SIGMA TEK ETT 2144-W User manual

ETT 2144-W
Build-in Touch Terminal
Operating Manual
Date of creation: 16.07.2020
Version date: 09.04.2021
Article number: 01-230-2144-WE

Publisher: SIGMATEK GmbH & Co KG
A-5112 Lamprechtshausen
Tel.: [phone]
Fax: [phone]
Email: [email protected]
WWW.SIGMATEK-AUTOMATION.COM
Copyright © 2020
SIGMATEK GmbH & Co KG
Translation from German
All rights reserved. No part of this work may be reproduced, edited using an electronic system, duplicated or dis-
tributed in any form (print, photocopy, microfilm or in any other process) without express permission.
We reserve the right to make changes in the content without notice. SIGMATEK GmbH & Co KG is not responsible
for technical or printing errors in this handbook and assumes no responsibility for damages that occur through its
use.

BUILD-IN TOUCH TERMINAL ETT 2144-W
09.04.2021 Page 1
Build-in Touch Terminal ETT 2144-W
The ETT 2144-W is an intelligent panel for visualizing, operating and monitoring automated
processes.
A capacitive touch screen serves as the input medium for process data and parameters. The
output is shown on a 21.5" TFT color display.
Via the high-performance processor, complex HTML5 applications can be displayed without
problems.
The available interfaces can be used to exchange process data or configure the multi-touch
terminal. An M.2 SSD serves as the storage medium for the operating system, application
and application data.

ETT 2144-W BUILD-IN TOUCH TERMINAL
Page 2 09.04.2021
Contents
1Introduction............................................................................. 5
1.1 Target Group/Purpose of this Operating Manual ......................5
1.2 Important Reference Documentation .........................................5
1.3 Contents of Delivery.....................................................................5
2Basic Safety Guidelines......................................................... 6
2.1 Symbols Used...............................................................................6
2.2 Disclaimer......................................................................................8
2.3 General Safety Guidelines...........................................................9
3Norms and Guidelines...........................................................10
3.1 Guidelines....................................................................................10
3.1.1 EU Declaration of Conformity............................................................10
4Technical Data .......................................................................11
4.1 Performance Data.......................................................................11
4.2 Electrical Requirements.............................................................12
4.3 Display.........................................................................................13
4.4 Control Unit.................................................................................13
4.5 Minimum Distance between Operating Elements for Multi-
touch Applications .....................................................................14
4.6 Environmental Conditions.........................................................15
4.7 Miscellaneous .............................................................................15
5Mechanical Dimensions........................................................16

BUILD-IN TOUCH TERMINAL ETT 2144-W
09.04.2021 Page 3
6Interfaces ...............................................................................17
6.1 Connections Bottom...................................................................17
6.1.1 X1: Supply (4-pin Phoenix RM 3.5)................................................... 17
6.2 Left Side Connectors..................................................................18
6.2.1 X2: DisplayPort Output V1.2a........................................................... 18
6.2.2 X3, X4: Ethernet 1, 2 10/100/1000 (RJ45)........................................ 19
6.2.3 X5-X8: USB 2.0 (Type A).................................................................. 19
6.3 Applicable Connectors...............................................................19
7Display ...................................................................................20
7.1 Status LEDs Front.......................................................................20
8Transport/Storage.................................................................21
9Assembly/Installation ...........................................................22
9.1 Check Contents of Delivery.......................................................22
9.2Installation...................................................................................22
9.3 Restricted Space Around Rear Trimming ................................23
9.4 Required Cutout for Mounting the Terminal............................24
9.5 Mounting Position.......................................................................25
10 Wiring.....................................................................................26
10.1 Ground.........................................................................................26
10.2 Shielding......................................................................................27
10.3 ESD Protection............................................................................27
10.4 USB Interface Connections .......................................................27

ETT 2144-W BUILD-IN TOUCH TERMINAL
Page 4 09.04.2021
11 Display “Burn-In” Effect........................................................28
12 Buffer Battery.........................................................................29
12.1 Exchanging the Battery..............................................................30
13 Maintenance...........................................................................31
13.1 Cleaning the Touch Screen .......................................................31
13.2 Service.........................................................................................32
13.2.1 Calibrating the Touch Screen............................................................32
13.3 Repair...........................................................................................32
14 Modularity...............................................................................33
14.1 Removing the PIM from the Touch Panel.................................34
14.2 Mounting the PIM onto the Touch Panel..................................35
15 Disposal..................................................................................36
16 Accessories............................................................................37
16.1 Battery..........................................................................................37

BUILD-IN TOUCH TERMINAL ETT 2144-W
09.04.2021 Page 5
1 Introduction
1.1 Target Group/Purpose of this Operating Manual
This operating manual contains all information required to operate this product.
This operating manual is intended for:
•Project planners
•Technicians
•Commissioning engineers
•Machine operators
•Maintenance/test technicians
General knowledge of automation technology is required.
Further help and training information, as well as the appropriate accessories can be found on
our website www.sigmatek-automation.com.
Our support team is also happily available to answer your questions.
Please see our website for our hotline number and business hours.
1.2 Important Reference Documentation
•PIM 041-W
•TP 2161
This and additional documents can be downloaded from our website or obtained through
SIGMATEK Support.
1.3 Contents of Delivery
ETT 2144-W
14x angle bracket
1x 4-pin Phoenix connector plug

ETT 2144-W BUILD-IN TOUCH TERMINAL
Page 6 09.04.2021
2 Basic Safety Guidelines
2.1 Symbols Used
The following symbols are used in the operator documentation for warning and danger mes-
sages, as well as informational notes:
DANGER
Danger indicates that death or serious injury will occur, if the specified
measures are not taken.
To avoid death or serious injuries, observe the all guidelines.
Danger indique une situation dangereuse qui, faute de prendre les
mesures adéquates, entraînera des blessures graves, voire mortelles.
Respectez toutes les consignes pour éviter des blessures graves,
voire mortelles.
WARNING
Warning indicates that death or serious injury can occur, if the specified
measures are not taken.
To avoid death or serious injuries, observe the all guidelines.
Avertissement d’une situation dangereuse qui, faute de prendre les
mesures adéquates, entraînera des blessures graves, voire mortelles.
Respectez toutes les consignes pour éviter des blessures graves,
voire mortelles.
CAUTION
Caution indicates that moderate to slight injury can occur, if the specified
measures are not taken.
To avoid moderate to slight injuries, observe the all guidelines.
Attention indique une situation dangereuse qui, faute de prendre les
mesures adéquates, peut entraîner des blessures assez graves ou lé-
gères.
Respectez toutes les consignes pour éviter des blessures graves,
voire mortelles.
INFORMATION
Provides important information on the product, handling or relevant sections
of the documentation, which require attention.
Fournit des recommendations importantes sur le produit, la manipulation ou
sections relevantes de la documentation, qui nécessitent prêter une attention
particulière.

BUILD-IN TOUCH TERMINAL ETT 2144-W
09.04.2021 Page 7
Danger for ESD-sensitive components.
Les signes de danger pour les composants sensibles aux décharges élec-
trostatiques.

ETT 2144-W BUILD-IN TOUCH TERMINAL
Page 8 09.04.2021
2.2 Disclaimer
The contents of this operating manual were prepared with the greatest care.
However, deviations cannot be ruled out. This operating manual is regularly
checked and required corrections are included in the subsequent versions.
The machine manufacturer is responsible for the proper assembly, as well
as device configuration. The machine operator is responsible for safe han-
dling, as well as proper operation.
The current operating manual can be found on our website. If necessary,
contact our support.
Subject to technical changes,which improve the performance of the devices.
The following operating manual is purely a product description. It does not
guarantee properties under the warranty.
Please thoroughly read the corresponding documentation and this operating
manual before handling a product.
SIGMATEK GmbH & Co KG is not liable for damages caused through
non-compliance with these instructions or applicable regulations.

BUILD-IN TOUCH TERMINAL ETT 2144-W
09.04.2021 Page 9
2.3 General Safety Guidelines
The Safety Guidelines in the other sections of this operating manual must be observed.
These instructions are visually emphasized by symbols.
According to EU Guidelines, the operating instructions are a component of a
product.
This operating manual must therefore be accessible in the vicinity of the ma-
chine since it contains important instructions.
This operating manual should be included in the sale, rental or transfer of the
product, or its online availability indicated.
Maintain this operating manual in readable condition and keep it accessible
for reference.
Regarding the requirements for Safety and health connected to the use of
machines, the manufacturer must perform a risk assessment in accordance
with machine guidelines 2006/42/EG before introducing a machine to the
market.
Before commissioning this product, check that conformance with the provi-
sions of the 2006/42/EG guidelines is correct. As long as the machine with
which the with the product should be used does not comply with the guide-
line, operating this product is prohibited.
Operate the unit with devices and accessories approved by SIGMATEK only.
CAUTION
Handle the device with care and do not drop or let fall.
Prevent foreign bodies and fluids from entering the device.
The device must not be opened, otherwise it could be damaged!
The module complies with EN 61131-2.
In combination with a machine, the machine builder must comply with EN
60204-1 standards.
For your own safety and that of others, compliance with the environmental
conditions is essential.
The control cabinet must be connected to ground correctly.
To perform maintenance or repairs, disconnect the system from the power
supply.

ETT 2144-W BUILD-IN TOUCH TERMINAL
Page 10 09.04.2021
3 Norms and Guidelines
3.1 Guidelines
The product was constructed in compliance with the following European Union guidelines
and tested for conformity.
3.1.1 EU Declaration of Conformity
EU Declaration of Conformity
The product ETT 2144-W conforms to the following European guidelines:
•2014/35/EU Low-voltage guideline
•2014/30/EU “Electromagnetic Compatibility” (EMC guideline)
•2011/65/EU “Restricted use of certain hazardous substances in
electrical and electronic equipment” (RoHS Guideline)
The EU Conformity Declarations are provided on the SIGMATEK website.
See: Products/downloads or use the search function and keyword “EU Dec-
laration of Conformity”.

BUILD-IN TOUCH TERMINAL ETT 2144-W
09.04.2021 Page 11
4 Technical Data
4.1 Performance Data
Processor
Intel® Celeron® J4005
Processor cores
2 (#)
Processor clock
2.0-2.7 GHz
Internal cache
4 Mbytes
Internal program and data
memory (RAM)
2-Gbyte DDR4 (SODIMM)
Graphics
Intel® UHD Graphics 600
Hard drive
64-Gbyte SATA M.2 SSD
Interfaces
4x USB 2.0 (Type A)
1x DisplayPort output V1.2a (max. 1920 x 1200 px at 60 Hz)
2x Ethernet (Gbit)
Default IP address
Intel Ethernet (X3)
Realtek Ethernet (X4)
automatic (DHCP)
automatic (DHCP)
Internal interfaces
1x Panel Interface Connector
Signal generator
no
Display
Resolution
21.5“ TFT color display
Full HD 1920 x 1080 pixels
Operating panel
touch screen (projective capacitive)
Status LEDs
1x red, 1x green
Real-time clock
yes
Cooling
passive (fanless)
(#) Attention: When programming (with LASAL) on multicore CPUs, particular focus must be placed on thread security!

ETT 2144-W BUILD-IN TOUCH TERMINAL
Page 12 09.04.2021
4.2 Electrical Requirements
Supply voltage
+24 V DC ±20 % (SELV/PELV)
UL Class 2 or LVLC(1)
Current consumption of (+24 V)
power supply
typically 1500 mA
(without externally connected de-
vices)
maximum 2000 mA
(with external devices connected)
Inrush current with 24 V/10 A
fixed voltage supply
maximum 2.2 A (for 1.8 ms, load-dependent)
Inrush current without current-
limiting supply
maximum 3.5 A (for 6 µs, load-dependent)
(1) For USA and Canada:
The supply must be limited to:
a) max. 5 A at voltages from 0-20 V DC, or
b) 100 W at voltages from 20-60 V DC.
The limiting component (e.g. transformer, power supply or fuse) must be certified by an
NRTL (Nationally Recognized Testing Laboratory).

BUILD-IN TOUCH TERMINAL ETT 2144-W
09.04.2021 Page 13
4.3 Display
Type
21.5” TN color display
Resolution
FullHD 1920 x 1080 pixels
Color depth
24-bit RGB
LCD mode
normally black (1)
LCD Polarizer
transmissive (2)
Pixel size
0.248 x 0.248 mm
Active surface
476.64 x 268.11
Backlighting
LED
Contrast ratio
typically 5000:1
Brightness
typically 300 cd/m²
Angle CR ≥ 10
left, right, top, bottom typically 89°
Life span
by compliance with the ambient conditions, the brightness of the display
sinks after 50,000 operating hours to 50 % of the original brightness
(1) If no display data is available, the display remains black when the backlighting is on.
(2) Display technology, with which display backlighting is used.
Due to the manufacturing process, individual pixel errors cannot be excluded to 100% and therefore do not
constitute a reduction in quality.
4.4 Control Unit
Touch panel
projective capacitive touch panel
Cleaning
see chapter 13.1.
A projective capacitive touch screen is built into the panel, with which 10-
finger input, Zoom and gesture functions can be implemented.
Data can be input using fingers, a project capacitive touch pen as well as
with thin gloves. The device must always be grounded to ensure stable func-
tion of the touch screen. The touch function may still have to be individually
adapted to the respective environmental conditions.

ETT 2144-W BUILD-IN TOUCH TERMINAL
Page 14 09.04.2021
4.5 Minimum Distance between Operating Elements for Multi-touch Appli-
cations
To guarantee smooth operation with multitouch applications, buttons and control elements
that should be operated at the same time must have the minimum clearance shown below
(depending on the estimated touch point).
The size of the buttons and operating elements directly affect the operability
of the application. Small operating elements should therefore be avoided.

BUILD-IN TOUCH TERMINAL ETT 2144-W
09.04.2021 Page 15
4.6 Environmental Conditions
Storage temperature
-10 ... +70 °C
Environmental temperature
0 ... +50 °C
Humidity
10-95 %, non-condensing
Installation altitude above sea
level
0-2000 m without derating
> 2000 m with derating of the maximum environment temperature by 0.5 °C
per 100 m
Operating conditions
pollution degree 2
EMC resistance
in accordance with EN 61000-6-2 (industrial area)
EMC noise generation
in accordance with EN 61000-6-4 (industrial area)
Vibration resistance
EN 60068-2-6
5-200 Hz: amplitude 3.5 mm
Transition frequency: 8.42454 Hz
acceleration: 1 g
duration: 10 cycles
cycle: 1 octave/minute
Shock resistance
EN 60068-2-27
15 g (147.15 m/s²)
Protection type
EN 60529
protected through the housing
front: IP65 (1)
cover IP20 (1)
(1) IP housing protection type was tested for Europe and is not part of a UL-certification for the device
4.7 Miscellaneous
Article number
01-230-2144-W
Hardware version
1.x
Operating system
Windows 10 IOT
Approvals
CE;
ETT 2144-W consists of a TP 2161 (CULUS (E247993)) and
a PIM 041-W (designed according to UL)

ETT 2144-W BUILD-IN TOUCH TERMINAL
Page 16 09.04.2021
5 Mechanical Dimensions
Dimensions
539 x 331 x 90 mm (W x H x D)
Material
front plate: 2.8 mm glass (touch screen) in black anodized aluminum frame
housing: sheet steel
heat sink: anodized aluminum
Weight
6.5 kg

BUILD-IN TOUCH TERMINAL ETT 2144-W
09.04.2021 Page 17
6 Interfaces
6.1 Connections Bottom
Symbol Image ETT 1544
6.1.1 X1: Supply (4-pin Phoenix RM 3.5)
Pin
Function
1
+24 V DC
2
+24 V DC
3
GND
4
GND

ETT 2144-W BUILD-IN TOUCH TERMINAL
Page 18 09.04.2021
6.2 Left Side Connectors
Symbol Image ETT 1544
6.2.1 X2: DisplayPort Output V1.2a
Pin
Function
1
Lane 0 (p)
2
GND
3
Lane 0 (n)
4
Lane 1 (p)
5
GND
6
Lane 1 (n)
7
Lane 2 (p)
8
GND
9
Lane 2 (n)
10
Lane 3 (p)
11
GND
12
Lane 3 (n)
13
Config1
14
Config2
15
AUX CH (p)
16
GND
17
AUX CH (n)
18
Hot Plug
19
Return
20
DP_VCC_3V3
