Silvercrest 375571-2104 User manual

IAN 375571_2104
MINI CHOPPER SMZ 260 J4
MINI CHOPPER
Operating instructions
ΜΠΛΕΝΤΕΡ
Οδηүίες χρήσης
MULTIZERKLEINERER
Bedienungsanleitung

GB/IE/NI/CY Operating instructions Page 1
GR/CY Οδηүίες χρήσης Σελίδα 15
DE/AT/CH Bedienungsanleitung Seite 29
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

ml
max.
max.
300 10
200
6
100
OZ
TURBO
A
ml
max.
max.
300 10
200
6
100
OZ
TURBO
B
ml
max.
max.
300 10
200
6
100
OZ
TURBO
TURBO
C

SMZ 260 J4 GB│IE│NI│CY │ 1 ■
Contents
Introduction...................................................2
Intended use ..................................................2
Package contents ..............................................2
Unpacking ....................................................2
Disposal of the packaging.................................................. 3
Appliance description ...........................................3
Technical details ...............................................4
Safety information .............................................4
Operation ....................................................7
Chopping............................................................... 7
Whipping cream ........................................................10
Cleaning and care.............................................11
Troubleshooting ..............................................12
Appendix....................................................12
Disposal of the appliance ................................................. 12
Kompernass Handels GmbH warranty ....................................... 13
Service................................................................ 14
Importer ............................................................... 14
Read these operating instructions carefully before using the appliance
for the first time and retain them for future reference. Please pass these
operating instructions on to any future owner(s).

SMZ 260 J4■ 2 │ GB│IE│NI│CY
Introduction
Congratulations on the purchase of your new appliance!
You have chosen a modern, high-quality product. These operating instructions are
part of the product. They contain important information about safety, usage and
disposal. Before using the product, please familiarise yourself with all operating
and safety instructions. This appliance may only be used as described and for
the purposes indicated. Please also pass these operating instructions on to any
future owner.
Intended use
This appliance is intended for the chopping of boneless foods in small amounts
or for whipping cream. This appliance is intended exclusively for use in domestic
households.
All other uses are deemed to be improper and may result in property damage or
even in personal injury. No liability will be accepted for damages which result
from improper use of the appliance.
This appliance is not intended for use in companies or for other commercial uses.
Package contents
The appliance is supplied with the following components as standard:
▯ Mini Chopper
▯ Blade holder with blade
▯ Whisk attachment
▯ Stand
▯ Operating instructions
Unpacking
1) Remove all parts of the appliance and the operating instructions from the box.
2) Remove all packaging materials from the appliance.
NOTE
► Check the package for completeness and for signs of visible damage.
► If the delivery is incomplete or damage has occurred as a result of
defective packaging or during transport, contact the Service hotline (see
section Service).

SMZ 260 J4 GB│IE│NI│CY │ 3 ■
Disposal of the packaging
The packaging protects the appliance from damage during transport. The
packaging materials have been selected for their environmental friendliness and
ease of disposal, and are therefore recyclable.
Returning the packaging to the material cycle conserves raw materials and
reduces the amount of waste that is generated. Dispose of packaging materials
that are no longer needed in accordance with applicable local regulations.
Dispose of the packaging in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging material
components for disposal if necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following meanings:
1–7: Plastics,
20–22: Paper and cardboard,
80–98: Composites.
NOTE
► If possible, keep the original packaging of the appliance for the entire
duration of the warranty period so that the appliance can be packed
properly for return shipment in the event of a warranty claim.
Appliance description
Figure A:
1Turbo button
2Motor unit
3Lid flange
4Lid
5Blade holder
6Bowl
7Blade
8Bearing
9Stand
0Whisk attachment

SMZ 260 J4■ 4 │ GB│IE│NI│CY
Technical details
Mains voltage 220–240V ∼ (alternating current), 50Hz
Rated power 260 W
Protection class II / (double insulation)
CO time 1 minute ( with whisk attachment 0)
Capacity 840 ml
Max. filling quantity Food products up to the 300 ml marking
Liquids up to the 200 ml marking
All parts of this appliance which come into
contact with food are food-safe.
CO TIME
The CO time (continuous operation time) is the amount of time an appliance
can be operated without the motor overheating and becoming damaged.
After the appliance has been operated for this duration of time, switch it off
until the motor has cooled down.
This mark confirms that the product complies with the product safety
requirements applicable in the UK.
Safety information
WARNING! RISK OF ELECTRIC SHOCK!
► Connect the appliance only to a correctly installed power
socket supplying a mains power voltage of 220– 240 V ∼,
at 50 Hz.
► To prevent accidents, have defective plugs and/or power
cables replaced immediately by an authorised specialist, or
our Customer Service or a similarly qualified person.
► In event of operating malfunctions and before cleaning the
appliance, remove the power plug from the mains power
socket.
► Always remove the power cable from the socket by pulling
on the plug, not on the power cable itself.

SMZ 260 J4 GB│IE│NI│CY │ 5 ■
WARNING! RISK OF ELECTRIC SHOCK!
► Do not kink or crush the power cable, and route the cable
so that it cannot be stepped on or tripped over.
► Do not expose the appliance to humidity and do not use it
outdoors. If any liquid gets into the housing, disconnect the
appliance from the mains power socket immediately and
have it repaired by a qualified technician.
► Never hold the appliance, power cable or power plug with
wet hands.
► If the power cable or the motor unit are damaged, you must
have the appliance repaired by qualified technicians before
using it again. Do not attempt to open the motor unit
housing. This can lead to risks and also invalidates the
warranty.
► Disconnect the appliance from the mains power source
immediately after use. The appliance is completely free of
electrical power only when unplugged.
Never immerse the motor unit in liquid and do not
allow any liquids to enter the motor unit casing.
WARNING! RISK OF INJURY!
► Before changing any accessories or additional parts which
move during operation, the appliance must be switched off
and disconnected from mains power.
► Never use the appliance for purposes other than those
described in these instructions.
► Take care when emptying the bowl! The blade is extremely
sharp!
► Take care when cleaning the appliance! The blade is
extremely sharp!

SMZ 260 J4■ 6 │ GB│IE│NI│CY
WARNING! RISK OF INJURY!
► The appliance must always be disconnected from the mains
when left unsupervised and before assembly, disassembly or
cleaning.
► This appliance may not be used by children.
► The appliance and its connecting cable must be kept away
from children.
► This appliance may be used by persons with limited physical,
sensory or mental capabilities or lack of experience and
knowledge, provided that they are under supervision or
have been told how to use the appliance safely and are
aware of the potential risks.
► Do not allow children to use the appliance as a plaything.
► Children should be supervised to ensure that they do not
play with the appliance.
► Handle the extremely sharp blade with caution as it can
cause injuries. Reassemble the appliance after using and/or
cleaning it so that you do not injure yourself with the exposed
blade. Keep the blade out of the reach of children.
► Never attempt to remove foodstuffs from the bowl for as
long as the blade is still rotating. Risk of injury!
► Wait until the blade has stopped rotating before removing
the motor unit.
► Never try to grasp the blade if it is still rotating!
Risk of injury!

SMZ 260 J4 GB│IE│NI│CY │ 7 ■
WARNING! RISK OF FIRE!
► Do not allow the appliance to run for more than 1 minute.
Afterwards, allow it to cool down.
CAUTION! APPLIANCE DAMAGE!
► See the table on the recommended fill quantities in the
section "Chopping". Otherwise, there is a risk of
contamination due to leaking contents.
► Do not clean the motor unit in the dishwasher, as this will
damage it.
► Never fill the appliance with hot liquids! Otherwise the
appliance could be damaged!
Operation
Chopping
NOTE
► Before first use, you must clean the appliance thoroughly as described in
the section on cleaning.
1) Place the bowl 6on the stand 9.
2) Insert the blade holder 5with the blade 7onto the bearing 8.
3) Prepare the food by chopping larger pieces into pieces (approx. 2 cm) which
will fit better into the bowl 6.
4) Add the food to the bowl 6. Please note the following table: For optimum
results, we recommend the following maximum filling quantities:
Food
Max.
filling
quantity
Processing time Speed
Onions 100 g pulse turbo
Garlic 150 g pulse turbo
Tomatoes 200 g 10 sec. normal
Hazelnuts 200 g 3 x 8 sec. turbo

SMZ 260 J4■ 8 │ GB│IE│NI│CY
Food
Max.
filling
quantity
Processing time Speed
Almonds 200 g
coarse: 1 x 15 sec.
medium: 2 x 15 sec.
fine: 3 x 15 sec.
turbo
Cheese
(Gouda, young,
fridge
temperature)
150 g 2 x 15 sec. turbo
Eggs
(hard-boiled) 3 (150 g) 2 x 4 sec. turbo
Meat 200 g 4 x 12 sec. turbo
Ice cubes 100 g 15 x 1 sec.
pulse turbo
5) Close the bowl 6with the lid 4: Place it onto the bowl 6so that the lugs on
the lid 4grip into the guides on the bowl 6. Turn the lid 4so that the lugs
slide into the guides below.
6) Place the motor unit 2on the lid flange 3.
7) Press the motor unit 2downwards as shown in fig. B. The motor starts at
normal speed.
■ For a higher processing speed (Turbo) for the food, press on both the motor
unit 2and the Turbo button 1and keep both pressed down as shown in
Fig. C.
NOTES
► If larger pieces start collecting on the wall of the bowl during processing,
lift the motor unit 2off the lid flange 3. Give the bowl 6a firm shake
and restart the processing. Any residues can be removed with a spatula.
► Particularly hard foods should be cut into small pieces (approx. 2 cm)
before processing. Otherwise, the motor unit could block. Use a pulsing
processing method when working with hard foods. To do this, press the
Turbo button 1several times briefly (in addition to the motor unit 2). If
the food is not completely chopped, you can either cut it into smaller
pieces or lift the motor unit 2off of the lid flange 3. Give the bowl 6
a firm shake and restart the processing.

SMZ 260 J4 GB│IE│NI│CY │ 9 ■
8) If the food is fully chopped, let go of the motor unit 2and, if applicable, the
Turbo button 1.
9) Remove the power plug from the socket.
WARNING! RISK OF INJURY!
► Never attempt to remove food from the bowl 6while the blade 7is still
turning. There is a risk of injury and food can also spray out and make a
mess.
10) Wait until the blade 7has come to a complete standstill.
11) Lift the motor unit 2off the lid flange 3.
12) Remove the lid 4.
WARNING! RISK OF INJURY!
► Handle the extremely sharp blade 7with caution as it can cause injuries.
Keep the blade 7out of the reach of children.
13) Pull the blade holder 5with the blade 7carefully out of the bowl 6.
14) Remove the food.
NOTES
► Chopping harder, abrasive foods can cause the bowl 6to take on a dull
appearance. This is normal and will not impair the functioning of the
appliance.
► After you have finished processing the food, you can use the stand 9as
a lid for the bowl 6to keep the food fresh for longer.
–Take the motor unit 2and the lid 4off the bowl 6.
–The blade holder 5with the blade 7can, if so desired, remain in the
bowl 6.
–Remove the stand 9from the underside of the bowl 6. Turn the
stand 9. You can now place the stand 9on the bowl 6so that it
closes off the bowl 6.

SMZ 260 J4■ 10 │ GB│IE│NI│CY
Whipping cream
You can also use the appliance to whip cream with the help of the whisk
attachment 0:
1) Place the bowl 6on the stand 9.
2) Push the whisk attachment 0onto the blade holder 5:
–For 100 ml of cream, place it onto the blade holder 5so that the whisk
attachment 0is in contact with both blades 7and clicks into place (fig. 1):
Fig. 1
–For 200 ml of cream, turn the whisk attachment 0horizontally by 180°
(fig. 2), so that it is in contact with only one blade 7and clicks into place
(fig. 3). It then churns higher through the cream.
180°
Fig. 2
Fig. 3
3) Attach the blade holder 5together with the whisk attachment 0to the bearing 8.

SMZ 260 J4 GB│IE│NI│CY │ 11 ■
4) Add the cream.
5) Close the bowl 6with the lid 4: Place it onto the bowl 6so that the lugs on
the lid 4grip into the guides on the bowl 6. Turn the lid 4so that the lugs
slide into the guides below.
6) Place the motor unit 2on the lid flange 3.
7) Press the motor unit 2downwards as shown in fig. B. The motor starts at
normal speed.
NOTE
► To whip cream, you should make sure that it is well chilled before whipping
(max. 8°C/fridge temperature).
► For 100ml of cream, we recommend a whipping time of around 30 seconds
at normal speed.
► For 200ml of cream, we recommend a whipping time of around
30–50 seconds at normal speed.
► Depending on certain factors, such as fat content or the ambient
temperature, the whipping time can vary. Keep an eye on the cream while
you are whipping it and adjust the whipping time to fit your needs.
Cleaning and care
WARNING! RISK OF ELECTRIC SHOCK
► Always remove the plug from the mains power socket before cleaning the
appliance.
You must never immerse the appliance in water when cleaning it or hold
it under running water.
WARNING! RISK OF INJURY!
► Handle the extremely sharp blade 7with caution as it can cause injuries.
Reassemble the appliance after using and/or cleaning it so that you do not
injure yourself with the exposed blade 7. Keep the blade 7out of the
reach of children.
CAUTION! PROPERTY DAMAGE!
► Do not clean the motor unit 2in the dishwasher, as this will damage it.
■ Remove the power plug from the socket.
■ Clean the motor block 2and the blade holder 5and the blade 7with a
well-wrung-out sponge.

SMZ 260 J4■ 12 │ GB│IE│NI│CY
■ Clean the bowl 6, the whisk attachment 0, the lid 4and the stand 9in
warm water with a little mild detergent. Rinse all the parts afterwards using
fresh water and dry them with a tea towel.
Alternatively, you can clean all of the parts apart from the motor
unit 2in the dishwasher. If possible, place the parts in the top basket
of the dishwasher. Ensure that the parts are not trapped in any way.
Troubleshooting
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTIONS
The appliance
is not working.
The appliance is not connected to a
mains power socket.
Connect the appliance to a mains
power socket.
The appliance is damaged. Contact the Customer Service
department.
A household fuse has blown. Check the household fuses and
replace them if necessary.
The appliance is possibly defective. Contact the Customer Service
department.
If the malfunction cannot be corrected using one of the suggestions above, or if you have
found some other kind of malfunction, please contact our Customer Service department.
Appendix
Disposal of the appliance
Never dispose of the appliance in your normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU.
Dispose of the appliance via an approved disposal company or your municipal
waste facility. Please comply with all applicable regulations. Please contact your
waste disposal centre if you are in any doubt.
Your local community or municipal authorities can provide information on how to
dispose of the worn-out product.

SMZ 260 J4 GB│IE│NI│CY │ 13 ■
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase. If this product
has any faults, you, the buyer, have certain statutory rights. Your statutory rights
are not restricted in any way by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your receipt in a
safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the date of
purchase of the product, we will either repair or replace the product for you or
refund the purchase price (at our discretion). This warranty service requires that
you present the defective appliance and the proof of purchase (receipt) within
the three-year warranty period, along with a brief written description of the fault
and of when it occurred.
If the defect is covered by the warranty, your product will either be repaired or
replaced by us. The repair or replacement of a product does not signify the
beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty.
This also applies to replaced and repaired components. Any damage and
defects present at the time of purchase must be reported immediately after
unpacking. Repairs carried out after expiry of the warranty period shall be
subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality
guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not
extend to product parts subject to normal wear and tear or to fragile parts which
could be considered as consumable parts such as switches, batteries or parts
made of glass.
The warranty does not apply if the product has been damaged, improperly used
or improperly maintained. The directions in the operating instructions for the
product regarding proper use of the product are to be strictly followed. Uses and
actions that are discouraged in the operating instructions or which are warned
against must be avoided.
This product is intended solely for private use and not for commercial purposes.
The warranty shall be deemed void in cases of misuse or improper handling, use
of force and modifications/repairs which have not been carried out by one of
our authorised Service centres.

SMZ 260 J4■ 14 │ GB│IE│NI│CY
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
■ Please have the till receipt and the item number (IAN)375571_2104
available as proof of purchase.
■ You will find the item number on the type plate on the product, an engraving
on the product, on the front page of the operating instructions (below left) or
on the sticker on the rear or bottom of the product.
■ If functional or other defects occur, please contact the service department
listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service address
that will be provided to you. Ensure that you enclose the proof of purchase (till
receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals, product
videos and installation software at www.lidl-service.com.
This QR code will take you directly to the Lidl service page
(www.lidl-service.com) where you can open your operating instructions
by entering the item number (IAN)375571_2104.
Service
Service Great Britain
Tel.: [phone]
E-Mail: komper[email protected]
Service Ireland
Tel.: [phone]
(0,08EUR/ Min.,(peak))
(0,06EUR/ Min.,(off peak))
E-Mail: komper[email protected]
CY Service Cyprus
Tel.: [phone]
E-Mail: komper[email protected]
IAN 375571_2104
Importer
Please note that the following address is not the service address. Please use the
service address provided in the operating instructions.
For EU market For GB market
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Lidl Great Britain Ltd
Lidl House 14 Kingston Road
Surbiton
KT5 9NU

SMZ 260 J4 GR│CY │ 15 ■
Περιεχόμενα
Εισαγωγή ....................................................16
Προβλεπόμενη χρήση..........................................16
Παραδοτέος εξοπλισμός........................................16
Αποσυσκευασία ..............................................16
Απόρριψη της συσκευασίας ............................................... 17
Περιγραφή συσκευής ..........................................17
Τεχνικά χαρακτηριστικά........................................18
Υποδείξεις ασφαλείας ..........................................18
Χειρισμός ....................................................21
Τεμαχισμός ............................................................21
Χτύπημα κρέμας ........................................................24
Καθαρισμός και φροντίδα ......................................25
Διόρθωση σφαλμάτων .........................................26
Παράρτημα ..................................................26
Απόρριψη συσκευής .....................................................26
Εγγύηση της Kompernass Handels GmbH ....................................27
Σέρβις ................................................................28
Εισαγωγέας ............................................................28
Διαβάστε προσεκτικά τις οδηγίες χρήσης πριν από την πρώτη χρήση
και φυλάξτε τις για μελλοντική χρήση. Σε περίπτωση παράδοσης της
συσκευής σε τρίτους παραδώστε μαζί και τις οδηγίες χρήσης.

SMZ 260 J4■ 16 │ GR│CY
Εισαγωγή
Συγχαρητήρια για την αγορά της νέας σας συσκευής!
Αποφασίσατε έτσι για την απόκτηση ενός προϊόντος υψηλής ποιότητας. Οι
οδηγίες χρήσης αποτελούν τμήμα αυτού του προϊόντος. Περιέχουν σημαντικές
υποδείξεις για την ασφάλεια, τη χρήση και την απόρριψη. Πριν από τη χρήση
του προϊόντος, εξοικειωθείτε με όλες τις υποδείξεις χειρισμού και ασφάλειας.
Χρησιμοποιείτε αυτό το προϊόν μόνο όπως περιγράφεται και για τα αναφερόμενα
πεδία χρήσης. Παραδώστε όλα τα έγγραφα σε περίπτωση παράδοσης του προϊ-
όντος σε τρίτους.
Προβλεπόμενη χρήση
Η παρούσα συσκευή εξυπηρετεί αποκλειστικά στο κομμάτιασμα τροφίμων χωρίς
κόκαλα σε μικρές ποσότητες ή για το χτύπημα κρέμας. Η συσκευή αυτή προορί-
ζεται αποκλειστικά για χρήση στο ιδιωτικό νοικοκυριό.
Κάθε άλλη χρήση ισχύει ως μη σύμφωνη με τους κανονισμούς και μπορεί να
οδηγήσει σε υλικές ζημιές ή ακόμη και σε σωματικές βλάβες. Δεν αναλαμβάνουμε
καμία ευθύνη για βλάβες που προκαλούνται από χρήση μη σύμφωνη με τους
κανονισμούς.
Η συσκευή δεν προβλέπεται για τη λειτουργία σε επιχειρήσεις ή για
επαγγελματική χρήση.
Παραδοτέος εξοπλισμός
Η συσκευή παραδίδεται κανονικά με τα εξής στοιχεία:
▯ Μπλέντερ
▯ Στήριγμα λεπίδας με λεπίδα
▯ Εξάρτημα ανάδευσης
▯ Βάση στήριξης
▯ Οδηγίες χρήσης
Αποσυσκευασία
1) Αφαιρέστε όλα τα εξαρτήματα της συσκευής και τις οδηγίες χρήσης από το κουτί.
2) Απομακρύνετε όλα τα υλικά συσκευασίας από τη συσκευή.
ΥΠΟΔΕΙΞΗ
► Ελέγξτε τον παραδοτέο εξοπλισμό ως προς την πληρότητα και για εμφανείς
φθορές.
► Σε περίπτωση ελλιπούς παραδοτέου εξοπλισμού ή ζημιών λόγω ελλιπούς
συσκευασίας ή λόγω μεταφοράς, απευθυνθείτε στην ανοικτή τηλεφωνική
γραμμή εξυπηρέτησης (βλ. κεφάλαιο Σέρβις).

SMZ 260 J4 GR│CY │ 17 ■
Απόρριψη της συσκευασίας
Η συσκευασία προστατεύει τη συσκευή από φθορές κατά τη μεταφορά. Τα υλικά
συσκευασίας έχουν επιλεγεί σύμφωνα με τους οικολογικούς παράγοντες και τους
παράγοντες της τεχνικής απόρριψης και για το λόγο αυτό είναι ανακυκλώσιμα.
Η επιστροφή της συσκευασίας στο κύκλωμα υλικών εξοικονομεί πρώτες ύλες και
μειώνει την ποσότητα των απορριμμάτων. Απορρίπτετε τα υλικά συσκευασίας
που δεν χρησιμοποιούνται πλέον σύμφωνα με τις τοπικές ισχύουσες προδια-
γραφές.
Απορρίπτετε τη συσκευασία με φιλικό τρόπο προς το περιβάλλον. Λαμβάνετε
υπόψη τη σήμανση στα διαφορετικά υλικά συσκευασίας και, εφόσον απαιτείται,
ξεχωρίζετέ τα. Τα υλικά συσκευασίας φέρουν σήμανση με συντομογραφίες (a)
και ψηφία (b) με την εξής σημασία:
1–7: Πλαστικά,
20–22: Χαρτί και χαρτόνι,
80–98: Συνθετικά υλικά.
ΥΠΟΔΕΙΞΗ
► Εάν είναι δυνατόν, φυλάξτε τη γνήσια συσκευασία κατά τη διάρκεια της
εγγύησης, για να μπορείτε, σε περίπτωση εγγύησης, να συσκευάσετε τη
συσκευή σωστά.
Περιγραφή συσκευής
Εικόνα A:
1Πλήκτρο τούρμπο
2Μοτέρ
3Σύνδεση καπακιού
4Καπάκι
5Στήριγμα λεπίδας
6Μπολ
7Λεπίδα
8Έδρανο
9Βάση στήριξης
0Εξάρτημα ανάδευσης
