USB 2.0 to DVI/VGA Pro
Installation Guide
04-0671C
Introduction
The USB 2.0 to DVI/VGA Pro adds DVI or VGA
port to your USB enabled system.
Key Features and Benefits
• Quickly adds a monitor, LCD or projector
to your USB 2.0 enabled system
• Built with a DisplayLink chipset DL-195
• Resolution (max): 1080p and WUXGA 1920
x 1200
• Connects up to 6 adapters in one system
System Requirements
• Desktop or notebook PC with a single core
1.2 GHz CPU or faster
• An available USB 2.0/3.0 port
• Windows® 8 (32-/64-bit) / 7 (32-/64-bit) /
Vista (32-/64-bit) / XP (32-bit, SP3)
• Mac OS®
X v10.4 to v10.8.x (Intel-based
Apple computers only)

2
Package Contents
•USB 2.0 to DVI/VGA Pro
• DVI-I to VGA adapter
• USB Cable (Type A to B)
• Driver CD & installation guide
Layout
Figure 1: Layout
USB cable connector
DVI port
Windows Software Installation
Make sure the proper driver for your graphics
card is installed, the USB 2.0 to DVI/VGA Pro is
not designed to work with Windows' Standard
VGA Graphics Adapter driver.
Important: Do not plug the USB 2.0 to DVI/VGA
Pro into the computer until instructed to do so.

3
1. Insert the driver CD.
2. Double click Setup at the autoplay CD
driver window, or press Windows key and
R, type D:\Setup.exe in the Run window,
then click OK. (Change D: to match your
CD/DVD-ROM drive letter)
3. Click Yes or Allow at the User Account
Control. Skip this step if not prompted.
4. Connect your second monitor to the USB
2.0 to DVI/VGA Pro and turn it on, then
plug the USB 2.0 to DVI/VGA Pro into the
computer.
5. Restart the computer.
To Verify Windows Installation
1. Go to Device Manager to verify installation.
For Window 8 / Windows 7 / Windows XP:
Right click Computer or My Computer,
click Manage, then click Device Manager.
For Windows Vista: Right click Computer,
click Manage, click Continue, then click
Device Manager.
2. Double click USB Display Adapters, a
AN2240D3 should be displayed.

4
Uninstalling the Adapter Driver
Windows 8 / Windows 7
1. Double click Control Panel on desktop, or
click Start, Control Panel.
2. Click Programs, then click Programs and
Features.
3. Select DisplayLink Graphics, then click
Uninstall.
4. Click Yes, Yes, then click OK.
5. Click Yes to complete the uninstallation.
Windows Vista
1. Click Start, Control Panel.
2. Click Classic View, double click Programs
and Features.
3. Select DisplayLink Graphics, then click
Uninstall, then click Yes.
4. Click Allow, then click Yes to complete
uninstalling the driver.
Windows XP
1. Click Start, Control Panel.
2. Double click Add/Remove Programs.

5
3. Select DisplayLink Graphics, click
Remove, then click Yes.
4. Click Yestocomplete uninstallingthe driver.
Windows Display Utility
After successful driver installation a AN2240D3
Adapter utility icon will appear in the taskbar.
This display utility allows you to quickly change
the viewing modes and resolutions. Access the
utility by clicking the icon.
Viewing Modes
•Screen Resolution: Displays a list of
available resolutions.
•Screen Rotation:
Normal - No rotation is applied.
Rotated Left - Rotates the extended or
mirrored display by 270 degrees.
Rotated Right - Rotates the extended or
mirrored display by 90 degrees.
Upside-Down - Rotates the extended or
mirrored display by 180 degrees.

6
•Extend to:
Right - Extends the display to the right of
the main display.
Left - Extends the display to the left of the
main display.
Above - Extends the display above of the
main display.
Below - Extends the display below the main
display.
• Extend (default): This mode extends your
desktop for easy viewing of multiple
windows. Windows will move off the
primary display from the right side and
enter the extended display from the left.
•Set as Main Monitor: This mode, makes
the USB 2.0 to DVI/VGA Pro the main display
adapter in the system.
•Mirror: You will see the same image on
both monitors.
•Off: This setting turns off the USB 2.0 to
DVI/VGA Pro adapter.

7
•Optimize for Video (not available in
Windows XP): Configures the secondary
display for optimum full screen video
performance output. Note: Text may appear
less clear.
•Fit to TV: Adjust the size of the Windows
desktop when the Windows desktop does
not completely appear on the TV.
Using Windows Display Properties (WDP)
Note: Not all the WDP functions are
available in Windows Vista.
Instead of using the AN2240D3 utility, you can
use the embedded Windows Display
Properties(WDP) to do the basic setting. WDP
allows you to rotate, duplicate or extend screens
as well as modify screen resolution.
Position the mouse anywhere on the Windows
Desktop,
For Windows 8 / Windows 7: Right click and select
Screen Resolution.
For Windows Vista: Right click and select
Personalize, then click Display Settings.

8
For Windows XP: Right click then select Properties.
WDP allows you to rotate, duplicate or extend
screens as well as modify screen resolution.
•Display: Use the drop down list to select a
display to be configured.
•Resolution: Use the drop down list and
user the slider to choose a resolution.
•Orientation:
Landscape - Sets the display to landscape
view.
Portrait - Sets the display to portrait mode.
Landscape (flipped) - Setsthe displayto upside
down landscape mode.
Portrait (flipped) - Sets the display to upside
down landscape mode.
•Multiple displays:
Duplicates these displays - Reproduces the
main display on the second display.
Extend these displays - Extends the main
display onto the secondary display.
Show Desktop only on 1 - The display marked
2 becomes blank.

9
Shows Desktop only on 2 - The desktop
appears on the display marked 2. The
display marked 1 becomes blank.
•Make this my main display: Check the box
and you will make your USB 2.0 to DVI/
VGA Pro the main display adapter in the
system.
Make sure the secondary monitor is selected
before choosing this option.
• Display Positions: To move the position of
a display, click and hold the display you
wish to move then drag it to the desired
position. The display will be highlighted
with a blue border while you are moving
the display to its new position.
Mac OS Driver Installation
1. Connect your second monitor to the USB
2.0 to DVI/VGA Pro and turn it on, then
plug the USB 2.0 to DVI/VGA Pro into the
computer.
2. Insert the driver CD, then double click
Driver CD icon on the Desktop.

10
3. For Mac OS 10.4.x-10.5.x: Double click Mac
OS X 10.4-10.5 folder.
For Mac OS 10.6.x-10.8.x: Double click Mac
OS X 10.6-10.8 folder.
4. Double click DisplayLink_Installer_
1.7.dmg or DisplayLink_MacOSX_V2.0.
dmg
5. At the DisplayLink Installer, double click
DisplayLink Software Installer.pkg.
6. At the Introduction, click Continue for one
to two times.
7. At the License, click Continue, and Agree.
8. At the Select Destination, click Continue.
Skip this step if not prompted.
9. At the Installation Type, click Change
Install Location if you want to change the
default saving folder; otherwise, click
Install.
10. Type in Name and Password, click OK or
Install Software, then click Continue
Installation.
11. Click Restart to complete the installation.
