DT41BL, DT41MB ASSEMBLY INSTRUCTIONS

2
For our most up-to-date instructions, to request missing, lost, or broken parts, or for any other Customer Service issues,
please visit our website at www.walkeredison.com or call us at 877-207-5906.
General Assembly Guidelines
I. Ensure that all parts are available before beginning assembly.
II. Follow each step carefully to ensure proper assembly of this product.
III. The four main types of hardware used to construct this unit are: wood dowels,
cam and bolt, hex-head bolts, and screws.
IV. Power tools should not be used to assemble this product.
V. To attach wood dowels, place provided glue in the holes before inserting dowel.
Wipe away excess glue immediately.

3
9
4
8
6
3
6
6
.
.
5.
1
2
7
DT41BL, DT41MB Parts List

4
DT41BL, DT41MB Hardware Parts List
* The hardware quantities listed are required for proper assembly.
Some extra hardware may have also been included.
Phillips head screwdriver not included
A. Cam lock 2 pcs
B. Cam bolt 2 pcs
C. Dowel 4 pcs
D. Glue tube 1 pc
E. Screw (6x50mm) 4 pcs
F. Hex wrench 1 pc
G. Door stopper 1 pc
H. Screw (3x12mm) 2 pcs
I. Shelf support pin 12 pcs
J. Nail 18 pcs
K. Screw 2 pcs
L. Door hinge 4 pcs
M. Screw (4x20mm) 16 pcs
N. Handle 2 pcs
P. Screw (4x22mm) 4 pcs
Q. Screw (4x32mm) 2 pcs
R. Plug
S. Nylon Strap
1 pc
1 pc
T. Screw (3x12mm) 1 pc
Sticker 2 pcs

5
1
HG
Q
5.
G
H
T
Step 2Step 1
S
1
B
4
3
A
A
C
D
Attach mounting block (5) to stand top (1) using screws (Q).
Attach nylon strap (S) to stand top (1) using screw (T).
Attach door stopper (G) to mounting block (5) using screws (H).
Insert cam bolts (B) into stand top. Insert dowels (C) into stand top and cam locks (A) into side panels
(3 & 4). Attach side panels (3 & 4) to stand top. Tighten cam locks (A) using a screwdriver as shown in
the diagram.

6
Attach stand base (2) to frame assembly using hex screws (E). Tighten using
hex wrench (F). Cover cam locks (A) with the provided stickers as shown in the
diagram.
Turn stand upright. Attach the back panel (7) using nails (J) at the points shown in the diagram.
Step 4
Step 3
2
F
E
7
J
STICKER X 2

7
Insert shelf support pins (I) into the stand frame as shown in the diagram.
Attach shelves (6) to the support pins. Adjust to desired height if necessary.
Attach door handles (N) to the stand doors using screws (P).
Attach door hinges to the doors using screws (M).
Attach screw (K) to the corner of each door as shown in the diagram.
Step 6
Step 5
6
6
6
I
8
.
M
L
K
9
.
K
NP
N
P
M
L
ML
ML

8
Attach doors (8 & 9) to stand frame at the hinges using screws (M).
Step 8Step 7
8
.
9
.
M
M
Finished stand should appear as shown in the diagram.

9
We strongly recommend that you attach the unit to your wall to help prevent it from falling over.
Due to the wide variety of wall types, the necessary wall screws are not provided. However, we have
included illustrations showing installation for the four most common wall types.To attach to the wall,
use only wall screws and plugs (if needed) suitable for the particular wall as illustrated below.
Suitable screws and plugs are available from any hardware store. Please seek professional advice if
you are unsure of your own ability to do this correctly.
Step 9 (Optional)
BACK PANEL
NYLON STRAP
WALL
WOOD SCREW
(NOT INCLUDED)
BACK PANEL
NYLON STRAP
CEMENT WALL
PLUG
CEMENT SCREW & PLUG
(NOT INCLUDED)
BACK PANEL
NYLON STRAP
DRYWALL
DRYWALL ANCHOR SCREW
(NOT INCLUDED)
BACK PANEL
NYLON STRAP
WALL
METAL SCREW
(NOT INCLUDED)
Cement/Brick Wood Studs
Metal Studs
Drywall
CABINET TOP CABINET TOP
CABINET TOP CABINET TOP
WOOD STUD
METAL STUD
