Simplicity 4562 Setup guide

Attachment
Illustrated
Parts List
Rev. 04/2007
500 N. Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
www.simplicitymfg.com
MANUFACTURING, INC.
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.2007 TP 400-4562-00-AT-SMA
Mf
g
. No. Descri
p
tion
Attachment
1694496 48" Turbo Collector Legacy XL
1734846
Part No.:

Table Of Content
s
Torque Specification Chart ..................................................................... Inside Back Cover
PRODUCT COMPONENTS PAGES
48" Turbo - Mounting Group ................................................................................................................................ 4
48" Turbo - Turbo Blower Assembly .................................................................................................................... 6

48" Turbo - Mounting Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
986434D2
The above parts group applies to the following Mfg. Nos.:
4
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694496 - 48" Turbo Collector Le
g
ac
y
XL
TP 400-4562-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
48" Turbo - Mounting Group
Footnotes
KNOB, Plastic1 1700669SM 1
COVER, Belt (Includes Ref. No. 3 & 6)2 1700728SM 1
POP-RIVET, 3/16 x 5/163 2828707SM 2
NUT, Push, 5/164 1933988SM 1
NUT, Hex Flange, #10-325 1928919SM 2
HINGE6 1700649SM 1
PLUG, Mower Cover7 1674020SM 1
COVER, LH Mower8 1700013SM 1
SCREW, Rd Hd Machine, #10-32 x 3/89 1922121SM 2
CAPSCREW, Hex Hd, 7/16-14 x 2-1/410 1927120SM 1
PULLEY ASSEMBLY11 1679903ASM 1
PIN, Cotter12 1918447SM 2
ROD, Pivot13 1700853SM 1
NUT, Hex, 3/8-1614 1916950SM 2
WASHER, Lock, 3/815 1916965SM 2
CAPSCREW, Hex Hd, 3/8-16 x 116 1921210SM 2
HINGE ASSEMBLY, Front, 48"17 1727403SM 1
BRACKET, LH Pivot18 1700801ASM 1
CAPSCREW, Hex Hd, 5/16-18 x 7/819 1923325SM 2
NUT, Hex, 7/16-1420 1918213SM 2
WASHER, Lock, 7/1621 1918199SM 2
BRACKET, RH Pivot22 1700802ASM 1
NUT, Hex, 5/16-1823 1917372SM 4
WASHER, Lock, 5/1624 1917356SM 4
SPRING, Torsion25 1700851SM 1
CAPSCREW, Hex Hd, 7/16-14 x 2-3/426 1926110SM 2
HINGE ASSEMBLY, Rear, 48"27 1725998ASM 1
The above parts group applies to the following Mfg. Nos.:
5
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694496 - 48" Turbo Collector Le
g
ac
y
XL
TP 400-4562-00-AT-SMA

48" Turbo - Turbo Blower Assembly
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
986434D1
The above parts group applies to the following Mfg. Nos.:
6
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694496 - 48" Turbo Collector Le
g
ac
y
XL
TP 400-4562-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.
48" Turbo - Turbo Blower Assembly
Footnotes
PLATE, Mounting1 1727404ASM 1
CAPSCREW, Hex Hd,1/4-20 x 5/82 1921959SM 9
CAPSCREW, Hex Hd,1/4-20 x 2-1/43 1960346SM 1
STOP, Deflector4 1700936SM 1
CAPSCREW, Hex Hd, 1/4-20 x 7/85 1924009SM 1
NUT, Hex Flange Whiz Lock, 5/16-186 1927557SM 6
RETAINER, Bearing7 1665982ASM 4
BEARING8 2108202SM 2
DECAL, Danger9 1700259SM 1
HOUSING, Blower (Incl. Ref. No. 9)10 1706654SM 1
HOOK, Stone Guard11 1679900SM 1
NUT, Hex Flange Whiz Lock, 1/4-2012 1960608SM 9
NUT, Push, 5/1613 1933988SM 6
WASHER, Plain,1/214 1676435SM 1
CARRIAGE BOLT, 5/16-18 x 3/415 1931333SM 6
FAN ASSEMBLY (5 Blade)16 1706631ASM 1
KEY, Woodruff, 3/1617 2860403SM 1
CARRIAGE BOLT, 3/8-16 x 1-1/418 1960268SM 1
NUT, Hex Jam Lock, 3/8-1619 1928731SM 3
PLATE, Shroud20 1706652ASM 1
STOP, Belt21 2170397SM 1
WASHER, 5/1622 1919326SM 1
COVER, Top23 1702553SM 1
WASHER, 3/824 1924940SM 5
SETSCREW, Sqr Hd, 5/16-18 x 3/825 1960619SM 2
PULLEY, Driven26 1706634SM 1
SPACER27 1666114SM 1
CAPSCREW, Hex Hd, 3/8-16 x 1-1/228 1921969SM 1
SPRING, Extension29 1679554SM 1
PULLEY, Idler, Adjustable30 2174561SM 1
IDLER ARM ASSEMBLY31 1701827ASM 1
CAPSCREW, Hex Hd, 3/8-16 x 132 1921210SM 1
WASHER, 3/8 Special33 2157424SM 1
WASHER, Lock, 5/1634 1917356SM 1
NUT, Hex, 5/16-1835 1917372SM 1
PULLEY, Idler, Fixed36 2154534SM 1
CAPSCREW, Hex Hd, 1/4-20 x 3/437 1923341SM 2
S-HOOK39 1672689SM 1
NUT, Hex Nylon Lock, 1/4-2040 1920397SM 4
The above parts group applies to the following Mfg. Nos.:
7
2007Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
1694496 - 48" Turbo Collector Le
g
ac
y
XL
TP 400-4562-00-AT-SMA

Torque Specification Chart
FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%)
Hardware
Grade
SAE Grade 2 SAE Grade 5 SAE Grade 8
Size Of in/lbs in/lbs in/lbs
Hardware ft/lbs Nm. ft/lbs Nm. ft/lbs Nm.
8-32 19 2.1 30 3.4 41 4.6
8-36
20 2.3 31 3.5 43 4.9
10-24
27 3.1 43 4.9 60 6.8
10-32
31 3.5 49 5.5 68 7.7
1/4-20
66 7.6 810.9 12 16.3
1/4-28
76 8.6 10 13.6 14 19.0
5/16-18 11 15.0 17 23.1 25 34.0
5/16-24 12 16.3 19 25.8 27 34.0
3/8-16 20 27.2 30 40.8 45 61.2
3/8-24 23 31.3 35 47.6 50 68.0
7/16-14 30 40.8 50 68.0 70 95.2
7/16-20 35 47.6 55 74.8 80 108.8
1/2-13 50 68.0 75 102.0 110 149.6
1/2-20 55 74.8 90 122.4 120 163.2
9/16-12 65 88.4 110 149.6 150 204.0
9/16-18 75 102.0 120 163.2 170 231.2
5/8-11 90 122.4 150 204.0 220 299.2
5/8-18 100 136 180 244.8 240 326.4
3/4-10 160 217.6 260 353.6 386 525.0
3/4-16 180 244.8 300 408.0 420 571.2
7/8-9 140 190.4 400 544.0 600 816.0
7/8-14 155 210.8 440 598.4 660 897.6
1-8 220 299.2 580 788.8 900 1,244.0
1-12 240 326.4 640 870.4 1,000 1,360.0
Hex Head Capscrew
Hex Nut
Lockwasher
Washer
Carriage Bolt
NOTES
1. These torque values are to be used for all hardware
excluding: locknuts, self-tapping screws, thread forming
screws, sheet metal screws and socket head setscrews.
2. Recommended seating torque values for locknuts:
a. for prevailing torque locknuts - use 65% of grade 5
torques.
b. for flange whizlock nuts and screws - use 135% of
grade 5 torques.
3. Unless otherwise noted on assembly drawings, all torque
values must meet this specification.
Hardware Identification & Torque Specifications
Common Hardware Types
Screw, 1/2 x 2
Body
Diameter
Body
Length
Inside
Diameter
Nut, 1/2”
No
Marks
3/8” Bolt or Nut
Wrench—9/16”
3/8
5/16” Bolt or Nut
Wrench—1/2”
5/16
1/4” Bolt or Nut
Wrench—7/16”
1/4
1/2” Bolt or Nut
Wrench—3/4”
1/2
DIA.
7/16
DIA.
7/16” Bolt or Nut
Wrench (Bolt)—5/8”
Wrench (Nut)—11/16”
Wrench & Fastener Size Guide
Standard Hardware Sizing
When a washer or nut is identified as 1/2”, this is the
Nominal size , meaning the inside diameter is 1/2 inch; if a
second number is present it represent the
threads per inch
When bolt or capscrew is identified as 1/2 - 16 x 2”, this
means the
Nominal size , or body diameter is 1/2 inch; the
second number represents the
threads per inch (16 in this
example, and the final number is the
body length of the
bolt or screw (in this example 2 inches long).
The guides and ruler furnished below are designed to
help you select the appropriate hardware and tools.
0
1/4 3/4
1/2
1
1/4 3/4
1/2
2
1/4 3/4
1/2
3
1/4 3/4
1/2
4
