.5 Resetting the GL7x00
2.1 July 04, 2017 Updated: •1.5.3 Last Gasp
•2.2.1.2.3 2-wire Serial Interface Hardware Design
3.0 October 11, 2017 Added 18 Appendix C: Mounting
Updated 5.1 +LASTGASP Command: Last Gasp Status
4.0 December 12, 2017 Updated 2.1.2 Flash LED
5.0 August 21, 2018 Updated:
•1.4.1 RoHS Compliance
•6.5 Resetting the GL7x00
6.0 January 21, 2019 Updated 17.1 Model Label
6.1 January 28, 2019 Removed CE number from 17.1 Model Label

41110590 Rev 6.1 January 28, 2019 5
Contents
1. OVERVIEW ........................................................................................................11
1.1. Variants..............................................................................................................................11
1.2. Overall Dimensions ...........................................................................................................11
1.3. General Features...............................................................................................................12
1.4. Environmental Compliance................................................................................................13
1.4.1. RoHS Compliance ...................................................................................................13
1.4.2. Disposing of the Product..........................................................................................13
1.5. Functional Architecture......................................................................................................13
1.5.1. RF Functionalities....................................................................................................14
1.5.2. Operating System....................................................................................................14
1.5.3. Last Gasp.................................................................................................................14
1.6. Mechanical Specifications.................................................................................................15
1.6.1. Mechanical Drawing ................................................................................................15
1.6.2. Product Color...........................................................................................................16
2. INTERFACES/PERIPHERALS...........................................................................17
2.1. Front Interface ...................................................................................................................17
2.1.1. SIM Interface............................................................................................................18
2.1.1.1. External SIM ....................................................................................................18
2.1.1.2. Embedded SIM................................................................................................18
2.1.2. Flash LED................................................................................................................19
2.2. Back Interface....................................................................................................................19
2.2.1. 8-pin Micro-Fit Connector ........................................................................................19
2.2.1.1. Power Supply...................................................................................................20
2.2.1.2. Serial Link (RS232) .........................................................................................21
2.2.2. Micro USB Connector..............................................................................................23
2.2.2.1. Pin Description.................................................................................................23
2.2.2.2. USB Driver.......................................................................................................24
2.2.3. RF Interface.............................................................................................................24
2.2.3.1. RF Performances.............................................................................................24
2.2.3.2. Antenna Specifications....................................................................................25
3. USING THE GL7X00..........................................................................................26
3.1. Getting Started ..................................................................................................................26
3.1.1. Inserting the SIM Card.............................................................................................27
3.1.2. Extracting the SIM Card...........................................................................................28
3.2. Operational Status.............................................................................................................28
4. COMMUNICATING WITH THE GL7X00............................................................29
4.1. Communications Testing...................................................................................................29
4.2. Checking the PIN Code Status..........................................................................................29
4.3. Verify the Received Signal Strength..................................................................................30
4.4. Verify the Network Registration.........................................................................................30
4.5. Main AT Commands for the GL7x00.................................................................................31

41110590 Rev 6.1 January 28, 2019 6
Product Technical Specification and
User Guide
4.6. Echo Function....................................................................................................................32
5. LAST GASP CONFIGURATION........................................................................33
5.1. +LASTGASP Command: Last Gasp Status......................................................................33
5.2. +LASTGASPSMS Command: Last Gasp Configuration Command for SMS Content .....34
5.3. +LASTGASPUDP Command: Last Gasp Configuration Command for UDP Content......35
6. TROUBLESHOOTING THE GL7X00.................................................................37
6.1. No Communications with the GL7x00 through the Serial Link..........................................37
6.2. No Communications with the GL7x00 through the USB ...................................................38
6.3. Receiving an “ERROR” Message......................................................................................38
6.4. Receiving a “NO CARRIER” Message..............................................................................39
6.5. Resetting the GL7x00........................................................................................................40
7. POWER CONSUMPTION ..................................................................................41
7.1. Consumption Measurement Procedure.............................................................................41
7.1.1. Hardware Configuration...........................................................................................41
7.1.1.1. Equipment........................................................................................................41
7.1.1.2. SIM Cards........................................................................................................42
7.1.2. Software Configuration............................................................................................42
7.1.2.1. Modem Configuration......................................................................................42
7.1.2.2. Equipment Configuration.................................................................................42
7.2. Operating Modes...............................................................................................................43
7.2.1. Entering Sleep Mode ...............................................................................................43
7.2.2. Serial Port Shutdown Mode.....................................................................................44
7.3. Power Consumption Values..............................................................................................44
7.3.1. GL7500....................................................................................................................44
7.3.2. GL7600....................................................................................................................45
8. RELIABILITY COMPLIANCE AND RECOMMENDATIONS..............................47
8.1. Environmental Specifications ............................................................................................47
8.1.1. Function Status Classification..................................................................................47
8.2. Reliability Prediction Model ...............................................................................................48
8.2.1. Life Stress Test........................................................................................................48
8.2.2. Environmental Resistance Stress Tests..................................................................48
8.2.3. Corrosive Resistance Stress Tests .........................................................................49
8.2.4. Thermal Resistance Cycle Stress Tests..................................................................49
8.2.5. Mechanical Resistance Stress Tests.......................................................................50
8.2.6. Handling Resistance Stress Tests...........................................................................51
9. REGULATORY INFORMATION.........................................................................52
9.1. RF Exposure......................................................................................................................52
9.2. FCC ID and IC Number .....................................................................................................52
9.3. Maximum Antenna Gain....................................................................................................52
9.4. EU......................................................................................................................................53
9.5. Declaration of Conformity..................................................................................................53
9.6. WEEE Notice.....................................................................................................................53

41110590 Rev 6.1 January 28, 2019 7
Product Technical Specification and
User Guide
10.CABLES AND ACCESSORIES .........................................................................54
10.1. Adaptive Cable ..................................................................................................................54
10.1.1. 8-pin Micro-Fit Edge ................................................................................................54
10.1.2. DB9 Edge.................................................................................................................55
10.1.3. 2-pin Micro-Fit Edge ................................................................................................56
10.2. DC Cable...........................................................................................................................56
11.RECOMMENDED CONNECTORS AND ACCESSORIES.................................57
11.1. Mating Connector ..............................................................................................................57
12.MECHANICAL CONSTRAINTS.........................................................................58
12.1. Micro-Fit Connector...........................................................................................................58
13.PROTECTIONS..................................................................................................59
13.1. Power Supply.....................................................................................................................59
13.2. Electrostatic Discharge......................................................................................................59
13.3. Miscellaneous....................................................................................................................59
14.UPGRADE GUIDELINES...................................................................................60
14.1. Operating System Upgrade...............................................................................................60
14.2. Firmware Upgrade.............................................................................................................60
15.REFERENCES ...................................................................................................61
15.1. Sierra Wireless Reference Documentation.......................................................................61
15.2. General Reference Documentation...................................................................................61
15.3. List of Abbreviations..........................................................................................................61
16.APPENDIX A: PACKAGING..............................................................................64
17.APPENDIX B: PRODUCT LABELING...............................................................65
17.1. Model Label.......................................................................................................................65
17.2. IMEI and Approval Label...................................................................................................65
18.APPENDIX C: MOUNTING ................................................................................66

41110590 Rev 6.1 January 28, 2019 8
List of Figures
Figure 1. GL7x00 Modem (front and back views) ..........................................................................11
Figure 2. Functional Architecture....................................................................................................13
Figure 3. Mechanical Drawing........................................................................................................15
Figure 4. Front View .......................................................................................................................17
Figure 5. Back View........................................................................................................................19
Figure 6. Pin Assignment of the 8-pin Micro-Fit Connector............................................................19
Figure 7. RS232 Serial Link Signals...............................................................................................21
Figure 8. 4-wire Serial Link Implementation...................................................................................22
Figure 9.2-wire Serial Link Implementation...................................................................................22
Figure 10. USB Signals on the Micro USB Connector .....................................................................23
Figure 11. Typical Hardware Configuration......................................................................................41
Figure 12. Adaptive Cable for the GL7x00.......................................................................................54
Figure 13. 8-pin Micro-Fit Edge of the Adaptive Cable ....................................................................54
Figure 14. DB9 Edge of the Adaptive Cable.....................................................................................55
Figure 15. 2-pin Micro-Fit Edge of the Adaptive Cable ....................................................................56
Figure 16. Pin Assignment of the 2-pin Micro-Fit Edge....................................................................56
Figure 17. DC Cable.........................................................................................................................56
Figure 18. Pin Assignment of the DC Cable.....................................................................................56
Figure 19. Two Pizza Boxes in an Outer Box...................................................................................64
Figure 20. GL7x00 in a Pizza Box....................................................................................................64
Figure 21. Model Label.....................................................................................................................65
Figure 22. SN and IMEI Label ..........................................................................................................65

41110590 Rev 6.1 January 28, 2019 9
List of Tables
Table 1. GL7x00 Physical Dimensions..........................................................................................11
Table 2. GL7x00 Feature Set........................................................................................................12
Table 3. Supported Bands/Connectivity on the GL7500...............................................................14
Table 4. Supported Bands/Connectivity on the GL7600...............................................................14
Table 5. Available Interface Signals..............................................................................................17
Table 6. SIM Interface Electrical Characteristics ..........................................................................18
Table 7. LED Status ......................................................................................................................19
Table 8. Micro-Fit Connector Pin Description................................................................................20
Table 9. Input Power Supply Voltage............................................................................................20
Table 10. Effects of Power Supply Overload/Underload.................................................................20
Table 11. Typical Inrush Current.....................................................................................................20
Table 12. Serial Link Pin Description from the Micro-Fit Connector (CN201).................................21
Table 13. USB Pin Description........................................................................................................23
Table 14. GL7500 Conducted RX Sensitivity (dBm).......................................................................24
Table 15. GL7600 Conducted RX Sensitivity (dBm).......................................................................24
Table 16. GL7500 Antenna Specifications......................................................................................25
Table 17. GL7600 Antenna Specifications......................................................................................25
Table 18. AT+CPIN Responses......................................................................................................29
Table 19. Received Signal Strength Values....................................................................................30
Table 20. Network Registration Values...........................................................................................31
Table 21. Main AT Commands for the GL7x00...............................................................................31
Table 22. Solutions for No Connection with the GL7x00 through the Serial Link ...........................37
Table 23. No Communications with the GL7x00 through the USB.................................................38
Table 24. Solutions for Receiving a “NO CARRIER” Message.......................................................39
Table 25. Extended Error Codes.....................................................................................................40
Table 26. List of Recommended Equipment...................................................................................42
Table 27. Operating Modes.............................................................................................................43
Table 28. GL7500 Power Consumption (Typical Values)...............................................................44
Table 29. GL7600 Power Consumption (Typical Values)...............................................................45
Table 30. Operating Class Temperature Range .............................................................................47
Table 31. ISO Failure Mode Severity Classification........................................................................47
Table 32. Life Stress Test................................................................................................................48
Table 33. Environmental Resistance Stress Tests .........................................................................48
Table 34. Corrosive Resistance Stress Tests.................................................................................49
Table 35. Thermal Resistance Cycle Stress Tests .........................................................................49
Table 36. Mechanical Resistance Stress Tests..............................................................................50
Table 37. Handling Resistance Stress Tests ..................................................................................51

41110590 Rev 6.1 January 28, 2019 10
Product Technical Specification and
User Guide
Table 38. FCC ID and IC Number...................................................................................................52
Table 39. Maximum Antenna Gain..................................................................................................52
Table 40. 8-pin Micro-Fit Pin Description of the Adaptive Cable.....................................................54
Table 41. DB9 Connector Pin Description.......................................................................................55
Table 42. 2-pin Micro-Fit Connector Pin Description ......................................................................56
Table 43. DC Cable Pin Description................................................................................................56
Table 44. Recommended Mating Connector for the Micro-Fit Connector ......................................57
Table 45. Micro-Fit Connector Mechanical Constraints ..................................................................58

41110590 Rev 6.1 January 28, 2019 11
1. Overview
The GL7x00 is a wireless modem that allows users to connect to a wireless network. It offers data
connectivity on GSM, WCDMA and LTE networks; and was designed by using the AirPrime HL7
series of embedded module.
Figure 1. GL7x00 Modem (front and back views)
The following section provides information about the physical attributes, and briefly summarizes the
modem’s features, interfaces and connectors.
1.1. Variants
The GL7x00 comes in two variants:
•GL7500 which utilizes an HL7588 embedded module, and
•GL7600 which uses an HL7692 embedded module.
1.2. Overall Dimensions
The following table lists the GL7x00’s physical characteristics.
Table 1. GL7x00 Physical Dimensions
Length 67 mm (excluding the RF connectors)
72.85 mm (including the RF connectors)
Width 51.5 mm
Thickness 23.5 mm
Weight 45 g for the GL7500;
49 g for the GL7600

41110590 Rev 6.1 January 28, 2019 12
Product Technical Specification and
User Guide Overview
1.3. General Features
The following table summarizes available features on the GL7x00.
Table 2. GL7x00 Feature Set
Feature Description
RF
For the GL7500:
•Penta-band LTE:
LTE B2: 1900 MHz PCS
LTE B4: 1700 MHz AWS
LTE B5: 850 MHz CLR
LTE B13: 700 MHz Upper SMH
LTE B17: 700 MHz Lower SMH
Category 4 (up to 150 Mbit/s in downlink, 50 Mbit/s in uplink)
•Dual-band UMTS
UMTS B2: 1900 MHz PCS
UMTS B5: 850 MHz CLR
HSDPA (High Speed Uplink Packet Access); up to Category 24
(DC, 42.2Mbps)
HSUPA (High Speed Uplink Packet Access); Category 7
(11.5Mbps)
For the GL7600:
•Tri-band LTE:
LTE B3: 1800 MHz DCS
LTE B8: 900 MHz E-GSM
LTE B20: 800 MHz EU Digital Dividend
Category 1 (up to 10 Mbit/s in downlink, 5 Mbit/s in uplink)
•Dual-band GSM/GPRS/EDGE:
E-GSM-900
DCS-1800
Class 33 (296 kbits downlink and 236.8 kbits uplink)
Connectors
•Two SMA connectors
•One Micro-USB connector
•One Micro-Fit connector with RS-232
Interfaces
•RS-232 serial interface
•USB 2.0 interface, x speed
•1.8V/3V SIM interface
Environmental
Operating temperature ranges (industrial grade):
•Class A: -20 °C to +55°C
•Class B: -30 °C to +75°C

41110590 Rev 6.1 January 28, 2019 13
Product Technical Specification and
User Guide Overview
1.4. Environmental Compliance
1.4.1. RoHS Compliance
GL7x00 modems are compliant with RoHS Directive 2011/65/EU, including directive 2015/863
amending annex II, which sets limits for the use of certain restricted hazardous substances. This
directive states that electrical and electronic equipment put on the market does not contain lead,
mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB), polybrominated diphenyl
ethers (PBDE), Bis (2-ethylhexyl) phthalate (DEHP), Butyl benzyl phthalate (BBP), Dibutyl phthalate
(DBP) or Diisobutyl phthalate (DIBP) above threshold limits.
1.4.2. Disposing of the Product
This electronic product is subject to the EU Directive 2012/19/EU for Waste Electrical
and Electronic Equipment (WEEE). As such, this product must not be disposed of at a
municipal waste collection point. Please refer to local regulations for directions on how
to dispose of this product in an environmental friendly manner.
1.5. Functional Architecture
The global architecture of the GL7x00 is shown in the figure below.
AirPrime
HL7xxx
Embedded
Module
SIM
Card
Holder
Flash
LED
DC/DC
Converter
UART
Transceiver
8-pin
Micro-Fit
Connector
Diversity RF
Connector
GL7x00
Serial Link
Power Supply
Last Gasp*
Last Gasp is only available in the GL7600*
Micro USB
Connector Data
Primary RF
Connector
Figure 2. Functional Architecture

41110590 Rev 6.1 January 28, 2019 14
Product Technical Specification and
User Guide Overview
1.5.1. RF Functionalities
The Radio Frequency (RF) range of the GL7x00 complies with 3GPP requirements. The
corresponding frequency recommendations for both transmission and reception bands are listed in
the tables below.
Table 3. Supported Bands/Connectivity on the GL7500
RF Band Transmit Band (Tx) Receive Band (Rx) Maximum Output Power
LTE B2 1850 to 1910 MHz 1930 to 1990 MHz 23 dBm (± 2 dBm) Class 3bis
LTE B4 1710 to 1755 MHz 2110 to 2155 MHz 23 dBm (± 2 dBm) Class 3bis
LTE B5 824 to 849 MHz 869 to 894 MHz 23 dBm (± 2 dBm) Class 3bis
LTE B13 777 to 787 MHz 746 to 756 MHz 23 dBm (± 2 dBm) Class 3bis
LTE B17 704 to 716 MHz 734 to 746 MHz 23 dBm (± 2 dBm) Class 3bis
UMTS B2 1850 to 1910 MHz 1930 to 1990 MHz 23 dBm (± 2 dBm) Class 3bis
UMTS B5 824 to 849 MHz 869 to 894 MHz 23 dBm (± 2 dBm) Class 3bis
Table 4. Supported Bands/Connectivity on the GL7600
RF Band Transmit Band (Tx) Receive Band (Rx) Maximum Output Power
LTE B3 1710 to 1785 MHz 1805 to 1880 MHz 23 dBm ± 2 dBm
LTE B8 880 to 915 MHz 925 to 960 MHz 23 dBm ± 2 dBm
LTE B20 832 to 862 MHz 791 to 821 MHz 23 dBm ± 2 dBm
E-GSM 900 880 to 915 MHz 925 to 960 MHz 2 Watts GSM, GPRS and EDGE
DCS 1800 1710 to 1785 MHz 1805 to 1880 MHz 1-Watt GSM, GPRS and EDGE
1.5.2. Operating System
The operating system of the modem is responsible for the following functions:
•Drives the modem via an AT Command interface over a serial port
•Real Time Clock (RTC) with calendar
•Dual-mode GSM/LTE or UMTS (WCDMA)/LTE operation
Note: The GL7x00 is not programmable.
1.5.3. Last Gasp
Additionally, the GL7600 supports Last Gasp which allows the modem to send an emergency
message (either an SMS or a UDP package) to the server when the main power is unexpectedly cut.
It makes use of the modem’s internally stored emergency power to send a message after a sudden
power outage.
For Last Gasp configuration information, refer to 5 Last Gasp Configuration.

41110590 Rev 6.1 January 28, 2019 15
Product Technical Specification and
User Guide Overview
1.6. Mechanical Specifications
1.6.1. Mechanical Drawing
Figure 3. Mechanical Drawing

41110590 Rev 6.1 January 28, 2019 16
Product Technical Specification and
User Guide Overview
1.6.2. Product Color
The GL7x00 comes in:
OSAKI BLACK
Muncell 10B 1.5/0.5
DIC 581B
(PANTONE 426C)
C5%M5%Y0or5%K90%
R24G25B26
HTML: #18191A

41110590 Rev 6.1 January 28, 2019 17
2. Interfaces/Peripherals
This section describes the different connectors, interfaces and peripherals that connect with the
modem.
The modem is distributed in the market as a finished product with the following interfaces:
•an 8-pin Micro-Fit connector
•a micro USB connector
•two SMA RF connectors
•a SIM connector
•a Flash LED indicator
The interface signals available from the modem are listed in the following table. For more information
about these signals, refer to the corresponding chapters.
Table 5. Available Interface Signals
Name Driven by AT Commands
Serial Link (RS232) Yes
USB Yes
SIM Interface Yes
LED Signal Yes
2.1. Front Interface
Figure 4. Front View
LED Indicator
SIM Interface

41110590 Rev 6.1 January 28, 2019 18
Product Technical Specification and
User Guide Interfaces/Peripherals
2.1.1. SIM Interface
The GL7x00 has two SIM interfaces – an external SIM and an Embedded SIM. Having an embedded
SIM option allows the GL7x00 to support Dual SIM Single Standby (DSSS) using AT+KSIMSEL. Refer
to documents [3] AirPrime HL7588 AT Commands Interface Guide and [4] AirPrime HL76xx AT
Commands Interface Guide for more information regarding this command.
2.1.1.1. External SIM
The external SIM can be directly inserted in the modem through the SIM door and is the default
hardware configuration of the GL7x00.
This interface controls both 1.8V and 3V SIM/USIM cards and it is fully compliant with ETSI UICC
specification.
This interface is ESD protected. Transient Voltage Suppressor diodes are internally added on the
signals connected to the SIM interface to prevent any damage from electrostatic discharge.
The SIM uses five SIM signals, namely:
•SIM-VCC, which is the SIM power supply
•SIM-RST, which is reset
•SIM-CLK, is clock
•SIM-IO, as the I/O port
•SIM-DET, for SIM detection
Refer to the following table for the electrical characteristics of the SIM interface.
Table 6. SIM Interface Electrical Characteristics
Parameter Minimum Typical Maximum Notes
SIM Interface Voltage (V)
(VCC, CLK, IO, RST) -
2.90 - The appropriate output
voltage is auto-detected and
selected by software.
-1.80 -
SIM-DET - 1.80 - High active
SIM-VCC Current (mA) --10 In sleep mode, maximum
output current = 3mA
SIM-VCC Line Regulation (mV/V) --50 At Iout_Max
SIM-VCC Power-up Setting Time
from power down (µs) - 10 -
2.1.1.2. Embedded SIM
The GL7x00 has the option to use an embedded SIM which could either be a Sierra Wireless SIM or
a customized SON8 SIM.
With an external SIM, the GL7x00 can support Dual SIM Single Standby (DSSS).

41110590 Rev 6.1 January 28, 2019 19
Product Technical Specification and
User Guide Interfaces/Peripherals
2.1.2. Flash LED
The GL7x00 has an LED indicator to show the status of the wireless network.
Table 7. LED Status
Modem State LED Status Modem Status
ON
Permanently lighted The modem is powered ON, but not
registered in the network.
Slow flash (LED is switched ON for 200ms,
OFF for 2s) The modem is powered ON, and registered in the network.
Quick flash (LED is switched ON for 200ms,
OFF for 600ms) The modem powered ON, registered on the
network, and circuit-switched communication
is in progress.
OFF OFF The modem is either switched OFF or the
FLASH-LED has been disabled by the user.
The Flash LED can be
•deactivated by the AT command AT+KSYNC=0
•activated by the AT command AT+KSYNC=2,8
2.2. Back Interface
Figure 5. Back View
2.2.1. 8-pin Micro-Fit Connector
The 8-pin Micro-Fit connector is used for the following connections:
•External DC power supply connection with voltage from 4.75V to 32V
•Serial link (RS232) interface
Figure 6. Pin Assignment of the 8-pin Micro-Fit Connector
8-pin Micro-Fit Connector
Diversity RF Interface
Main RF Interface

41110590 Rev 6.1 January 28, 2019 20
Product Technical Specification and
User Guide Interfaces/Peripherals
Table 8. Micro-Fit Connector Pin Description
Pin # Signal I/O I/O Type Voltage Description
1 DCIN I Power Supply 4.75V to 32V 4.75V to 32V DC input
2 RS232-DTR I RS-232 -5.5V to 5.5V Data Terminal Ready
3 RS232-RXD O RS-232 -5.5V to 5.5V Receive Serial Data
4 RS232-CTS O RS-232 -5.5V to 5.5V Clear To Send
5 - - - - Reserved
6 GND - GND GND Ground
7 RS232-TXD I RS-232 -5.5V to 5.5V Transmit Serial Data
8 RS232- RTS I RS-232 -5.5V to 5.5V Request To Send
Note: Pins 2-4 and Pins 7-8 are used by the serial link interface. It is strictly prohibited to connect them to
any power supply at the risk of damaging the GL7x00.
2.2.1.1. Power Supply
The GL7x00 can only be supplied by an external DC voltage (DCIN) that ranges from 4.75V to 32V at
2.2A. This input is available via the 8-pin Micro-Fit connector.
Table 9. Input Power Supply Voltage
Pin Number Signal Description
1 DCIN 4.75V to 32V DC input
6 GND Ground Connection
Note that the correct operation of the GL7x00 in communication mode is not guaranteed if input
voltage (DCIN) falls below 4.75V.
The following table describes the consequences of having the GL7x00 go either over or under the
specified voltage range.
Table 10. Effects of Power Supply Overload/Underload
If the voltage Then
Falls below 4.75V Wireless communication is not guaranteed.
Is over 32V (transient peaks) External protection should be implemented on the GL7x00.
Is over 32V (continuous over voltage) External protection should be implemented on the GL7x00.
Additionally, when a GL7600 has not been used for a long time, the power supply should provide
sufficient inrush current for the modem.
Table 11. Typical Inrush Current
Power Supply (V) Measurement Time from Power-Up (s) Typical Inrush Current Value (mA)
4.75 0.1 120
9 0.1 80
16 0.1 60
