INTRODUCTION
The AV-GM0A73-S1 4-Display HDMI2.0a 4K 4:4:4 Video Wall Processor is a powerful, cost effective,
and fully real time data/video processor for multiple flat panel displays or projectors. Virtually any
setups for the display layout can be possible by the control software. The AV-GM0A73-S1 allows
user to input HDMI up to 4K2K@60Hz 4:4:4. And the embedded scaler converts signals from HDMI
source to match the native resolution of monitors, flat panel displays, projectors as well as
user-selectable output settings up to WUXGA (1920x1200). The AV-GM0A73-S1 sends the resulting
processed video thru HDMI interface to the connected monitors/projectors based on the setup
display layout. The layout can be readily modified to fit your applications in digital signage,
broadcasting, education and surveillance systems and optimize visual effects.
FEATURES
Four HDMI outputs from 640x480 to 1920x1200
Supports HDMI input from 640x480 to 4K2K@60 (YUV 4:4:4), interlaced or progressive
HDCP compliant
Image parameters and layouts are automatically saved in flash memory of the device and can
be recalled for later use
Several image parameters and layouts can be saved in computers and can be loaded for later
use
Firmware upgradable for new features and technology enhancements
Supports IR remote control
Software control through USB and Ethernet
Resize, position, zoom for each HDMI output video
User-selectable output settings, up to 1920x1200
Supports remote control to switch 1x1, 2x2, 1x3 rotate, and 1x4 rotate mode
Supports independent input rotation at the resolution up to 1080p
4K2K60 (YUV 4:4:4) can be divided and displayed onto four 1080p60 TV (2x2 layout only)
Supports individual propagation delay on each display to have the best visual perception
PACKAGE CONTENTS
1x AV-GM0A73-S1
1x User Manual
1x 1U rack-mounting ear set
1x 12V power supply
1x Installation software CD
1x IR Remote control (15 keys)
