UNIS To Tha Net Low Profile GMP User manual

Operation Manual
IMPORTANT
Low Profile Version

To Tha Net Low Profile GMP Manual
08/25/2020
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]
When contacting Service, you will need the following information
and the name of your authorized distributor.

To Tha Net Low Profile GMP Manual
08/25/2020
2
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.......................................................................3
1. SPECIFICATIONS....................................................................................................5
2. CONTENTS OF THE ACCESSORY KIT................................................................... 7
3. PART NAME............................................................................................................8
4. SET UP & INSTALLATION...................................................................................... 9
5. HOW TO PLAY......................................................................................................25
6. GAME OPTION..................................................................................................... 27
7. TROUBLESHOOTING............................................................................................33
8. MAINTENANCE & INSPECTION..........................................................................36
9. OVERALL CONSTRUCTION................................................................................. 45
10. WIRING DIAGRAM............................................................................................ 64

To Tha Net Low Profile GMP Manual
08/25/2020
3
Thank you for purchasing To Tha Net (Low Profile). We hope you enjoy the
product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

To Tha Net Low Profile GMP Manual
08/25/2020
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

To Tha Net Low Profile GMP Manual
08/25/2020
5
1. SPECIFICATIONS
Rated power supply: AC110V~ 50/60Hz; AC220-240V~ 50/60Hz
Min. Power consumption: 300W
Max. Power consumption: 350W
Dimension: Width: 39.52’’ (1004mm)
Depth: 94.05’’ (2389mm)
Height: 96.14’’ (2442 mm)
Weight：Approximately 518lb/235kg
Part No: T155
Model No: C-605
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game specifications are subject to change without notice.

To Tha Net Low Profile GMP Manual
08/25/2020
6
Transport dimension:
Width: 43.07’’ (1094mm)
Depth: 41.22’’ (1047mm)
Height: 79.92’’ (2030mm)
Note: Game specifications are subject to change without notice.

To Tha Net Low Profile GMP Manual
08/25/2020
7
2. CONTENTS OF THE ACCESSORY KIT
No.
Part No.
Code
Name
SPEC
Qty
1
T155-801-000
41440000279C
Manual
/
1
2
T155-302-000
20101010005
Hexagon socket
button head screw
M4×12 black
50
3
T155-315-000
20101018014
Hexagon socket
button head screw
M6×40 black
16
4
T155-335-000
20104020002
Cross recessed
hexagon screw set
M6×16
12
5
T155-802-000
20101048006
Hexagon socket
button head screw
M8×45
8
6
T155-316-000
20101048012
Hexagon socket
button head screw
M8×70
6
7
T155-317-000
20102010023
Hexagon nut
M8 black
18
8
T155-303-000
20113010302
A washer
4×1h black
50
9
T155-348-000
20113010053
C washer
6×1.6h black
8
10
T155-344-000
20113010051
C washer
8×1.6h black
12
11
T155-803-000
25101181002
Plug
Φ10 Black
10
/
12
T155-607-000
410000019A
Basketball
/
8
13
T155-804-000
21504000001
Photoelectric
switch reflector
50×55
1
14
T155-805-000
25300171002
Key
171A
2
15
T155-806-000
25300172002
Key
171B
1
16
T155-608-000
40613050001
Pump needle
/
2
17
T155-807-000
23301010040
Power cord
3×16AWG 3M
1
18
T155-415-000
21901000030B
Fuse
Ф5×20mm T10A
250VAC(PSE UL)
1
19
T155-420-000
21901000012
Fuse
Φ5×20mm T5A
250VAC
1
1. Following accessories
Open the package and make sure all the items are included:

To Tha Net Low Profile GMP Manual
08/25/2020
8
Ticket Dispenser
Speaker
Control Panel Assembly
Ball Gate
Monitor
Hoop Assembly
Coin Mechanism
Optional accessories:
3. PART NAME
Key Components
No.
Part No.
Code
Name
SPEC
Qty
1
T155-808-000
23302000012
Network cable
T568A-T568A
5M
Refer
to 6.3
2
T155-809-000
21108000078
Network switch
5 ports

To Tha Net Low Profile GMP Manual
08/25/2020
9
Levele
About 0.2 in/5mm
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid.
Place the unit on a dry level surface.
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this game on a flat surface. If the game is installed on an unsuitable floor, it could
cause game malfunction.
To secure the game, loosen the nut, utilize wrench to adjust the leveler down until it
touches the floor, lifting the casters off the ground by 0.2 in/5mm. Repeat the same for all
levelers.
Make sure the machine is level.
NOTICE
Leveler
Leveler
Leveler
We do not recommend using power tools as they may cause damage.
NOTICE

To Tha Net Low Profile GMP Manual
08/25/2020
10
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 20 in
4.4 Card Reader Installation Safety Notice
Take precaution to assure that all wiring voltages are confirmed prior to installation
of card reader. All warranties are void if not properly installed resulting in logic board
damage.
Important: This game is pre-wired to AAMA standards. It is highly recommended to utilize
this wiring for Card reader installation.
Service area
Your unit must be leveled to operate properly.
NOTICE

To Tha Net Low Profile GMP Manual
08/25/2020
11
4.5 Machine Installation
Before processing with assembly assure you have the following tools.
Step 1 Unfold the L front frame and R front frame.
No.
Name
1
Allen wrench
2
Spanner
3
Phillips screwdriver
Name
L front frame
Qty
1
Name
R front frame
Qty
1

To Tha Net Low Profile GMP Manual
08/25/2020
12
Turn the Block ball net to the proper position as shown below.
Utilize Allen wrench and Spanner to tighten 4 screws and 4 nuts as shown.
Name
Block ball net
Qty
1
Name
Hexagon socket
button head screw
SPEC
M8X70
Qty
4
Name
Hexagon nut
SPEC
M8 black
Qty
4

To Tha Net Low Profile GMP Manual
08/25/2020
13
Step 2 Utilize Allen wrench to tighten 4 screws to fix the Front middle beam bracket to the
cabinet.
Name
Front middle
beam bracket
Qty
1
Name
Hexagon socket
button head screw
SPEC
M6X40 black
Qty
4

To Tha Net Low Profile GMP Manual
08/25/2020
14
Step 3 Place the Ball gate assembly as shown.
Utilize Phillips screwdriver to tighten 6 screws from the reverse side as shown.
Step 4 Utilize Allen wrench to tighten 4 screws to fix the Front beam to the cabinet.
Name
Cross recessed
hexagon screw set
SPEC
M6X16
Qty
6
Name
Ball gate
assembly
Qty
1
Name
Front beam
Qty
1
Name
Hexagon socket
button head screw
SPEC
M6X40 black
Qty
4

To Tha Net Low Profile GMP Manual
08/25/2020
15
Step 5 Utilize Phillips screwdriver to tighten 6 screws from the reverse side as shown.
Step 6 Utilize Allen wrench to tighten 4 screws to fix the Front lower beam to the cabinet.
Name
Cross recessed
hexagon screw set
SPEC
M6X16
Qty
6
Name
Front ball track plate
Qty
1
Name
Hexagon socket
button head screw
SPEC
M6X40
Qty
4
Name
Front lower beam
Qty
1

To Tha Net Low Profile GMP Manual
08/25/2020
16
Step 7 Utilize Allen wrench to tighten 4 screws to fix the Control panel assembly to the
cabinet.
Name
Hexagon socket
button head screw
SPEC
M6X40
Qty
4
Name
Control panel
assembly
Qty
1

To Tha Net Low Profile GMP Manual
08/25/2020
17
Step 8 Utilize Allen wrench to tighten 6 screws to fix the Bottom side light plates to the
Control panel assembly.
Name
Bottom side
light plates
Qty
1 set
Name
A Washer
SPEC
4X1h
Qty
6
Name
Hexagon socket
button head screw
SPEC
M4X12
Qty
6

To Tha Net Low Profile GMP Manual
08/25/2020
18
Step 9 Turn the Upper side plates upright.
Step 10 Utilize Allen wrench to remove 8 screws on two sides. Keep the screws for Step 13.

To Tha Net Low Profile GMP Manual
08/25/2020
19
Step 11 Locate the Spanner indicated and take it off.
Step 12 Lift up the Monitor assembly to a proper position(the screw holes match well).
Turn clockwise to lift up.
Turn counterclockwise to lift down.
