Simrad SP90 - REV E User manual

Simrad SP90
Low frequency long range fishery sonar
Operator manual
A L W A Y S A T T H E F O R E F R O N T O F T E C H N O L O G Y
www.simrad.com

Simrad SP90
Low frequency long range fishery sonar
Software version V1.1.XX
WARNING
The sonar must never be powered up when the ship is
in dry dock. The transducer will be damaged if it
transmits in open air. To prevent inadvertent use of the
sonar, set switch S102 at the rear side of the Sonar
processor Unit to Off whenever the vessel is in dry dock.
850--164511

Note
Simrad AS makes every effort to ensure that the information contained within this
document is correct. However, our equipment is continuously being improved and
updated, so we cannot assume liability for any errors which may occur.
Warning
The equipment to which this manual applies must only be used for the purpose for which
it was designed. Improper use or maintenance may cause damage to the equipment or
injury to personnel. The user must be familiar with the contents of the appropriate manuals
before attempting to operate or work on the equipment.
Simrad AS disclaims any responsibility for damage or injury caused by improper
installation, use or maintenance of the equipment.
Copyright
E2002 Simrad AS
ISBN 82-8066-003-8
The information contained within this document remains the sole property of Simrad AS.
No part of this document may be copied or reproduced in any form or by any means, and
the information contained within is not to be communicated to a third party, without the
prior written consent of Simrad AS.
Simrad AS
Strandpromenaden 50
Boks 111
3191 Horten
Telephone: [phone]
Facsimile: 33 04 29 87
Internet: www.simrad.com
A L W A Y S A T T H E F O R E F R O N T O F T E C H N O L O G Y

Operator manual
I
850--164511 / B
Sections
This document is the Operator manual for the Simrad SP90. sonar system. It provides the
information and specifications necessary to operate the system safely and efficient.
1 System description (page 1)
2 Display modes (page 12)
3 Sonar Operating Panel (page 22)
4Operation(page 35)
5 Menu description (page 52)
6 Parameters (page 82)
7 Maintenance (page 147)

Simrad SP90
II 850--164511 / B
Remarks
References
Further information about the SP90 system may be found in the following manuals:
•SP90 Installation manual

Operator manual
III
850-164511 / B
Table of contents
1 SYSTEM DESCRIPTION 1..................................
1.1 Introduction 1..............................................
1.2 System overview 2..........................................
Main units 2..............................................
Wheelhouse units 2........................................
Sonar room units 4.........................................
1.3 Options 5.................................................
General 5................................................
Stabilization system 5......................................
Triple- or multiple-frequency 5...............................
Scientific output 6.........................................
1.4 Functional description 7......................................
Introduction 7.............................................
Functional principles 7......................................
Reception 9...............................................
Transmission 10............................................
1.5 Peripheral equipment 11......................................
2 DISPLAY MODES 12.........................................
2.1 Introduction 12..............................................
2.2 Bow Up 13.................................................
2.3 North Up 14................................................
2.4 True Motion 15.............................................
2.5 1805 / Audio 16.............................................
2.6 2705 / Vertical 17............................................
2.7 Bow Up / Vertical 18.........................................
2.8 True Motion / Vertical 19......................................
2.9 Dual 1 20..................................................
2.10 Dual 2 21..................................................
3 SONAR OPERATING PANEL 22.............................
3.1 Introduction 22..............................................
3.2 The fields 22...............................................
Main switch 23.............................................
Symbol 24................................................
Mode 26..................................................
Gain 27...................................................

Simrad SP90
IV 850-164511 / B
Range 28..................................................
Cursor 29.................................................
Train 31..................................................
Tilt 33....................................................
Various 34.................................................
4OPERATION 35..............................................
4.1 Introduction 35..............................................
What this chapter contains 35.................................
Maintaining the sonar 35.....................................
Important when docking the vessel 35...........................
4.2 Start and stop procedures 36...................................
Start procedure 36..........................................
Stop procedure 36...........................................
Dry-docking safety measures 37...............................
4.3 Menu operation 38...........................................
Introduction 38.............................................
Screen presentations 39......................................
Menu structure 41..........................................
Menu buttons 42............................................
Selecting a new parameter value 43.............................
Stored parameters 44........................................
4.4 Visual aids 45...............................................
Common information on the display 45.........................
Moving the boundary lines 45.................................
4.5 Cosmetics 46...............................................
4.6 Installation of options 49......................................
4.7 On--line help 51.............................................
5 MENU DESCRIPTIONS 52...................................
5.1 Introduction 52..............................................
5.2 Menu structure 54...........................................
Purpose 54................................................
Sonar type 55..............................................
Mode selection 55..........................................
Menus 56.................................................
Status 56..................................................
5.3 Active menus 57.............................................
Overview 57...............................................
Horizontal 58..............................................

Operator manual
V
850-164511 / B
Vertical 59................................................
Display 60................................................
Setup 61..................................................
Objects 62.................................................
Second ping 63.............................................
5.4 Temporary menus 64.........................................
Cosmetics 65..............................................
Store/Recall 66.............................................
System test 67.............................................
Sort Modes 68.............................................
View pop-up 69............................................
Object pop-up 71...........................................
5.5 View menus 73..............................................
GeoView 74...............................................
VerticalView 75............................................
CatchView 76..............................................
5.6 Messages 77................................................
Message categories 77.......................................
Warnings 78...............................................
Operator alarms 79..........................................
System alarms 80...........................................
Errors 81..................................................
6 PARAMETERS 82............................................
6.1 About parameter dialogues and help 82...........................
6.2 Alphabetical list 83..........................................
About 84..................................................
AGC (Automatic Gain Control) 85.............................
Audio volume 86...........................................
Bearing (Horizontal) 87......................................
Bearing (Vertical) 89........................................
Colour Threshold 90........................................
Colours 91................................................
Data Source 92.............................................
Default Setting 93..........................................
Direction Indicator 94.......................................
Display Gain 95............................................
Edit Gear (Purse) 96.........................................
Edit Gear (Trawl) 97........................................
Edit school 98..............................................

Simrad SP90
VI 850-164511 / B
External Synchronizing 99....................................
Fish alarm 100..............................................
Frequency 101..............................................
Gain 102...................................................
Gear 103...................................................
Heading 104................................................
Inspect object 105...........................................
Language 106...............................................
Menu 107..................................................
Message Bar 108............................................
Mode 109..................................................
Movements 110.............................................
Palette 111.................................................
Panel Backlight 112..........................................
Ping Sector 113.............................................
PP Filter 114...............................................
Pulse Form 115.............................................
Range 117..................................................
Range (CatchView) 119.......................................
RCG (Reverberation Controlled Gain) 120........................
Recall 121..................................................
Recall Mode 121............................................
Ruler 122..................................................
Scale 123..................................................
School 124.................................................
Scientific Output 125.........................................
Slant Range/True Range 126...................................
Speed 127..................................................
Stabilizer 128...............................................
Status 129..................................................
Store 130..................................................
Store Mode 130.............................................
Target Track 131.............................................
Tilt 132....................................................
Time and Date 134...........................................
Track History 135............................................
Track Window 136...........................................
Transducer 137..............................................
TVG (Time Variable Gain) 138.................................
Tx Power 139...............................................

Operator manual
VII
850-164511 / B
Units 140..................................................
User Setting 142.............................................
Wind Direction 143..........................................
Wind Speed 144.............................................
Zoom 145..................................................
Zoom Scale 146.............................................
7 ON-BOARD MAINTENANCE 147..............................
7.1 Introduction 147..............................................
7.2 Wheelhouse units 148.........................................
Cleaning 148...............................................
Dust filter 148..............................................
7.3 Transceiver Unit 149..........................................
Dust filter 149..............................................
Replacing fuses 149..........................................
7.4 Hull unit 150................................................
General 150................................................
Docking the vessel 151.......................................
Cleaning the transducer 152....................................
Motor overload switch 152....................................
Hoisting and lowering the transducer from the Sonar Room 152.......
Air bleeding 153.............................................
Lubrication of the Hull Unit 154................................

Simrad SP90
VIII 850--164511 / B
Document logistics
Rev Date Written Checked Approved
A01.03.02 RBr SØJ SØJ
B05.11.02 RBr SØJ SØJ
C
D
E
F
G
(The original signatures are recorded in the company’s logistic database.)
Rev Comments
AOriginal issue.
BUpdated to conform with SW 1.1.xx.
C
D
To assist us in making improvements to the product and to this manual, we would welcome
comments and constructive criticism. Please send all such - in writing or by e-mail - to:
Simrad AS
Documentation Department
P.O.Box 111
N-3191 Horten
Norway
or e-mail:
simrad.documenta[email protected]

System description
1
850-164511 / B
1 SYSTEM DESCRIPTION
1.1 Introduction
The Simrad SP90 sonar is a long range omnidirectional low
frequency sonar, designed for medium and large sized fishing
vessels, preferably for purse seiners. The standard frequency is 26
kHz (triple and multiple frequencies as option), and the beam can
be electronically tilted from +10 to –60 degrees.
Great emphasis has been placed on giving the best possible
presentations on a high resolution colour display. The processor
unit is controlled by Microsoft’s Windows 2000operating
system, which result in a flexible choice of display modes for a
large range of user applications.
The signal processing and beamforming is performed in a fast
digital signal processing system using the full dynamic range of the
signals. In addition to the traditional single frequency transceiver
system, the SP90 sonar contains an advanced frequency modulated
filter system (FM).
The cylindrical multi-element transducer allows the
omni-directional sonar beam to be tilted electronically down to -60
degrees. This allows you to automatically track schools of fish, and
to observe the whole water volume around the vessel. An optional
stabilization system is available for electronic pitch and roll
compensation.
This chapter covers the following subjects:
→System overview, page 2.
→Options, page 5.
→Functional description, page 7.
→Peripheral equipment, page 11.
Important notice:
Windows, Windows NT and Windows 2000 are either registered
trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries.

Simrad SP90
2850-164511 / B
1.2 System overview
Main units
The Simrad SP90 sonar consists of the following units:
•Wheelhouse units:
- Display monitor
- Sonar Operating Panel
- Processor Unit
- Loudspeaker
•Sonar room units:
- Transceiver Unit
- Hull Unit
→Seefigure1onpage3fortheSP90systemdiagram.
Wheelhouse units
The Display Monitor is normally a 18” or 20” high-resolution
colour LCD (Liquid Crystal Display). In addition to the sonar
picture, the monitor can also display the user menu for the
interactive operation. In order to ease the situation comprehension,
certain colours have been chosen to better the distinction between
the various elements in the scene.
The Operating Panel contains all necessary control functions for
operating the sonar. The controls are arranged in function groups,
which gives a clear and easy operation. Note that all sonar
operation also may be made from the roller ball, or from an
optional remote standard mouse.
The Processor Unit contains a ruggedized computer with
interface for the auxiliary equipment (log, gyro, GPS, echo
sounder, trawl systems, purse seine systems etc.). The processor
unit runs the Microsoft Windows 2000operating system,
modified by Simrad to suit the SP90 sonar requirements. One
signal cable is used for the communication with the Transceiver
Unit in the sonar room.
The Loudspeaker reproduces the audio of the echoes for the
selected audio channel.

System description
3
850--164511 / B
Display
unit
115/230Vac mains
115/230Vac mains
115/230Vac mains
Operating
panel
Processor
unit Loud-
speaker
Speed log
Course gyro
GPS
Transceiver Unit
Echo sounder
Trawl system
Purse seine system
230/380/440Vac
3 phase mains
(CD5997 / WMF / GIF)
Hull Unit
Figure 1 SP90 System diagram

Simrad SP90
4850--164511 / B
Sonar room units
The Transceiver Unit is located in the sonar room, close to the
Hull Unit. One signal cable is used for communication with the
Processor Unit in the wheelhouse. The transceiver performs the
signal processing and the digital beamforming of the 256
transmitters and 256 receiver channels, which are located on the
eight identical transceiver boards.
The standard Hull Unit is designed to be lowered 1.2 meters below
the ship’s hull. (An optional hull unit will lower the transducer to
1,6 meters below the hull.) The transducer can also be lowered to
any selectable middle position. Note that in case of voltage failure,
the Hull Unit can be manually raised or lowered by means of a hand
crank.
The cylindrical 256-elements transducer allows the sonar beam
to give full 360 degrees coverage of the water volume down to -60
degrees.
The optional sensor for the electronic stabilization of the sonar
beams is housed in the motor control unit which is mounted on the
Hull Unit.
WARNING If the transducer hits larger objects or bottom, the transducer
shaft may be bent, or in worst case it can be broken off. A
broken transducer shaft will cause water leakage in the top of
the shaft. To prevent larger leakages in such a case, do not raise
the transducer shaft to the upper position. To prevent serious
damages it is therefore of great importance to have a good
pump and warning system in the sonar room.

System description
5
850--164511 / B
1.3 Options
General
The standard SP90 is a single 26 kHz version with maximum 60
degrees tilt, and without beam stabilization.
Note that the options described below are pre-programmed into the
standard version. A code word is required to make the actual option
available. Simrad offers a 1 month free test period for each option.
→To enter the code words, refer to the procedure on page 49.
For a permanent installation of any of the option, a new code word
will be released when ordering the option.
Stabilization system
When the optional beam stabilizer is activated, both horizontal and
vertical beams will be stabilized electronically for roll and pitch
movements up to ±20 degrees. The beam direction will then
change continuously according to the vessel’s movements, and
secure an optimal contact with the targets even in rough seas.
Figure 2 Optional stabilization system
Triple- or multiple-frequency
In addition to the standard 26 kHz frequency, options are available
for triple and multiple frequencies.
•In the triple-frequency version, you can select between 24 kHz,
26 kHz and 28 kHz.
•In the multiple-frequency version you can select from 11
frequenciesfrom20to30kHzin1kHzsteps.
These selections are particulary useful when it is necessary to
suppress interference from other sonars.

Simrad SP90
6850--164511 / B
Scientific output
The Scientific Output is designed for research purposes. When
activated, the following data are available on an Ethernet (LAN)
output:
•Beam data
•Target data
•Own ship data
•Gear data
The scientific output option does not include any storage module.

System description
7
850-164511 / B
1.4 Functional description
Introduction
The basic principles of the SP90 sonar are unique because of the
256 separate transmitter and receiver channels with their
transducer elements spread around on the cylindrical transducer
array.
The transmission, reception and data processing are under
computer control, and the powerful capabilities of the sonar are the
results of sophisticated digital signal processing software and state
of the art hardware.
Functional principles
When the Omni beam is tilted, the total beam picture can be
compared with folding an umbrella, which means that all beams
in 360 degrees around the vessel have the same tilt angle.
Figure 3 Omni beam
The beam can be tilted from +10 up to -60 degrees down.
In addition to seeing the target from above, it is also possible to see
the target from the side, by using the vertical slice presentation. In
this case the beam covers a continuous vertical beam from 0 to -60
degrees in one transmission.

Simrad SP90
8850-164511 / B
Figure 4 60 degrees vertical slice
This vertical slice, which is presented by the white audio line in the
horizontal picture, can be selected to any bearing by the manual
training control. The combination of the Omni mode and the
vertical slice will give an optimal visualization of the catch
situation.
Figure 5 60 degrees Omni/Vertical combination
