Manual
Simrad StructureScan™ LSS-1
Sonar Module
English

Disclaimer
As Navico is continuously improving this product, we
retain the right to make changes to the product at any
time which may not be reflected in this version of the
manual. Please contact your nearest distributor if you
require any further assistance.
It is the owner’s sole responsibility to install and use the
instrument and transducers in a manner that will not
cause accidents, personal injury or property damage.
The user of this product is solely responsible for
observing safe boating practices.
NAVICO HOLDING AS AND ITS SUBSIDIARIES,
BRANCHES AND AFFILIATES DISCLAIM ALL LIABILITY
FOR ANY USE OF THIS PRODUCT IN A WAY THAT MAY
CAUSE ACCIDENTS, DAMAGE OR THAT MAY VIOLATE
THE LAW.
Governing Language: This statement, any instruction
manuals, user guides and other information relating
to the product (Documentation) may be translated
to, or has been translated from, another language
(Translation). In the event of any conflict between any
Translation of the Documentation, the English language
version of the Documentation will be the official version
of the Documentation.
This manual represents the product as at the time
of printing. Navico Holding AS and its subsidiaries,
branches and affiliates reserve the right to make
changes to specifications without notice.
Copyright
Copyright © 2010 Navico Holding AS.
Feedback from you
Your feedback is important and helps Navico ensure
that this manual is a valuable resource for all marine
technicians. E-mail your comments or suggestions about
this manual to the following address:
[e-mail]
StructureScan LSS-1 Installation manual | 1

2 | StructureScan LSS-1 Installation manual
Compliance Statements
The StructureScan™ LSS-1 complies with the following
regulations:
• FCC Part 15
• CE compliant per EN60945
• C - Tick
For more information please refer to our website:
www.simrad-yachting.com.
Warning
The user is cautioned that any changes or modifications
not expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
the interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna•
Increase the separation between the equipment and•
receiver
Connect the equipment into an outlet on a circuit•
different from that of the receiver
Consult the dealer or an experienced technician for•
help

StructureScan LSS-1 Installation manual | 3
Contents
Introduction .................................................. 4
Parts included in package...............................4
Required tools and supplies ............................5
LSS-1 Indicator lights ....................................5
Installation and wiring .................................. 6
Selecting mounting location ...........................6
Mounting the LSS-1 module............................7
Wiring .........................................................7
Connecting the LSS-1 to your display.......7
Connecting the transducer .....................7
Power connection ..................................8
Specications .............................................. 10
Spare parts and accessories........................ 11
Spare parts ........................................ 11
Assessories ........................................ 11
Drawings ..................................................... 12
LSS-1 dimensions ....................................... 12

4 | StructureScan LSS-1 Installation manual
Introduction
This document describes how to install the
StructureScan™ LSS-1 and connect the unit to
transducers and display units.
Separate installation instruction for transducers are
included with the transducer package.
Parts included in package
For spare parts and part numbers, see Parts list page
11.
Item No. Description.
1 LSS-1 Black box module
14 pin power cable
1 Fuse, 3A Automotive Type
1 Fuse holder
2 Yellow Ethernet caps
1 Close end crimp connector
4Phillips stainless steal screws (#8)
1Warranty
1 This manual

StructureScan LSS-1 Installation manual | 5
Required tools and supplies
Drill
2 mm
(5/64”)
Drill Bit
Phillips screw
driver Pencil
LSS-1 Indicator lights
IND. STATUS DESCRIPTION
1, 2 and 3
Off
No Ethernet communication
(cable unplugged, bad cable or
remote unit not powered)
Flashing -
yellow
Ethernet communication is
working (link/active light)
Sonar
Off Transducer not connected or
cable/transducer is broken
On - Green Transducer detected/locked on to
bottom
Flashing -
green
Transducer detected/not locked
on to bottom
Power
Off No power or not switched on
(check yellow wire)
On - Red System booting
On - Green System operating
Slow ashing
- Red/green
Product in factory mode;
Ethernet communication working
Fast ashing -
Red/green
Product in factory mode; no
Ethernet communication (cable
unplugged or bad cable)
LINK/ACT
1 2 3 SONAR
POWER

6 | StructureScan LSS-1 Installation manual
Installation and wiring
The LSS-1 connects between the transducer and display
unit, or via a network switch.
Before installing the LSS-1, consider location and cable
runs necessary to connect the module to the display unit
and power source.
Do not run the transducer cabling near the LSS-1 DC
power cables or any VHF antenna coax or power cables
for the VHF.
The LSS-1 conforms to the appropriate Electromagnetic
Compatibility (EMC) standards; but proper installation is
required to get the best use and performance from this
product.
Selecting mounting location
When installing the module certain factors that could
affect its operation should be considered. Ensure you
have as much separation as possible between different
electrical equipment, (see diagram).
Make sure the transducer cable is long enough to
connect to the LSS-1. If not, an extension cable is
available. For transducer cable length see Spare parts
and accessories, page 11.
X
X
Electromagnetic interference
Gasoline fumes
Vibration
Heat
Sunlight
Salt spray
Physical damage
2.0 m (6.5 ft) Min 1.8 m (6 ft) Min
1.5 m (5 ft) Min
RADAR
Radio or AIS Transmitter
Compass

StructureScan LSS-1 Installation manual | 7
Mounting the LSS-1 module
Preferably mount the LSS-1 module on a vertical surface
so that cables exit sideways. If that is not feasable,
create drip loops to prevent moisture entering the
connectors.
Fasten the LSS-1 by using the screws included with the
unit.
Secure cables and ensure to not put strain in the
connectors.
Wiring
Refer to the Wiring diagram on page 9.
Removing the transducer cable from the LSS-1
while the module is powered on can cause sparks.
Remove the transducer cable only after the module
has been disconnected from its power source.
Connecting the LSS-1 to your display
The LSS-1 connects to your display over an Ethernet
network, either directly or via an Ethernet network
switch.
Connecting the transducer
The StructureScan transducer connects to the LSS-1
with the cable supplied with the transducer.

8 | StructureScan LSS-1 Installation manual
On boats with large dead rise angle two
StructureScan transducers can be used.
They are connected to the LSS-1 by using
the optional Y cable.
Connect the transducers according to the
labeling on the Y-cable.
Power connection
The unit will turn on when power is applied.
It is recommended to connect the LSS-1 to NSE Power
control bus (A), and set NSE to power control master.
Alternatively the unit can be powered directly from the
vessel’s battery (B).
Pin Color Signal
1
2
4
3
1Black 12 V battery -
2Blue NC
3Red 12V battery +
4Yellow Ignition sense
Red
Fuse
Black
NSE
Power
Control
bus
Black
BA
Yellow
Red
Yellow
Switch
Blue
(no connect)
Blue
(no connect)
12 V DC
12 V DC
+_
+
_
LTWLTW
LTW

StructureScan LSS-1 Installation manual | 9
If the LSS-1 is connected directly to the vessel’s battery,
the module will continue to draw power even when it
is not in operation. It is recommended that the yellow
power cable wire be tted with an optional on/off switch,
allowing the LSS-1 to be powered off when not in use.
Reference Description
A Ethernet cable
B StructureScan Transducer cable
C StructureScan Y-cable (option)
For part numbers, see Spare parts and assessories
on page 11.
A
A
B
B
B
orC
PWR
LTWLTW
LTW LTW
LTW LTW

10 | StructureScan LSS-1 Installation manual
Specications
Mechanical
Dimensions: .................................................. See page 12
Weight: ..................................................... 0.8 kg (1.8lbs)
Material: ................................................ Plastic/Aluminum
Environmental
Operating temperature:............... -15° - +55°C (5° - 131°F)
Storage temperature:...............-40° - +85°C (-40° - 185°F)
Waterproof integrity.................................................. IPx7
Notified compliance.......................... CE, FCC, C-Tick, RoHS
Electrical
Power supply:....................................................... 12V DC
Voltage input: ...............................................10 - 17 V DC
Fuse:..................External: 3A Fast Acting Automotive Blade
Transmit power: .......................................... WRMS: 500W
WPK: 4000W
Current drain: ................................................Max: 0.75 A
Typical: 0.60 A
Inrush: 4.7 A pk
Communication
Ethernet: ............................................................. 3 ports
Shared device support: ..................................................3
Transducer
Number of devices support: ............................................1
Frequencies: ...................................... 455kHz and 800kHz

StructureScan LSS-1 Installation manual | 11
Spare parts and accessories
Spare parts
Item Part no. Description.
000-10238-001 Simrad LSS-1 module
032-0055-08 4 pin power cable
Assessories
Item Part no. Description.
000-00099-003 LSS-1 Thru-hull transducer,
including 9 m (30 ft) cable
000-00099-007
LSS-1 Skimmer mount
transducer, including 6 m
(20 ft) cable
LTW LTW
000-00099-006 Transducer Extension cable,
3 m (10 ft)
LTW
LTW
LTW
000-10202-001 StructureScan Y-cable,
0.3 m (11.8”)
000-0127-51 Ethernet cable, 1.8 m (6 ft)
000-0127-29 Ethernet cable, 4.6 m (15 ft)
000-0127-30 Ethernet cable, 7.6 m (25 ft)
000-0127-37 Ethernet cable, 15.2 m (50 ft)
000-0124-70 Kit of 4 replacement caps for
connectors

12 | StructureScan LSS-1 Installation manual
Drawings
LSS-1 dimensions
178 mm (7.0”)
188 mm (7.4”)
191 mm (7.5”)
210 mm
(8.26”)
58 mm
(2.27”)
ø 4.7 mm
(0.185”)
200 mm
(7.87”)

Simrad LSS-1 manual, English, Doc.no.988-10003-001 *988-10003-001*
