Silux Control Thermo Stabilzer User manual

OPERATION MANUAL
SC-TS01
Thermo Stabilzer

Appendix I:
1. Introduction to Silux Control®
2. Introduction to the Thermo Stabilizer®
3. Applications
4. Electrical Specifications
5. Instructions
I. Installing the Thermo Stabilizer®
II. Replacing the CR2032 3V battery
III. How to pair with your smart device
IV. How to pair with Touch Lamina®
6. Hubcentric Topology
7. What is a Trigger
8 Factory Reset
9. Safety precautions
10. Versions and Changes
11. More Silux Control ®automation products
Appendix II:
1. Troubleshooting
2. Warranty
I. What this warranty covers
II. What period does this warranty cover
III. What Silux®will do to correct any problems
IV. What is not covered by this warranty
3. Support
4. Disclaimer of Liability

Appendix I:
1. Introduction to Silux Control®
PLEASE NOTE: You are not able to connect directly to the
Thermo Stabilizer®.You will be required to connect to the
Intellihub®to ensure you can control all devices via the Intellihub®
and Silux Control®app.
The idea behind the Silux Control® automation series is to have a
fully automated lifestyle. No longer will you need to push a button
to switch on appliances or lights; it will simply be switched on for
you with motion, schedules and scenes. You can schedule your
geyser or water heater to turn on and set it to the temperature you
wish. Your irrigation system can be automated, and so much more
can be controlled. The sky is the limit, and all this under one app,
all controlled from one place. You can create scenes or even
control a couple of appliances from the convenience of your living
room or anywhere across the world using any smart device
running Android or iOS. At Silux Control®, we tried to keep our
products as affordable as possible, without compromising quality.
Our devices are specially designed to make it as easy as possible
to install with easy usability and a wide range of applications. With
encrypted data control, you are also protected from the outside
world, providing you with peace of mind. We have thought of
everything. What are you waiting for? Install Silux Control®and let
us help you control your world safely, securely, and efficiently.
2. Introduction to Thermo Stabilizer®
The Thermo Stabilizer®is one of the many useful and wonderful
products that form part of the the Silux Control®automation series.
The purpose of this product is to control and monitor your geyser /
water heater from your smart device. The Thermo Stabilizer©can
also be controlled with the Touch Lamina©and the Seeker©which
will be explained at a later stage.
Warning: Please follow all safety precautions when installing this
product. It is always recommended to use a qualified electrician.
Silux Control® and its distributors and resellers cannot be held
responsible for any injury or death.
3. Application
The Thermo Stabilizer©was designed mainly to control and
monitor your geyser / water heater, but can also be used to control
other devices with a high wattage rating.
4. Electrical Specifications
Power supply Operating Voltages: 110V AC – 230V AC
Power supply Frequency Range: 50Hz ~ 60Hz
Maximum Switching Power: Output A = 4000W
Output B = 4000W
Wire Thickness 2.5mm - 3mm
Operating Temperatures: -5°C – 60°C
5. Instructions

Warning: Please follow all safety precautions when installing this
product. It is always recommended to use a qualified electrician.
Silux Control® and its distributors and resellers cannot be held
responsible for any injury or death.
3. Application
The Thermo Stabilizer©was designed mainly to control and
monitor your geyser / water heater, but can also be used to control
other devices with a high wattage rating.
4. Electrical Specifications
Power supply Operating Voltages: 110V AC – 230V AC
Power supply Frequency Range: 50Hz ~ 60Hz
Maximum Switching Power: Output A = 4000W
Output B = 4000W
Wire Thickness 2.5mm - 3mm
Operating Temperatures: -5°C – 60°C
5. Instructions AB
STATUS
Device Device
Mains
2
3
OFF
1
Screw
holes
Thermo Stabilizer
Output A
Status
Output B Red light
Status/Power
Green light
Device 1 connected
Green light
Device 2 connected
Thermo Stabilizer
IntelliHub®
Smart Device
Running
Silux Control®App
ON
6
5
Mounting
holes
4

I. Installing the Thermo Stabilizer®
1. Ensure that the main switch to the device you wish to control
is off.
2. Cut the wire going to the device and strip a small piece of the
insulation plastic from all the wires. No wire should be exposed.
3. Unscrew the plastic cover and push the wire coming from the
mains (110V ~ 230V) through the centre gland and the wire
going to the Thermo Stabilizer
®
to the output A terminal and tighten
the screws.
4. Remove your current thermal couple from your water heater and
replace it with the supplied Silux
©
thermal couple. Push the
connector coming from the Silux
©
thermal couple through the small
gland and plug it into the socket on the Thermo Stabilizer
©
.
*Please Note: The thermal couple is necessary to get live
temperature readings and keep the water at the selected
temperature.
5. Tighten all the glands and screw the plastic cover back on
again. You can mount the Thermo Stabilizer
®
to a desired location
using the mounting holes on the side of the Thermo Stabilizer
®
with
the supplied plugs and screws.
6. Turn the main switch to this device on. The RED light on the
front of the device will switch on. This means the Thermo
Stabilizer
®
has power.
*Please Note:
There is a green light for output A and a green
light for output B of the Thermo Stabalizer®which switches on
to show the corresponding devices is on.
II. Replacing the CR2032 3V battery
There will be one CR2032 battery included with the product. This
battery is used to keep time and date as well as schedules in case of
power disruptions.The battery will have a life span of up to 1-2 years,
depending on how the
Thermo Stabilizer
®is used.
We recomend switching the
Thermo Stabilizer
®’s power off before
changing the battery.

I. Installing the Thermo Stabilizer®
1. Ensure that the main switch to the device you wish to control
is off.
2. Cut the wire going to the device and strip a small piece of the
insulation plastic from all the wires. No wire should be exposed.
3. Unscrew the plastic cover and push the wire coming from the
mains (110V ~ 230V) through the centre gland and the wire
going to the Thermo Stabilizer
®
to the output A terminal and tighten
the screws.
4. Remove your current thermal couple from your water heater and
replace it with the supplied Silux
©
thermal couple. Push the
connector coming from the Silux
©
thermal couple through the small
gland and plug it into the socket on the Thermo Stabilizer
©
.
*Please Note: The thermal couple is necessary to get live
temperature readings and keep the water at the selected
temperature.
5. Tighten all the glands and screw the plastic cover back on
again. You can mount the Thermo Stabilizer
®
to a desired location
using the mounting holes on the side of the Thermo Stabilizer
®
with
the supplied plugs and screws.
6. Turn the main switch to this device on. The RED light on the
front of the device will switch on. This means the Thermo
Stabilizer
®
has power.
*Please Note:
There is a green light for output A and a green
light for output B of the Thermo Stabalizer®which switches on
to show the corresponding devices is on.
II. Replacing the CR2032 3V battery
There will be one CR2032 battery included with the product. This
battery is used to keep time and date as well as schedules in case of
power disruptions.The battery will have a life span of up to 1-2 years,
depending on how the
Thermo Stabilizer
®is used.
We recomend switching the
Thermo Stabilizer
®’s power off before
changing the battery.
1. Open the plastics with a star screw driver.
2. Pop out the old CR2032 battery and replace it with the new
CR2032 battery.
3. Place the
Thermo Stabilizer
©
cover back over the plastics and
screw tight.
*Please Note: It’s not necessary to pair the Silux Control®
devices again after replacing the battery.
III. How to pair with your smart device:
Please remember that the IntelliHub®needs to be powered to be
able to control the
Thermo Stabilizer
©
from your smart device.
Please refer to the user manual of the IntelliHub®for pairing the
Thermo Stabilizer
©
to your Android or iOS device.
IV. How to pair with the Touch Lamina
©
Take note: When pairing directly to the Thermo Stabilizer
©
the
button only controls Output A.
1. A red light will indicate that the the
Thermo Stabilizer
©
has
power. Press the Teach button on the
Thermo Stabilizer
©
. The
green light on the
Thermo Stabilizer
©
will start flashing.
2. Ensure the Touch Lamina
©
has power. Press the Teach button
on the Touch Lamina
©
. The green light on the Touch Lamina®
will start flashing.
3. Tap the button on the Touch Lamina®corresponding to the
Silux®device you wish to pair with this device. The green light
will switch off on both devices after successfully paired.
If the green light stays on, the pairing was unsuccessful
and you should wait for 30 seconds for the green light to
go off before trying again.
Please refer to the Touch Lamina®and Seeker®manuals
regarding controlling your
Thermo Stabilizer
©
from network
paired devices.

TV
TV
Water Heater
IntelliHub
Tier 1 Tier 2 Tier 3
6. Hubcentric topology.
Your Silux Control®automation system uses a technology known as
Hubcentric topology. This means that all your devices communicate with
each other. In larger areas, it is possible that a device might be too far
from the IntellihHub®to communicate reliably. Your IntelliHub®will then
use other devices which are more in range to create a more reliable
connection to the out of range device. The distance at which your
IntelliHub®can communicate with your Silux Control®devices varies
according to the environment. The IntelliHub®has been developed to
achieve a distance of 20m, however, thick walls, large electrical
appliances and long distances are 3 factors that can limit communication
with Silux Control®devices. Use the “diagnostics” section of your Silux
Control®app to diagnose any issues you might be experiencing with
communication on your Silux Control®Network.
7. What is a Trigger:
An ‘trigger’ is a device, used to control a Silux Control
®
device. Think
of it as a remote control. This device will only be on for a brief period
of time while sending the command to your Silux Control
®
device and
will go back into sleep mode if the command was successful. Since
this device will be in sleep mode, most of the time, it doesn’t form part
of the intercommunication system. Please see the diagram above for
the intercommunication system.
*Please Note: The Seeker®and Touch Lamina®are examples of end
points.
8. Factory Reset:
This function will remove all paired devices and restore the settings to
the original state. Press and hold the Teach button on the
Thermo
Stabilizer
©
for 5 consecutive seconds. On the 5th second, the light will
flash 3 times. Your device will now be restored to its default state.

9. Safety precautions
• Always make sure the power source is off before
installing or repairing this product. Switch main power off at circuit
breaker if uncertain.
• Treat this device as if it’s live or energized even if there is no
power or indication lights on.
• Screw the plastic cover back on before switching this device on.
• Always use insulating tools when working with or installing this
device.
• Avoid cold rooms or other areas with a high humidity.
• If water or any chemical is spilt on this device, please shut the
main switch or circuit breaker off.
• Never handle this product when hands, feet or body are wet or
when standing on a wet floor.
• When electrocuted, consult a doctor.
• Keep highly flammable liquids away from this device.
• Do research about wire insulating colour codes for your country.
• Please consult a qualified electrician.
Warning: Please follow all safety precautions when installing
this product. It is always recommended to use a qualified
electrician. Silux Control®and its distributors and resellers
cannot be held responsible for any injury or death.

10. Versions and changes
Currently, there is only one variant of this product. In the future,
this might change or new types of
Thermo Stabilizer
© ’s may join
the family.
At Silux Control® , we implemented an over-the-air firmware update
for the
Thermo Stabilizer
©
to ensure that the Thermo Stabilizer
©
is
always compatible with the latest Silux Control®devices.
The
Thermo Stabilizer
©
Model no: SC-TS01
User Manual Revision No: TS01.1
This user manual may be outdated.
Please visit our website at www.siluxcontrol.com for updated
models & versions, updated user manuals, future products and to
see the rest of the wonderful products Silux®has to offer.
11. More Silux Control®automation products
Product Silux Control®Name
Hub IntelliHub®
Relay Module Dry contact Collector®
Relay Module Collector Relay®
Relay Module Dimmable Collector Dimmable®
Repeater/Range Extender Silux RPT®
PIR Sensor Seeker®
Touch Plate EU/SA Touch Lamina Altus®
Touch Plate USA Touch Lamina Artatus®
Plug Electrifier®
Smoke/Gas Detector Halitus®
Water Heater / Geyser Thermo Stabilizer®
High Power Appliances Tolleno®
Irrigation Saturizer®
Garage Tilt Tylten Pro®
Smart Switch Smart Module®
RGB Globe Spektra Globe®
RGB Downlight Spektra Downlight®
*Please note: Not all the products on this list are available yet,
but will become available in the near future. This list can
change at any time. Please refer to www.siluxcontrol.com for
new and discontinued products. New products will be added in
time.

Appendix II
1. Troubleshooting
Please visit our website at www.siluxcontrol.com/FAQ for detailed list of all the
Frequently Asked Questions.
• Ensure that the power going to the device is on.
• Ensure that all the wires are connected to their proper places
• Ensure that the RED Light is on.
• Ensure that the GREEN Light on the front switches on and off when
switching with the app or Touch Lamina®.
• Ensure that the Light flashes when pressing the Teach button.
• Ensure the IntelliHub®is on and connected to your local network.
• Verify that you have the latest app installed on your smart device.
• Verify that the Silux® device is added to your device list when using the app.
• Verify that you have the correct Silux®device selected when on the app.
• Verify that you have the latest firmware installed on the IntelliHub®.
2. Warranty
I. What this warranty covers:
Silux Control®warrants to the original purchaser of this Silux Control®product
that the product shall be free from defects in design, assembly, material, or
workmanship under normal use and operation.
Silux Control®‘s sole and exclusive obligation under the foregoing warranty shall
be to repair or replace, at its option, any defective product that fails during the
warranty period. The expense of removal and reinstallation of any item is not
included in this warranty.
WARNING: Silux Control®and its distributors and resellers cannot be held
responsible for any damages this product might have caused including
3rd party damages.
II. What period does this warranty cover:
Silux Control®warrants this product for 12 months.
III. What Silux Control®will do to correct any problems:
Silux Control®will repair or replace, at its option, any defective product free of
charge (except for shipping charges for this product). Silux Control®reserves the
right to discontinue any of its products without notice and disclaims any limited
warranty to repair or replace any such discontinued products.

Appendix II
1. Troubleshooting
Please visit our website at www.siluxcontrol.com/FAQ for detailed list of all the
Frequently Asked Questions.
• Ensure that the power going to the device is on.
• Ensure that all the wires are connected to their proper places
• Ensure that the RED Light is on.
• Ensure that the GREEN Light on the front switches on and off when
switching with the app or Touch Lamina®.
• Ensure that the Light flashes when pressing the Teach button.
• Ensure the IntelliHub®is on and connected to your local network.
• Verify that you have the latest app installed on your smart device.
• Verify that the Silux® device is added to your device list when using the app.
• Verify that you have the correct Silux®device selected when on the app.
• Verify that you have the latest firmware installed on the IntelliHub®.
2. Warranty
I. What this warranty covers:
Silux Control®warrants to the original purchaser of this Silux Control®product
that the product shall be free from defects in design, assembly, material, or
workmanship under normal use and operation.
Silux Control®‘s sole and exclusive obligation under the foregoing warranty shall
be to repair or replace, at its option, any defective product that fails during the
warranty period. The expense of removal and reinstallation of any item is not
included in this warranty.
WARNING: Silux Control®and its distributors and resellers cannot be held
responsible for any damages this product might have caused including
3rd party damages.
II. What period does this warranty cover:
Silux Control®warrants this product for 12 months.
III. What Silux Control®will do to correct any problems:
Silux Control®will repair or replace, at its option, any defective product free of
charge (except for shipping charges for this product). Silux Control®reserves the
right to discontinue any of its products without notice and disclaims any limited
warranty to repair or replace any such discontinued products.
IV. What is not covered by this warranty
Upon claiming this warranty, all above warranties are null and void
if the purchased Silux Control®product is not returned for an
authorized inspection, at the sole expense of the purchaser, or if
Silux Control®determines that the Silux Control®product has been
improperly installed, altered in any way, or opened/tampered with.
The Silux Control®product warranty does not protect against
instances of uncontrollable natural disasters such as flood,
lightning, earthquake, war, vandalism, theft, normal use wear and
tear, erosion, depletion, obsolescence, physical damage, water
damage, damage due to low voltage disturbances (i.e. brownouts
or sags), non-authorized program, or system equipment
modification or alteration.
3. Support
Please visit our website at www.siluxcontrol.com for any other
support, products, future products, and updated user manuals.
4. Disclaimer of Liability
Please read this user manual thoroughly before using the
product. Follow all safety precautions when installing this
product. It is always recommended to use a qualified
electrician.
Under no circumstances shall Silux Control®or its associates
be liable for any direct, indirect, incidental, special or
consequential damage that results from the use of or inability
to use the Silux Control®products. By using the IntelliHub®or
any other Silux Control®Automation products, you expressly
agree that the use of these products are at own risk. Neither
Silux Control®nor its affiliates, subsidiaries, or designees nor
each of their respective officers, directors, employees,
agents, third party content providers, designers, contractors,
distributors, merchants, sponsors or licensors can be held
responsible for any injury, death or damages this product
might have caused.

Download Our Free Silux Control App
Google Play App Store
Available on
or in the User Manual of the product under the Warranty secon.
SILUX WARRANTY CARD
The full text of warranty is available on our website
www.siluxcontrol.com
Please take a moment to fill out your informaon
.
Please return the warranty card with defective product and the sales receipt as
proof of the date purchase.
Warranty cannot be carried out without it.
Product:
Model No:
Serial No:
Date of Purchase:
Name:
Surname:
E-Mail Address:
Phone No: +
Address:
Country:
D D M M Y E A R
Cut Here
