Silver SD100 Instruction manual

SD100
Counterfeit Bill/
Document Validator
www.SILVERMoneyCounters.com
QUICK USER GUIDE
Manual Detection
UV LED Light
Lightweight

Important Safety Instructions
This device has been designed to operate with the specific
5V 2A Power Adaptor (included). Failing to use the included
adaptor may cause malfunction and may void the warranty.
•Avoid looking directly at the super-bright ultraviolet LEDs
hidden inside the unit.
•Avoid operating the unit near or under strong natural or
artificial light sources. The effect of the UV light will be
overpowered, and it will affect the UV feature’s fluorescence.
Installation
Box Contents
1. UV Validator 4. User Guide
2. Power Adapter (5V 2A) 5. Warranty Booklet
3. USB Charging Cable 6. Rechargeable Battery
1. Install the rechargeable
battery correctly, as
shown in the image.
(Sold separately)
3. Turn on the unit using the
power switch.
NOTA: The light will only turn on as long as the sensor is activated.
2. Connect the 5V 2A power
adaptor to the electrical
outlet and then to the equi-
pment using the USB cable.
4. To activate the UV LED light,
place the bill or document
in the inspection area.
Power Switch Sensor

Operation
To use the unit appropriately and efficiently, we recommend
that the user familiarize themselves with the ultraviolet
security features of the bills or ocuments they want to
analyze. In doing so, the ultraviolet security features will be
highlighted and easily recognizable by the user(s). The UV
reaction may differ depending on the side being analyzed
(for bills or documents that have UV security features visible
from both sides). For this reason, we recommend analyzing
both sides of the bill or document.
Place the banknote or document in the verification area, and
try to activate the automatic sensor with the banknote itself
while positioning it. The detector has an internal timer that
turns off the light a few seconds after the bill is removed. It
also has a protection mode that will deactivate the UV light
if the lamp is in continuous use for more than 3 minutes. If
you need more time to continue examining the banknote,
simply remove the banknote from the activation sensor and
reposition it to activate the light again.
NOTE: The detector includes a “Security Thread
Identification” label that shows the operator the COLOR and
POSITION of the security thread embedded on the U.S.
dollar bill for every specific denomination. Use the following
image as a reference. Please keep in mind that, for the
operator to validate the bill, the security thread must
match the approximate position and color shown on the
“Security Thread Identification” label.
www.SILVERMoneyCounters.com

Cleaning and Maintenance
•Do not use the unit near strong natural or artificial light
sources, as this will minimize the desired effect of the
ultraviolet light.
•Do not use the unit where it may be exposed to water or
other liquids.
•Dust may collect near the UV detector, in which case it is
recommended to clean it with a soft, damp cloth.
•Do not use liquid or aerosol cleaners.
•Do not use the unit if it or any of its parts have a problem,
as this could cause accidents.
•When not using the unit for a long time, remove the
power plug from the electric outlet.
PRODUCT SPECIFICATIONS
Temperature 32 - 104 °F (0 - 40 °C)
Power Source INPUT: 100 - 240 VAC 60/50 Hz
OUTPUT: 5VDC / 2.0 A
UV Light Source Super-Bright UV LEDs
UV LED Light Lifetime Long-Lasting
10,000 hours
Power Consumption 6 Watts Max.
Certifications CE
Product Dimensions 8 x 4.1 x 4.1 in
(20.2 x 10.5 x 10.5 cm)
Product Weight 1 lb (0.45 kg)
*Manual detectors will require you to look for the security features yourself
using the technology the detector supplies. There are many tools that provide
a manual counterfeit detection guide so you can spot key discrepancies
between fake and real bills.
1-888-993-2228 · 7104 NW 50 Street, MIAMI, FL 33166 USA
