Simoco SRP9100 User manual

SRP9100
Portable Radio
Conventional – PMR
Operating Instructions
TNM- -E-0047 Issue 1.2a, January 2010
Comgroup Australia Pty. Ltd.
1270 Ferntree Gully Road
Scoresby
ictoria, 3179
Aus
tralia
www.comgroup.net.au

SRP9100 ~ PMR Portable Radio ser Guide
© Comgroup Australia 2010 i TNM- -E-0047 Issue 1.2a
ASSOCIATED DOC MENTATION
The following documentation is available for use with the SRP9100 series of
products:
TNM-U-E-0048 SRP9100 Trunked Operating Instructions
TNM-U-E-0045 SRP9120 Brief User Guide
TNM-U-E-0046 SRP9130 Brief User Guide
To order copies of any of the above publications, or any other Simoco product,
contact SImoco on [phone] or send a Fax on [phone]. The
Simoco web site also has a comprehensive list of documentation available for
download.
www.simoco.com
ABO T THIS DOC MENT
This publication is copyright and no part may be reproduced without prior
permission of Comgroup Australia.
Due to our policy of continuous improvement to our products and services,
technical specifications and claims, correct at time of publication, may be
subject to variation without prior notice.
Comgroup Australia has endeavoured to ensure that the information in this
document is fairly and accurately stated, but does not accept liability for any
errors or omissions.

SRP9100 ~ PMR Portable Radio ser Guide
TNM- -E-0047 Issue 1.2a Page ii © Comgroup Australia 2010
SAFETY
1. Do NOT operate your portable radio, without a handsfree kit, whilst
driving a vehicle.
2. Do NOT operate your radio in an explosive atmosphere.
Obey the 'Turn Off Two-way Radios' signs where these are posted,
e.g. on a petrol station forecourt.
3. Do NOT dispose of batteries in a fire.
EMR SAFETY
The SRP9100 portable radio transceiver complies with the RF exposure
guidelines as defined in the ARPANSA* standard "Radiation Exposure Levels
to Radiofrequency fields – 3kHz to 300GHz", Schedule 5 when:
(1) the radio is operated by an "aware" user and
(2) the transmit duty cycle does not exceed 50% over a six minute period
and
(3) the normal operation entails the antenna being separated from the
users body by not less than 2.5cm.
* Australian Radiation Protection and Nuclear Safety Agency Radiation
Protection Series Publication No. 3.
HINTS FOR SING THE RADIO
• When speaking, hold the radio a few centimeters from your mouth and
speak across it, rather than into it. The microphone is located near the
top left of the portable radio’s speaker grille.
• Keep the length of your conversation to a minimum to conserve battery
life.
• When it is possible to move location, avoid making calls from known poor
signal-strength areas such as the radio systems fringe areas (limit of
range) or from screened or shadowed areas, e.g. an underground car
park or underpass.

SRP9100 ~ PMR Portable Radio ser Guide
© Comgroup Australia 2010 iii TNM- -E-0047 Issue 1.2a
CONTENTS
ASSOCIATED DOC MENTATION .......................................................... I
ABO T THIS DOC MENT....................................................................... I
SAFETY ................................................................................................... II
EMR SAFETY .......................................................................................... II
HINTS FOR SING THE RADIO ............................................................. II
CONTENTS............................................................................................. III
1. INTROD CTION ................................................................................ 1
1.1 Overview......................................................................................1
1.2 Configuration ..............................................................................1
2. FRONT PANEL CONTROLS ............................................................. 2
3. MEN SYSTEM.................................................................................. 4
3.1 Menu Navigation.........................................................................4
3.2 Default Settings ..........................................................................5
4. MAIN MEN SCREENS..................................................................... 6
4.1 Channels Screen ........................................................................6
4.2 Phonebook Screen .....................................................................7
4.3 Status Screen..............................................................................8
4.4 Stored Calls Screen....................................................................9
4.5 Setup Screen...................................Error! Bookmark not defined.
5. COMMON F NCTIONS AND FACILITIES ...................................... 12
5.1 Switch-On/Switch-Off...............................................................12
5.1.1 olume Adjustment ..........................................................12
5.2 Receiving...................................................................................13
5.3 Transmitting..............................................................................14

SRP9100 ~ PMR Portable Radio ser Guide
TNM- -E-0047 Issue 1.2a Page iv © Comgroup Australia 2010
5.4 SELCALL Functions................................................................. 15
5.4.1 Receiving a Selcall........................................................... 15
5.4.2 Sending a Selcall ............................................................. 15
5.4.3 Other Selcall Functions .................................................... 15
5.5 Scan Functions ........................................................................ 17
5.5.1 Scan Screen..................................................................... 17
5.5.2 Scan-Edit Screen [keypad version only]........................... 18
5.6 M TE Level Setting.................................................................. 19
5.7 DTMF Operation ....................................................................... 19
5.8 Keypad Lock ............................................................................. 19
6. SET P...............................................................................................20
6.1 Set-up Sub-Menus.................................................................... 20
6.1.1 User Options .................................................................... 21
6.1.2 Mute Adjust ...................................................................... 21
6.1.3 Phone Book Edit .............................................................. 21
6.1.4 Contrast 23
6.1.5 Alert olume..................................................................... 23
6.1.6 Information ....................................................................... 23
6.1.7 Network 23
7. SPECIAL F NCTION B TTONS .....................................................24
7.1 Monitor ...................................................................................... 24
7.2 Squelch Defeat ......................................................................... 24
7.3 Reset ......................................................................................... 24
7.4 Scan........................................................................................... 24
7.5 Send-2 ....................................................................................... 24
7.6 Transpond Disable................................................................... 24
7.7 CTCSS ....................................................................................... 24
7.8 Mute........................................................................................... 24
7.9 Goto Chan A, B, C, D................................................................ 24
7.10 Special Enc 1…8 ...................................................................... 24
7.11 Alarm ......................................................................................... 25

SRP9100 ~ PMR Portable Radio ser Guide
© Comgroup Australia 2010 v TNM- -E-0047 Issue 1.2a
7.12 Repeater Defeat ........................................................................25
7.13 Low Power ................................................................................25
7.14 Channel p and Down .............................................................25
7.15 Send Channel Encode..............................................................25
7.16 Send DTMF 1 and 2 ..................................................................25
7.17 ser CTCSS ..............................................................................25
7.18 Scramber On/Off.......................................................................25
8. OPTIONS.......................................................................................... 26
8.1 High Capacity Battery...............................................................26
8.2 Mid Capacity Battery ................................................................26
8.3 Single Pocket Charger .............................................................26
8.4 Four Pocket Charger ................................................................26
8.5 Vehicle Mounted Charger ........................................................26
8.6 Lightweight Carry Case............................................................26
8.7 Heavy Duty Carry Case.............................................................26
8.8 Shoulder Strap..........................................................................26
8.9 Lightweight lapel Speaker Microphone..................................26
8.10 Medium weight lapel Speaker Microphone ............................26
8.11 Heavy Duty lapel Speaker Microphone...................................26
8.12 Lightweight Headset ................................................................26
8.13 Earpiece.....................................................................................26
9. TRO BLESHOOTING...................................................................... 27
APPENDIX A - ALERT TONES AND MESSAGES
APPENDIX B – LCD DISPLAY LAYO T
APPENDIX C - GLOSSARY

SRP9100 ~ PMR Portable Radio ser Guide
© Comgroup Australia 2010 1 TNM- -E-0047 Issue 1.2a
1. INTROD CTION
1.1 O VERVIEW
The SRP9100 Series Radios are versatile Digital Signal Processor (DSP)
controlled, two-way portable radios. The SRP9100 Series is available in a
number of frequency bands and versions for specific applications. This
manual describes the operation of the SRP9130 PMR model with a 12 key
keypad and SRP9120 PMR without numeric keypad.
The radio is software programmable and it can be customised to the
operational requirements of your particular fleet. Your Simoco representative
can help in programming your radio facilities to meet your present and future
requirements.
A wide range of accessories is available to complement the SRP9100 series
radios, including chargers, antenna, headsets, covert kits, holsters and carry
cases. Refer to Simoco for comprehensive descriptions.
This guide describes the facilities that are currently available and can be
programmed into the PMR mode of the SRP9100.
1.2 C ONFIG RATION
Before you can use the SRP9100, it must be configured using the Field
Personality Programmer (FPP). The configuration process loads the
customised radio channels, signalling and user options so that the radio will
operate with your system.
Although this manual defines the configuration and use of the PMR mode, the
radio can be configured easily to trunk mode using the FPP.

SRP9100 ~ PMR Portable Radio ser Guide
TNM- -E-0047 Issue 1.2a Page 2 © Comgroup Australia 2010
2. FRONT PANEL CONTROLS
Press To Talk Switch
On-Off Volume
Function Button # 5
Function Button # 6
Function Button # 7
Often used as Alarm
Keypad for DTMF or
Channel or Selcall Entry
Function Button # 2
Function Button # 1
Function Button # 3
Function Button # 4
Accessory Socket
Microphone
Indicator LED
Figure 1 – SRP9100 Portable
Button/ Control Function
On/Off/ olume Rotate the switch clockwise to turn on the
radio and then set the volume to the desired
level.
Rx/Tx/Power LED Green LED illuminates when receiving a
signal. Red LED Illuminates when the radio is
transmitting. Flashing Red indicates low
battery.
Keypad Used to dial channel numbers, set status and
send DTMF or Selcall. Note that the
SRP9120 variant does not have a keypad.
Function Button F1
M This button’s function may be configured by
the programmer, it is typically programmed as
the menu select key.
Function Button F2
- This button’s function may be configured by
the programmer, it is typically programmed as
the channel down key

SRP9100 ~ PMR Portable Radio ser Guide
© Comgroup Australia 2010 3 TNM- -E-0047 Issue 1.2a
Function Button F3
+ This button’s function may be configured by
the programmer, it is typically programmed as
the channel up key
Function Button F4
OK This button’s function may be configured by
the programmer, it is typically programmed as
the Send Channel Encode key. Note that
during menu operations, it becomes a confirm
key.
Special Function F5
This button’s function may be configured by
the programmer.
Special Function F6
This button’s function may be configured by
the programmer.
Special Function F7
This button’s function may be configured by
the programmer, it is typically programmed as
the Alarm/Emergency key

SRP9100 ~ PMR Portable Radio ser Guide
TNM- -E-0047 Issue 1.2a Page 4 © Comgroup Australia 2010
3. MEN SYSTEM
The SRP9100 radio software uses a programmed Menu structure to enable
the operator to access all of the radio options. The structure of the menu
(comprising up to thirteen screens) can be programmed to meet the specific
needs of individual customers. Figure 2 illustrates the complete menu
structure of the radio.
Any or all of the Screens can be programmed or hidden with the following
provisos:
• The Phone Book Screen is always programmed in and is the default
Screen displayed.
• The Main Menu provides access to the usual Screens required to operate
the radio.
• The Setup Sub-Menus provide access to the radio setup parameters.
• When options are placed in a Setup Sub-Menu, Setup should be offered
as a sub menu in the Main Menu selection.
• Both the Main Menu and the Setup submenus can each hold up to ten
screens.
Programming of menus is a configuration task normally performed by the
system manager using programmer software.
3.1 M EN N AVIGATION
The menu button is normally labelled ‘M’ and enables you to step through all
of the Menu Screens by repeatedly pressing the button.
The menu button may be reassigned to any function key using the field
programmer.

SRP9100 ~ PMR Portable Radio ser Guide
© Comgroup Australia 2010 5 TNM- -E-0047 Issue 1.2a
3.2 D EFA LT S ETTINGS
Figure 2 - Menu Navigation
Note that the menu flow shown is an example of the default menu. The menu
options can be configured and changed in the field programmer. Other menu
sequences are possible in your radio.
Pressing the “M” key steps through the
menus on the left. The Set-up sub menu
on the right can be entered by pressing
the “OK” key when Set-up is selected.
Once in the Set-up sub menu, pressing the
“M” key steps through the sub menus. Exit
by reset key or wait for timeout.

SRP9100 ~ PMR Portable Radio ser Guide
TNM- -E-0047 Issue 1.2a Page 6 © Comgroup Australia 2010
4. MAIN MEN SCREENS
4.1 C HANNELS S CREEN
502
Mt Buller
Channel Number
Channel Name Signal Strength (RSSI)
Battery Level
The Channels Screen shows the current channel and allows it to be changed.
The Channel Name shows the text associated with the radio channel.
The RSSI Bars indicate the signal strength of the current channel.
The Battery Level indicates the current battery condition
Several Icons can be displayed as shown below:
ICONS INDICATION
The envelope icon indicates that there are one or more stored
messages.
The outline speaker icon indicates that a signal is present and
the radio is unmuted.
Received Signal Strength Indication (RSSI). A stronger
signal will display more bars.
One bar shown = approx. –118dBm, Two bars = approx. –
106dBm, Three bars = approx. -96dBm, Four bars = approx. –
84dBm.
Battery level indicator. A new battery should display four
bars.
The – and + buttons scroll through the entries within the current Menu Screen
(e.g. Channels).

SRP9100 ~ PMR Portable Radio ser Guide
© Comgroup Australia 2010 7 TNM- -E-0047 Issue 1.2a
The Keypad may be used to enter numbers directly, which temporarily appear
on the Message-Line, e.g. Changing channels from the keypad can be done
by entering the channel number and pressing the ‘#’ button. [only available on
keypad version]
Note: If DTMF is enabled then pressing keypad buttons will send the
corresponding DTMF tone. [only available on keypad version]
4.2 P HONEBOOK S CREEN
This Screen need only be accessed if Selcall is used. Selcall Identity
information is stored for various users and calls can be placed to them from
this Screen.
The -/+ buttons scroll through the Phonebook entries.
002
J. Wright
Entry Number
Entry Name Signal Strength (RSSI)
Battery Level
The display will alternately show the name of the entry and the Selcall identity
when viewing a Phonebook entry.
Pressing the OK button will place a call to the displayed identity.
Notes: 1 If the Selcall requires a Status to be included then the Saved-
Status-Value will be used (See description of Status below )
2 The Identity shown on the display when this Screen is exited may
be referenced from other Menu Screens and is called the
Current-Phonebook-Entry

SRP9100 ~ PMR Portable Radio ser Guide
TNM- -E-0047 Issue 1.2a Page 8 © Comgroup Australia 2010
4.3 S TAT S S CREEN
This Screen need only be accessed if Selcall is used. Selcall Status is stored
here and can be sent from this Screen.
S02
On Route
Status Number
Status Text Signal Strength (RSSI)
Battery Level
The -/+ buttons scroll through the Status List entries.
Pressing the OK button will send the displayed Status to the Current-
Phonebook-Entry.
Notes: 1 When a Status is sent, it becomes the current Saved-Status-
Value, and can be used at a later time from other Menu Screens
2 The Saved-Status-Value can also be set from the Channel or
Phonebook Screens by entering the number (from the Keypad)
and pressing the * button The value is saved but not sent [only
available on keypad version]

SRP9100 ~ PMR Portable Radio ser Guide
© Comgroup Australia 2010 9 TNM- -E-0047 Issue 1.2a
4.4 S TORED C ALLS S CREEN
This screen allows the ten most recent missed Selcalls (ones not answered
before the Alert-tone stops) and received Status Selcalls to be reviewed.
The icon will show in the Main Channel Screen when there is an entry in
this Screen. Note that storing of calls is configurable and must be enabled in
the Field Programmer Selcall decodes menu.
Q02
Warehouse
Stored Call Number
Calling Party Text
The displayed text identifies the caller (e.g. Warehouse). If Status text is
used, (e.g. Call Depot) it will be displayed alternately in the position of the
calling party text.
The displayed number (Q02) shows the queued position of the entry. The
most recent call is shown whenever this Screen is displayed.
Press the -/+ buttons to scroll through other Stored Calls.
Press the OK button to Selcall that caller.
Press the assigned Reset key to return to the Channel Screen without
making a call.
Note that the Stored Calls Screen will eventually time out and return to the
Channel Screen.

SRP9100 ~ PMR Portable Radio ser Guide
TNM- -E-0047 Issue 1.2a Page 10 © Comgroup Australia 2010
4.5 S END M ESSAGE S CREEN
This Screen allows the user to send a free form text message to another radio
user in a similar manner to a cell phone SMS.
M7
Send Message
Memory Entry Number
(defined by FPP)
Upon selecting the Send Message menu option with the OK button, a flashing
cursor will appear on the lower left hand corner of the screen.
Each key is labelled with up to 3 text characters. The text characters are
entered by pressing the keypad key once for the first character, twice for the
second and three time for the third.
After a short delay, the cursor will advance for the next character entry.
To move the cursor left or right, use the -/+ buttons.
To delete a character, move the cursor over the character and then press the
function key that is programmed with the Reset function.
When the message is complete, press the OK button to send it. The screen
will then ask for the address to send it to with “Enter No.” Enter the address
and then press OK. The message will be sent.

SRP9100 ~ PMR Portable Radio ser Guide
© Comgroup Australia 2010 11 TNM- -E-0047 Issue 1.2a
4.6 S ET P S CREEN
Use this Screen to access the other Set-up submenus.
M10
User Options
Memory Entry Number
(defined by FPP)
Press (OK) button to show the first of the submenus, and then the -/+
buttons to scroll through these screens.
The actual set-up submenus available will depend on the configuration by the
Field Programmer.
These can include:
• Screen Contrast
• Phone Book Edit
• Mute Adjust
• Alert olume
• Network
• Info
• User CTCSS
• Received Signal Strength Indication (RSSI)
Refer to section 6 for a description of these functions.

SRP9100 ~ PMR Portable Radio ser Guide
TNM- -E-0047 Issue 1.2a Page 12 © Comgroup Australia 2010
5. COMMON F NCTIONS AND FACILITIES
5.1 S WITCH -O N /S WITCH -O FF
Turn the On Off Volume Knob clockwise to switch the portable radio ON.
The display will illuminate and show a ‘Welcome Message’ and the Selcall
Identity of the portable radio.
After a brief time the display will revert to the Channel Screen, at which time
the portable radio is ready for use.
Turning the On Off Volume knob anticlockwise will switch the portable radio
off.
If the radio Inactivity Timer is enabled, the portable radio will automatically
turn off after several hours of inactivity (i.e. no buttons pressed).
The radio will emit warning beeps for 10 seconds prior to switching off.
Pressing any button will reset this timer.
5.1.1 Volume Adjustment
The olume Control adjusts the speech level at the loudspeaker or remote
speaker microphone. Rotating clockwise increases the volume and anti-
clockwise decreases the volume.
Note: The radio may be programmed so that the volume cannot be turned off
completely
