CyberParallel ExpressCard
Quick Installation Guide
04-0468A
Introducing the CyberParallel ExpressCard
TheCyberParallelExpressCardhigh-speedparalleladapter
provides one parallel port to your ExpressCard equipped
system.
Features and Benefits
•Full support for Windows-based software
•SupportsSPP,PS2,EPPandECPparallelportmodes
•Compliant with IEEE 1284-1994 parallel port
standard
•Compliant with PCI Express Specification, Rev. 1.0a
•SupportsSPP,PS2,EPPandECPparallelportmodes
•Fast ECP/EPP parallel port optimizes performance
fromparallelportdevicessuchasprinters,removable
drives, scanners, CD-R/RWs, and more
System Requirements
•Notebook or Desktop system with an available
ExpressCard slot
•Windows®2000/XP (32-/64-bit)/Server 2003
(32-/64-bit)/Vista (32-/64-bit)
PackageContents
•CyberParallelExpressCard
• ExpressCard 1P Cable
• Driver CD and Quick Installation Guide

2
ExpressCard 1P
Cable connector
Layout
Figure 1. Layout
ExpressCard 1P Cable
Figure 2. Cable Layout
Parallel port (DB25)
ExpressCard 1P
connector

3
Hardware Installation
General instructions for installing the ExpressCard are
provided. Since the design of systems may vary, refer to
your system’s reference manual for further information,
if needed.
1. Connect the ExpressCard 1P Cable to the cable
connector on the ExpressCard.
2. Insert the CyberParallel ExpressCard into the
ExpressCard slot of your system with the label
facing up. Make sure it is inserted all the way in for
a solid connection.
Note:Whenconnecting/disconnectingdevices,hold
the CyberParallel ExpressCard so it does not move
from side to side, otherwise it may eject from the
slot or lose connection.
Figure 3: Connecting the cable

4
Driver Installation
This section provides information on how to install the
CyberParallel ExpressCard drivers.
Windows 2000
1. At the Found New Hardware Wizard, click Next.
2. Select Search for a suitable driver for my device
(recommended), and click Next.
3. Check Specify a location, uncheck the other boxes,
then click Next.
4. Insert the driver CD, type in D:\2000, then click OK.
(Change D: to match your CD-ROM drive letter)
5. Click Next and Finish.
6. Repeat steps 1-5 one or two times.
7. RestartWindowstocompletethe driver installation.
32-bit Windows XP/Server 2003
1. At the Found New Hardware Wizard, insert the
driver CD.
For XP w/SP1 or earlier/ Server 2003: go to step #2.
For XP w/SP2 or later/Server 2003 wSP1 or later:select
No, not this time, click Next.
2. Select Install the software automatically
(Recommended,then click Next.
3. Click Finish.
4. Repeat steps 1-3.
5. RestartWindowstocompletethe driver installation.
64-bit Windows XP/Server 2003
1. At the Found New Hardware Wizard, insert the
driver CD. Select No, not this time, click Next.

5
2. Select Install the software automatically
(Recommended,then click Next.
3. Click Continue Anyway, then click Finish.
4. Repeat steps 1-3 to complete the driver installation.
Verify Windows 2000/XP/2003 Installation
1. Right click My Computer, click Manage, then click
Device Manager.
2. Click on the +(plus sign) in front of Ports (COM &
LPT), SIIG CyberPro Parallel port.... should be
displayed one time.
Windows Vista™
1. At the Found New Hardware window, insert the
driver CD, click Locate and install driver software
(recommended), then click Continue.
2. Click Next, then click Close.
3. Repeat step #2 to complete the driver installation.
Note: If your internet connection is enabled the
driver installation may not match the steps above
because Windows Vista operating system will use
Windows Update to install the driver for the
CyberParallel ExpressCard. In this case, verify Vista
installation as described below.
Verify Windows Vista Installation
1. Right click My Computer, click Manage, click
Continue, then click Device Manager.
2. Click on the +(plus sign) in front of Ports (COM &
LPT), SIIG CyberPro Parallel Port.... should be
displayed one time.

6
Changing Parallel Port
Some parallel port devices need a specific LPT in order
to function properly. If your device works, do not make
any changes.
1. Right click My Computer, click Manage,
For 2000/XP/2003: then click Device Manager.
ForVista:click Continue,thenclickDevice Manager.
2. Click on the +(plus sign) in front of Ports (COM &
LPT), double click the SIIG CyberPro Parallel port
you want to change.
3. Click the Port Settings tab.
4. Click the down arrow next to the LPT Port Number
box, then select a parallel port that is not in use.
5. Click OK to save the changes.
Legacy Device Support
If your parallel port device is not detected or does not
work properly, follow the steps below to enable legacy
plug and play support.
1. Right click My Computer, click Manage,
For 2000/XP/2003: click Device Manager.
ForVista: clickContinue,then clickDevice Manager.
2. Click on the +(plus sign) in front of Ports (COM &
LPT), double click the SIIG CyberPro Parallel port
you want to change.
3. Click the Port Settings tab.
4. Check Enable legacy Plug and Play.
5. Click OK to save the changes.

7
Technical Support and Warranty
QUESTIONS? SIIG’sOnline Support hasanswers! Simplyvisitour
web site at www.siig.com and click Support. Our online support
database is updated daily with new drivers and solutions. Answers
toyourquestionscouldbejustafewclicksaway. Youcanalsosubmit
questions online and a technical support analysts will promptly
respond.
SIIGoffersalifetimemanufacturer warrantywiththis product. Please
see our web site for more warranty details. If you encounter any
problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the
product to the store where you purchased from.
B) Ifyourpurchasehaspassedthe store's return policy period, please
follow these steps to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective, an RMA number will be issued. SIIG RMA department
can also be reached at [phone].
Step 2: After obtaining an RMA number, ship the product.
•Properly pack the product for shipping. All software, cable(s)
and any other accessories that came with the original package
must be included.
•Clearly write your RMA number on the top of the returned
package. SIIG will refuse to accept any shipping package, and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•You are responsible for the cost of shipping. Ship the product
to the following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
•SIIG will ship the repaired or replaced product via Ground
in the U.S. and International Economy outside of the U.S. at
no cost to the customer.

CyberParallelExpressCardisatrademarkofSIIG,Inc. SIIGandtheSIIGlogoareregisteredtrademarks
ofSIIG,Inc. Microsoft,WindowsandWindowsVistaareregisteredtrademarksofMicrosoftCorporation.
Other names used in this publication are for identification only and may be trademarks of their
respectivecompanies.
September, 2007 Copyright © 2007 by SIIG, Inc. All rights reserved.
