SIP 06434 Specification sheet

Heat Induction Tool
06434
Instructions for use and
Maintenance

2
1Table of contents
1TABLE OF CONTENTS 2
2INTRODUCTION 3
3TECHNICAL DATA 3
4SAFETY INSTRUCTIONS 3
4.1 General safety rules 3
4.2 Safety rules for personal protection 4
4.3 Electrical safety rules 4
4.4 Fire safety rules 5
4.5 Safety rules for using the device 5
5COMPONENTS 6
6USE 7
6.1 Detachable coils 7
6.2 Flat coil 9
6.3 Customized fixed coil 10
6.4Flexible coil 10
6.5 Focus coil 11
7DEVICE INDICATORS 11
8POSSIBLE PROBLEMS AND TROUBLESHOOTING 11
9STORAGE AND MAINTENANCE 12
9.1 Cooling, dismantling and storage 12
9.2 Proper cleaning and maintenance 12
10 WARRANTY 12
11 WARRANTY SERVICE 13
12 DISPOSAL OF USED EQUIPMENT 13
13 CONSUMABLE SPARE PARTS 14
13 CONSUMABLE SPARE PARTS 15
14 ELECTROTECHNICAL SCHEME 15
15 MEANING OF USED SYMBOLS 16
16 POSSIBLE DEFECTS AND REMEDY OF DEFECTS 17
17 DECLARATION OF CONFORMITY 18

3
2Introduction
This device generates alternating current of high frequency. The current passing through a heating
coil creates an alternating magnetic field which by using the principle of electromagnetic induction
vibrates electrons inside the heated material. The energy of moving electrons is dissipated as heat,
which heats the metal in the work field of the instrument. The more easily magnetized the material,
the more heat it creates. That is why the device heats easily nonferrous metals and their alloys, but
has no effect on glass, plastics, wood, textiles and other non-conductive materials.
3Technical data
Name (type)
06434
Input voltage
~230V, 50/60Hz
Input current
max. 7.5A
Power
max. 1.75kW
PF
0.99
Load factor
50%@1.5kVA a 100%@1.0kVA
Cover
IP20
Weight
4.5kg / 9,921lb
Dimensions
200 x 140 x 75mm
4Safety instructions
4.1 General safety rules
Read carefully all instructions in the manual. Failure to follow these instructions may
result in electric shock or burns, fire and / or serious personal injury.
The user is Users are responsible for installing and using the system in accordance with the
instructions provided in this manual. The contractor shall not be liable for damages resulting from
improper use and handling.
The device may be operated only by persons properly trained and appropriately qualified. Do not
operate 06434 under the influence of drugs, alcohol or medication
Bystanders and animals should be kept safely away when operating with the device, even when
cooling the heated material.
Avoid working in the rain, water and moist environments. Keep work area well ventilated and dry,
clean and well lit.
When working with the 06434 always have a fully functional fire extinguisher within reach.

4
4.2 Safety rules for personal protection
Persons with pacemakers or other metal or electronic surgical implants must not
operate with the 06434 and must keep a safe distance of at least 1m from the device.
When working with 06434 do not wear any metal objects such as jewelry, rings,
watches, necklaces, identification tags, belt buckles, piercing and even clothing with
metal parts such as metal rivets, buttons and zippers, etc. - 06434 can heat up these
metal objects quickly and cause serious burns or clothing ignition.
ATTENTION: Coil applicator and heated object can reach high temperatures and
cause burns or cause a fire.
When using the 06434 always wear safety goggles or face shield.
When using the 06434 hazardous fumes may be produced by burning old paint,
lubricants, sealants, adhesives, etc. These exhalations can be toxic. Always wear
appropriate protective masks or respirators.
When working with the 06434 always wear protective gloves with corresponding
thermal resistance. High temperatures generated by the use of 06434 may cause
serious burns in the case of touching the heated part.
Always keep proper footing and balance for safe control of the 06434 even in unexpected situations.
Do not use the 06434 near any device with pyrotechnics (e.g. airbag). The resulting heat can cause
their unexpected explosion. Keep a minimum distance of 10-20 cm from these devices.
4.3 Electrical safety rules
This is a safety Class I device, which may be supplied with power only from the
power outlet with a protective conductor, which must be connected to the device as
first and in any case must not be interrupted (e.g. by an extension cord). Any
interruption of the protective earth conductor, or its disconnection will cause a
potential electric shock hazard that can cause injury. Make sure that the device
(device chassis) is properly grounded.
Do not twist or sharply bend the power cord, as it may damage the internal wiring.
Never use 06434 if the power cord shows any signs of damage. Keep the power cord
away from heat, oil, sharp edges or moving parts. Never repair the power cord –if
damaged, the power cord must be replaced. Damaged cords create a risk of electric
shock.

5
Before replacing the applicator (coil), disconnect 06434 from the power source (wall outlet).
If you are not using 06434, unplug the power cord from the outlet.
CAUTION
This product is for Class A industrial use. It may cause radio interference in
residential, commercial and light industrial environments. This product is not
intended for installation in residential environment, business environment and light
industry with connection to the public supply network; user may be required to take
adequate measures to reduce interference.
4.4 Fire safety rules
Do not heat aerosol or other cans, metal containers, and any pressure vessel used
for the storage of fuel, compressed gases and liquids. The heat generated by heating
06434 may cause them to explode and their contents may ignite.
Do not use the heating spiral (coil), if the insulation is damaged. A defect in the insulation may cause
sparks in contact with metal objects or between the turns of the coil. In particular, when working on
/ or near gas pipes and / or gas tanks it may pose a danger of explosion or fire. Using coils with
damaged insulation will void the warranty.
4.5 Safety rules for using the device
Do not leave 06434 uncontrolled when it is started. Always use the main switch to turn 06434 off if
it is not used for heating!
Make sure that the power supply unit and the handle has an adequate supply of air for cooling. Make
sure the vents are clean and free of dust and dirt not to impede the flow of cooling air.
Do not attempt to repair 06434. The device does not contain any user-serviceable components,
except for replaceable heating coils.
Before connecting 06434 to the wall outlet make sure the outlet voltage corresponds
to the voltage on the rating plate. If the wall outlet voltage does not match the
voltage indicated on the rating plate, it may result in a serious risk of damage to
06434.
Do not exceed the operating cycle 06434 –2 minutes heating (on) a 2 minutes
cooling (off). The main equipment is protected against device overheating, but
heating coils are not, which may cause their damage.
EXTENSION CORDS:
Extension cords –if necessary, you may use only the following extension cords:
up to 5m with 2.5 mm2diameter
up to 15m with 4 mm2diameter

6
Use only one extension cord –do not connect two or more extension cords. Do not use any other
extension cords than those mentioned above. Unpack the extension cords - tightly packed extension
cords may overheat and cause fire.
GENERATORS:
When using the device with an alternate source of power –e.g. with mobile electric generator, it is
necessary to use a quality alternate source of sufficient power and AVR quality control. Use a
generator with a power output of at least 3-4 kW, or DC / AC inverter with a power output of 2-3 kW
and only with a sine wave –do not use the inverter with a square or quasi-sine wave. Failure to
comply with the above requirements may result in damage to the device and void the warranty.
The device must be protected from rain and moisture, mechanical damage and possible ventilation
of neighboring machines, excessive overloading and rough handling.
