Simuline Mini Rider 2 User manual

★★★
Mini Rider 2
User’s Manual

BEFORE USING THE PRODUCT, PLEASE READ THE FOLLWING:
To ensure the safe installation and operation of the Mini Rider #2, please follow the instructions
aimed at the users, operators and the person in charge of the installation. After careful reading and
understanding the warning displays and cautions please operate Mini Rider #2 carefully. It is
important to keep the ser ice manual with the product or in a con enient place for future reference.
Herein, an explanation that requires special attention is enclosed with dual lines. Depending on the
potentially hazardous degrees, the terms of DANGER, WARNING, CAUTION, etc. are used.
Try to understand the contents of the displays before the text.
Indicates that mishandling the
product by disregarding this
pictograph will cause se ere
injury or death.
Indicates that mishandling the
product by disregarding this
caution will cause a slight
hazardous situation, which can
result in personal injury and or
material damage.
Indicates that mishandling the
product by disregarding this
warning will cause a potentially
hazardous situation, which can
result in death or serious injury.
For safe usage of this product, the following pictographs are used:
Indicates, “HANDLE WITH CARE.” In order to protect the human body and
equipment, this display is attached to places where the User Manual should be
referred.
Indicates a “Protecti e Earth Terminal.” Before operating the equipment, make sure
the equipment is connected to the Earth Terminal (Ground Potential)
(This step may be omitted for products in which a power cord with earth wire is
used.)
● Per orm work in accordance with the instructions herein stated.
Instructions for the machine installation are explained by paying attention to the aspect of the
accident pre ention iews. Failing to perform work as per the instructions can cause accidents.
Only those who ha e technical expertise should perform the work to a oid hazardous situations,
the instructions herein state that the electrically and electronically qualified ser icemen should
perform such work on Mini Rider #2, which is designed to performed electromechanical functions
on a 3 DOF platform. (3 DOF = 3 x Degree of Freedom)
● Mains Power must be switched OFF be ore working on the machine.
To pre ent any electric shock, please turn OFF the mains power before starting the maintenance
work. If the work is to be performed during the power-on, then the qualified ser ice engineer
should follow the detailed technical & engineering Instructions from the Ser ice Manual.
● Make sure the Earth Terminal is at the Ground Potential (this is not required where a power cord is
build with an earth wire) This product is fitted with the Earth Terminal, therefore please connect that to
the “indoor earth terminal” by using the earth wire which will a oid any electric shock. After
performing repair of the Control equipment, ensure that the Earth Wire is firmly connected and
measure the Earth Bond Resistance with your test meter and the readings must be recoreded.
SIMULINE INC..
2

● It is important that the Power Supply used is itted with an “Earth Leakage Breaker”
Mini Rider #2 (MR #2) does not incorporate the Earth Leakage Breaker.
● Please use 20 Ampere “D” type MCB which will handle the surge current (Start up
Current)
Re er to Page (7) or detailed in ormation o “D” type MCB and why you must use 20A / “D” MCB
Using standard fuses exceeding the specified rating can cause a fire and electric shock.
● Speci ication changes by third party developers are NOT Allowed. Re-locating o the
machinery parts with in MR #2, and carry out Conversions, Modi ications o MR #2 with
out the consent o Simuline are also not allowed.
All the mo ing and static parts of the MR #2 include warning labels for safety and designed
related co ers for personal protection, etc. It is ery hazardous to operate the MR #2 by
remo ing parts and or modifying the circuits. Should doors, lids and protecti e parts being
damaged or lost, refrain from operating the product, and contact your MR #2 supplier or the
nearest distributor immediately. Simuline shall not be held responsible for any accidents,
compensation or damages to any third party, resulting from the specifications changes not
designated by Simuline. This will also oid the manufacturers Warranty.
● Ensure that the product meets the requirements o appropriate Electrical Speci ication.
Before installing the product, check for Electrical Specifications. Simuline products ha e a
nameplate on which Electrical Specifications are described. Ensure that the product is
compatible with the power supply AC oltage and with the AC frequency requirements of the
location. Using any Electrical Specifications different from the designated Specifications can
cause a fire or an electric shock and this will oid the manufacturers Warranty.
● Install and operate the product in places where appropriate lighting is available, allowing
warning labels to be clearly visible and understanding.
To ensure safety of the customers, labels and printed instructions describing potentially
hazardous situation are applied to places where accidents can be caused. Make sure where
MR #2 is operated has sufficient lighting allowing the warning labels are to be isible and read. If
any labels ha e been peeled off, please apply them again immediately. It is important to place an
order for warning labels etc with the machine supplier or with the nearest MR #2 distributor.
● Servicing the Game Display Monitor.
Display monitor (TV) parts are subject to (EHT) Extra High-Tension Voltage. E en, when the
Power is “OFF” some of the components are still accumulating oltage until the highly charged
capacitors are fully discharged. Therefore, only a Monitor Service Engineer should perform the
repairs and parts replacement, failing these procedures will oid the manufacturers Warranty.
● Make sure the Monitor Adjustments are carried out, as per display service manual.
Do not operate the product with “On-Screen” flickering or with colour blurring.
Using with-out proper adjustments may cause dizziness to the game players, or to the customers.
● When transporting or re-selling MR #2, the service manuals must accompany the product.
In case, commercially a ailable equipments such as printers ha e been used with MR #2, then it
is important to keep all the ser ice manuals together to help the next purchaser or the third party
operator to install the MR #2 with out any problems.
・Description herein contained may be subject to impro ement changes without notice.
・The contents described herein are full prepared with due care. Howe er, should any question
arise or errors can be found, please contact Simuline.
SIMULINE INC..
3

INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION.
Normally, at the time of shipment, Simuline products are in a status allowing for usage immediately
after transporting to the location. Ne ertheless an irregular situation may occur during
transportation. Before turning on the power, check the following points to ensure that the product
has been transported in a satisfactory status.
□Are there any dented portions or defects (cuts, etc.) on the external surfaces of the
cabinet?
□Are the Casters and Adjusters damaged?
□Does the power supply oltage and frequency requirement meet with those of the
location?
□Are all wiring connectors correctly and securely connected? Unless connected in the
correct direction, connector connections can not be made accurately. Do not insert
connectors forcibly.
□ The fuses used meet specified rating? Is the Circuit Protector in an energized status?
□ Are all accessories a ailable?
□Can all Doors and Lids be opened with the Accessory keys? Can Doors and Lids firmly
close?
SIMULINE INC..
4

◈ TABLE OF CONTENTS ◈
■ BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING
1. HANDLING CAUTION .........................................................................................................................5
2. INSTALLATION LOCATION CAUTION.................................................................................................8
3. CAUTIONS:OPERATION ..................................................................................................................10
4. SPECIFICATION ...........................................................................................................................14
5. NAME OF THE PARTS........................................................................................................................15
5-1. MAIN BODY ...................................................................................................................15
5-2.SCU (SYSTEM CONSOLE UNIT) - FRONT...................................................................................16
5-3. SCU (SYSTEM CONSOLE UNIT) – BACK ..........................................................................17
5-4. MCU (MOTION CONTROL UNIT)............................................................................................17
5-3. O.P PANEL ........................................................................................................... 18
6. ACCESSORY ...........................................................................................................................19
7. INSTALLING THE FENCE.............................................................................................................. ..19
8. INSTALLATION ASSEMBLY................................................................................................................20
9. PRECAUTION OF MOVING SYSTEM AT THE LOCATION ............................................................40
10. DESCRIPTION OF SAFETY DEVICES ................................................................................41
11. DESCRIPTION OF RIDES...................................................................................................................42
12. RIDE OPERATION INSTRUCTION...................................................................................................43
13. SYSTEM ON ................................................................................................................44
13-1. System On (POWER ON)).................................................................................................44
13-2. System O (Power OFF) ................................................................................................44
13-3. Emergency Situation..........................................................................................................45
14. Monitor ..............................................................................................................................46
15. Area Sensor .......................................................................................................................48
16. Grease up ..........................................................................................................................49
16-1. Actuator Grease Up ................................................................................................50
16-2. UNIVERSAL JOINT IN THE ACTUATOR..........................................................................50
16-3. Grease Up o Middle Joint ............................................................................................51
17. Maintenance ............................................................................................................................52
17-1. PERIODIC INSPECTION..................................................................................................... 52
18. TROUBLE SHOOTING .................................................................................................................54
18-1. TROUBLESHOOTING TABLE…………………………………………………………………….54
18-2. MCU ERROR…………………………………………………………………………………………54
SIMULINE INC..
5

1. HANDLING CAUTIONS
When installing, maintaining or handling the product, the following cautions should be obser ed in
order to enjoy the game safely.
Failure to follow the warnings listed below and in other parts of this manual may cause physical
injuries or damage to the machine.
●Before any installation or maintenance work, make sure to turn off the power.
Failure to do so may cause an electric shock or short-circuit. In case it is
necessary to keep the power on for a certain type of work, the manual will
explicitly state so.
● Do not suddenly pull out or insert the power plug from / into an outlet. It may
cause an electric shock or short-circuit.
● Do not attempt to touch any plug with wet hands. It may cause an accident due
to electric shock.
●Power cables / cords or grounding wires should not be exposed such as on a
passage. The exposure may cause physical injuries, possibly resulting in short-
circuit or electric shock.
● Do not place any article on power cables / cords nor damage them, for it may
cause a fire or electric shock.
● Do not pull on the power cables / cords unnecessarily during or after
installation. Damaged cords may cause a fire or electric shock.
● If any power cord is damaged, ask the manufacturer / supplier for a
replacement power cord. Using a damaged power cord can result a fire,
electric shock or electric current leakage.
● Make sure to earth the product. Incorrect grounding may also cause an electric
shock.
●Use the rated fuse only. Using any fuse of incorrect rating may cause a fire or
electric shock.
●Firmly connect IC boards and all connectors completely. Unstable connections
may cause an electric fire.
● Do not make any unauthorized changes or modifications to the product.
・Doing so may cause fire or an electric shock. In some cases it can hurt and
cause physical injury to the user / operator.
・ The manufacturer / distributor will not be liable for any accidents that occur
on products that ha e undergone unauthorized modifications or changes
performed by a third party.
● Make sure to always execute the routine maintenance procedures specified in
the manual.
●When cleaning the “Surface of the Monitor” (Glass / TFT/ LCD / Plasma) use a
soft and dry cloth. Do not use chemicals such as thinner or benzene.
● Static electricity can destroy electronic parts on IC boards. Make sure to
discharge any static electricity by measures such as setting hands to a
grounded metal plate before handling IC boards.
●There are some components / parts, which are not specially designed and
manufactured for the product. Please understand that in case the manufacturer
of such components / parts discontinues production or changes the
specifications, it may not be possible to repair or replace such products
regardless of the warranted period.
SIMULINE INC..
6

STICKER LABELS
The Mini Rider #2 contains sticker and labels stating the product’s Serial Number (S/N) and electrical
specifications. When you request a repair done or ha e any inquiries with regard to spare parts, check your
S/N first, before you contact the manufacturer or the machine distributor. The S/N is the identification number
of each product. Same models may ha e different parts used depending on the production time. Also models
may be impro ed after the manual is issued. To deal with each case effecti ely, it is necessary to supply the
unique Serial Number of the Equipment.
WARNING LABELS
All Simuline products ha e stickers and labels to warn the users, of their safety and any possible danger
situations. Also the warning labels are fitted to a oid any possible accidents while operating or maintenance
work is carried out. When machine needs ser icing please set up a warning sign to warn the players and the
general public. Specially, a qualified electrical & electronic engineer should carry out the necessary
maintenance work. Anyone, who will not follow the warning sings, will not be allowed to carry out the
engineering work or other maintenance duties.
SIMULINE INC..
7

SIMULINE INC..
“D” type MCB @ 20 Amp - Single Pole circuit breaker
MCBs or ‘Miniature Circuit Breakers’ are intended to gi e protection against o erloads and short circuits,
which can cause damage to cables and equipment.
Industrial Range “D” type MCBs detect o er currents due to both o erload and fault currents. The MCB will
operate and interrupt the supply to pre ent damage to the installation.
www.tlc-direct.co.uk/Products/CM9020D.html
For aluable information, please click the abo e Link.
The Electrical Power Consumption o Mini Rider 2
1. Start up current (Start – up “Peak Current”) : 19.8 amp = 5 K Watts
2. Running current: 10amp. = 3 K Watts
3. Single phase supply oltage : 200 ~ 240 olts
8

SIMULINE INC..
9

2. INSTALLATION LOCATION CAUTIONS
The product is intended for indoor use. Therefore, do not install it outdoors.
E en when installed indoors, the following locations should be a oided. They
may cause a fire, electric shock or breakdown.
・Places with raindrops or water leakage, or places with high humidity & damp
such as indoor swimming pools or showers.
・Places that ha e a high temperature such as places with direct sunlight or
close to heating sources.
・Places near flammable gas, explosi e chemical or dangerous substances.
・Places that are dusty
・ Places with an incline.
・Places with intense ibration
・Places near anti-disaster facilities such as emergency exit or fire extinguisher
・Any other place outside of the allowable temperature range (ambient temp.)
of ５℃~30℃.
RESTRICTIONS FOR USE
SIMULINE INC..
10

●Check your electric specifications.
Check whether the product conforms to the oltage, current and frequency
pro ided at the installation location. For the electric specifications, see the
plate (label) attached on the product.
If electric source outside of the specification is used, it can cause a fire or
electric shock.
●Inside the installation location, a breaker and an earth connection for the
product are required. An independent electric source for the product should be
pro ided to pre ent fire or electric shock.
●Make sure to use the power cable in accordance with power consumption as
described below. Using power cable of other electric specifications can cause
a fire or electric shock.
● Make sure to use the power with independent circuit breaker. Using any
power source without circuit breaker can cause a fire.
●Do not ha e many electrical cords connected to a single socket. O erload can
cause the generation of heat or a fire.
●If an extension cord is used, it should be rated the max current or higher as
described below. Using a cord of different specifications can cause a fire or
electric shock.
Please refer to page (7) “D” type MCB information and
The Electrical Power Consumption of Mini Rider 2
SIMULINE INC..
11

OPERATIONAL FLOOR AREA
●For proper operation, a floor area of 3700mm X 2500mm or more is required. In
case of interference with the motion of the cabin.
●Ventilation area specified in this manual should be secured. In addition,
obstacles should not block entilation ents and ports. Blocked entilation
may cause the generation of heat or a fire.
●In case any accident occurs while the product is operated on a floor area less
than specified, the manufacturer will not be responsible for any damages and
liability.
●In case the product cannot fit through the entrance of a location, do not
disassemble without proper preparations. Disassemble only the parts, as
specified in this manual. Do not attempt a disassembly procedure not
described in this manual. Special tools and adjustment procedures are
required to disassemble / assemble much of the mechanical parts of the
product. Improper disassemble / assemble can lead to accidents such as
electrical shock and human injury. If the product does not fit through the
entrance e en after the disassembly specified in this manual, then contact the
manufacturer or the distributor of the product or the contact pro ided in this
manual.
● Do not tilt the product or subassemblies in an attempt to pass through small
entrances. This can cause accidents during the transportation. In addition, it
can cause damage or deformation to parts and result in accidents during
operation.
To fit the product in a location, the size of the entrance should be, at least,
1300mm wide and 1550mm high.
SIMULINE INC..
12

3. CAUTIONS: OPERATION
For safe operation, please obey the following warnings and instructions.
CAUTIONS: OPERATION
Check the following cautions before working hours to pre ent accidents.
● To pre ent any player or other customers from headache or dizziness, the
product should be installed in a well-lighted place so that warning signs are
clearly isible. Improper lighting can cause unexpected problems such as
contact between customers, collision, and other undesirable situations.
● Adjust the monitor appropriately.
If monitor blinking is detected, do not lea e it un-adjusted. Inappropriate monitor
adjustment can cause dizziness or headache to players.
● Prepare a resting facility for players to take a rest in case he (she) needs to rest
due to conditions such as motion sickness.
● Check whether the le el adjusters are securely set to the ground. If not, the
product is not properly set and can result in an accident.
● Do not place any hea y article on the product. It can cause an accident if
dropped and can also damage components.
● Do not climb on the product. Accident can be caused from falling. If it is
necessary to check the top of the product, use a stepladder.
● Check whether any doors or co er sections are damaged or separated. It can
cause electric shock.
● Do not place the following articles on or inside the control panel, on top of the
seat, on the top of the product or in the icinity of the product. Doing so may
cause short-circuit, electric shock or damages to machine parts.
Vases, pots, cups, water containers, cosmetics and containers full with
chemicals, water bottles, soft drink cans, take away food packages etc…
● Check the surroundings before turning the product on. Once it is turned on, the
product is automatically initialized. If any person is too near to the product
during initialization, possible collision can occur during the mo ing of the cabin.
● For safe operation, make sure to execute a trial operation after power is on.
Since the cabin mo es, the product is equipped with safety de ices. Please
check whether these safety de ices are working normally as follows.
▪ Does the seat belt is fitted and secured by the player?
▪ Does the seat belt is free of damages or excessi e wear?
▪ Does the motion stop automatically when the seat belt is loosened / taken off?
▪ Does the seat belt is attached securely without looseness?
▪ Does the machine stop when the STOP button is pressed?
▪ Does the machine stop when the front / side beam sensors are tripped?
▪ Does the machine stop when the floor beam sensor is tripped?
● In addition to checking the safety de ices, make sure that the product mo es
normally. Any abnormal motion can cause accidents. Do not operate the
product unless all abnormalities are resol ed.
▪ Does the machine mo e in sync with steering wheel operation?
▪ Does the machine mo e smoothly?
▪ Does the machine mo e securely without looseness?
▪ Is there any abnormal noise or sound when mo ing?
▪ Is there any abnormal ibration when mo ing?
▪ Does the product return to the initial standby position and stop when the game
is completed?
SIMULINE INC..
13

● If any abnormality in the motion system is suspected, immediately stop all
operations, turn off the product and disconnect the power cord. Then, call your
machine distributor or the contact point listed in this manual. If the product is
operated abnormally, serious accidents such as electric shock, fire, collision can
occur.
● For the proper maintenance of the motion system, please call the contact point
listed in this manual. If improperly trained personnel perform the maintenance
work, it is possible that accidents can occur during the maintenance work and
that can cause accidents to customers and players. This will oid the
manufacturers Warranty.
● To help pre ent accidents, make sure to install the auxiliary fence and ensure
that the product operates properly within the fenced area. Failure to secure
sufficient floor space with the fence can result in accidents due to collision and
contact between players and objects.
● Make sure there is no damage to surfaces that the player touches during play.
Such damaged surfaces can cause cuts and injury.
CAUTIONS : OPERATION (PLAYER CONDITIONS)
To pre ent accidents and / or unnecessary problems, alert players or customers to be aware of
the following.
SIMULINE INC..
● Anyone who falls into one or more of the following categories should be pre ented
from playing the game. It may cause an accident or injuries.
▪ Persons who need assistance when walking, and persons with high blood
pressure or heart disease.
▪ Persons who ha e experienced spasms / con ulsions or unconsciousness’ after
playing a TV ideo or similar game.
▪ Persons who ha e neck or back trouble.
▪ Pregnant women or persons who are intoxicated..
▪ Persons susceptible to omiting from amusement rides.
▪ Persons that do not follow warning signs.
● E en persons who ha e ne er experienced discomfort due to phobic stimulation
may experience dizziness, nausea, and / or headaches from playing this game.
● If discomfort becomes se ere, ad ice a player to consult a doctor.
● Do not place any hea y articles or be erages on top of the product. Accidents from
the falling articles and accidents due to electric shock can occur.
● Do not insert your finger or any foreign substances into any open parts or doors of
the product. It may cause electric shock or short-circuit.
● Do not lean on or climb on the product. It may cause accidents from falling and
turno er of the product.
● Do not pull out the power plug recklessly. It may cause short-circuit or electric
shock.
14

SIMULINE INC..
● For safety reasons, persons shorter than 140cm (55.11 in.) are not permitted to
play this game. Please explain that such persons cannot be safely secured with
the pro ided safety belt.
● Persons whose weight is o er 120kg (265lbs.) are not permitted to board.
● Playing without the seat belt fastened can cause an accident by falling from the
cabin. Make sure the player secures their body with the seat belt before playing the
game
●. No one should hang on the cabin behind the seat. This can cause serious injury
due to falling, jamming of body parts between structures, and turno er of the
product. If anyone is found hanging on to the cabin, make sure the person gets off
immediately.
15

●. Make sure the game is not played with a child sitting on the players lap. Serious
injury can result due to the child being jammed between the player and the
control panel, or the child falling from the mo ing cabin.
● Nobody except the players should approach the product during play. Injury
resulting from collision and contact with mo ing parts can occur.
The safety sensor senses foreign substances on top of the base only. In
particular, since small children cannot anticipate the potential danger, make sure
that they are properly attended to near the product.
● Ensure that player’s feet are always inside the cabin and on the pedals. Feet that
are carelessly hung out or protruded from the cabin can be caught due to cabin
motion and serious injury such as fracturing can occur.
● Pre ent potential accidents or problems by disallowing play with bags, mufflers,
and other items strapped on the players’ necks, entering the cabin with drinks,
and other player actions that are potentially dangerous.
● If any abnormal or dangerous situation with the player is obser ed, stop the
motion of the product by pressing the “Motion Stop” button.
● Do not handle the product recklessly such as by hitting or kicking it.
Such beha ior can cause turno er of the product and material damage and may
result in injuries.
● When getting on the cabin, there is the danger of players tripping on the base and
hitting his/her head on steel structures of the product. Please make sure players
get on the product carefully.
● Ensure that nobody except the player touches or acti ates the ride and other
controls of the ride during play. It can cause injury due to collision between
persons or with mo ing parts of the product. It can also cause trouble between
the customers.
● Please alert players not to place any articles or baggage on the base floor of the
product. If the floor beam sensor does not detect them for some reason and keeps
operating, the items can be dispersed and/or projected and cause accidents to
bystanders.
● Before playing the game, ha e the player adjust the seat suitable for his/her
indi idual physical size. Playing the game in an unnatural position can cause
unexpected accidents.
SIMULINE INC..
16

4. Speci ication
■ Diamentions : 2300mm (W) x 3000mm (L) x 2450mm (H)
■ Weight: approx. 1200Kg
■ Power: Single Phase 230 olts AC @ 11A (during normal game operation)
■ Power Consumption: approx. 3Kw (during normal game operation)
■ Monitor: 42”
■ Weight Limit: 240kg for two passengers
5. Name o the parts
SIMULINE INC..
17

5-1. Main Body
Item Description
Motion Actuator
Mechanism Motion Dri ing Actuators and anti-twist structure made of links.
MCU (Motor Controller
Unit) Controllers that dri e the actuators. 3 units.
SCU (System Console
Unit) Contains system control, mo ie control unit and coin tower.
Area Sensor Area sensors that detect any obstacles. When triggered, motion stops
until the obstacles are remo ed and resumes after 3 sec.
Door Door for riders. (one side)
Cabin Sensor Cabin sensors that detect any obstacles. When triggered, motion stops
until the obstacles are remo ed and resumes after 3 sec
Pillar Frame Structure that hold up the motion system and MCU.
Cabin Semi-enclosed cabin with seats for 2.
Top Sign Board Sign Board
5-2. SCU (System Console Unit) - Front
SIMULINE INC..
18
Coin Selector
#1 Actuator
Top sign board
Cabin
Pillar frame
Cabin sensor Door
Area sensor
SCU
MCU
#2 Actuator #3 Actuator
Area sensor

<SCU Front Panel>
5-3. SCU(System Console Unit) – Back
SIMULINE INC..
19
②
③
⑧
④
①
①
①
②
Coin ault
Cash Box
<Coinchute Tower >
<System Control Computer>
<Trans ormer>
①
O.P Panel
Can Cable
DI/O Cable
VGA Cable
Speaker Cable

<SCU Rear Panel>
5-4. MCU (Motion Control Unit)
< MCU>
Item Description
1 Coin chute Tower Coin Selector, Coin Vault, Cash box
2 System Control PC Computer that controls the hardware and e erything that operates
the machine.
3 Transformer Adjusts the oltage according to the country.
SIMULINE INC..
20
Motor Power Connector Can Connector
④ ⑤
Power Cutoff Switch
System Off Switch
Power Cable
Main Power Switch
④
⑤
⑥
⑦
MCU Power input Connector
Actuator
Encoder
Limit
