SIIG 2x1 USB DisplayPort KVM Switch with Remote... User manual

1
2x1 USB DisplayPort KVM
Switch with Remote Control
Quick Installation Guide
Introduction
The2x1USBDisplayPortKVMSwitchwithRemoteControlallows
youtoswitchbetweentwocomputerstoshareaDisplayPortorHDMI
monitorandsetofUSBMouse,USBKeyboard,USB2.0device,MIC
andEarphone.Theinputandoutputcanbecontrolledbymanualand
remotecontrol.
Features and Benefits
SupporttwoDual‐modeDisplayPortinputstooneDual‐mode
DisplayPortorHDMIoutput
SupportDisplayPortversion1.1aforboth1.62and2.7Gbpslink
rates
SupportHDMIspecificationmaxupto1920x1080p@60Hz@36bit,
225MHz/2.25Gbpsperchannel(6.75Gbpsallchannel)bandwidth
SupportHDMIuncompressed2channelaudiosuchasLPCM
SupportUSB2.0portconnectionandenableHUBfunctionfor
sharingUSBdevices
SupportMICandEarphonefunctionforexternalaudioequipments
FrontpanelLEDsindicatewhichSource&Sinkareselected
System Requirements
DeviceorPCcomputerwithanavailableDisplayPort&USBPort
(USB2.0recommended)
Windows®7(32‐/64‐bit)/Vista(32‐/64‐bit)/XP(32‐/64‐bit)
MacOS®Xv10.4orlater
04‐0765B

2
Package Contents
2x1USBDisplayPortKVMSwitchwithRemoteControl
DisplayPorttoMiniDisplayPort(male)cable
DisplayPorttoMiniDisplayPort(female)cable
Remotecontrol
Poweradapter
Quickinstallationguide
Layout
Figure1:FrontPanelLayout
RS232:ConnecttheporttoPC,andPCwillswitchthisproductby
superterminalcommand.
IR:TheIRreceiverwillacceptcommandsfromtheRemote
Control
USBPort:ThethreeUSBportswillbeconnectedtoUSBdevices,
suchasmouse,keyboardandharddisk.
MIC:TheportwillbeconnectedtoMicrophonedevice
Earphone:Theportwillbeconnectedtoaudioamplifierdevice
PC1:TheselectedPC1inputwillbeindicatedwithanactiveLED
PC2:TheselectedPC2inputwillbeindicatedwithanactiveLED
SourceSelect:PressingthisbuttonwillswitchthePC1orPC2as
input
DisplayPort:TheselectedDisplayPortoutputwillbeindicated
withanactiveLED
HDMI:TheselectedHDMIoutputwillbeindicatedwithanactive
RS232 IR USB Port MIC
Earphone PC LED
Source
Select Display
LED Sink
Select

3
LED
SinkSelect:PressingthisbuttonwillswitchtheDisplayPortor
HDMIasoutput.
Figure2:RearPanelLayout
DC/5V:Connectstotheincludedpoweradapter.
PowerLED:ThisLEDwillbelitoncepowerisbeingsuppliedby
included5Vpowersupply
IRExt:ExtendIRfunction.
HDMIOutput:TheportwillbeconnectedtoHDMIdisplay.
DisplayPortOutput:TheportwillbeconnectedtoDisplayPort
display.
DisplayPortSource:TheportwillbeconnectedtoDisplayPort
sourcePC1andPC2devices.
USBSource:TheportwillbeconnectedtoUSBsourcePC1and
PC2devices.

DC/5V
Power
LED
IR Ext
HDMI
Output DisplayPort
Output DisplayPort
Source USB
Source

4
Hardware Installation
1. Poweroffthecomputersandmonitoryouplantoconnecttothis
switch.
2. ConnectDisplayPortPortoftheswitchPC1toComputer1usinga
DisplayPortcableorDisplayPortmaletoMiniDisplayPortmale
cable(included).
3. ConnectUSBportoftheswitchPC1toComputer1usingaUSBA
maletoBfemalecable(notincluded).
4. Repeatforstep1&2forcomputer2.
5. ConnectUSBdevice(suchasmouse,keyboard)totheUSBHub
portoftheswitch.
6. Connectyouraudiocablestothe3.5mmMICandEarphoneports
oftheswitch.
7. ConnectyourDisplayPortandHDMIdisplaystotheswitch’ssink
portsusinganDisplayPortandHDMIcable(notincluded).
8. Plugthepoweradapterintotheswitchʹspowerjackthenplugthe
poweradapterintoareliablepoweroutlet.
9. EnsurethatthePowerLEDislit.
10.The2x1USBDisplayPortKVMSwitchwithRemoteControlis
readytouse.
DeviceSwitching
YoucanchoosetheSelectbutton(thatleadsyouthroughmultiple
computers),RemotecontrolorRS232.
1. Selectingsourceandsinkdevicesbybuttonsonthefrontpanel,
pressingtwoSelectbuttonsseparatelytoselectinputsignalsor
outputsignals.
2. SelectingsourceandsinkdevicesbyRemotecontrol.
‐Powerbutton
ThepowerbuttonoftheIRremotecancontrolthepowerofthe
product.Pressthisbutton,thepower‐onunitwillbeturnedoff.
Pressagain,theunitwillbeturnedon.

5
‐Input1andInput2buttonforDisplayPortandHDMIoutput
PresstheInput1orInput2buttonforDisplayPort,DisplayPort
outputoftheproductwillbeselectedandinput1orinput2of
theproductwillalsobeselectedatthetime.
PresstheInput1orInput2buttonforHDMI,HDMIoutputof
theproductwillbeselectedandinput1orinput2oftheproduct
willalsobeselectedatthetime
3. SelectingsourceandsinkdevicesbyRS232
‐IntroductionofRS232remoteoperation:
RS232remoteoperationismainlybasedonthesuperterminal
ofWindowsoperationsystem.Itsparametershouldbe:ANSI
48008‐N‐1‐non
‐Operation
a. ConnecttheswitchsplittertotheCOMofPCwithaRS232
cable
b. ChosetherightCOMwhenyousettingsuperterminaland
thensettheparameterasfollow:
Baudfrequency：4800
Databit:8
Paritybit:N
Stopbit:1
Datastream:NON
c. InputyourinstructionandfinishwithEnterbuttononthe
Keyboard.Bothcapitalandsmalllettersoftheinstructionare
fine.
PleaseinputnextinstructioninthreesecondsortheOvertime
instructionwillappear.
Theinputinstructionshouldberight,oryouwillberejected
withthewronginstruction,
Iftheinputoroutputthatyouchoseisnotconnectedto
devicesornotinpower‐onmode,ineffectiveinstructionwill
informyou.
Ifyourinstructionisperformed,youcanseetheinstructionof
successfuloperation.


6
‐Instructionfunction
ON:Turningontheproduct
OFF:Turningofftheproduct
QS:Thisorderenablesyouknowwhichinputandoutputare
availableandtheconnectionsofinputandoutput.
DP1:Selectsource1asinput,SelectDisplayPortasoutput
DP2:Selectsource2asinput,SelectDisplayPortasoutput
HDMI1:Selectsource1asinput,SelectHDMIasoutput
HDMI2:Selectsource2asinput,SelectHDMIasoutput

7
