SIIG VV-CV0012-S1 User manual

1
Introducing the DP ADD2 PCIe DVI Adapter
The DP ADD2 PCIe DVI Adapter is an economical way to
add a second monitor to PCs using select Intel PCI
Express based graphics controllers. Increase your
productivity by using it as an extended desktop or as a
larger/different display for your main screen.
FeaturesandBenefits
• Adds a DVI-D port for an additional monitor
• Multiple display functionality: primary, extended,
twin (mirror) and rotation
• Dual profile design to work with standard height
and low profile chassis
• Supports Intel SDVO (Serial Digital Video Output)
technology
• DVI 1.0 compliant
• Bandwidth: 25 - 165 MHZ
• Maximum resolution: 1600 x 1200 (UXGA)
SystemRequirements
• Intel®915G/945/965 based desktop PC
• An available x16 PCI Express slot
• Intel Graphics Media Accelerator Driver installed
• Windows®2000 / XP (32-/64-bit) / Vista (32-/64-
bit) / Server 2008 (32-/64-bit)
04-0534A
DPADD2PCIeDVIAdapter
Quick Installation Guide

2
Figure 1: DP ADD2 PCIe DVI Adapter
PackageContents
•DP ADD2 PCIe DVI Adapter
• Spare low profile bracket
• This quick installation guide
Layout
DVI port

3
Hardware Installation
Note: For low-profile systems, remove the full-profile
bracket and install the low-profile bracket before
proceeding.
General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer's reference
manual for further information, if needed.
Static electricity discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
1. Turn OFF the power to your computer and any
other connected peripheral devices.
2. Unplug the power cord from the computer.
3. Remove the computer cover.
4. Remove the slot bracket cover from the x16 PCI
Express slot.
5. To install the card, carefully align the card's bus
connector with the selected PCIe slot on the
motherboard. Push the board down firmly, but
gently, until it is well seated.
6. Replace the slot bracket holding screw to secure the
card.
Driver Installation
Desktop systems using Intel 915G/945/965 chipset with
Intel Graphics Media Accelerator Driver installed have
the driver available and ready to go when the board is
installed. No driver installation is needed. Contact your
system vendor or go to Intel.com for the latest driver.

4
Using the DP ADD2 PCIe DVI Adapter
To get the full function from the DP ADD2 PCIe DVI
Adapter, Intel Graphics Media Accelerator Driver must
be installed and working properly with the existing
monitor. For systems that do not have this utility, contact
thesystemmanufacturerdirectlyorgotowww.Intel.com
for the latest graphics drivers.
IntelGraphicsMediaAcceleratorDriver
The Intel Graphics Media Accelerator Driver graphics
utility will appear as an icon in the system tray, in the
lower right corner of the taskbar, by the system clock.
This utility allows you to quickly and easily configure
the DP ADD2 PCIe DVI Adapter.
Figure 2: System Tray icon
Right click the icon and select Graphics Properties to
access the utility. The default view when starting the
utility is the Display Devices screen (shown on the next
page).

5
Figure 3: Display Devices screen
Modes
• Extended Desktop: extends your desktop for easy
viewing of multiple windows. Use the two monitor
graphic representation, in the bottom right corner,
to virtually position each monitor to conveniently
move from one screen to the other
•Primary Device: selects the main display adapter in
the system when multiple display mode is active
•Secondary Device: selects the secondary display in
the system when multiple display mode is active
•Twin (Intel Dual Display Clone): the two monitors
will mirror each other. The same image will display
on each monitor
•Single Display: when only one display is desired.
selecting one display turns off the other display
Click Apply or OK to view or save any changes you have
made, respectively.

6
Figure 4: Display Settings screen
Modes
• Color Quality: selects the amount of colors your
monitor will display
•Screen Resolution: changes the resolution of the
selected monitor
•Refresh Rate: selects the refresh rate of the selected
monitor
•Rotation: rotates the screen from 0, 90, 180, and 270
degrees of the selected monitor
Click Apply or OK to view or save any changes you have
made, respectively.

7
Technical Support and Warranty
QUESTIONS? SIIG’sOnline Support hasanswers! Simply visitour
web site at www.siig.com and click Support. Our online support
database is updated daily with new drivers and solutions. Answers
toyour questionscould be justa fewclicksaway. You canalso submit
questions online and a technical support analysts will promptly
respond.
SIIGoffers a5-year manufacturerwarranty withthis product. Please
see our web site for more warranty details. If you encounter any
problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the
product to the store where you purchased from.
B) Ifyour purchasehas passedthestore's returnpolicy period,please
follow these steps to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective, an RMA number will be issued.
Step 2: After obtaining an RMA number, ship the product.
•Properly pack the product for shipping. All software, cable(s)
and any other accessories that came with the original package
must be included.
•Clearly write your RMA number on the top of the returned
package. SIIG will refuse to accept any shipping package, and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•You are responsible for the cost of shipping. Ship the product
to the following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
•SIIG will ship the repaired or replaced product via Ground
in the U.S. and International Economy outside of the U.S. at
no cost to the customer.

DP ADD2 PCIe DVI Adapter is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered
trademarksofSIIG,Inc. Microsoft,WindowsandWindowsVistaareeitherregisteredtrademarksor
trademarksofMicrosoftCorporationintheUnitedStatesand/orothercountries. Intelisaregistered
trademark of Intel Corporation in the United States and other countries. Other names used in this
publication are for identification only and may be trademarks of their respective companies.
December, 2008 Copyright ©2008 by SIIG, Inc. All rights reserved.
