Simpli Home WyndenHall Brooklyn + Max AXCBSAVN08-WH User manual

Avington / Mia / Hayes
Laundry Hamper
Model # AXCBSAVN08-WH
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

This furniture is designed for indoor use.
CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
Care & Maintenance
To clean, use a soft or slightly damp cloth, then wipe with a clean, dry cloth.
Dust with a soft dry cloth.
Do not use ammonia-based cleaning products, as they will damage the finish.
Do not leave liquids or damp cloths on this furniture.
To avoid dulling of the finish, do not place this furniture in direct sunlight.
Please inspect and tighten all screws or bolts on a regular basis to ensure
proper performance and safety of your item.
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

.A.BL .BR
Part Description
TOP
QTY 1 LEFT SIDE
QTY 1 RIGHT SIDE QTY 1
BOTTOM SHELF
QTY 1 BOTTOM BAR QTY 1 TOP BAR QTY 1
BACK PANEL
QTY 1 DOOR
QTY 1 INSIDE LEFT PANEL QTY 1
.C.D.E
.F.G.HL
.HR .I.J
Front /
Avant
Front /
Avant
Front /
Avant
INSIDE RIGHT PANEL
QTY 1 INSIDE BOTTOM PANEL QTY 1 INSIDE BACK PANEL QTY 1
6
Model # AXCBSAVN08-WHPre-Assembly Information

Hardware Description
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
CAM LOCK PIN
CAM LOCK
QTY 12 SETS
WOOD DOWEL
Ø8 X 30mm
QTY 18 HINGE
QTY 2
MAGNET AND PLATE
QTY 1 SET
PHILLIPS SCREW
M4 X 40mm
QTY 4
PHILLIPS SCREW
M3 X 15mm
QTY 20
HANDLE
M4 X 25 mm
QTY 1 SET
PHILLIPS SCREW ROUND HEAD
M4 X 15mm
QTY 14
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
LID SUPPORT
QTY 1
.1.2.3
.4.5.6
.7.8.9
.10
7
Model # AXCBSAVN08-WHPre-Assembly Information

Front /
Avant
Front /
Avant
Front /
Avant
A
BL
BR
F
E
D
C
G
HR
HL
I
J
8
Model # AXCBSAVN08-WHComponents - Key Diagram

Step 1
P
X
1
1
1
Front /
Avant
A
2
2
Front /
Avant
Front /
Avant
2
2
11
2
1. Attach Cam Lock Pins 1 into pre-drilled holes on each part A , BL , BR .
2. Insert Wood Dowels 2 into guide holes on each part BL , BR , C .
3. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
BL
BR
C
9
Model # AXCBSAVN08-WHAssembly

Step 2
P
X
11
9
4
3
9
G
1. Attach four Cam Lock Pins 1
into pre-drilled holes on Door G .
2. Attach Magnet Plate 4 using Phillips Screws 9 into
pre-drilled holes on Door G .
3. Attach Hinge 3 to Door G using Phillip Screws 9 into pre-drilled holes on Door G .
4. Use Phillips screwdriver to secure Cam Lock Pins and Screws. Do not over-tighten.
22
2
22
D
E
5. Insert four Wood Dowels 2 into guide holes on parts D , E .
6. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
7. Attach Magnet 4 using Phillips Screws 9 into pre-drilled holes on part E .
8. Use Phillips screwdriver to secure Screws. Do not over-tighten.
9
4
10
Model # AXCBSAVN08-WHAssembly

Step 3
I
J
HL
HR
HL
HR
J
7
7
1. Use four Phillips Screws 7 to attach part J through guide holes from parts HL , HR
to pre-drilled holes of part J .
2. Use Phillips screwdriver to secure Screws . Do not over-tighten.
3. Slide part I firmly into slots on parts HL , HR , J .
Step 4
Front /
Avant
Front /
Avant
BL
BL
EE
C
C
DD
1
1. Align Wood Dowels and Cam Lock Pins with
guide holes and attach parts C , D , E to Left Side BL .
2. Insert two Cam Locks 1 into guide holes on Bottom Shelf C .
3. Use Phillips screwdriver to secure Cam Locks.
1
11
Model # AXCBSAVN08-WHAssembly

Step 5
1
1. Repeat Step-4 for the Right Side BR .
Front / Avant
Front / Avant
Front / Avant
Front / Avant
BL
BL
BR BR
CC
EE
D
D
Step 6
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
1
1. Align Cam Lock Pin and Wood Dowels with guide holes on Sides BL , BR and Top A
and attach Top A to Sides BL , BR .
2. Insert two Cam Locks 1 into guide holes on each Side BL , BR .
3. Use Phillips screwdriver to secure Cam Locks.
BR BR
BL BL
A
A
12
Model # AXCBSAVN08-WHAssembly

Step 7
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
G
9
D
G
6
6
1. Attach Hinge on Door G to Bottom Bar D using Phillips Screws 9 into pre-drilled holes
on Bottom Bar D .
2. Use Phillips screwdriver to secure screws .
3. Use Phillips screwdriver to attach Handle 6 to Door G .
4. Attach Lid Support 5 to Door G and Left Side BL
using Phillips Screws 9 into pre-drilled holes on parts G , BL .
5. Use Phillips screwdriver to secure screws .
G
9
9 5
BR
BL
G
BL
G
13
Model # AXCBSAVN08-WHAssembly

Step 8
2
HL
J
HR
I
2
2
1. Insert two Dowels 2 into guide holes on each Side HL , HR .
2. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
Step 9
HL
HR
J
G
G
HL
HR
1
1
G
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
1. Align Cam Lock Pin and Wood Dowels with
guide holes on Sides HL , HR and Door G
and attach Sides HL , HR to Door G .
2. Insert two Cam Locks 1 into guide holes
on each Sides HL , HR .
3. Use Phillips screwdriver to secure Cam Locks.
14
Model # AXCBSAVN08-WHAssembly

Step 10
Note:
The back of the cabinet frame does not have pre-drilled holes to attach the back panels.
Warning Label
1. Attach the Back Panel F to back frame using Phillips Screws Round Head 8
through guide holes from Back Panel.
2. Use Phillips Screwdriver to tighten screws. Do not over-tighten.
Front /
Avant
F
F
Front / Avant
8
8
15
Model # AXCBSAVN08-WHAssembly

Furniture Tip Over Restraint Assembly
NOTE: The screwdriver is not
included in the hardware pack.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
Step 11
WALL
10
10
16

1. Attach one of the mounting brackets securely to the back edge of
the furniture. Use the shorter screw.
2. Determine where furniture is to be placed and mark location on
the wall for mounting bracket screw hole approximately 2 inches
below the bracket mounted to the furniture.
3. Drill a 3/16 inch hole in the wall. Press the plastic anchor into the
hole and gently tap until the flange on the anchor is against the
wall surface.
4. Position the bracket over the anchor and use the longer screw to
securely attach the bracket to the wall.
5. Place the furniture so the back edge is in line with the bracket on
the wall.
6. Lace an end of the nylon zip-tie strap down through each bracket.
Bring both ends together and slide the smooth side upright
through the square-shaped end and pull through to create the
“locked” position.
7. Check to make sure the strap is securely laced and locked to the
brackets.
·DO NOT put a TV or other heavy objects on top of furniture not
intended for use with a TV
·DO NOT place heavy objects in top drawers or on top shelves
·DO NOT let children climb or hang on drawers, doors or shelves
Px
P
P
x
x
Furniture Anti-Tipping Restraint Instructions
17
