Signtex Lighting CAEBB Series Manual

Before connecting to power supply, TURN OFF ELECTRICAL
POWER AT CIRCUIT BREAKER OR FUSE
Disconnect AC power before servicing.
Refer to wiring diagram for proper connections.
All servicing should be performed by qualified personnel.
Consult your local building code for approved wiring and installation.
Do not use outdoors.
Suitable for indoor damp locations (when specified).
Do not let power cords touch hot surfaces.
Do not mount near gas or electric heaters.
Mount and secure exit sign at a location and height to avoid
ready access and tampering by unauthorized persons.
(Exception: Floor proximity installations)
The use of accessory equipment is not recommended by
the manufacturer and may cause an unsafe condition.
Do not use this equipment for other than intended use.
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Signtex Inc
LIGHTING
Series CAEBB
Installation Instructions & Users Manual
Crystal Accessible Exit Edge- Lit LED Sign System
Battery Backup Models 06.16.00
Designed to meet requirements of State of Connecticut, State Fire Safety Code Para 1011.1.1 and 1011.1.2

-2-
Before installing or connecting any primary power wiring,
DISCONNECT MAIN POWER SUPPLY AT THE CIRCUIT BREAKER OR FUSE.
#6-32 LOCK NUT
LOCK NUT
TEST PANEL
BATTERY
CONNECTOR
NICAD
BATTERY PACK
POWER
SUPPLY
LED LAMP
CONNECTOR
BACK BOX
TEST PANEL
TEST PANEL
TEST PANEL ASSEMBLY
#6-32 LOCK NUT
BACKBOX
Series CAEBB
Crystal Accessible Exit Edge- Lit LED Sign System
Battery Backup Models 06.16.00
CEILING MOUNT
TRIM PLATE #8-32 SCREWS
(2 REQD)
TEST PANEL
TRIM PLATE
BATTERY
POLARIZED
CONNECTOR
BACKBOX
POWER
MODULE
LAMP HOUSING
#6-32 SCREWS
(4 REQD)
AC POWER
INPUT 120/277 VAC

-3-
20 1/2" 24 - 48"
ANGLE BRACKET 2 SUPPLIED
WITH HARDWARE
B-CLIP 4 REQD.
ROTATE B-CLIPS
90° TO FIT BAR
HANGERS AS
REQUIRED
BAR HANGER SUPPLIED
BY OTHERS
HANGER ALTERNATE
POSITION
PANEL THICKNESS
RANGE 3/8" - 1 3/8"
EDGE OF BACK BOX MUST BE
FLUSH OR SLIGHTLY BELOW
PANEL SURFACE
MOUNT BRACKET
SCREW: 8 SUPPLIED B-CLIP 4 SUPPLIED
CEILING
PANEL CUTOUT
12-48"
CEILING MOUNT
T-BAR MOUNTING DETAIL TO GRID CEILING
Series CAEBB
Crystal Accessible Exit Edge- Lit LED Sign System
Battery Backup Models 06.16.00

Series CAEBB
Crystal Accessible Exit Edge- Lit LED Sign System
Battery Backup Models 06.16.00
Wiring Diagrams & Instructions
-4-
Wiring
1. This equipment to be connected to an un- switched
circuit only.
2. For exits with Master- Remote or Self-Diagnostics,
refer to supplementary data sheet for wiring diagrams
and additional instructions.
3. CAUTION: Damage to battery will occur if battery
connector is connected to charger board for
prolonged period of time without continuous AC
power provided.
Inspection and Maintenance
Important Note: Emergency lighting systems
should be tested as often as local codes require,
or at least monthly, to a certain that all
components are operational. Allow battery to
charge 8 hours before initial testing, and 24 hours
to fully charge battery.
1. Normal Operation: When unit is functioning
properly, with AC power supplied, the Status light and
exit lamp will be on.
2. To Test: Press manual test switch. Status light will
turn off and exit lamp will remain on in DC mode.
Note: Turn off AC power and disconnect battery before
servicing unit.
Battery Replacement
Remove fixture from J-Box. Locate battery wiring and
disconnect 2- pin polarized battery plug. Pry battery
out of cavity to release hook and loop fastener. Replace
battery, reconnect battery plug and replace fixture.
Power Module Replacement
Remove fixture from J-Box. Remove two #8-32 screws
to J-Box and remove Power Module Assembly from J-
Box.Disconnect wire nuts or push nut connectors to AC line
inputs. To replace with new Power Module, reverse this
sequence.
220 VFW Avenue, Grasonville, MD 21638
TEL: [phone] Fax:[phone]
[e-mail] www.signtexinc.com
Signtex Inc
LIGHTING
POWER
MODULE
R E D B R O W N
OUTPUT 2.4-5 VDC
E M E R G E N C Y S I G N S A C F I X T U R E S
FIXTURE HOUSING
BLK
R E D
R E D
V I O L E T
V I O L E T
B R O W N
B R O W N
Y E L L O W
G R E E N
P I N K
O R A N G E
B L A C K
OUTPUT 2.4-5 VDC
RED
LAMP CIRCUIT BOARD
LAMP CIRCUIT BOARD
FIXTURE
GROUND
NEUTRAL
120-277 VAC
W H I T E
B L A C K
G R E E N GROUND
NEUTRAL
LINE
LINE
120-277 VAC
B L U E
B R O W N
G R E E N
POLARIZED
CONNECTOR
TEST PANEL
DIAGNOSTICS INDICATOR
CHARGE LIGHT
TEST SWITCH
8-PIN POLARIZED
2-PIN POLARIZED
CONNECTOR
CONNECTOR HOUSING
BATTERY
BATTERY DIAGNOSTIC FUNCTIONS:
Microprocessor programmed to perform tests as follows:
Continuous
Monitoring w/ 1
Second Sampling
Lamp
Connections
Transfer switch
function
Test switch
indicator
function
Full 90 minute
emergency
operation test
with test/ fail
and manual
report signal
Battery discharge
rate under
full load
Battery
Connections
Every
28 Days
Every
12 Months
SELF- TEST DIAGNOSTIC FUNCTIONS
STATUS
NORMAL FULL CHARGE
NORMAL FAST CHARGE
FAILED BATTERY
FAILED LAMP
FAILED TRANSFER
FAILED CHARGER
GREEN ON
ORANGE ON
RED FLASH FAST
GREEN FLASH
ORANGE FLASH
RED FLASH SLOW
LED DISPLAY
