Sigma BM60 DT User manual

Via Artigianato 85 – 25030 Torbole Casaglia (BRESCIA) ITALY – Tel. [phone] – Fax [phone]
INSTRUCTION BOOK
PLANETARY MIXER
BM60/80/100 DT
www.gk-nhl.ru
8(831) 273-97-50

CONTENTS
EXPLODED VIEW BM60-BM80-BM100 DT
Table 1
LIFTING BOWL GROUP
www.gk-nhl.ru
8(831) 273-97-50

EXPLODED VIEW BM60-BM80-BM100 DT
Table 2
www.gk-nhl.ru
8(831) 273-97-50

SPARE PARTS LIST FOR PLANETARY MIXER BM60-BM80-BM100 DT
N° RIF. N° CODE DESCRIPTION QUANTITY
01 25009096 START button + code 25009093 + 25009094 1
02 25009094 Lift/Descent push button + 25009093 + 25009043 2
03 25007039 Timer + Knob 25007038 1
04 13000319 Ball bearing 6208 2RS 40-80-18 3
05 13000317 Ball bearing 6206 2RS 30-62-16 3
06 01101022 Planetary shaft for reducer 1
07 01101073 Variator belt 41,5x12x1419 1
08 13000326 Ball bearing 6305 2RS 25-62-17 2
09 01101017 Return shaft 60 Hz 1
01101070 Return shaft 50 Hz 1
10 01101016 Drive pulley 1
11 01101013 Variable half pulley 2
12 01101012 Variable pulley shaft 1
13 01101083 Variator spring upper cover 1
14 01101084 Variator spring lower cover 1
15 08101014 Variable pulley spring 2
16 08000001 Shock absorber 588434 700N 1
17 03101057 Upper cover 1
18 11001301 Motor G100 4P 2,2 Kw 230-400V/3 B5R (BM60DT) 1
11001302 Motor G100 4P 3 Kw 230-400V/3 B5R (BM80DT) 1
11001302 Motor G100 4P 3 Kw 230-400V/3 B5R (BM100DT) 1
19 14002822 Small foot M16 98/6364 1
20 25001301 Microswitch + lever 25001302 2
21 01095028 Round microswitch 1
22 01098108 Bowl blocking handle 2
23 01101019 Planetary 1
24 04101120 Bowl BM60 DT 1
04101156 Bowl BM80 DT 1
04101212 Bowl BM100 DT 1
25 01101148 Sleeve 1
26 05101160 Protection grid 1
27 01101149 Anti-unlocking ring 1
28 01101080 Tool shaft 1
29 13000311 Ball bearing 6200 2RS 10-30-09 4
30 01101077 Toothed crown for planetary 50 Hz 1
01101079 Toothed crown for planetary 60 Hz 1
31 01101020 Planetary pinion 1
32 01101018 Toothed crown 1
33 25009027 Net Lamp 1
34 25009097 STOP button + code 25009093 + 25009047 1
35 01101043 Bowl supporting arm 1
36 13000016 Ball bearing 6205 2RS 25-52-15 2
37 01101100 Bowl lifting screw 1
38 11000501 Motor G71 4P 0,55 Kw 400V/3 50Hz B14 1
39 01106025 Motor pulley Q18 1
40 12003301 Toothed belt SPZ 512 2
www.gk-nhl.ru
8(831) 273-97-50

41 01101095 Lifting bowl pulley 1
42 01101096 Bowl lifting screw nut 1
43 13000315 Ball bearing 6204 2RS 20-47-17 1
44 01097047 Bevel gear pair for reducer 1
45 01101023 Bevel gear for reducer 1
46 01101009 Motor chair bars 2
47 01101181 Rack pole 1
48 01101040 Speed selecting lever 1
49 14002203 Knob 40M8 PB /41 1
50 01098041 Closure cover 1
51 01101179 Speed pin 1
52 08098055 Handle spring 1
53 01095065 Speed lever support 1
54 01101036 Toothed wheel 1
55 01095008 Motor chair 1
56 02047046 Micro square 1
57 01101066 Bowl blocking tube 1
58 25005120 Remote control switch LC1K0901B7 1
59 25005123 Remote control switch LC1K0601B7 2
60 25008006 Transformer 25VA 0/230/440 – 0/24 1
61 25001320 Microswitch MV15 1
62 01101044 Bowl lifting bars 2
63 01101076 HUDSON – MESA shaft 1
64 01097078 Reducer support HUDSON – MESA 1
65 31000001 Closure handwheel HUDSON – MESA 1
66 01097079 Closure cap 1
LIST OF RECOMMENDED SPARE PARTS FOR BM60-BM80-
BM100DT
(2 YEARS OPERATION)
N° RIF. N° CODE DESCRIPTION QUANTITY
01 25009096 START button + code 25009093 + 25009094 1
02 25009094 Lift/Descent push button + 25009093 + 25009043 2
03 25007039 Timer + Knob 25007038 1
04 13000319 Ball bearing 6208 2RS 40-80-18 3
05 13000017 Ball bearing 6206 2RS 30-62-16 3
07 01101073 Variator belt 41,5x12x1419 1
08 13000326 Ball bearing 6305 2RS 25-62-17 2
20 25001301 Microswitch +lever 25001302 2
58 25005120 Remote control switch LC1K0901B7 1
59 25005123 Remote control switch LC1K0601B7 2
60 25008006 Transformer 25VA 0/230/440 – 0/24 1
61 25001320 Microswitch MV15 1
www.gk-nhl.ru
8(831) 273-97-50

CONTROL PANEL
USE AND PROGRAMMING OF THE CONTROL PANEL
Selection of automatic/manual mode
Press the correspondent button (only when the mixer is not working).
In manual mode the display of the program will show “ - “
Timer/speed/temperature selection
Press various times the correspondent button till the desired selection.
PROGRAM
THERMIC ALARM OR EMERGENCY
OPEN GRID ALARM
MANUAL/ AUTOMATIC SELECTION
SPEED SELECTION
TIMER
SPEED
TEMPERATURE
BOWL LIFTING
BOWL LOWERING
TIMER
EMERGENCY
www.gk-nhl.ru
8(831) 273-97-50

After a minute the display will go automatically on the timer selection (default)
Speed selection
Press the speed button correspondent to the desired value (1 – 6) or the buttons “ + “ and “ – “
Time selection
Keep pressed the buttons “ + “ o “ – “ that are below the display of the timer till the desired value.
Programming mode
You can store 10 programs with 8 different cycles. To start the programming mode:
1) Select the manual or automatic mode
2) Keep pressed for 3 seconds both buttons “ + ” and “ – “ that are below the display (display program = “ 1 “
blinking)
3) Select with the button “ + “ or “ – “ the desired program.
4) Select the speed button correspondent to the desired value for the first cycle (1 – 6)
5) Select the desired time for the first cycle
6) Press the “ START “ button to store the first cycle. As confirmation there will appear “MEM”
7) Press the “ STOP “ button if you wish to ultimate the programming or repeat the points 4, 5, 6 to store the other
cycles.
Start the mixer
In manual mode:
- Press the “ START “ button. If there are no impediments ( open grid, bowl not in position…) the mixer will
start its cycle of work till the depletion of the memorized time. Pressing the “ STOP “ button the mixer will
stop the cycle; pressing it again the mixer will set again the time initially memorized.
In automatic mode:
- Select the desired program and press the “ START “ button. If there are no impediments ( open grid, bowl
not in position…) and the program is valid the mixer will start its cycle of work till the depletion of the
memorized time (NOTICE: a no-valid program will be signalled by the indication “ E E E E “ on the display
of the timer). Pressing the “ STOP “ button the mixer will stop the cycle; pressing it again the mixer will start
the cycle from the beginning.
Lower the bowl
Keep pressed the button “ bowl descent “. If the mixer is working it will be stopped and then once it is completely still
(speed = 0 ), the bowl will lower.
General information
During the programming both leds “ automatic “ and “ manual “ will light.
During the functioning it is no more possible to change the automatic/manual selection.
During the functioning it is possible to change speed and time, but this value will not be stored.
