SIGMA TEK HGW 1033 User manual

HGW 1033/-01
Wireless Handheld Operating
Panel
Technical Manual
Date of creation: 14.01.2019
Version date: 20.08.2019
Article number: 12-246-1033-E

Publisher: SIGMATEK GmbH & Co KG
A-5112 Lamprechtshausen
Tel.: [phone]
Fax: [phone]
Email: [email protected]
WWW.SIGMATEK-AUTOMATION.COM
Copyright © 2019
SIGMATEK GmbH & Co KG
Translation from German
All rights reserved. No part of this work may be reproduced, edited using an electronic system, duplicated or dis-
tributed in any form (print, photocopy, microfilm or in any other process) without the express permission.
We reserve the right to make changes in the content without notice. SIGMATEK GmbH & Co KG is not responsible for
technical or printing errors in the handbook and assumes no responsibility for damages that occur through use of
this handbook.

10.1“ HANDHELD OPERATING PANEL HGW 1033
20.08.2019 Page 1
10.1” Wireless Handheld Operating Panel HGW 1033
In combination with a BWH 001 base station and a PLC,
the HGW 1033 is a wireless, intelligent handheld operat-
ing unit that enables the programming, visualization and
diagnosis of processes and systems control.
Process data, procedures and parameters are comforta-
bly presented on the 10.1” display and can be entered or
changed via the touch screen.
The HGW 1033 can be coupled with machines via base
stations, which allows the flexible application of the oper-
ating unit.
The interfaces can be used to configure the terminal. The
integrated battery pack provides 2 hours of operation at
full capacity.
The HGW is availablein portrait and landscape for-
mat.

HGW 1033 10.1“ HANDHELD OPERATING PANEL
Page 2 20.08.2019
Contents
1Introduction............................................................................. 6
1.1 Target Group/Purpose of this Manual ........................................6
1.2 Important Reference Documentation .........................................6
1.3 Contents of Delivery.....................................................................6
2Basic Safety Guidelines......................................................... 7
2.1 Symbols Used...............................................................................7
2.2 Disclaimer......................................................................................8
2.3 General Safety Guidelines...........................................................9
2.4 Designated Use...........................................................................10
2.5 Software/Training .......................................................................10
3Residual Risks .......................................................................11
3.1 Safety of the Machine or Equipment ........................................11
3.2 Guidelines....................................................................................12
3.2.1 EU Conformity Declaration................................................................12
3.3 Wireless System Operation .......................................................12
4Technical Data .......................................................................13
4.1 Performance Data.......................................................................13
4.2 Electrical Requirements.............................................................14
4.3 Display.........................................................................................15
4.4 Input.............................................................................................15
4.5 Environmental Conditions.........................................................16

10.1“ HANDHELD OPERATING PANEL HGW 1033
20.08.2019 Page 3
4.6 Wireless .......................................................................................17
4.6.1 WLAN 2.4 GHz ................................................................................. 17
4.6.2 WLAN 5 GHz .................................................................................... 17
4.6.3 Antennae........................................................................................... 17
4.7 Miscellaneous .............................................................................18
5Mechanical Dimensions........................................................19
5.1 HGW 1033 ....................................................................................19
5.2 HGW 1033-01...............................................................................20
5.3 HGW 1033 with BWH ..................................................................21
5.4 HGW 1033-01 with BWH.............................................................22
6Interfaces ...............................................................................23
6.1 Connections Bottom...................................................................23
6.1.1 X1: USB 2.0 (Type A) ....................................................................... 23
6.1.2 X2: USB 2.0 DualRole (Type C)........................................................ 24
6.2 Rear Connectors.........................................................................25
6.2.1 X15: Power/Data............................................................................... 25
6.3 Display .........................................................................................27
6.3.1 Underside.......................................................................................... 27
6.3.2 Front ................................................................................................. 28
6.4 WLAN ...........................................................................................29
6.5 Acoustic.......................................................................................31
6.6 On/Off Button (illuminated)........................................................32
7Status and Error Messages..................................................33

HGW 1033 10.1“ HANDHELD OPERATING PANEL
Page 4 20.08.2019
8Transport/Storage..................................................................41
9Assembly/Installation............................................................42
9.1 Check List....................................................................................42
9.1.1 Check Contents of Delivery...............................................................42
9.2 Preparing the Hardware .............................................................42
10 Operation/Start-up.................................................................43
10.1 Battery/Power Supply.................................................................44
10.2 Configuration ..............................................................................44
10.3 Testing the Operating Area........................................................45
10.4 Operation.....................................................................................46
10.4.1 General..............................................................................................46
10.4.2 Turning On.........................................................................................47
10.4.3 Non-Safety Mode...............................................................................47
10.4.4 Turning Off.........................................................................................47
11 Storage ...................................................................................48
12 Help with Disruptions/Troubleshooting...............................49
13 Maintenance...........................................................................50
13.1 Cleaning the Touch Screen .......................................................50
13.2 Maintenance................................................................................51
13.2.1 Calibrating the Touch Screen............................................................51
13.3 Repair...........................................................................................51

10.1“ HANDHELD OPERATING PANEL HGW 1033
20.08.2019 Page 5
14 Disposal .................................................................................52
15 Accessories...........................................................................53
15.1 Antennae......................................................................................53
15.2 Touch Pen....................................................................................53
15.3 Edge Protection ..........................................................................53
16 Application Information........................................................54
16.1 Visualization................................................................................54
16.1.1 Application Example ......................................................................... 54
16.2 Updates........................................................................................55

HGW 1033 10.1“ HANDHELD OPERATING PANEL
Page 6 20.08.2019
1 Introduction
1.1 Target Group/Purpose of this Manual
This manual contains all information required for operating the HGW 1033.
This manual is intended for:
•Project planners
•Technicians
•Configurators/commissioning engineers
•Machine operators
•Maintenance/test technicians
General knowledge of automation technology in systems is required.
Further help and training information, as well as the appropriate accessories can be found on
our website www.sigmatek-automation.com
Our support team is happily available to answer your questions.
For our support hotline and business hours, please visit our website.
1.2 Important Reference Documentation
•HGW 1033-X_Maintantance Manual
•HGW_BWH_Configuration Manual
•WLAN Configuration
These documents can be downloaded from our website or obtained through Support.
1.3 Contents of Delivery
1x HGW 1033/-01
This document can be downloaded from our website.
Additional documents may be included with delivery.

10.1“ HANDHELD OPERATING PANEL HGW 1033
20.08.2019 Page 7
2 Basic Safety Guidelines
2.1 Symbols Used
The following symbols are used in the operator documentation for warning and danger mes-
sages, as well as informational notes:
DANGER
Identifies an immediate danger with high risk, which will lead to immediate
death or serious injury if not avoided.
Identifie un danger immédiat avec un risque élevé, entraînant le décès im-
médiat ou des blessures graves s’il n’est pas évité
WARNING
Identifies a possible danger with a mid-level risk, which can lead to death or
(serious) injury if not avoided.
Indique un danger possible d’un risque moyen de décès ou de (graves)
blessures si les consignes de sécurité ne sont pas respectées
CAUTION
Identifies a low risk danger, which can lead to injury or property damage if
not avoided.
Indique un danger avec un niveau de risque faible des blessures légères ou
des dommages matériels si les consignes de sécurité ne sontpas respectées
Warning, dangerous electrical voltage.
Attention, tension électrique dangereuse.
Provides user tips, informs of special features and identifies especially im-
portant information in the text.
Fournit des conseils d’utilisation, informe sur les fonctions particulaires et
souligne les informations particulièrement importantes dans le texte.
Danger for ESD-sensitive components.
Les signes de danger pour les composants sensibles aux décharges élec-
trostatiques.

HGW 1033 10.1“ HANDHELD OPERATING PANEL
Page 8 20.08.2019
2.2 Disclaimer
The contents of this document were prepared with the greatest care. How-
ever, deviations cannot be ruled out. This document is regularly checked and
required corrections are included in the subsequent versions. The machine
manufacturer is responsible for the proper assembly, as well as device con-
figuration. The machine operator is responsible for safe handling, as well as
proper operation.
The current document can be found on our website. If necessary, contact our
support.
Subject to technical changes,which improve the performance of the devices.
The following documentation is purely aproduct description. It does notguar-
antee properties under the warranty.
Please thoroughly read the corresponding data sheets, operating instructions
and this system handbook before handling a product.
SIGMATEK GmbH & Co KG is not liable for damages caused through
non-compliance with these instructions or applicable regulations.
The general and special safety instructions described in the following sec-
tions, as well as technical regulations, must therefore be observed.

10.1“ HANDHELD OPERATING PANEL HGW 1033
20.08.2019 Page 9
2.3 General Safety Guidelines
According to EU Guidelines, the operating instructions are a component of a
product.
This manual must therefore be accessible in the vicinity of the machine since
it contains important instructions.
This technical documentation should beincluded in the sale, rental or transfer
of the product, or its online availability indicated.
Maintain this manual in readable condition and keep it accessible for refer-
ence.
This device contains a Li-Ion battery. For this reason, we refer you to the
manufacturer’s specification (battery safety data sheet). This can be found
on our website.
Regarding the requirements for Safety and health connected to the use of
machines, the manufacturer must perform a risk assessment in accordance
with machine guidelines 2006/42/EG before introducing a machine to the
market.
Before commissioning this product, check that conformance with the provi-
sions of the 2006/42/EG guidelines is correct. As long as the machine with
which the with the HGW or BWH should be used does not comply with the
guideline, operating this product is prohibited.
Operate the unit with devices and accessories approved by SIGMATEK only.
CAUTION
Handle the device with care and do not drop or let fall.
Prevent foreign bodies and fluids from entering the device.
The device must not be opened, otherwise it could be damaged!
Manipulez l’appareil avec précaution et ne le laissez pas tomber.
Empêchez les corps étrangers et les liquides de pénétrer dans l’appareil.
L’appareil ne doit pas être ouvert, sinon il risque d’être endommagé!
Regularly check the housing for mechanical damage.
Vérifier régulièrement l’absence de dommages mécaniques sur le boîtier

HGW 1033 10.1“ HANDHELD OPERATING PANEL
Page 10 20.08.2019
2.4 Designated Use
CAUTION
In addition, the Safety Guidelines in the other sections of these instructions
must be observed. These instructions are visually emphasized by symbols.
The module complies with EN 61131-2.
In combination with a machine, the machine builder must comply with EN
60204-1 standards.
For your own safety and that of others, compliance with the environmental
conditions is essential.
The control cabinet must be connected to ground correctly.
To perform maintenance or repairs, disconnect the system from the power
supply.
En outre, les consignes de sécurité mentionnées dans d’autres sections de
ce manuel doivent être respectées. Ces directives sont indiquées avec les
symboles graphiques.
Le module est conforme à la norme EN 61131-2.
En combinaison avec une machine, le constructeur de la machine doit re-
specter la norme EN 60204-1.
L’armoire de commande doit être raccordée correctement à la terre.
Pour l’entretien et les réparations, débranchez le système de l’alimentation.
Before delivering the module, the machine manufacturer must ensure that it
is in “delivery condition”. See chapter 8 for more information.
Hardware and software features (application-specific data) can be found in
chapter 16 Application Information.
2.5 Software/Training
The application is created with the software LASAL Class 2 and LASAL Screen Editor.
Training for the LASAL development environment, with which the HGW can be configured, is
provided. Information on our training schedule is available on our website.

10.1“ HANDHELD OPERATING PANEL HGW 1033
20.08.2019 Page 11
3 Residual Risks
CAUTION
According to the EU guideline 2006/42/EG (machine guideline), the machine
manufacturer must perform a risk assessment, which includes the possible
residual risks posed by the product. These include:
•unwanted movements of driven machine components
•unwanted temperatures, emissions of gas, particles, smell and light.
•dangerous contact voltages
•the effects of electrical, magnetic and electromagnetic fields pro-
duced during operation (for example, on pacemakers and implants)
•possible effects of information technology devices (cell/smart
phones etc.)
•release of non-environmentally compatible substances and emis-
sions
Conformément à la directive européenne 2006/42/CE (directive machines),
le fabricant de la machine doit procéder àune évaluation des risques, y com-
pris les risques résiduels éventuels présentés par le produit. Il s’agit notam-
ment de:
•Mouvements involontaires des pièces entraînées de la machine.
•Températures non désirées, les émissions de gaz, les particules,
l’odeur et la lumière.
•Tensions de contact dangereuses
•Les effets des champs électriques, magnétiques et électro-
magnétiques produites pendant le fonctionnement (par exemple,
sur les stimulateurs cardiaques et les implants).
•Les effets possibles sur les dispositifs de technologie de l’infor-
mation (téléphones cellulaires / téléphones intelligents, etc.)
•Dégagement de substances et d’émissions non respectueuses de
l’environnement.
3.1 Safety of the Machine or Equipment
Strict compliance with the safety guidelines is required, otherwise all warranties and claims
are invalid.
Observe all on-site rules and regulations for accident prevention and occu-
pational safety.

HGW 1033 10.1“ HANDHELD OPERATING PANEL
Page 12 20.08.2019
3.2 Guidelines
The device was constructed in compliance with European Union guidelines.
3.2.1 EU Conformity Declaration
CE Declaration of Conformity
The HGW 1033/-01 conforms to the following European guidelines:
•2006/42/EG “Directive of the European Parliament and of the Coun-
cil of 17 May 2006 on Machinery and Change to the Directive
95/16/EC” (machine guideline)
•2014/30/EU “Electromagnetic Compatibility” (EMC guideline)
•2014/53/EU “Directive of the European Parliament and of the Coun-
cil of 16 April 2014 on the harmonization of the laws of the Member
States relating to the provision of wireless equipment on the market
and repealing Directive 1999/5/EC” (wireless device guideline)
•2011/65/EU “Restricted use of certain hazardous substances in
electrical and electronic equipment” (RoHS Guideline)
The EU Conformity Declarations are provided on the SIGMATEK website.
See Products/Downloads or use the search function and the keyword “EU
Declaration of Conformity”.
3.3 Wireless System Operation
CAUTION
Technical changes to the device (such as different antennae), as well as im-
proper use can lead to the loss of the FCC license and generate interference,
which can affect the function of nearby devices.
Please note the national standardization when operating the wireless device!
Les changements techniques apportés à l’appareil (comme les différentes
antennes), ainsi qu’une utilisation incorrecte peuvent entraîner la perte de la
licence FCC et générer des interférences, ce qui peut affecter le fonctionne-
ment des appareils voisins.
Lors de l’utilisation de l’appareil sans fil, veuillez respecter les normes natio-
nales en vigueur!

10.1“ HANDHELD OPERATING PANEL HGW 1033
20.08.2019 Page 13
4 Technical Data
4.1 Performance Data
Processor
EDGE2 Technology
Processor cores
2
Internal cache
32-kbyte L1 Instruction Cache
32-kbyte L1 Data Cache
512-Kbyte L2 Cache
Internal program and
data memory (DDR3 RAM)
2048 Mbytes
Internal remnant
data memory
512-kbyte MRAM
Internal storage device
512-Mbyte microSD card, expandable*
Internal I/O
no
Battery
3780 mAh (minimum) Lithium-Ion
Runtime: >2 h continuous operation with new battery
Charge/status display via the on/off button
Charging time
3 h via USB-C as well as base station at 25 °C
with a rising temperature and active use of the device, the charge time may
increase
Interfaces
1x USB 2.0 Type-A (Host)
1x USB 2.0 Type-C (Dual Role Port, charging)
1x WLAN dual-band (2.4 GHz, 5 GHz simultaneously)
Internal interface connections and
devices
1x TFT color display
1x USB (touch connection)
Control Elements
Touch screen (multi-touch, projective capacitive)
1x illuminated on/off button (with application interface)
Display
Resolution
10.1” TFT color display, 16:10,
WXGA 800 x 1280 pixels, portrait mode
WXGA 1200 x 800 pixels, landscape mode
Status LEDs
2x front (controllable via application)
1x rear (boot status/controllable via the application)
1x power switch (shows power and charge status)
Signal generator
yes (at least 83 dB at 30 cm)

HGW 1033 10.1“ HANDHELD OPERATING PANEL
Page 14 20.08.2019
Real-time clock
yes (buffered circa 3 days via internal battery)
Temperature sensors
4 (2x LP, 1x CPU, 1x battery)
Cooling
passive (fanless)
Input voltage measurement
yes
(*) For safety reasons, the device may only be expanded by trained personnel.
4.2 Electrical Requirements
Charging voltage
magnetic connector
typically +19 V DC
minimum +15 V DC
maximum +24 V
Charging current
via base station: up to 2.5 A at 15.5 V
USB Host current load
maximum 0.5 A
The specified charging time applies to the charging process when the panel
is not simultaneously in use. If the device is in use while charging, the charg-
ing time can increase.
To protect the battery, the intelligent charging circuit monitors the ambient
temperature. For this reason, the charging time can be extended at high am-
bient temperatures.
The specified current consumption applies to the status without connected
peripherals (USB stick ...)

10.1“ HANDHELD OPERATING PANEL HGW 1033
20.08.2019 Page 15
4.3 Display
Type
10.1” TFT LCD color display
Active range
135.6 (V) x 216.96 (H) mm
Resolution
WXGA 800 x 1280 pixels
Color depth
18-bit RGB (16.7 million colors)
LCD mode
normal black
LCD Polarizer
transmissive
Pixel size
0.1695 x 0.1695 mm
Backlighting
LED, adjustable
Contrast
typically 800: 1
Brightness
typically 300 cd/m²
Angle CR ≥ 10
85° from all sides
4.4 Input
Input
Multi-touch screen (PCAP)
On/off button
1

HGW 1033 10.1“ HANDHELD OPERATING PANEL
Page 16 20.08.2019
4.5 Environmental Conditions
Storage temperature
-5 … +60 °C (in transport mode)
Environmental temperature, dis-
charging
0 ... +50 °C
Environmental temperature charg-
ing
0 ... +40 °C
Humidity
10-95 %, non-condensing
Installation altitude above sea
level
0-2000 m without derating,
> 2000 m up to a maximum of 5000 m with derating of the maximum envi-
ronment temperature by 0.5 °C per 100 m
Operating conditions
pollution degree 2
EMC resistance
EN 61000-6-2:2007 (industrial area)
(increased requirements according to IEC/EN 62061)
EMC noise generation
EN 60068-2-6
Shock resistance
EN 60068-2-27
150 m/s²
Vibration resistance
10 m/s²
Protection type
EN 60529
IP54
(with USB cover only)
Free fall
(with rough handling)
DIN EN 60068-2-31
1000 mm
Free fall
(with packaging)
IEC 60068-2-32
500 mm
The HGW has an intelligent charging circuit, which ensures optimal charging
of the integrated battery pack. For this reason, the HGW can remain docked
to the base station.
The HGW is delivered with a partially charged battery and should be com-
pletely charged by the customer before use.
With a 30 % charge, the device can be stored in transport mode for 6 months
at 25 °C.
After 6 months, the battery must be recharged to avoid damage to the bat-
tery.

10.1“ HANDHELD OPERATING PANEL HGW 1033
20.08.2019 Page 17
4.6 Wireless
4.6.1 WLAN 2.4 GHz
Frequency range
2399.5-2484.5 MHz
Transmission power max.
20 dBm (100 mW) EIRP
Channels
1-14 (2412-2483.5 MHz)
4.6.2 WLAN 5 GHz
Frequency range
5150-5350 MHz
5470-5725 MHz
Transmission power max.
23 dBm (200 mW) EIRP
Channels
36-64 (5180-5320 MHz)
100-140 (5500-5700 MHz)
4.6.3 Antennae
Number
2
Frequency range
2.4/5 GHz (Dual-Band)
Transmission power max.
25 W
Antenna gain
2.4 GHz-4 dBi Peak Gain
5 GHz-5.2 dBi Peak Gain
Impedance
50 Ω
Transmission angle/characteristic
Transmission characteristic: omnidirectional
Polarization: linear
The panels can only be used in the country designated or configured for this
purpose, as the maximum permitted transmission power, aswell as approved
channels can greatly differ.
Non-compliance with these specifications can result in legal consequences,
for which SIGMATEK accepts no liability!
Already during the planning stage, caution must be taken to ensure that the
radio channels are configured so that interference with other products is pre-
vented.

HGW 1033 10.1“ HANDHELD OPERATING PANEL
Page 18 20.08.2019
CAUTION
Only antennae approved by SIGMATEK can be used. See chapters 15.1.
Seules les antennes recommandées par SIGMATEK peuvent être utilisées.
Voir chapitre 15.1.
Regularly check the screw fitting for the antennae. If necessary, manually
tighten them or use a torque wrench (1 Nm) for SMA connectors.
Vérifiez régulièrement le vissage des antennes. Si nécessaire, serrez-les
manuellement ou utilisez une clé dynamométrique (1 Nm) pour les connec-
teurs SMA.
4.7 Miscellaneous
Article number
12-246-1033 (portrait format)
12-246-1033-01 (landscape format)
Hardware version
1.x
Operating system
Salamander
Approvals
CE
