SIP 01552 User manual

1
01552
8”x 8” Planer Thicknesser
Please read and fully understand the instructions in this
manual before operation.
Keep this manual safe for future reference.

2
Table of Contents
ProductSpecifications Page3
SafetyRules Page4
Unpacking Page6
Installation Page6
StructureandFunctions Page6
SupplementarySafetyInstructions Page7
OperationRegulations Page9
Maintenance Page13
Attention Page13
AssemblyDiagram Page14
PartList Page15

3
PRODUCT SPECIFICATIONS
Motor
(Please choose proper power source, voltage and frequency that are shown in the label
foryourmachine.)
Cutter block rpm 8500RPM
Number of Blade 2
Technical data - Surfacing
Max planing width 204mm
Maxcuttingdepth 2mm
Fence 520x102mm
Fence angle 90~135°
Table size 737x210mm
Technical data - Thicknessing
Max planing width 204mm
Maxcuttingdepth 2mm
Max planing thickness 210mm
Table size 250x204mm

4
SAFETY RULES:
WARNING: When using electric tools, basic safety precautions should always be followed to reduce the
risk of fire, electric shock and personal injury, including the following.
Read all these instructions before attempting to operate this product and save these instructions.
(1) Keep work area clear
- Cluttered area and benches invite injuries.
(2) Consider work area environment
- Don’t expose electric tools to rain.
- Do not use electric tools in damp or wet locations.
- Keep work area well lit.
- In particular, no inflammable liquids or gases must be present.
(3) Guard against electric shock
- Avoid body contact with earthed or grounded surface.
(4) Keep children and other persons away
- Don’t let especially children, persons not involved in the work touch the tool or extension cord and
keep them away from the work area.
(5) Store idle tools
- When not in use, tools should be stored in a try locked up place, out of reach of children.
(6) Don’t force the tool
- It will do the job better and safer at the rate for when it was intended.
(7) Use the right tool
- Don’t force small tools to do the job of a heavy-duty tool.
- Don’t use tools for purposes not intended: for example, don’t use circular saws to cut tree limbs or logs.
(8) Dress properly
- Don’t wear loose clothing or jewelry. They can be caught in moving parts.
- Rubber gloves and non-skid footwear are recommended when working outdoors.
- Wear protective hair covering to contain long hair.
(9) Use protective equipment
- Use safety glasses.
- Use face or dust mask if cutting operations create dust.
(10) Don’t abuse cables
- Never carry tool by cable or rank it to disconnect it from socket. Keep cable from heat,
oil and sharp edges.
(11) Do not abuse the cord
- Never yank the cord to disconnect it from the socket. Keep the cord
away from heat, oil and sharp edges.
(12) Don’t overreach
- Keep proper footing and balance at all times.
(13) Maintain tools with care
- Keep cutting tools sharp and clean for better and safer performance.
- Follow instruction for lubricating and changing accessories.
- Inspect tool cords periodically and if damaged have them repaired by
an authorized service facility.
- Inspect extension cords periodically and replace if damaged.

5
- Keep handles dry, clean and free from oil and grease.
(14) Disconnect tools
- When not in use, before servicing and when changing accessories
such as blades, bits and cutters, disconnect tools from the power
supply.
(15) Remove adjusting wrenches
- Form the habit of checking to see that adjusting wrenches are removed from the tool before turning it
on.
(17) Avoid unintentional starting
- Ensure switch is in “off” position when plugging in
(18) Use outdoor extension leads
- When the tool is used outdoors, use only extension cords intended for outdoor use and so marked.
(19) Stay alert
- Watch what you are doing, use common sense and do not operate the tool when you are tired.
(20) Check damaged parts
- Before further use of tool, it should be carefully checked to determine that it will operate properly
and perform it’s intended function.
- Check for alignment of moving parts, binding of moving parts, mounting and any other conditions that
may affect it’s operation.
- A guard or other part that is damaged should be properly repaired or replaced by an authorized
service centre unless otherwise indicated in this instruction manual.
- Have defective switches replaced by an authorized service centre.
- Do not use the tool if the switch does not turn it on and off.
(21) Warning
- The use of any accessory or attachment other than one recommended in this instruction manual may
present a risk of personal injury.
(22) Have your tool repaired by a qualified person
-This electric tool complies with the relevant safety rules. Qualified persons using original spare parts
should only carry out repairs. Otherwise this may result in considerable danger to the user.
(23) Never use the machine without the appropriate guard in place and correctly adjusted.
(24) Do not use knives, which are blunt as this increases the danger of kickback.
(25)Any portion of the cutter block not being used for planning shall be guarded.
(26) When planning short workpieces, a push-stick should be used.
(27)When planning narrow workpieces additional measures. Such as of horizontal pressure devices and
spring-loaded guards, may be necessary to ensure safe working.
(28) Do not use the tool cut rebate.
(29)The effectiveness of the device for the prevention of kickback and the feed spindle should be
regularly inspected to ensure safe operation.
(30)Tools equipped with chip collection and extractor hoods shall be connected to the dust and
chip-collecting device.
(31) Use the tool only for wood or similar materials.
When the blade is abraded 95%, you must change it to the new one, which must meet EN847-1.
(32)Two persons are required for moving round the workshop due to its heavy weight.
(33) The machine should be fixed on the floor by screws when operating.

6
UNPACKING
Check for shipping damage. If damage has occurred, a claim must be filed with carrier. Check for
completeness. Immediately report missing parts to dealer.
The machine is shipped complete in one carton. Additional parts which need to be fastened to machine
should be located and accounted for before assembling. Refer to figure 1.
A. Planer and Thicknesser
B. Dustcollector
C. Guide fence
D. Extraction hose and clamps AB
E. Bag
F. Push-stick
C D
F E
Figure 1
INSTALLATION
The planer weighs approximately 32Kg. when completely assembled. The planer must be installed in a
place with ample lighting and correct power supply. To install planter:
-Make sure there is plenty of room for moving the work-piece through the entire cut. There must be enough
room that neither the operators nor the bystanders will have to stand in line with the wood while using the
tool.
-Planer should be installed on a workbench using bolts, Locking Nuts and hex nuts.
-The planer must be bolted to a firm, level surface.
-Make sure the planer does not rock and the tables are level.
Refer to Figure 2
380
Figure 2
240

7
STRUCTURE AND FUNCTIONS
The planer-thicknesser is a transportable electric tool. The machine is driven by a single-phase series motor,
and it is double insulated. It is used to planer-thicknesser wood. It has the characteristics of rational
structure, easy operation and high efficiency. Refer to figure 3.
Circuit Breaker Safety Switch
Figure 3
ELECTRICAL REQUIREMENTS
POWER SUPPLY AND MOTOR SPECIFICATIONS
WARNING: To avoid electrical hazards, fire hazards, or damage to the tool, use proper circuit protection. Use a separate
electrical circuit for your tools. To avoid shock or fire, if power cord is worn or cut, or damaged in any way, have it replaced
immediately.
GROUNDING INSTRUCTIONS
WARNING: This tool must be grounded while in use to protect the operator from electrical shock.
IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides a path of least resistance for electric current and
reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment-grounding conductor
and a grounding plug. The plug MUST be plugged into a matching receptacle that is properly installed and grounded in
accordance with ALL local codes and ordinances.
DO NOT MODIFY THE PLUG PROVIDED. If it will not fit the receptacle, have the proper receptacle installed by a qualified
electrician.
IMPROPER CONNECTION of the equipment-grounding conductor can result in risk of electric shock. The conductor with
green insulation (with or without yellow stripes) is the equipment-grounding conductor. If repair or replacement of the electric
cord or plug is necessary, DO NOT connect the equipment-grounding conductor to a live terminal.
CHECK with a qualified electrician or service person if you do not completely understand the grounding instructions, or if you
are not sure the tool is properly grounded.
Refer to nether picture:
Properly Ground Outlet
GroundingProng
3-ProngPlug
WARNING: Improper connection of equipment grounding conductor can result in the risk of electrical shock. Equipment
should be grounded while in use to protect operator from electrical shock.
Continued Overleaf

8
-Check with a qualified electrician if you do not understand grounding instructions or if you are in doubt as to whether the
tool is properly grounded.
-This tool is equipped with an approved cord and a 3-prong grounding type plug for you protection against shock hazards.
-Grounding plug should be plugged directly into a properly installed and grounded 3-prong grounding-type receptacle, as
shown.
-Do not remove or alter grounding prong in any manner. In the event of a malfunction or breakdown, grounding provides a
path of least resistance for electrical shock.
WARNING: This machine is for indoor use only. Do not expose to rain or use in damp locations.
SUPPLEMENTARY SAFETY INSTRUCTIONS
1 Regularly check that blades and lock bars are locked tight in cutter block.
2 Max. allow able blade projection over cutter block 1.0mm/0.004 inch +10%.
3 Never remove any of the machine’s safety guards other than for servicing and repair work. Keep
guards operational at all times.
4 Set and secure safety guards in position before operating machine.
5 This machine must be safety earthed. The yellow/green (green) lead is the earth conductor.
6 Regularly check anti-kickback fingers for proper operation.
7 Always wear eye protection.
8 Rebating, tenoning , moulding and recessing may not be undertaken without the use of special
guards
9 Never make jointing or planning cut deeper than 2 mm
USER RESPONSIBILITY
This machine will perform in conformity with the description contained in this manual when installed,
operated, maintained and repaired in accordance with the instructions provided.
This machine must be checked periodically. Defective equipment (including power cable) should not be
used. Parts that are broken, missing, plainly worn, distorted or contaminated, should be replaced
immediately. Should such repair or replacement become necessary, it is recommended that such repairs
be carried out by qualified persons.
This machine or any of its parts should not be altered or changed or changed from standard
specifications. The user of this machine shall have the sole responsibility for any malfunction which results
from improper use or unauthorized modification from standard specification, Faulty maintenance,
damage or improper repair.

9
OPERATION REGULATIONS
ATTENTION: Make sure that the switch is in off position before adjusting the cutting depth, replacing or
adjusting the blades. Make sure the blade screws are securely tightened.
SETTING ANGLE FENCE
Insert screw into hole A, then locate the fence on screw; tighten screw.
Loosen the lock handle B to adjust the fence angle.
Refer to figure 5
3
A
B
Figure 5
△ The angle fence has some different modus, if you have any question about it, please contact the
Seller.
OVERLOAD PROTECTION
If the motor protection responds, this always indicates that the motor is overloaded. The cause must be
located and the fault eliminated.
If the motor is overloaded or in the event of power failure, the motor switches off automatically. The
machine can not be switched on again until the motor is cooled down or the power supply has been
restored.
CHIP EXTRACTION
To ensure trouble free and reliable operation on enclosed premises, the machine must be connected to
an extractor unit at the dust collector 1 (accessory)
DUST COLLECTOR CONNECTION WHEN PLANING :
- Connect the dust collector to the extremity of cannulation by hoop.
- Connect the other extremity of cannulation to the fan house entrance by hoop.
- Fit the chip bag to the fan house export.
- Lift up the blade guard arm C so that the longitude holes D being exposed;
- Pull out the key E on both sides of the dust collector 1;
- Move down the working table 12 to the lowest position, and insert the dust collector 1; referring to Fig.
9,10.
AB
3

10
Figure6 Figure7
C
D
12
Figure8 Figure9
E
1
Figure 10
- The dust collector 1 is so positioned that both keys E are in line with the longitude holes D. Then push both
keys E into the longitude holes D. Referring to Fig. 11
-
Figure 11
DUST COLLECTOR CONNECTION WHEN THICKNESSING:
-Take off the Angle fence.
-Remove the blade guard 4 and place the dust collector 1. See Figure 13.
