Simfer MIDI OVEN 45 LT User manual

GB ELECTRIC OVEN USER'S MANUAL

Dear customer,
Thank you for relying on our products. We aim to allow you to optimally
and efficiently use this environment-friendly product produced in our
modern facilities under precise conditions with respect to sense of quality
intotal.
We advise you to read this operating manual thoroughly before using the
midi oven and keep it permanently so that the features of the midi oven
you have purchased will stay the same as the first day for a long time
and serve in an optimum efficient way.
NOTE:
This Operating Manual is prepared for multiple models. Your appliance may
not feature some functions specified in the manual.
The product images are schematic.
This product has been produced in modern environment-friendly
facilities without adversely affecting nature.
“Complies with AEE Regulation."

3,4,5
6
6
7
8
8
9
9
9
10
11
CONTENTS
Warnings
Electrical Connection and Safety
Explanation ofthe Oven and the Control Panel Technical
Specifications
Cooking Chart
Operation ofthe Oven
If Your Oven does not Work
Oven lamp
Maintenance and Cleaning
Yogurt fermentation and the use of steam cleaning
function Using the Digital Timer (*)
Compliance with AEEE regulations and Waste Disposal
Package Information
16
(*) optional
2
2

WARNINGS
This appliance ismanufactured inaccordance with the
safety regulations. Operation against the rules causes
harm both tothe person and the appliance.
Do not put any flammable, ignitable materials or material
that may melt or deform due to the heat inside the
oven against possible risks even if your appliance is
not operated.
Appliance isnot designed tobe set from remote or tobe
remotely operated.
Door surface may reach high temperature when the
appliance is operated.
Do not pour cold water into the tray or inside the oven
while the surface of the appliance is still hot. Surface
of the appliance may get damaged as a result of the
sudden change in the temperature, and it may cause
scaldings.
Long term intense use of the appliance may require
extra ventilation, for example, opening awindow, or a
better ventilation, such as increasing the mechanical
ventilation level. Put curtains, tulles, paper or any
flammable (ignitable) material away from the
appliance before starting to use the appliance. Do
not put ignitable or flammable materials on or in the
appliance.
3

Keep aneye on the children inthe vicinity of the appliance.
This appliance is not intended to be used by people with
physical, sensory and mental disabilities (including
children) or those who have not adequate experience and
knowledge regarding its use, unless they are under the
supervision of a person responsible for the safety of the
appliance.
Appliance may be used by children above age of 8, people
with limited physical, perceptual or mental abilities or
people with alack of experience and knowledge if they are
supervised or given instructions on the operation of the
appliance and any relevant risks they may be encountered.
Children should not tamperwith the appliance.
Cleaning and user maintenance ofthe appliance should
not be performed by unattended children.
Appliance should be very hot while it is being operated
or after ashort while when it is operated; do not
touch heater surfaces, and let children touch these
surfaces.
Keep the appliance and cord away from children under 8.
Children should besupervised to ensure that they donot
play with the appliance.
4

This appliance issuitable foruse athome and similar
environments.
Do not apply pressure on the oven door with heavy objects
when the door is open; do not lean, place heavy objects on
the door or handle the appliance by holding its door.
Use your appliance for cooking and heating your meal only.
Do not use your appliance for unintended purposes
(heating the room, for commercial purposes etc.).
Ensure that the appliance is unplugged before replacing
the lamp of your appliance to prevent a risk of electric
shock.
Life time of this product is ten (10) years.
CAUTION!
The surfaces of the areas with this
label are hot. Do not touch.
5

1-
Control panel
6-
Oven pedestals
2-
Oven body
7-
Oven glass door
3-
Handle
8-
Control buttons
4-
Cooker
9-
Circular tray (Option)
5-
Heaters
10-
Rectangular tray
11-
Wire grill
ELECTRICAL CONNECTION AND SAFETY
Your appliance requires acurrent of 16 Amperes. Have the appliance installed by
qualified people,ifrequired.
Your appliance isdesigned for a power supply of230 V,50Hz. Ifyour mains supply
specifications are different from the specified values, contact qualified people
Electrical connection ofyour appliance should only beperformed with earthed
outlets installed asper the regulations. Contact authorized service if anearthed
outlet is not available where the appliance should be placed. Manufacturer is not
responsible for the damages caused byunearthed outlets.
If the mains cord (plugged cord) is damaged, this cord must bereplaced bythe
importer or itsservice agent or an equally qualified personnel toprevent a hazardous
situation.
Power cord of your appliance should not come into contact with the hot components
of the appliance.
EXPLANATION OF THE OVEN AND THE CONTROL
PANEL
6

Timer: Set the timer to the recommended cooking time
at the desired thermostat degree. When the set time expires, timer shall cut off the
power ofthe heaters and providesa warning with a tingling sound. Set the timer
cuts off programmer and thermostat buttons to zero position toturn off your
device. When
the timer is set to position, itwill work independent ofthe time. Thermostat:
Thermostat ensures a temperature from 40 to240 °Cinside the oven.
TECHNICAL SPECIFICATIONS
Features
MIDI OVEN 45 LT
External width
590 mm
External depth
470 mm
External height
330 mm
Internal width
440 mm
Internal depth
420 mm
Internal height
240 mm
Thermostat
40 to 240°C
Timer (*)
0 to 90 min.
Bottom heater
800 W
Top heater
600 W
Supply voltage
220-240V, ~ 50/60Hz.
Turbo fan (*)
13 - 15 W
Oven lamp (*)
15 W
(*): This feature is only available on some models.
Top heater
Timer
Bottom heater
Bottom and top heater
Thermostat
Bottom heater and Turbo Fan
Programmer Bottom and Top heater
and Turbo fan
7

COOKING CHART
Below you may find the information about the food we have tested in our laboratories
to determined their cooking time. Cooking time may vary as per mains voltage,
quality, amount of the ingredients to be cooked, and the temperature. Meals you cook
using these values may not appeal to your taste. You may discover different values
by making experiments to achieve different flavours and results that appeal to your
taste.
"Pre-heat your oven before cooking.
You may consider the time required until the temperature light isturned off for the
first time as the pre-heating time."
OPERATION OF THE OVEN
Connect the plug to the earthed outlet. Bring the timer to manual orautomatic
cooking position. Set the thermostat to aproper temperature as per the values in the
cooking chart. Ifyou have set the timer tomanual, you shall hear awarning sound at
the end ofcooking.
Some smoke and odour may occur while the protective materials onthe heaters
harden during the first operation ofyour oven. This isnormal and not amanufacturing
fault.
In order to make yoghurt: Boil the unpasteurised milk. Cure the boiled milk after it is
cooled. Set the oven temperature to40- 50 °C, and operate the fan. Cook the cured
milk inthe oven for 3 to3.5 hours ina pan with alid.
Thawing: Remove the food tobethawed from itscontainer and place itonthe grill.
Slide the rectangular tray under the grill to collect dripping water. Thus, thawed food
shall not be kept inside its thawed water. Donot use thawed water (for health
purposes) and discharge it.
You may use thawing feature asspecified inthe cooking chart.
Food
Cookie
Cake
Pie
Muffin
Pasta (baked)
Fish
Lamb
Mutton
Veal
Turkey
Poultry
Defrost
170-180
170-190
180-220
160-180
190-210
220-MAX
220-MAX
220-MAX
220-MAX
220-MAX
220-MAX
60-120
Cookingtime(min.)
25-30 Center shelf
30-40 Center shelf
40-50 Center shelf
30-40 Center shelf
20-30 Center shelf
30-40 Center shelf
90-120 Center shelf
90-120 Center shelf
90-120 Center shelf
45-55 Center shelf
75-100 Center shelf
55-60 Center shelf
8

Usage of top and bottom heaters and turbo fan is recommended while
thawing. Asthe thawing time varies as per the weight ofthe food, check it
once inawhile.
Do not cook using the rectangular and circular trays at the same time in the
oven.
We recommend you topre-heat your oven 8 to10minutes before cooking.
This oven is intended for household cooking only. Do not use for other
purposes.
IF YOUR OVEN DOES NOT OPERATE
Please check ifthe power cord isplugged in the outlet securely. Check the
mainssupply.
Check the fuse.
Check for any damage to the power cord. Contact the authorized dealership if
the issue isnot resolved.
OVEN LAMP (*)
WARNING: Toavoid electric shock, ensure that the device
circuit is open before changing the lamp. (Open circuit means
that the power iscut-off.)
Cut off power supply ofyour appliance first, and endure
that it is cooled down.
Remove glass protector byrotating as shown inthe figure.
Then, remove the lamp byrotating it,and install the new
lamp with the same specifications. Lamp specifications
should be as follows:
230 V, AC
15 W
Type E14
Finally, install the glass protector to itsoriginal position.
MAINTENANCE AND CLEANING
Unplug your appliance.
Appliance may be very hot while it is being operated or after a short while when it is
operated.
In this case, do not touch hot parts.
Do not clean the interior parts, door, tray and other parts of the oven with tools such
as bristle brushes, steel wool or knives. Do not use abrasive and scratching detergents.
9

CURING YOGHURT
Select yoghurt mode from thermostat section while the oven is
empty, set the switch to lower resistance, pre-heat for 10
minutes and start curing at somewhere else.
For curing, weboil the rawmilk we have purchased at 90°C for
minutes, and then cool itdown to 43-45°C (curing temperature).
Add yeast with a ratio of1%-3%add stir slowly while the milk is at
this temperature. Put the milk mixed with yeast to the 1st shelf of
the pre- heated oven without closing its lid and close the oven
door and set the timer to manual. After 5 hours, remove the
cured yoghurt from the oven and keep it at room temperature for
15-20minutes, and keep the yoghurt without shaking it for 1 day
at 4°C in a refrigerator. After 1 day, yoghurt is ready tobe
consumed. Bon appetite.
STEAM CLEANING
This allows cleaning of the dirt that issoftened bythe steam
occurred inside the oven without using chemicals.
Remove all accessories from the oven. Put 2 glasses ofwater
inside the square tray, andplace the tray to the bottom shelf.
Bring the thermostat to steam cleaning
mode. Set the timer to 30minu tes.
Bring the switch to lower resistance mode.
After operating the oven for 30minutes, open the door and wipe
the inner surface ofoven with adamp cloth.
3
3
10

OVERVIEW
Using the Digital Programmer
OT-2000-LED-CL-X3FA6X is an electronic timing module that allows your food in the
oven to be ready for service at any time you want. You only need to program the
cooking time and the time that you want your food to be ready.
It can also be used as a minute-programmed alarm clock independent from the oven.
WHEN THE POWER IS SUPPLIED
When the power is first supplied, the oven is deactivated. The time and letter A are
flashing on the screen. The time that seems on the screen is not correct and should
be adjusted (see. Time settings). To set the cooking program, you should first switch
to Manual Mode (see. ManualMode)
MANUAL MODE
1) Press ‘M button toswitch to
manual mode
TIME SETTING:
The time can be set only in a cooking program. First press the keys + and - at the same
time and then you can set the time forward and backward using the keys + and -. A
long press on these buttons will change the time faster.
11
2) Press the keys + and - at the same
time to switch to manual mode

1) Press + and - at the same time.
2)Set the time using the keys +
Note: If the button - or + is not pressed for 5 seconds, the time setting mode
automatically stops. You can stop the time setting mode immediately by pressing the
keys + and - at the same time.
12

ALARM TIME SETTINGS
Using this function, you can set your alarm clock to go off at the desired time.
1) Select the setting mode 2) Set the time using 3) In a few seconds, the
CANCELLING THE ALARM
1) Alarm starts to go off 2) You can cancel the alarm by pressing
AUTOMATIC COOKING PROGRAM
If you start to cook the food you put into the oven immediately, you only need to
enter the cooking time. Example: We put the food we want to cook in the oven,
and we want to cook it for 2 hours and 15 minutes.
1) Now, it is 18:30 2) Enter the cooking time
setting mode by
pressing
‘M’ button twice.
3) Set the time using the
keys + or -.
The oven clock is programmed to cook
your meal for 2 hours and 15 minutes
starting from now. Make sure you set
the other control buttons on the oven
to the desired cooking functions and
temperature.
4) In a few seconds, the
screen will show the time and
cooking program selected.
Note: You can cancel the cooking program by switching to Manual Mode when setting
the cooking program or when
13

the program is running.
We have seen in the example above that the automatic cooking process can be
immediately started by setting the cooking time. By pressing the button “M” three
times, you can see and adjust, if necessary, the time when the food is ready (end of
cooking). In the example below, the food in the oven is set to be ready at 21:30.
1) Pressing the button “M” three times. The ‘End’ signal and the time when the food
is ready will be shown one after another, 18:30+2:15=20:45.
2) Set the end of cooking time using
the buttons + or
3)In a few seconds, the screen will
show the current time
In this case, we have programmed our oven so that your food will be ready at 21:30.
We have programmed the cooking time before to 2 hours and 15 minutes. In this case,
the oven starts cooking at 19:15 and will cook for 2 hours and 15 minutes and the
cooking program will finish at 21:30.
The screen to be displayed
when cooking starts
The screen to be displayed when cooking
finishes
When the cooking program has finished, the buzzer is activated and it will play for 7
minutes if not silenced.
1) Turn off the oven. 2) Reset the oven time.
Note: The oven will be deactivated until you switch your timing
module to manual mode.
In the example above, first the cooking time isset and the end ofcooking
time automatically calculated
14

has been changed by us in the second phase. You can also set the end of cooking time
first if you want; in this case, the cooking time will be automatically calculated and can
be changed in the second phase if desired.
IN CASE OF POWER FAILURE
In case ofmains power failure, the oven will remain off for safety reasons. Inthis case,
the time and the letter ‘A’on the screen flash. If there isarunning cooking program
in this position, itwill bedeleted. The time will be displayed 0:00 and it should be set.
First switch to Manual Mode (See.Manual Mode). Then you can set the time using the
buttons + or-.(Note: The system will maintain its status in case ofshort-term power
failure.
Note: If you are not going to use your oven, make sure that you set the button onthe
oven tooff position.
THE FLASHING LETTER ‘A’ SHOWS THAT THE OVEN IS DEACTIVATED AND YOU SHOULD
SWITCH TO ‘MANUAL MODE’ TO GO BACK TO NORMAL POSITION.
ALARM LOUDNESS SETTING
You can change the loudness ofyour alarm with this setting.
You can hear the loudness level you set bypressing the button (-).
You can listen to and select the next loudness level by pressing the button (-) and then
keep and pressing itagain. (3 Levels)
Now, your alarm will go off at the lastloudness level that you listen.
Note: By default, the alarm loudness level isthe highest. In case the mains power fails
for a long time, if the alarm loudness ischanged, itwill return to default settings.
15

COMPLIANCE WITH AEEE REGULATIONS AND WASTE DISPOSAL
10
16
1- This product does not contain the dangerous and prohibited
materials indicated in "Waste Electrical and Electronic Equipment Control
Regulation" published by Ministry of Environment and Urbanisation of
Republic of Turkey. it complies with AEEE Regulation.
2-
You can help to protect the environment and natural resources by delivering the used
products for recycling. Before disposing of the product, cut the power cord and
render it non functional form.
PACKAGE INFORMATION
The product's packaging is made of recyclable materials, in accordance with the
National Legislation. Do not dispose the packaging waste with the household
waste or other wastes, dispose it to the packaging collection areas specified by
local authorities.
This product is made of recyclable and reusable high quality parts
and materials. Therefore, do not dispose of this product with
other domestic wastes at the end of its life cycle. Take it to a
collection point for electrical and electronic equipment. You can
ask your local administration about these collection points.
