Signtex Lighting Moonlite LED MHE-AC Series Manual

Series MHE-AC
Installation Instructions & Users Manual
Moonlite LED™
High Output Emergency Light 04.15.01
1. Disconnect AC power before servicing.
2. Refer to wiring diagram for proper connections.
3. All servicing should be performed by qualified personnel.
4. Consult your local building code for approved wiring and installation.
5. Do not use outdoors.
6. Do not use this equipment for other than intended use.
7. Do not let power cords touch hot surfaces.
8. Mount and secure the fixture at a location and height to avoid ready access and tampering by unauthorized persons.
9. The use of accessory equipment is not recommended by the manufacturer and may cause an unsafe condition.
IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Fig. 1. DIRECT SURFACE MOUNT
1. See Fig 1. Identify mounting position on ceiling in accordance with fixture layout specifications, and install (2) screw anchors, minimum size
#10, at 8” between centers.
2. Insert small flat blade screwdriver or similar tool under notch at either end of cover, twist gently to release snap and lift cover. Unscrew (4) #8
lamp assembly screws, lift lamp assembly from Housing and disconnect lamp plug.
3. Mount housing to ceiling with (2) mount screws. Route 120/ 277 VAC IN/OUT wiring.
4. Connect wiring: BLACK- 120 VAC LINE
WHITE- NEUTRAL
ORANGE- 277 VAC LINE
GREEN- GROUND
5. Reconnect lamp plug and reinstall lamp assembly with (4) #8 screws, and replace cover. Supply power to check lamp operation.
220 VFW Avenue, Grasonville, MD 21638 P (410)827- 8300 F(410)827- 8866
Signtex Lighting
PUSH- IN
CONNECTORS
(SUPPLIED)
#12-22 AWG
120/ 277
VAC IN L
GN
CEILING
LAMP
CONNECTOR
LAMP
HOUSING
MOUNT SCREWS
(BY OTHERS)
LAMP
ASSBY
COVER
SCREW ANCHOR
(2 PLCS)
8”

-2-
Moonlite LED™
High Output Emergency Light
Fig. 2. SURFACE MOUNT WITH END BRACKETS Fig. 3. SURFACE MOUNT TO J-BOX
END BRACKET
(2) SUPPLIED
CEILING
POLARIZED LAMP
CONNECTOR
POLARIZED LAMP
CONNECTOR
LAMP
HOUSING
MOUNT
SCREWS
(2) REQ'D
LAMP
ASSBY
COVER
SCREW
ANCHOR
BRACKET
SCREW
(4) SUPPLIED
LAMP
ASSBY
COVER
15 1/2”
CEILING
J- BOX
4” x 4”
GND
120/ 277 VAC
IN/ OUT
WB
SURFACE MOUNT WITH END BRACKETS
1. See Fig 2. Install (2) screw anchors at 15 ½” centers.
2. Insert flat blade screwdriver under notch at end of cover, twist gently to release cover plate. Unscrew (4) #8 lamp assembly screws, lift lamp
assembly from Housing and disconnect lamp plug.
3. Attach end brackets with (4) #8 screws and nuts as shown, mount housing assembly to ceiling and route 120/77 VAC IN/OUT wiring into
housing.
4. Proceed as for STANDARD SURFACE MOUNT steps 4 - 5
SURFACE MOUNT TO J-BOX
1. See Fig 3. Install standard 4” J-box centrally above installation point as shown and secure to ceiling using appropriate screw anchors.
2. Route 120/ 277 VAC IN/OUT wiring into j-box.
3. Proceed as for STANDARD SURFACE MOUNT steps 4 - 5.
Series MHE-AC
L
GN
04.15.01

Moonlite LED™
High Output Emergency Light
14 1/2”
24"-48"
For T-Bar installations, rotate side bracket clips as
required to fit T-Bar hangers. For masonry ceilings,
attach side brackets to framing.
T-BAR T-BAR
ROTATE B-CLIPS
90° TO FIT BAR
HANGERS AS
REQUIRED
HANGER
ALTERNATE
POSITION
CENTERED CUTOUT
7/8" K.O. 2 PLCS
CEILING
MOUNT BRACKET 4 SUPPLIED
B-CLIP (4) SUPPLIED
DROPWIRES
BAR HANGER
(SUPPLIED
BY OTHERS)
CEILING
MOUNT BRACKET
SCREW: (4) SUPPLIED
B-CLIP
14 1/2””
3 3/8”
3 3/8”
12-48"
Fig. 3. RECESSED MOUNT: T-BAR CEILING
MOUNT BRACKET
(2) SUPPLIED
B-CLIP 4 REQD.
BACK BOX
-3-
Install Housing in ceiling using supplied end brackets with B-
Clips to framing or hanger bars (supplied by others). Long
edges of Housing should be flush or just below finished panel
surface.
Series MHE-AC
04.15.01

-4-
Moonlite LED™
High Output Emergency Light
Fig. 4. RECESSED MOUNT- WIRING
CEILING
POLARIZED
LAMP
CONNECTOR
LAMP
ASSBY
TRIM PLATE
CEILING
1. Route 120/ 277 VAC IN/OUT wiring into Housing.
2. Connect wiring: BLACK- 120 VAC LINE
WHITE- NEUTRAL
ORANGE- 277 VAC LINE
GREEN- GROUND
3. Connect lamp plug and install lamp assembly with (4) #8 screws. Attach Trim Plate with (2) color- matched #8-32 screws as shown.
4. Supply power to check lamp operation.
220 VFW Avenue, Grasonville, MD 21638
TEL: [phone] Fax:[phone]
[e-mail] www.signtexinc.com
Signtex Inc
LIGHTING
WIRING FOR EM OPERATION ONLY WIRING FOR EM & NORMAL ON OPERATION
PIGTAIL
(SUPPLIED)
Series MHE-AC
120/ 277
VAC IN 120/ 277
VAC IN
LL
GG
NN
PUSH- IN
CONNECTORS
(SUPPLIED)
#12-22 AWG
PUSH- IN
CONNECTORS
(SUPPLIED)
#12-22 AWG
04.15.01
