SIGLENT SSA5000A User manual

1
Quick Guide
SSA5000A
Spectrum Analyzer
Quick Guide
EN_01A

SSA5000A Quick Guide 1
Guaranty and Declaration
Copyright
SIGLENT TECHNOLOGIES CO., LTD All Rights Reserved.
Trademark Information
SIGLENT is the registered trademark of SIGLENT TECHNOLOGIES CO.,
LTD
Declaration
⚫SIGLENT products are protected by patent law worldwide
⚫SIGLENT reserves the right to modify or change parts of or all the
specifications or pricing policies at company’s sole decision.
⚫Information in this publication replaces all previously corresponding
material.
⚫Any way of copying, extracting or translating the contents of this manual
is not allowed without the permission of SIGLENT.
⚫SIGLENT will not be responsible for losses caused by either incidental or
consequential in connection with the furnishing, use or performance of
this manual as well as any information contained.
Product Certification
SIGLENT guarantees this product conforms to the national and industrial
standards in China as well as the ISO9001: 2008 standard and the ISO14001:
2004 standard. Other international standard conformance certification is in
progress.

2 SSA5000A Quick Guide
Contents
Guaranty and Declaration ........................................................................... 1
Contents...................................................................................................... 2
Important Safety Information....................................................................... 3
General Inspection.................................................................................... 13
Preparing for Use...................................................................................... 14
Front Panel................................................................................................ 15
Rear Panel................................................................................................ 19
User Interface............................................................................................ 21
Basic Control Operation............................................................................ 23
Firmware Operation................................................................................... 25
Remote Control......................................................................................... 27
Service and Support.................................................................................. 27
Troubleshooting......................................................................................... 28

SSA5000A Quick Guide 3
Important Safety Information
This manual contains information and warnings that must be followed by the
user for safe operation and to keep the product in a safe condition.
General Safety Summary
Carefully read the following safety precautions to avoid any personal injury or
damage to the instrument and any products connected to it. To avoid potential
hazards, please use the instrument as specified.
To Avoid Fire or Personal Injury.
Use Proper AC Power Line
Only the power cord designed for the instrument and authorized by local
country should be used.
Ground the Instrument
The instrument is grounded through the protective earth conductor of the
power line. To avoid electric shock, please make sure the instrument is
grounded correctly before connecting its input or output terminals.
Connect the Probe Correctly.
If a probe is used, do not connect the ground lead to high voltage since it has
isobaric electric potential as the ground.

4 SSA5000A Quick Guide
Look Over All Terminals’ Ratings
To avoid fire or electric shock, please look over all ratings and sign instruction
of the instrument. Before connecting the instrument, please read the manual
carefully to gain more information about the ratings.
Equipment Maintenance and Service
When the equipment fails, please do not dismantle the machine for
maintenance. The equipment contains capacitors, power supply, transformers,
and other energy storage devices, which may cause high voltage damage. The
internal devices of the equipment are sensitive to static electricity, and direct
contact is easy to cause irreparable damage to the equipment. It is necessary
to return to the factory or the company's designated maintenance organization
for maintenance.
Be sure to pull out the power supply when repairing the equipment. Live line
operation is strictly prohibited. The equipment can only be powered on when
the maintenance is completed and the maintenance is confirmed to be
successful.
Identification of Normal State of Equipment
After the equipment is started, there will be no alarm information and error
information at the interface under normal conditions. The curve of the interface
will scan from left to right freely; if there is a button in the scanning process or
there is an alarm or error prompt, the device may be in an abnormal state. You
need to view the specific prompt information. You can try to restart the setting.
If the fault information is still in place, do not use it for testing. Contact the
manufacturer or the maintenance department designated by the manufacturer
to carry out maintenance to avoid the wrong test data caused by the use of the
fault or endanger the personal safety.

SSA5000A Quick Guide 5
Not Operate with Suspected Failures
If you suspect that there is damage to the instrument, please let qualified
service personnel check it.
Avoid Circuit or Wire Exposed Components Exposed
Do not touch exposed contacts or components when the power is on.
Do not operate in wet/damp conditions
Do not operate in an explosive atmosphere
Keep the surface of the instrument clean and dry
Not to use the equipment for measurements on mains circuits, not to use
the equipment for measurements on voltage exceed the voltage range
describe in the manual. The maximum additional transient voltage
cannot exceed 1300V.
The responsible body or operator should refer to the instruction manual
to preserve the protection afforded by the equipment. If the equipment is
used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
Any parts of the device and its accessories are not allowed to be
changed or replaced, other than authorized by the manufacturer or agent.

6 SSA5000A Quick Guide
Safety Terms and Symbols
When the following symbols or terms appear on the front or rear panel of the
instrument or in this manual, they indicate special care in terms of safety.
This symbol is used where caution is required. Refer to the
accompanying information or documents to protect against
personal injury or damage to the instrument.
This symbol warns of a potential risk of shock hazard.
This symbol is used to denote the measurement ground
connection.
This symbol is used to denote a safety ground connection.
This symbol shows that the switch is an On/Standby switch.
When it is pressed, the analyzer’s state switches between
Operation and Standby. This switch does not disconnect the
device's power supply. To completely power off the analyzer, the
power cord must be unplugged from the AC socket after the
instrument is in the standby state.
This symbol is used to represent alternating current, or "AC".
CAUTION
The "CAUTION" symbol indicates a potential hazard. It calls
attention to a procedure, practice, or condition which may be
dangerous if not followed. Do not proceed until its conditions are
fully understood and met.
WARNING
The "WARNING" symbol indicates a potential hazard. It calls
attention to a procedure, practice, or condition which, if not
followed, could cause bodily injury or death. If a WARNING is
indicated, do not proceed until the safety conditions are fully
understood and met.

SSA5000A Quick Guide 7
Working Environment
The design of the instrument has been verified to conform to EN 61010-1
safety standard per the following limits:
Environment
The instrument is used indoors and should be operated in a clean and dry
environment with an ambient temperature range.
Note: Direct sunlight, electric heaters, and other heat sources should be
considered when evaluating the ambient temperature.
Warning: Do not operate the instrument in explosive, dusty, or
humid environments.
Ambient Temperature
Operating: 0 ℃to +50 ℃
Non-operation: -30 ℃to +70 ℃
Note: Direct sunlight, radiators, and other heat sources should be taken into
account when assessing the ambient temperature.
Humidity
Operating: 5% ~ 90 %RH, 30 ℃, derate to 50 %RH at 40 ℃
Non-operating: 5% ~ 95% RH
Mains supply voltage fluctuations
Refer to 2.5 Power and Ground Requirements

8 SSA5000A Quick Guide
Altitude
Operating: ≤ 3,048 m, 25 ℃
Non-operating: ≤ 12,191 m
Installation (overvoltage) Category
This product is powered by mains conforming to installation (overvoltage)
Category II.
Note: Installation (overvoltage) category I refers to situations where equipment
measurement terminals are connected to the source circuit. In these terminals,
precautions are done to limit the transient voltage to a correspondingly low
level.
Installation (overvoltage) category II refers to the local power distribution level
which applies to equipment connected to theAC line (AC power).
Degree of Pollution
The analyzers may be operated in environments of Pollution Degree II.
Note: Degree of Pollution II refers to a working environment that is dry and
non-conductive pollution occurs. Occasional temporary conductivity caused by
condensation is expected.
IP Rating
IP20 (as defined in IEC 60529).

SSA5000A Quick Guide 9
Cooling Requirements
This instrument relies on the forced air cooling with internal fans and ventilation
openings. Care must be taken to avoid restricting the airflow around the
apertures (fan holes) at each side of the analyzer. To ensure adequate
ventilation it is required to leave a 15 cm (6 inch) minimum gap around the
sides of the instrument.
CAUTION: Do not block the ventilation holes located on both sides
of the analyzer.
CAUTION: Do not allow any foreign matter to enter the analyzer
through the ventilation holes, etc.
Power and Grounding Requirements
The instrument operates with a single-phase, 100 to 240 Vrms (+/-10%) AC
power at 50/60 Hz (+/-5%), or single-phase 100 to 120 Vrms (+/-10%) AC
power at 400 Hz (+/-5%).
No manual voltage selection is required because the instrument automatically
adapts to line voltage.
Depending on the type and number of options and accessories (probes, PC
port plug-in, etc.), the instrument can consume up to 193 W of power.
Note: The instrument automatically adapts to the AC line input within the

10 SSA5000A Quick Guide
following ranges:
Voltage Range:
90 - 264 Vrms
90 - 132 Vrms
Frequency Range:
47 - 63 Hz
380 - 420 Hz
The instrument includes a grounded cord set containing a molded
three-terminal polarized plug and a standard IEC320 (Type C13) connector for
making line voltage and safety ground connection. The AC inlet ground
terminal is connected directly to the frame of the instrument. For adequate
protection against electrical shock hazards, the power cord plug must be
inserted into a mating AC outlet containing a safety ground contact. Use only
the power cord specified for this instrument and certified for the country of use.
Warning: Electrical Shock Hazard!
Any interruption of the protective conductor inside or outside of the
analyzer, or disconnection of the safety ground terminal creates a
hazardous situation. Intentional interruption is prohibited.
The position of the instrument should allow easy access to the socket. To make
the instrument completely power off, unplug the instrument power cord from
the AC socket.
The power cord should be unplugged from the AC outlet if the analyzer is not to
be used for an extended period.
CAUTION: The outer shells of the front panel terminals are
connected to the instrument’s chassis and therefore to the safety
ground.

SSA5000A Quick Guide 11
Cleaning
Clean only the exterior of the instrument, using a damp, soft cloth. Do not use
chemicals or abrasive elements. Under no circumstances allow moisture to
penetrate the instrument. To avoid electrical shock, unplug the power cord from
the AC outlet before cleaning.
Warning: Electrical Shock Hazard!
No operator serviceable parts inside. Do not remove covers.
Refer servicing to qualified personnel
Abnormal Conditions
Do not operate the analyzer if there is any visible sign of damage or has been
subjected to severe transport stresses.
If you suspect the analyzer’s protection has been impaired, disconnect the
power cord and secure the instrument against any unintended operation.
Proper use of the instrument depends on careful reading of all instructions and
labels.
Warning: Any use of the analyzer in a manner not specified by the
manufacturer may impair the instrument’s safety protection. This
instrument should not be directly connected to human subjects or
used for patient monitoring.

12 SSA5000A Quick Guide
Safety Compliance
U.S. nationally recognized testing laboratory listing
1. UL 61010-1:2012/R: 2018-11. Safety Requirements for Electrical
Equipment for Measurement, Control, and Laboratory Use –Part 1:
General Requirements.
2. UL 61010-2-030:2018. Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use –Part2-030: Particular
requirements for testing and measuring circuits.
Canadian certification
1. CAN/CSA-C22.2 No. 61010-1:2012/A1:2018-11. Safety Requirements for
Electrical Equipment for Measurement, Control, and Laboratory Use –
Part 1: General Requirements.
2. CAN/CSA-C22.2 No. 61010-2-030:2018. Safety Requirements for
Electrical Equipment for Measurement, Control, and Laboratory Use –
Part 2-030: Particular requirements for testing and measuring circuits.

SSA5000A Quick Guide 13
General Inspection
Inspect the shipping container
Keep the damaged shipping container or cushioning material until the contents
of the shipment have been completely checked and the instrument has passed
both electrical and mechanical tests.
The consigner or carrier will be responsible for damages to the instrument
resulting from shipment. SIGLENT will not provide free maintenance or
replacement.
Inspect the instrument
If the instrument is found to be damaged, defective or fails in electrical or
mechanical tests, please contact SIGLENT.
Check the accessories
Please check the accessories according to the packing list. If the accessories
are incomplete or damaged, please contact your SIGLENT sales
representative.

14 SSA5000A Quick Guide
Preparing for Use
Appearance and Dimension
Adjust the supporting legs properly to use them as stands to tilt the analyzer
upwards for stable placement as well as easier operation and observation of
the instrument display.
Connect to AC Power Supply
The analyzer accepts 100-240V, 50/60Hz or 100-120V 400Hz AC power
supply. Please use the provided power cord to connect the instrument to the
power source as shown in the figure below. Before powering on, make sure the
analyzer is protected by a fuse.
Fuse holder
The Plug

SSA5000A Quick Guide 15
Front Panel
1
2
3
4
5
Table 1 Front Panel Description
NO.
Name
Description
1
LCD
Screen
12.1 inch multi-touch screen, resolution 1280*800
2
Power
Switch
Stand by status: Orange
Power on status: White
Short press: To Stand by status with current state saved
Long press: To Stand by status without current state
saved

16 SSA5000A Quick Guide
3
Function
Keys
Function and control input panel. Most of the input
functions can be performed by the touch screen
operations.
4
USB Host
The analyzer can serve as a “host” device to connect
USB memory, USB mouse and keyboard, SIGLENT
USB-GPIB adaptor, etc.
5
RF Input
2.92 mm male connector, compatable with
2.92mm/3.5mm/SMA connector mechanically.
Use torque wrench to the male part shell wihle keep the
female part static.
CAUTION: To avoid damage to the RF input of analyzer, the DC
voltage component cannot exceed 50 V.
CAUTION: To avoid damage to the RF input of analyzer, the
maximum continuous power of the AC(RF) signal cannot exceed
+27 dBm with frequency larger than 10 MHz, and cannot exceed
+20 dBm with frequency less than 10 MHz.
CAUTION: Short the center pin and outer shield of cables to
neutralize any potential differences before connecting the cable to
any sensitive input
Use proper ESD protection when working with input connectors or
sensitive boards. Basic protection includes using a 1 MOhm
resistor-isolated ESD wrist strap and ESD minimized work surfaces.
Always use properly grounded power outlets and power cords

SSA5000A Quick Guide 17
Front Panel Function Keys
Table 2 Function keys description (For SpectrumAnalyzer Mode)
Name
Description
FREQ
Set frequency and span on the X axis
AMPTD
Set amplitude on the Y axis
Sweep
Set sweep and time
BW
Set RBW filter and VBW filter
Marker
Set the Markers and Peaks
Trace
Select Trace type, Detector and Trace operations.

18 SSA5000A Quick Guide
Peak Search
Search for the peak signal, peak search configuration
and peak table.
Trigger
Select triggers in Free Trigger, Video Trigger and
External Trigger.
Single/Cont
Shortcut for sweep control
Restart
Shortcut for sweep control
User Menu
Long press a menu and add it to the User Menu as a
quick access
Input/Output
Set the ref clock ,correction and trigger ou, etc
Mode/Meas
Selects the modes and measurement
Meas Setup
Set the modes and measurement parameters.
System
Set the system parameters and configrations.
Preset
Sets the system to certain status.
File
Use the file browser.
Help
Turn on the built-in help.
Quick Save
Save function shortcut.
Touch
Turn on/off the touch screen.
