C8051F912 DEVELOPMENT KIT USER’SGUIDE
1. Relevant Devices
The C8051F912 Development Kit is intended as a development platform for the microcontrollers in the
C8051F91x-C8051F90x MCU family. The members of this MCU family are C8051F912, C8051F911, C8051F902,
and C8051F901.
Notes:
1. The target board included in this kit is provided with a pre-soldered C8051F912 MCU (QSOP24 package).
2. Code developed on the C8051F912 can be easily ported to the other members of this MCU family.
3. Refer to the C8051F91x-C8051F90x data sheet for the differences between the members of this MCU family.
2. Kit Contents
The C8051F912 Development Kit contains the following items:
C8051F912 Target Board
C8051Fxxx Development Kit Quick-Start Guide
Silicon Laboratories IDE and Product Information CD-ROM. CD content includes the following:
Silicon Laboratories Integrated Development Environment (IDE)
Keil 8051 Development Tools (macro assembler, linker, evaluation C compiler)
Source code examples and register definition files
Documentation
C8051F912 Development Kit User’s Guide (this document)
AC to DC Power Adapter
USB Debug Adapter (USB to Debug Interface)
2 USB Cables
2 AAA Batteries
Figure 1. C8051F912 Target Board
Downloaded from Elcodis.com electronic components distributor

C8051F912-DK
2 Rev. 0.1
3. Software Overview
All software required to develop firmware and communicate with the target microcontroller is included in the CD-
ROM. The CD-ROM also includes other useful software.
Below is the software necessary for firmware development and communication with the target microcontroller:
Silicon Laboratories Integrated Development Environment (IDE)
Keil 8051 Development Tools (macro assembler, linker, evaluation C compiler)
Other useful software that is provided in the CD-ROM includes the following:
Configuration Wizard 2
Keil µVision Drivers
CP210x USB to UART Virtual COM Port (VCP) Drivers
3.1. Software Installation
The included CD-ROM contains the Silicon Laboratories Integrated Development Environment (IDE), Keil software
8051 tools and additional documentation. Insert the CD-ROM into your PC’s CD-ROM drive. An installer will
automatically launch, allowing you to install the IDE software or read documentation by clicking buttons on the
Installation Panel. If the installer does not automatically start when you insert the CD-ROM, run autorun.exe found
in the root directory of the CD-ROM. Refer to the ReleaseNotes.txt file on the CD-ROM for the latest information
regarding known problems and restrictions. After installing the software, see the following sections for information
regarding the software and running one of the demo applications.
3.2. CP210x USB to UART VCP Driver Installation
The C8051F912 Target Board includes a Silicon Laboratories CP2103 USB-to-UART Bridge Controller. Device
drivers for the CP2103 need to be installed before PC software such as HyperTerminal can communicate with the
target board over the USB connection. If the "Install CP210x Drivers" option was selected during installation, this
will launch a driver “unpacker” utility.
1. Follow the steps to copy the driver files to the desired location. The default directory is C:\SiLabs\MCU\CP210x.
2. The final window will give an option to install the driver on the target system. Select the “Launch the CP210x
VCP Driver Installer” option if you are ready to install the driver.
3. If selected, the driver installer will now launch, providing an option to specify the driver installation location. After
pressing the “Install” button, the installer will search your system for copies of previously installed CP210x
Virtual COM Port drivers. It will let you know when your system is up to date. The driver files included in this
installation have been certified by Microsoft.
4. If the “Launch the CP210x VCP Driver Installer” option was not selected in step 3, the installer can be found in
the location specified in step 2, by default C:\SiLabs\MCU\CP210x\Windows_2K_XP_S2K3_Vista. At this
location run CP210xVCPInstaller.exe.
5. To complete the installation process, connect the included USB cable between the host computer and the USB
connector (P3) on the C8051F912 Target Board. Windows will automatically finish the driver installation.
Information windows will pop up from the taskbar to show the installation progress.
6. If needed, the driver files can be uninstalled by selecting “Silicon Laboratories CP210x USB to UART Bridge
(Driver Removal)” option in the “Add or Remove Programs” window.
3.3. Silicon Laboratories IDE
The Silicon Laboratories IDE integrates a source-code editor, a source-level debugger, and an in-system Flash
programmer. See Section 5. "Using the Keil Software 8051 Tools with the Silicon Laboratories IDE‚" on page 9 for
detailed information on how to use the IDE. The Keil Evaluation Toolset includes a compiler, linker, and assembler
and easily integrates into the IDE. The use of third-party compilers and assemblers is also supported.
3.3.1. IDE System Requirements
The Silicon Laboratories IDE requirements:
Pentium-class host PC running Microsoft Windows 2000 or newer
One available USB port
64 MB RAM and 40 MB free HD space recommended
Downloaded from Elcodis.com electronic components distributor

C8051F912-DK
Rev. 0.1 3
3.3.2. 3rd Party Toolsets
The Silicon Laboratories IDE has native support for many 8051 compilers. The full list of natively supported tools is
as follows:
Keil
IAR
Raisonance
Tasking
Hi-Tech
SDCC
The demo applications for the C8051F912 target board are written to work with the Keil and SDCC toolsets.
3.4. Keil Evaluation Toolset
3.4.1. Keil Assembler and Linker
The Keil demonstration toolset assembler and linker place no restrictions on code size.
3.4.2. Keil Evaluation C51 C Compiler
The evaluation version of the C51 compiler is the same as the full version with the following limitations: (1)
Maximum 4 kB code generation, (2) There is no floating point library included. When installed from the CD-ROM,
the C51 compiler is initially limited to a code size of 2 kB, and programs start at code address 0x0800. Refer to
“AN104: Integrating Keil Tools into the Silicon Labs IDE" for instructions to change the limitation to 4 kB and have
the programs start at code address 0x0000.
Downloaded from Elcodis.com electronic components distributor

C8051F912-DK
4 Rev. 0.1
3.5. Configuration Wizard 2
The Configuration Wizard 2 is a code generation tool for all of the Silicon Laboratories devices. Code is generated
through the use of dialog boxes for each of the device's peripherals.
Figure 2. Configuration Wizard 2 Utility
The Configuration Wizard utility helps accelerate development by automatically generating initialization source
code to configure and enable the on-chip resources needed by most design projects. In just a few steps, the wizard
creates complete startup code for a specific Silicon Laboratories MCU. The program is configurable to provide the
output in C or assembly language. For more information, refer to the Configuration Wizard documentation.
Documentation and software is available on the kit CD and from the downloads webpage: www.silabs.com/
mcudownloads.
Downloaded from Elcodis.com electronic components distributor

C8051F912-DK
Rev. 0.1 5
3.6. Silicon Labs Battery Life Estimator
The Battery Life Estimator is a system design tool for battery operated devices. It allows the user to select the type
of battery they are using in the system and enter the supply current profile of their application. Using this
information, it performs a simulation and provides an estimated system operating time. The Battery Life Estimator
is shown in Figure 3.
Figure 3. Battery Life Estimator Utility
From Figure 3, the two inputs to the Battery Life Estimator are battery type and discharge profile. The utility
includes battery profiles for common battery types such as AAA, AA, A76 Button Cell, and CR2032 coin cell. The
discharge profile is application-specific and describes the the supply current requirements of the system under
various supply voltages and battery configurations. The discharge profile is independent of the selected power
source. Several read-only discharge profiles for common applications are included in the pulldown menu. The user
may also create a new profile for their own applications.
To create a new profile:
1. Select the profile that most closely matches the target application or choose the "Custom Profile".
2. Click Manage
3. Click Duplicate
4. Click Edit
Profiles may be edited with the easy-to-use GUI (shown in Figure 4).
Downloaded from Elcodis.com electronic components distributor

C8051F912-DK
6 Rev. 0.1
Figure 4. Battery Life Estimator Discharge Profile Editor
The Discharge Profile Editor allows the user to modify the profile name and description. The four text entry boxes
on the left hand side of the form allow the user to specify the amount of time the system spends in each power
mode. On the right hand side, the user may specify the supply current of the system in each power mode.
Since supply current is typically dependent on supply voltage, the discharge profile editor provides two columns for
supply current. The V2 and V1 voltages at the top of the two columns specify the voltages at which the current
measurements were taken. The Battery Life Estimator creates a linear approximation based on the input data and
is able to feed the simulation engine with an approximate supply current demand for every input voltage.
The minimum system operating voltage input field allows the system operating time to stop increasing when the
simulated battery voltage drops below a certain threshold. This is primarily to allow operating time estimates for
systems that cannot operate down to 1.8 V, which is the voltage of two fully drained single-cell batteries placed in
series.
Downloaded from Elcodis.com electronic components distributor

C8051F912-DK
Rev. 0.1 7
The wakeup frequency box calculates the period of a single iteration through the four power modes and displays
the system wake up frequency. This is typically the "sample rate" in low power analog sensors.
Once the battery type and discharge profile is specified, the user can click the "Simulate" button to start a new
simulation. The simulation engine calculates the estimated battery life when using one single-cell battery, two
single-cell batteries in series, and two single-cell batteries in parallel. Figure 5 shows the simulation output window.
Figure 5. Battery Life Estimator Utility Simulation Results Form
The primary outputs of the Battery Life Estimator are an estimated system operating time and a simulated graph of
battery voltage vs. time. Additional outputs include estimated battery capacity, average current, self-discharge
current, and the ability to export graph data to a comma delimited text file for plotting in an external graphing
application.
Downloaded from Elcodis.com electronic components distributor

C8051F912-DK
8 Rev. 0.1
3.7. Keil µVision2 and µVision3 Silicon Laboratories Drivers
As an alternative to the Silicon Laboratories IDE, the µVision debug driver allows the Keil µVision2 and µVision3
IDEs to communicate with Silicon Laboratories’ on-chip debug logic. In-system Flash memory programming
integrated into the driver allows for rapid updating of target code. The µVision2 and µVision3 IDEs can be used to
start and stop program execution, set breakpoints, check variables, inspect and modify memory contents, and
single-step through programs running on the actual target hardware. For more information, refer to the µVision
driver documentation. The documentation and software are available on the kit CD and from the downloads
webpage: www.silabs.com/mcudownloads.
4. Hardware Setup using a USB Debug Adapter
The target board is connected to a PC running the Silicon Laboratories IDE via the USB Debug Adapter as shown
in Figure 6.
1. Connect the USB Debug Adapter to the DEBUG connector on the target board with the 10-pin ribbon cable.
2. Connect one end of the USB cable to the USB connector on the USB Debug Adapter.
3. Verify that a shorting block is installed on J17 and that SW5 is in the ON position.
4. Connect the other end of the USB cable to a USB Port on the PC.
5. Connect the ac/dc power adapter to power jack P2 on the target board (Optional).
Notes:
Use the Reset button in the IDE to reset the target when connected using a USB Debug Adapter.
Remove power from the target board and the USB Debug Adapter before connecting or disconnecting the
ribbon cable from the target board. Connecting or disconnecting the cable when the devices have power can
damage the device and/or the USB Debug Adapter.
Figure 6. Hardware Setup using a USB Debug Adapter
PC
USB
Cable
AC/DC
Adapter
Target Board
P0.2 P0.3
J3
J4
J2
`
P3
CP
2103
U3
P2
DEBUG
J9
USB POWER
RESET
P1.6
P1.5
POWER OFF BEFORE
SW4
SWITCHING MODE
2 CELL 1 CELL
J17
IMEASURE
H2
SILICON LABS
www.silabs.com
H1
J6 VDD/DC+
J5
J7 J13
F912
U1
J14
J11
J10
VBAT
WALL_PWR
AAA_BAT
COIN_CELL
TOUCH SENSE SWITCH
P2.0 TOUCH SENSE SWITCH P2.1
J15
J16
R15
J12J8
+3VD
+1VD
VBAT
J1
SW5
ON
OFF
Silicon Laboratories
USB DEBUG ADAPTER
Run
Stop Power
USB Debug
Adapter
Downloaded from Elcodis.com electronic components distributor

C8051F912-DK
Rev. 0.1 9
5. Using the Keil Software 8051 Tools with the Silicon Laboratories IDE
To perform source-level debugging with the IDE, configure the Keil 8051 tools to generate an absolute object file in
the OMF-51 format with object extensions and debug records enabled. Build the OMF-51 absolute object file by
calling the Keil 8051 tools at the command line (e.g., batch file or make file) or by using the project manager built
into the IDE. The default configuration when using the Silicon Laboratories IDE project manager enables object
extension and debug record generation.
Refer to "AN104: Integrating Keil 8051 Tools into the Silicon Labs IDE" in
the “SiLabs\MCU\Documentation\ApplicationNotes” directory on the CD-ROM for additional information on using the
Keil 8051 tools with the Silicon Laboratories IDE.
To build an absolute object file using the Silicon Laboratories IDE project manager, you must first create a project.
A project consists of a set of files, IDE configuration, debug views, and a target build configuration (list of files and
tool configurations used as input to the assembler, compiler, and linker when building an output object file).
The following sections illustrate the steps necessary to manually create a project with one or more source files,
build a program, and download it to the target in preparation for debugging. (The IDE will automatically create a
single-file project using the currently open and active source file if you select Build/Make Project before a project is
defined.)
5.1. Creating a New Project
1. Select ProjectNew Project to open a new project and reset all configuration settings to default.
2. Select FileNew File to open an editor window. Create your source file(s) and save the file(s) with a
recognized extension, such as .c, .h, or .asm, to enable color syntax highlighting.
3. Right-click on “New Project” in the Project Window. Select Add files to project. Select files in the file browser
and click Open. Continue adding files until all project files have been added.
4. For each of the files in the Project Window that you want assembled, compiled and linked into the target build,
right-click on the file name and select Add file to build. Each file will be assembled or compiled as appropriate
(based on file extension) and linked into the build of the absolute object file.
5. If a project contains a large number of files, the “Group” feature of the IDE can be used to organize. Right-click
on “New Project” in the Project Window. Select Add Groups to project. Add pre-defined groups or add
customized groups. Right-click on the group name and choose Add file to group. Select files to be added.
Continue adding files until all project files have been added.
Downloaded from Elcodis.com electronic components distributor

C8051F912-DK
10 Rev. 0.1
5.2. Building and Downloading the Program for Debugging
1. Once all source files have been added to the target build, build the project by clicking on the Build/Make Project
button in the toolbar or selecting ProjectBuild/Make Project from the menu.
Note: After the project has been built the first time, the Build/Make Project command will only build the files that
have been changed since the previous build. To rebuild all files and project dependencies, click on the Rebuild
All button in the toolbar or select ProjectRebuild All from the menu.
2. Before connecting to the target device, several connection options may need to be set. Open the Connection
Options window by selecting OptionsConnection Options... in the IDE menu. First, select the appropriate
adapter in the “Serial Adapter” section. Next, the correct “Debug Interface” must be selected. C8051F91x-
C8051F90x family devices use the Silicon Labs 2-wire (C2) debug interface. Once all the selections are made,
click the OK button to close the window.
3. Click the Connect button in the toolbar or select DebugConnect from the menu to connect to the device.
4. Download the project to the target by clicking the Download Code button in the toolbar.
Note: To enable automatic downloading if the program build is successful select Enable automatic connect/
download after build in the ProjectTarget Build Configuration dialog. If errors occur during the build process,
the IDE will not attempt the download.
5. Save the project when finished with the debug session to preserve the current target build configuration, editor
settings and the location of all open debug views. To save the project, select ProjectSave Project As... from
the menu. Create a new name for the project and click on Save.
Downloaded from Elcodis.com electronic components distributor
