Silvercrest SHBS 3.7 C1 User manual

HOYER Handel GmbH
Tasköprüstraße 3
DE-22761 Hamburg
DEUTSCHLAND
Status of information · Informationernes stand · Version des informations
Stand van de informatie · ǾȝİȡȠȝȘȞȓĮȑțįȠıȘȢʌȜȘȡȠijȠȡȚȫȞ
Stand der Informationen:
5IN1 HAIR AND BEARD TRIMMER SHBS|3.7|C1
Bedienungsanleitung
HAAR- UND
BARTSCHNEIDER 5IN1
DE
AT
CH
IAN 288911
Mode d'emploi
TONDEUSE À BARBE ET À
CHEVEUX 5 EN 1
FR
BE
IAN 288911
11/2017 ID: SHBS 3.7 C1_17_V1.4
FR
NL
BE DE CY
GB
IE
NI
DK
Gebruiksaanwijzing
HAAR- EN BAARDTRIMMER
5IN1
NL
BE
Operating instructions
5IN1 HAIR AND BEARD
TRIMMER
GB
IE
NI
CY
Betjeningsvejledning
HÅR-OGSKÆGTRIMMER
5 I 1
DK
GB
IE
NI
ȅįȘȖȓĮȤȡȒıȘȢ
ȀȅȊȇǼȊȉǿȀ+ȂǾȋǹȃ+
ȂǹȁȁǿȍȃȀǹǿīǼȃǼǿ$ǻǹȈȈǼ
GR
CY
DK
BE
NL
CY

English.................................................... 2
Dansk................................................... 28
Français................................................ 54
Nederlands........................................... 84
ƧnjnjLjǎNJNjƽ ............................................ 112
Deutsch .............................................. 140

Overview / Oversigt / Aperçu de l'appareil /
Overzicht / ƧǑNJǔNjǝǑLjǔLj / Übersicht

C
B
A
12
3
4
5
6
7
8
11
10
12
14
13
9

2 GB
Contents
1. Overview ................................................. 3
2. Intended purpose ..................................... 5
3. Safety information ................................... 5
4. Items supplied ....................................... 10
5. Charging ................................................ 11
6. Operation .............................................. 12
6.1 Transport safety lock................................ 12
6.2 Changing the cutting attachments.............. 12
6.3 Changing the comb attachments................ 13
6.4 Cutting hair ............................................ 13
6.5 Trimming a beard.................................... 14
6.6 Cutting a hairline..................................... 15
6.7 Shaving.................................................. 15
6.8 Trimming nose and ear hair...................... 16
7. Cleaning and care .................................. 16
8. Storage .................................................. 18
9. Reordering parts .................................... 19
10.Disposal ................................................. 20
11.Troubleshooting ..................................... 21
12.Technical specifications ........................... 22
13.Warranty of the HOYER Handel|GmbH ... 24

3
GB
1. Overview
1Adjustable (3, 4, 5, 6 mm) comb attachment for the beard
trimmer attachment
2Comb attachments for the hair trimmer attachment 3, 6, 9,
12 mm
3Shaving attachment
4Precision trimmer attachment
5Hair and beard trimmer with connection for plug-in power
unit cable/battery charger
6Switch for cutting length fine tuning 1: 0.8 mm /
2: 1.3 mm / 3: 1.8 mm
7On/off switch
8Battery symbol
is lit green: device in operation
flashing green during charging: battery is fully charged
flashes blue 3 times: transport safety lock activated
9Plug symbol
Flashing red: battery almost empty
is lit red during charging: the battery is being charged
10 Power unit
11 Battery charger with charge contact
12 Nose/ear hair trimmer attachment
13 Hair trimmer attachment
14 Beard trimmer attachment

4 GB
not shown:
15 Scissors
16 Blade oil
17 Cleaning brush
18 Comb
19 Storage bag (for the hair and beard trimmer and its acces-
sories)
Thank you for your trust!
Congratulations on your new 5in1 hair and beard trimmer.
For a safe handling of the device and in order to get to know the
entire scope of features:
• Thoroughly read these operating instructions pri-
or to initial commissioning.
• Above all, observe the safety instructions!
• The device should only be used as described in
these operating instructions.
• Keep these operating instructions for reference.
• If you pass the device on to someone else, please
include these operating instructions.
We hope you enjoy your new 5in1 hair and beard trimmer!

5
GB
2. Intended purpose
The 5in1 hair and beard trimmer is intended exclusively for trim-
ming human hair. Only use the device for dry hair.
The device is designed for private home use and must not be used
for commercial purposes. The device must only be used indoors.
Foreseeable misuse
WARNING! Risk of material damage!
~Do not use the device to cut artificial hair or animal hair.
3. Safety information
Warnings
If necessary, the following warnings will be used in these operat-
ing instructions:
DANGER! High risk: failure to observe this warning
may result in injury to life and limb.
WARNING! Moderate risk: failure to observe this warning may
result in injury or serious material damage.
CAUTION: low risk: failure to observe this warning may result
in minor injury or material damage.
NOTE: circumstances and specifics that must be observed when
handling the device.

6 GB
Instructions for safe operation
~ This device can be used by children from the
age of 8 and people with restricted physical,
sensory or intellectual abilities or people with-
out adequate experience and/or understand-
ing, if they are supervised or instructed on how
to use this device safely and if they are aware
of the resulting danger. Children must not play
with the device. Cleaning and maintenance by
the user must not be performed by children
without supervision.
~ This device may be used by children aged
3 years or above with adult supervision.
~ Only use the included original power adaptor
for mains operation.
~WARNING! Keep the device dry.
DANGER for children
~Packing materials are not children's toys. Children should not
be allowed to play with the plastic bags: There is a risk of
suffocation!
~Keep the device out of the reach of children.
DANGER to and from pets and livestock
~Electrical devices can represent a hazard to pets and live-
stock. In addition, animals can also cause damage to the de-

7
GB
vice. For this reason you should keep animals away from
electrical devices at all times.
DANGER! Risk of electric shock due to
moisture
~Protect the device from moisture, water drops and water
splashes.
~Never touch the device with wet hands.
~The device, the battery charger and the power unit must not
fall into water or other liquids and must not be rinsed under
running water.
~If the device has fallen into water, pull out the power unit im-
mediately, and only then remove the device from the water.
Do not use the device again, but have this checked by a spe-
cialist.
~Should liquid enter the device, have it checked before start-
ing the device up again.
~If the device is used in a bathroom, the power unit must be
pulled out after use, as the proximity of water represents a
hazard, even when the device is switched off.
~Installation of a residual current device (FI/RCD) with a rated
residual operating current of no more than 30|mA is recom-
mended to provide additional protection. Ask your electri-
cian for advice. The installation should only be carried out
by a qualified electrician.
DANGER! Risk of electric shock
~Never put the device into operation if there are visible dam-
ages to the device, the battery charger or the cable or if the
device has been dropped before.
~Connect the cable to the device/battery charger before plug-
ging the power unit into a wall socket.

8 GB
~Only connect the power unit to a properly installed, easily
accessible wall socket, the voltage of which corresponds to
the specifications on the rating plate. The wall socket must
continue to be easily accessible after the device is plugged
in.
~Ensure that the cable cannot be damaged by sharp edges or
hot surfaces.
~Ensure that the cable is not trapped or crushed.
~When removing the power unit from the wall socket, always
pull the power unit and never the cable.
~Pull the power unit out of the wall socket, …
… after every use,
… after each charging process,
… if there is a fault,
… before connecting the device to the cable,
… before you clean the device and
… during thunderstorms.
~To avoid any risk, do not make modifications to the device.
Repairs must be carried out by a specialist workshop or the
Service Centre.
DANGER from batteries
~ Protect the battery against mechanical damages. Fire hazard!
~Do not expose the device to direct sunshine or heat. The am-
bient temperature should not be lower than
-10 °C and higher than +40 °C.
~The charge contacts on the device must not be connected by
metallic objects.
~The
battery may only be charged with the original accessory
(power unit).

9
GB
~Should the electrolyte solution leak out of the battery, avoid
contact with eyes, mucous membranes and skin. Rinse imme-
diately with plenty of clean water and consult a doctor. The
electrolyte solution can cause irritation.
~The device is provided with a lithium-ion battery.
- The battery cannot be removed!
- This device must not be opened!
- The device with the installed battery must be disposed of
properly.
WARNING! Risk of injury from cutting
~The points of the comb attachments, the hair trimmer attach-
ment, the beard trimmer attachment and the precision trim-
mer attachment are sharp. Handle with care.
~Do not use the device if the attachment shows damages.
~Switch off the device before pinning up or changing the at-
tachments and each time before cleaning.
WARNING! Risk of injury
~Place the cable in such a way that no one trips over it or
steps on it.
~Do not push the nose/ear hair trimmer attachment too deep
into the nostril or the ear canal.
~Do not use the device on open wounds, cuts, sunburn or blis-
ters.
WARNING! Risk of material damage
~ The battery charger is fitted with non-slip silicon feet. As furni-
ture is coated with a variety of different varnishes and acrylics
and treated with different cleaning agents, we cannot rule out
that some of these substances could damage and soften the
rubber feet. If necessary, place a non-slip mat under the bat-
tery charger.
~Use the original accessories only.

10 GB
~Never place the device on hot surfaces (e.g. hob plates) or
near heat sources or open fire.
~Do not cover the power unit to prevent overheating.
~Do not exert too much pressure on the shaving foil of the
shaving attachment, to avoid damaging the shaving foil.
~Do not detach the shaving foil from the shaving foil frame,
and do not clean it using the brush.
~Do not use any astringent or abrasive cleaning agents.
4. Items supplied
15in1 hair and beard trimmer|5
1Power unit|10
1Battery charger|11
5Interchangeable cutting attachments:
hair trimmer attachment|13
beard trimmer attachment|14
precision trimmer attachment|4
nose/ear hair trimmer attachment|12
shaving attachment|3
4Comb attachments|2for the hair trimmer attachment 3, 6, 9,
12 mm
1Adjustable (3, 4, 5, 6 mm) comb attachment|1for the beard
trimmer attachment|14
1Comb|18
1Scissors|15
1Cleaning brush|17
1Bladeoil|16
1Storage bag (for the hair and beard trimmer and its accesso-
ries)|19
1Operating Instructions

11
GB
5. Charging
NOTES:
• Before first use (without cable), and for every charging pro-
cedure afterwards, charge the hair and beard trimmer|5for
approx. 90 minutes.
• When the batteries are almost empty, the plug symbol|9
flashes in red. The device can then only be used for a short
time without being connected to the electricity supply.
1. Place the battery charger|11 on a level surface.
2. Connect the power unit|10 to the battery charger|11.
3. Switch off the device with the on/off switch|7if necessary.
4. Insert the power unit|10 into a readily accessible wall sock-
et whose voltage matches the voltage stated on the rating
plate.
5. Put the hair and beard trimmer|5into the battery charg-
er|11.
6. The plug symbol|9is lit red and the battery is charged.
When the battery is fully charged, the battery symbol|8
flashes in green. When the battery is fully charged, the de-
vice can be used for approximately 60 minutes without be-
ing connected to the power supply.

12 GB
6. Operation
Regardless of the charging state of the battery, the 5in1 hair and
beard trimmer can always be mains-operated.
1. For mains operation, ensure that the hair and beard trim-
mer|5is switched off.
2. Connect the power unit|10 to the connector of the hair and
beard trimmer|5.
3. Insert the power unit| 10 into a readily accessible wall socket
whose voltage matches the voltage stated on the rating plate.
4. Switch on the device with the on/off switch|7.
6.1 Transport safety lock
When the transport safety lock is activated, the battery symbol|8
flashes blue 3 times.
• Press and hold the on/off switch|7for approx. 3 seconds to
activate/deactivate the transport safety lock.
• By connecting the power unit|10, the transport safety lock is
deactivated, and also cannot be activated while plugged in
to the power supply.
6.2 Changing the cutting attachments
WARNING! Risk of injury!
~Switch off the hair and beard trimmer|5, before you attach
or remove the attachments.
•Figure A: to remove the attachments|13,|3,|4,|12, 14 use
your thumbs to press the attachment towards the rear of the
hair and beard trimmer|5.

13
GB
•Figure B: to attach the attachments, put the lower flap of
the attachment|13,|3,|4,|12,|14 into the slot in the hair
and beard trimmer|5and press the upper part of the attach-
ment against the hair and beard trimmer until it audibly locks
into place and sits firmly in position.
6.3 Changing the comb attachments
Pushing on
• To attach the comb attachments|2+|1carefully slide the ap-
propriate comb attachment over the hair or beard trimmer at-
tachment|13 /|14. Press the lower part of the comb
attachments|2firmly until they lock into place.
Removing
• To remove the comb attachments|2loosen the comb attach-
ment at its lower end and pull it off the hair and beard trim-
mer|5.
• Slide the comb attachment|1for the beard trimmer attach-
ment|14 upwards from the hair and beard trimmer|5.
6.4 Cutting hair
Hair trimmer attachment|13
NOTES:
• The hair to be dressed must be dry.
• The cutting length may deviate depending on the cutting angle.
• Place a sheet or cape around throat and neck to prevent cut-
off hair from dropping into the collar.
• Comb the hair well.

14 GB
• First, start with a comb attachment|2with a longer cutting
length and then, in the course of the cutting process, use
shorter cutting lengths step by step.
• Start by cutting the hair in the neck or on the sides and cut
towards the centre of the head. Then, cut the front section of
the hair towards the centre of the head.
• Hold the hair and beard trimmer|5in such a way that the
comb attachment|2lies as flat as possible on the head.
Move the device evenly through the hair.
• If possible, cut against direction of hair growth.
• In order to catch all the hair, move the hair and beard trim-
mer|5several times through each section of the hair.
• Comb the hair repeatedly and well.
• In order to achieve a straight cutting line for cutting lengths
over 12 mm, the hair and beard trimmer|5should be passed
through the hair several times from different directions.
6.5 Trimming a beard
Beard trimmer attachment|14
NOTE: please note that the cutting lengths will only be achieved
if the switch for cutting length fine tuning|6is at position 1and
the hair and beard trimmer|5is held at a right angle to the skin
surface.
• Comb the beard in the direction that it grows.
• Trim the beard downwards from ear to chin. First trim one
side, then the other.
•Comb attachment|1
Figure C: adjust the cutting length with the slider according
to the desired hair length and read off the cutting length us-

15
GB
ing the marking on the side of the comb attachment|1(3, 4,
5, 6 mm). Now, shorten your beard step-by-step.
• Use the beard trimmer attachment|14 without a comb attach-
ment|1, to cut the beard very short or to cut a moustache
and hairline.
• Using the switch for cutting length fine tuning| 6 the cutting
length can be slightly varied with three levels (
1 : 0.8 mm /
2 : 1.3 mm / 3 : 1.8 mm).
• To trim your moustache, first comb it straight downwards.
Then use either the beard trimmer attachment|14 or the pre-
cision trimmer attachment|4. Start at the centre above the
mouth and trim first one side, then the other.
6.6 Cutting a hairline
Precision trimmer attachment|4
• Use the precision trimmer attachment|4to shorten and shape
moustaches, whiskers, sideburns or eyebrows.
• Put the edge of the attachment at the desired hairline height
and move the hair and beard trimmer|5downwards.
6.7 Shaving
Shaving attachment|3
NOTE: your skin must be clean and dry.
• Hold the hair and beard trimmer|5at a right angle to the
skin surface and gently guide it over your face.
• Shave against the direction of your beard growth.

16 GB
• Stretch your skin in complicated areas, such as the chin, to
achieve better results.
6.8 Trimming nose and ear hair
Nose/ear hair trimmer attachment|12
• Insert only the metal tip slowly into a nostril or an ear.
• Slowly move the hair and beard trimmer|5with a circular
motion to trim the hair.
7. Cleaning and care
DANGER! Risk of electric shock!
~Unplug the power unit|10 from the wall socket before clean-
ing the hair and beard trimmer|5and the battery charg-
er|11.
WARNING! Risk of injury!
~Always switch the hair and beard trimmer|5off before
cleaning.
WARNING! Risk of material damage!
~Do not use any astringent or abrasive cleaning agents.
NOTE: clean and oil the device after every use.
Hair and beard trimmer| 5 and battery charger| 11
• Wipe the casing of the hair and beard trimmer and the bat-
tery charger with a damp cloth.

17
GB
Comb attachments|2,|1
• Remove the comb attachment. Rinse the comb attachment
with water and let it dry before using it again.
Hair trimmer, beard trimmer and precision trim-
mer attachments|13,|14,|4
1. Figure A: remove the attachment from the hair and beard
trimmer|5by pressing it with the thumb towards the rear.
2. Remove the hair remnants from the attachment using the
cleaning brush|17 included in the delivery.
3. Apply a few drops of blade oil|16 to the cutting edge of the
attachment. Using a soft cloth, wipe off the surplus oil, if
necessary. Only use acid-free oil, such as e.g. sewing ma-
chine oil.
Nose/ear hair trimmer attachment|12
• Remove the nose/ear hair trimmer attachment|12. Rinse it
with water and let it dry completely before using it again.
Shaving attachment|3
WARNING!
~Do not detach the shaving foil from the shaving foil frame,
and do not clean it using the cleaning brush|17.
NOTE: from time to time, oil the cutting blade with a few drops
of acid-free oil (e.g. sewing machine oil). Attach the shaving at-
tachment to the hair and beard trimmer|5and let it run for a few
seconds without using it. Using a soft cloth, wipe off the surplus
oil, if necessary.

18 GB
1. Remove the shaving attachment|3.
2. Press the button on the side of the shaving attachment and
remove the shaving foil frame. While removing the shaving
foil frame, only hold it at the side and do not press against
the shaving foil.
3. Clean the cutting blade using the included cleaning
brush|17.
4. Clean the shaving foil in the shaving foil frame under run-
ning water and allow it to dry completely before putting it
back on the shaving attachment|3.
5. Put the shaving foil frame back onto the shaving attach-
ment|
3 . While attaching the frame, make sure that the fasten-
ing tabs on the shaving foil frame fit into the appropriate
recesses on the shaving attachment, and press the shaving foil
frame gently downwards until it audibly locks into place.
8. Storage
• For storage …
… put the hair and beard trimmer|5in the battery charg-
er|11 or
… use the included storage bag|19.
