SISTEM AIR Tecno Star Dual Power User manual

23/10/13 Rev:2.0.0
1
• Type: domestic vacuum cleaner
• Model: Tecno Star Dual Power
• Revision 2.0.0
Line
TECNO Star Dual Power
INSTRUCTION MANUAL
CENTRAL VACUUM SYSTEMS ByTecnoplus s.r.l.
1 HOW TO USE THE MANUAL 4
2 DESCRIPTION OF THE CENTRAL VACUUM CLEANER 4
2.1 Distinctive product features 5
3 TECHNICAL FEATURES 6
4 CONSTRUCTION FEATURES 8
5 SAFETY FEATURES 9
5.1 IP protection degree 10
5.2 Electric insulation degree 10
5.3 Declaration of absence of dangerous substances 10
5.4 Fixed closure safety guards 10
5.5 Movable closure safety guards 11
5.6 Identification plate 11
6 AUTHORIZED USE OF THE VACUUM CLEANER 12
7 UNAUTHORIZED USE OF THE VACUUM CLEANER 12
8 EQUIPMENT AND ACCESSORIES 13
9 INSTALLATION 14
9.1 Preliminary operations 14
9.2 Recommended Installation 14
9.3 Transport and unpacking 15
9.4 Positioning of the vacuum cleaner 17
9.5 Transforming DX version (outlet pipes fitted on the right) into SX version
(outlet pipes fitted on the left) 17
9.6 Fixing the system to the wall 19
9.6.1 Connection to the piping network 19
10 STARTING THE VACUUM CLEANER 19
10.1 Control board 19
10.2 Electric connection 20
10.2.1 Auxiliary connection signal 21
11 USE OF THE VACUUM CLEANER 22
11.1 Switching on the vacuum cleaner 22
11.2 Using the vacuum cleaner 22
11.3 Programming and use of the computer for controlling the central unit 23
11.3.1 Programming the start up 24
11.3.2 Settings menu 27
11.4 Menu 27
11.4.1 Menu timer of the dust container 27
INDEX

2
23/10/13 Rev:2.0.0
• Type: domestic vacuum cleaner
• Model: Tecno Star Dual Power
• Revision 2.0.0
Line
TECNO Star Dual Power
INSTRUCTION MANUAL
CENTRAL VACUUM SYSTEMS ByTecnoplus s.r.l.
11.4.2 Menu suction stop 28
11.4.3 Menu maintenance 28
11.4.4 Menu info 28
11.4.5 Menu date and time 30
11.5 Set up 30
11.5.1 Setup turbo function 30
11.5.2 Setup autocleaner 31
11.5.3 Setup turbo function 31
11.5.4 Set up reset parameters 32
11.5.5 Set up language 33
11.5.6 Set up unit model 33
11.6 Autocleaner system management 34
11.6.1 Activation Autocleaner 34
11.6.2 Changing parameters Autocleaner 34
12 MAINTENANCE 36
12.1 Programmed routine maintenance 36
12.2 Extraordinary maintenance 36
12.3 Cleaning the vacuum cleaner body (cylinder) 37
12.4 Emptying the dust bin 37
12.5 Replacing the filter cartridge 39
12.6 Regeneration of the filter cartridge 41
12.7 Cleaning of the external body 41
13 REPAIRS AND SPARE PARTS 41
13.1 Intervention criteria 41
13.2 Recommended spare parts 42
13.3 Putting the vacuum cleaner out of service 42
14 SOUND EMISSION 42
15 IDEAL LOCATION OF THE VACUUM CLEANER TO REDUCE
SOUND EMISSION 42
16 VIBRATIONS 42
17 TROUBLESHOOTING 43
APPENDIX A - CONNECTION TO THE AUTOCLEANER APPLIANCE 45
A.1 Positioning of the Autocleaner 45
A.2 Pneumatic connection 46
A.3 Electric connection 46
INDEX

23/10/13 Rev:2.0.0
3
2
For the best results, we suggest to use SISTEM AIR original accessories and materials. The SISTEM AIR Trade-
mark is a registered trademark and is property of TECNOPLUS S.r.l.
English
INTRODUCTION
Dear Customer,
TECNOPLUS S.r.l., owner of the SISTEM AIR Trademark would first of all like to thank you for having
chosen to buy the new vacuum cleaner of the TECNO Star Dual Power. We are sure that the character-
istics described in this manual will satisfy your needs.
TECNO Star Dual Power has been designed and produced in strict compliance with the Machinery
Directive 2006/42/CE (transposed into Italian Legislation by Decree Law 17/10), Low Tension Directive
2006/95/ CE, and Electromagnetic Compatibility Directive 2004/108/CE. The system has been manu-
factured with top quality materials and with particular care paid to reducing as much as possible the risk
of injury.
We have therefore written this manual in order to provide adequate instructions for the correct use and
maintenance of the system which are crucial to ensure the user’s safety, the correct functioning and the
long working life of the vacuum cleaning unit.
Read the entire manual carefully, follow the instructions precisely, and above all, for safety rea-
sons, do not intervene in any way if not specifically indicated.

TECNO Star Dual Power instruction manual
4
23/10/13 Rev:2.0.0
CENTRAL VACUUM SYSTEMS ByTecnoplus s.r.l.
1 - GENERAL INFORMATION
1. HOW TO USE THE MANUAL
The instruction manual has been written by the manufacturer and is an integral part of the vacuum
cleaner. If the system is resold, given or hired out to others, the manual must be handed over to the
new user or owner.
We recommend using and storing it carefully for the entire working life of the vacuum cleaner.
This manual explains how to use the equipment correctly in order to obtain the best performance
while maintaining optimal working and safety conditions.
It is strictly forbidden to reproduce, copy or disclose any part of this document by any means without
prior written consent of TECNOPLUS s.r.l. which is the owner of the SISTEM AIR Trademark.
TECNOPLUS s.r.l . reserves the right to upgrade or modify this manual or the vacuum cleaner itself at
anytime without giving any prior notice to third parties.
2. DESCRIPTION OF THE VACUUM CLEANER
Constant research applied to central vacuum cleaners and advanced electronic technology have al-
lowed TECNOPLUS S.r.l. to create TECNO Star Dual Power.
The central vacuum cleaner, suitable for any type of residential building (private houses, offices,
hotels, service sector), consists of a network of PVC trace pipes, housed in walls or in false ceilings
running through the various rooms; at the end of the pipes are positioned the suction sockets.
The SISTEM AIR vacuum cleaner is usually placed in a utility room, garage or other storeroom and
connected to the suction pipes network.
The system is switched on by inserting the sleeve coupling of the flexible vacuum cleaning hose in
any of the suction sockets.
If the pipe network doesn’t feature any electrical power supply, the system can be switched on and off
by means of a remote control
device (optional accessory).
The Tecno Star Dual
Power vacuum cleaner, yet
equipped with brush motors,
features innovative charac-
teristics which make it more
suitable for professional
applications. The Tecno Star
Dual Power vacuum cleaner
is run by a second-generation
electronic system that Sistem
Air applies to its vacuum
cleaners to allow a simplified
management of the cleaning
unit.

5
2
23/10/13 Rev:2.0.0
English
Main features of the TECNO Star Dual Power vacuum cleaner:
- Possibility of contemporary use by two operators either with two separate micro lines or with one single
micro line.
- The Tecno Star Dual Power vacuum cleaner by Sistem Air adopts an innovative control and mainte-
nance system based on an electronic control board with microchip connected to pressure sensors
and programmed to easily and immediately interact with the user. Maintenance can be individually
programmed by the user who will receive messages about the machine status directly on a user-
friendly graphic display, as well as suggestions about actions to be taken in case of malfunctioning.
Thanks to the pressure sensor, the indications shown are not mere approximations but indicate the
real conditions of the system.
- With Tecno Star Dual Power, Sistem Air has obtained a 10% consumption decrease, with no reduction
of the available vacuum cleaning power.
2.1 Distinctive product features
- “TURBO” function by means two motors on a single micro line.
- Safety thermal sensor to protect the motor.
- Vacuum breaker valve to ensure the motor is not operating in critical conditions.
- Soft Start system to reduce the electric absorption during the starting phase of the vacuum suction.
- Control and routine maintenance system based on an electronic control board with microchip con-
nected to pressure sensors and programmed to easily and immediately interact with the user.
- Polyester L-Class filter cartridge, washable in water.
- Double protection electronic control board with fuse-holders and disconnecting switches both on the
primary and auxiliary circuit.
- Pressure transducer
- Class 1 isolation.
- Left or right connection to the pipe dust inlet and to the air exhaust.
- Wheeled machine body coated with epoxy-powders with large-capacity dustbin.
- Fastening and release of the dust bin with Soft-Touch-grip handle, reducing the effort when opening
the bin.
- Base coated with anti-choc material to protect the appliance.
- High-grade noiselessness thanks to the soundproofed motor housing.
- Further optional coupling of Autocleaner self-clean system (see page 45).
