Silvercrest 93841 User manual

EARPHONES SKAO 120 A1
OHRHÖRER
Bedienungsanleitung
IAN 93841
EARPHONES
Operating instructions
HØRETELEFONER
Betjeningsvejledning

GB / IE Operating instructions Page 1
DK Betjeningsvejledning Side 15
DE / AT / CH Bedienungsanleitung Seite 29
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Før du læser, vend siden med billeder frem og bliv bekendt med alle appara-
tets funktioner.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

1
SKAO 120 A1
GB
IE
Table of contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Information about these operating instructions. . . . . . . . . . . . . . . . .2
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Limitation of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Use for intended purpose. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Package contents (see fold-out page) . . . . . . . . . . . . . . . . . . . . . . .6
Disposal of packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the cable winder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Using the earphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Replacing the ear cushions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Connecting the earphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Fault rectification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Fault causes and rectification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Technical details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Notes on the Declaration of Conformity . . . . . . . . . . . . . . . . . . . .11
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
IB_93841_SKAO120A1_LB3.indb 1IB_93841_SKAO120A1_LB3.indb 1 04.12.13 15:1004.12.13 15:10

GB
IE
2SKAO 120 A1
Introduction
Information about these operating instructions
Congratulations on the purchase of your new device.
You have decided to purchase a high-quality product. The operating
instructions are a constituent of this product. They contain important
information with regard to safety, use and disposal. Before using the
product, familiarise yourself with all operating and safety instructions.
Use this device only as described and only for the specified areas of
application. Retain these instructions for future reference. Please also
pass these operating instructions on to any future owner(s).
Copyright
This documentation is subject to copyright protection. Any copying or
reproduction, including extracts of the documentation, and the repro-
duction of images or modified versions thereof, is only permitted with
the written authorisation of the manufacturer.
Limitation of liability
The manufacturer assumes no liability for damage caused by failure
to observe these instructions, non-intended use, improper repairs,
making unauthorised modifications or using non-approved replace-
ment parts.
Use for intended purpose
These earphones are exclusively intended for non-commercial use for
listening to audio material. Any other or additional usage is considered
to be improper use and can lead to damage. Claims of any kind for
damage arising as a result of non-intended use will not be accepted.
IB_93841_SKAO120A1_LB3.indb 2IB_93841_SKAO120A1_LB3.indb 2 04.12.13 15:1004.12.13 15:10

3
SKAO 120 A1
GB
IE
Warnings
The following warnings are used in these operating instructions:
WARNING
A warning at this risk level indicates a potentially
hazardous situation.
Failure to avoid this hazardous situation could result in physical
injury.
► Follow the instructions in this warning to prevent physical injury.
CAUTION
A warning at this risk level indicates potential
damage to property.
Failure to avoid this situation could result in damage to property.
► Follow the instructions in this warning to prevent damage to
property.
NOTE
► A note indicates additional information that will assist you in
handling the device.
IB_93841_SKAO120A1_LB3.indb 3IB_93841_SKAO120A1_LB3.indb 3 04.12.13 15:1004.12.13 15:10

GB
IE
4SKAO 120 A1
Safety instructions
For safe handling of the device, follow the safety information below:
■ Check the earphones for external signs of damage before use.
Do not operate damaged earphones or earphones that have
been dropped.
■ If the cables or connections are damaged, have them replaced
by an authorised specialist or customer service.
■ Persons who are incapable of operating the earphones safely
due to their physical, intellectual or motor abilities must only use
them under the supervision or direction of a responsible adult.
■ Children may only be permitted to use the earphones if they are
under supervision.
■ Repairs to the earphones should only be carried out by author-
ised specialist personnel or by the customer service department.
Failure to make proper repairs can put the user at risk. This will
also invalidate warranty claims.
■ Repairs to the earphones during the warranty period may only
be carried out by a customer service department that has been
authorised by the manufacturer, otherwise no additional warranty
claims can be considered for subsequent damage.
■ Defective components must always be replaced with original
replacement parts. It can only be guaranteed that safety require-
ments are being complied with if using original replacement parts
are used.
■ No unauthorised design changes or modifications must be made
to the earphones.
■ Protect the earphones from penetration by moisture and liquids.
■ Do not use the earphones in the vicinity of naked flames.
IB_93841_SKAO120A1_LB3.indb 4IB_93841_SKAO120A1_LB3.indb 4 04.12.13 15:1004.12.13 15:10

5
SKAO 120 A1
GB
IE
Risk of hearing damage
WARNING
Risks as a result of extremely high
sound levels!
Loud music can lead to hearing damage.
► Avoid extreme sound levels, especially over long
periods of time, when you are using these earphones.
Risk of accidents
WARNING
Danger as a result of affected perception!
► Acoustic warning and indication signals and ambient noise
may be perceived differently when earphones are being worn.
It is important to be aware of how these signals can differ so
that you can recognise them in the relevant situations.
► Do not use the headphones while driving a vehicle, riding a
bicycle, operating machinery or in any other situation in which
impaired perception of ambient noise could put you or other
people in danger. Please also observe the statutory provisions
and regulations of the country in which you are using the
headphones.
IB_93841_SKAO120A1_LB3.indb 5IB_93841_SKAO120A1_LB3.indb 5 04.12.13 15:1004.12.13 15:10

GB
IE
6SKAO 120 A1
Commissioning
WARNING
► The packaging material is not a toy. Keep plastic sheeting,
bags and all other packaging material away from children.
There is a risk of suffocation.
Package contents (see fold-out page)
The earphones are delivered with the following components as
standard:
▯ Earphones 1with pre-installed ear cushions (medium size 2)
▯ Cable winder 3
▯ 2 pairs of ear cushions (small 4 and large 5)
▯ These operating instructions (not shown)
NOTE
► Check contents for completeness and for signs of visible
damage.
► If the contents are incomplete or damaged due to defective
packaging or through transportation, contact the Service
Hotline (see chapter Service).
Disposal of packaging
The packaging protects the appliance from transport damage.
Recirculating the packaging into the material cycle conserves
raw materials and reduces the amount of waste that is
generated.
Dispose of packaging material that is no longer needed in
accordance with applicable local regulations.
IB_93841_SKAO120A1_LB3.indb 6IB_93841_SKAO120A1_LB3.indb 6 04.12.13 15:1004.12.13 15:10

7
SKAO 120 A1
GB
IE
Operation
Using the cable winder
The cable winder can be used to adapt the length of the earphone 1
cable to your needs and for storing the earphones when they are not
being used.
■ Remove silicone cap of cable winder 3and lead the cable
through the side recesses and the middle bar of the lower shell.
■ Fold over the silicone cap towards the outside and place it on
the middle bar of the lower shell again.
■ Wind one end of the cable around the middle bar until the
required cable length has been reached, and then lead it back
through the recess in the lower shell.
■ Fold the silicone cap back inwards again. Ensure that the recesses
in the silicone cap and the lower shell are in alignment with
each other.
IB_93841_SKAO120A1_LB3.indb 7IB_93841_SKAO120A1_LB3.indb 7 04.12.13 15:1004.12.13 15:10

GB
IE
8SKAO 120 A1
Using the earphones
■ When putting on the earphones 1, pay attention to the side
indicators “R” (right) and “L” (left) on the earpieces.
■ Carefully slide one of the earphones 1 deep into the ear canal.
In order to straighten the ear channel somewhat and therefore
make the earphone easier to insert, pull auricle backwards and
upwards a little.
■ Proceed in the same way to insert the other earphone 1.
Replacing the ear cushions
In the as-delivered condition, the earphones 1are provided with
medium size ear cushions 2. Depending on the size of your auricle
you can use ear cushions (4or 5) of a different size from the ones
supplied.
NOTE
► The better the ear cushion seals off the ear canal, the better
the sound quality, particularly at lower frequencies.
■ Use your fingers to carefully pull on the ear cushions 2 to detach
them from the earphones 1(see fig. 1).
■ Select suitable ear cushions (4or 5) from the ones that are
supplied. Push these directly onto the earphones 1until they slip
into the recesses on the earphones 1(see fig. 2).
Fig. 1 Fig. 2
IB_93841_SKAO120A1_LB3.indb 8IB_93841_SKAO120A1_LB3.indb 8 04.12.13 15:1004.12.13 15:10

9
SKAO 120 A1
GB
IE
Connecting the earphones
The earphones 1are equipped with a 3.5 mm jackplug. Many
electronic entertainment devices are provided with an appropriate
headphone socket. If your audio device has been equipped with
a different headphone connector, you may need to use a suitable
adapter (not supplied).
Fault rectification
Fault causes and rectification
The following table will help with localising and remedying minor
malfunctions:
Defect Cause/remedy
No sound
coming from
earphones 1.
The volume control of the playback device is set
to the minimum volume.
Increase the playback volume.
The 3.5 mm jackplug is not fully inserted into the
playback device's headphone socket. Push the
3.5 mm jackplug all the way into the socket.
Sound is only
coming from
one side of the
earphones 1.
The 3.5 mm jackplug is not fully inserted into the
playback device's headphone socket. Push the
3.5 mm jackplug all the way into the socket.
The Stereo-Balance-Control on the playback
device is incorrectly adjusted. Adjust it to the
setting you desire.
NOTE
► If the malfunction cannot be remedied with the described
solution proposals or if other types of malfunctions occur
please contact our service department (see chapter Service).
IB_93841_SKAO120A1_LB3.indb 9IB_93841_SKAO120A1_LB3.indb 9 04.12.13 15:1004.12.13 15:10

GB
IE
10 SKAO 120 A1
Cleaning
CAUTION
► Do not allow any liquids to penetrate the interior of the ear-
phones 1. This could cause irreparable damage to them.
■ Clean the earphones 1with a slightly damp cloth.
■ Remove the ear cushions (2, 4or 5) for cleaning. Clean the
ear cushions under running water. Dry the ear cushions properly.
Do not fold the ear cushions back over the earphones 1until they
are properly dry.
Storage
■ Store the earphones 1in the cable winder 3in a dry, dust-free
location.
Disposal
Never dispose of the appliance in your normal
domestic waste. This product is subject to the
provisions of European Directive 2012/19/EU.
Dispose of the appliance through an approved disposal centre or at
your community waste facility. Please observe the currently applicable
regulations. Please contact your waste disposal centre should you be
in any doubt.
IB_93841_SKAO120A1_LB3.indb 10IB_93841_SKAO120A1_LB3.indb 10 04.12.13 15:1004.12.13 15:10

11
SKAO 120 A1
GB
IE
Appendix
Technical details
Impedance 32 Ω +/- 4 Ω
Sensitivity 96 dB +/- 4 dB at 1 kHz
Frequency response 20 Hz - 20 kHz
Input power max. 50 mW / 1000 Hz
Wide band characteristic
voltage approx. 110 mV +/- 10%
Connector 3.5 mm jackplug
Cable length 120 cm
Weight (including cable
winder) 35 g approx.
Operating temperature 5 - 35 °C
Humidity (no condensation) 5 - 80 %
Notes on the Declaration of Conformity
Regarding conformity with essential requirements and other relevant
provisions, this appliance complies with RoHS Directive 2011/65/EU.
The complete original Declaration of Conformity is available from the
importer and may be requested if required (see Chapter Importer).
IB_93841_SKAO120A1_LB3.indb 11IB_93841_SKAO120A1_LB3.indb 11 04.12.13 15:1004.12.13 15:10

GB
IE
12 SKAO 120 A1
Warranty
The warranty provided for this appliance is 3 years from date of
purchase. This appliance has been manufactured with care and
inspected meticulously prior to delivery. Please retain your receipt
as proof of purchase. In the event of a warranty claim, please call
Customer Service. This is the only way to ensure that your goods will
be dispatched free of charge.
NOTE
► The warranty only covers claims for material and manufac-
turing defects, not for transport damage, wearing parts or
for damage to fragile components such as switches and
batteries.
This appliance is exclusively intended for private use and not for
commercial purposes. The warranty is deemed void if this product
has been subjected to improper or inappropriate handling, abuse
or modifications that were not carried out by one of our authorised
service centres. Your statutory rights are not restricted in any way by
this warranty.
The warranty period is not extended by repairs made under the
warranty. This also applies to replaced and repaired parts. Damage
and defects present at the time of purchase must be reported im-
mediately after unpacking, or no later than two days after the date
of purchase. Repairs made after expiry of the warranty period are
chargeable.
IB_93841_SKAO120A1_LB3.indb 12IB_93841_SKAO120A1_LB3.indb 12 04.12.13 15:1004.12.13 15:10

13
SKAO 120 A1
GB
IE
Service
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: [email protected]
IAN 93841
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: [email protected]
IAN 93841
Hotline availability: Monday to Friday 08:00 - 20:00 (CET)
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
IB_93841_SKAO120A1_LB3.indb 13IB_93841_SKAO120A1_LB3.indb 13 04.12.13 15:1004.12.13 15:10

14 SKAO 120 A1
IB_93841_SKAO120A1_LB3.indb 14IB_93841_SKAO120A1_LB3.indb 14 04.12.13 15:1004.12.13 15:10

15
SKAO 120 A1
DK
Indholdsfortegnelse
Introduktion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Om denne betjeningsvejledning. . . . . . . . . . . . . . . . . . . . . . . . . . .16
Ophavsret. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Ansvarsbegrænsning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Anvendelsesområde. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Advarsler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Sikkerhedsanvisninger. . . . . . . . . . . . . . . . . . . . . . . . .18
Første brug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Leverede dele (se klap-ud-siden) . . . . . . . . . . . . . . . . . . . . . . . . . .20
Bortskaffelse af emballagen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Betjening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Brug af kabelopviklingen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Indsætning af høretelefonerne . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Udskiftning af ørepolstringer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Tilslutning af høretelefoner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Afhjælpning af fejl. . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Fejlårsager og -afhjælpning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Rengøring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Opbevaring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Bortskaffelse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Tillæg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Tekniske data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Info til EF-overensstemmelseserklæringen . . . . . . . . . . . . . . . . . . . .25
Garanti. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Importør . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
IB_93841_SKAO120A1_LB3.indb 15IB_93841_SKAO120A1_LB3.indb 15 04.12.13 15:1004.12.13 15:10

DK
16 SKAO 120 A1
Introduktion
Om denne betjeningsvejledning
Tillykke med købet af dit nye produkt.
Du har dermed valgt et produkt af høj kvalitet. Betjeningsvejledningen
er en del af dette produkt. Den indeholder vigtige informationer om
sikkerhed, anvendelse og bortskaffelse. Du bedes sætte dig ind i alle
produktets betjenings- og sikkerhedsanvisninger før brug. Brug kun
produktet som beskrevet og kun til de angivne anvendelsesområder.
Opbevar denne vejledning, så du altid kan finde den igen. Lad
vejledningen følge med produktet, hvis du giver det videre til andre.
Ophavsret
Denne dokumentation er ophavsretligt beskyttet. Kopiering eller efter-
tryk – også i uddrag – samt videregivelse af billederne – også i
ændret tilstand – er kun tilladt med producentens skriftlige samtykke.
Ansvarsbegrænsning
Producenten påtager sig intet ansvar for skader på grund af mang-
lende overholdelse af vejledningen, anvendelse, som ikke hører ind
under anvendelsesområdet, forkerte reparationer, ændringer, som er
foretaget uden tilladelse samt anvendelse af ikke-tilladte reservedele.
Anvendelsesområde
Disse høretelefoner er udelukkende beregnet til privat aflytning af
audiomateriale. Al anden eller videregående anvendelse betragtes
som værende uden for anvendelsesområdet og kan føre til skader.
Der kan ikke stilles krav i forbindelse med skader forårsaget af an-
vendelse til formål uden for anvendelsesområdet.
IB_93841_SKAO120A1_LB3.indb 16IB_93841_SKAO120A1_LB3.indb 16 04.12.13 15:1004.12.13 15:10

17
SKAO 120 A1
DK
Advarsler
I denne betjeningsvejledning anvendes følgende advarsler:
ADVARSEL
En advarsel på dette faretrin angiver en mulig
farlig situation.
Hvis den farlige situation ikke undgås, kan det føre til personskader.
► Følg anvisningerne i denne advarsel for at undgå, at personer
kommer til skade.
OBS
En advarsel på dette faretrin angiver en mulig
materiel skade.
Hvis den farlige situation ikke undgås, kan det føre til materielle
skader.
► Følg anvisningerne i denne advarsel for at undgå materielle
skader.
BEMÆRK
► Et 'bemærk' henviser til yderligere oplysninger, som gør det
nemmere at bruge produktet.
IB_93841_SKAO120A1_LB3.indb 17IB_93841_SKAO120A1_LB3.indb 17 04.12.13 15:1004.12.13 15:10
