SIYI SYREBO SY-KE01 User manual

User Manual
Heating Knee Massager SY-KE01
Providing intelligent
rehabilitation equipment and services
for hospitals, communities, and families
®

Table of Contents
1.Notice to users ································· 1
Symbol descriptions ····························1
Target users ·································· 1
Precautions for use ···························· 2
Precautions for maintenance ···················· 3
2.Product functions······························ 3
3.Parts names ·································· 4
4.Use directions ·································· 5
Operating instructions···························4
Charging method ·······························6
Indicator descriptions ··························· 6
5.Maintenance and repair·························· 8
Cleaning method ······························· 8
Abandonment mode ··························· 9
6.Troubleshooting ·······························10
7.Main technical parameters ······················ 11
1
Notice to users
Please read this manual carefully and keep it properly before
using the product.
Prohibited Do as instructed
Symbol descriptions
Target users
The following people should use with caution.
• People with leg nerve disorders or skin sensory disorders.
• Those who had metal, silicon or plastic materials embedded
into their hands due to fracture or plastic surgery.
• The device has a heating surface, which must be noted when
used by people who are not sensitive to heat.
• People with leg or knee sequelae due to traffic accidents.
• People who have or have suffered from leg diseases (tendon
injuries, arthritis deformities, fractures, varicose veins, and other
diseases).
• People who are vulnerable to electromagnetic failures of
cardiac pacemakers with implanted medical electronic instru-
ments in vivo.
• People identified as having lost their sense of temperature.
• People with malignant tumors.
To avoid personal injury or property damages, please observe the
following contents.
• Use the following illustrations to describe the contents you must
follow.
1

Precautions for use
Use it once within 15 minutes. Please check the condition of
your knee joint and adjust the number of uses appropriately.
It is recommended to use the first level of force at the
beginning of using this product.
When using this product, your knees may turn red for a short
time, which does not mean anything abnormal. If the
symptom remains for long, please consult a surgeon.
When wearing silk stockings, the straps on the product may
tear your silk stockings. It is recommended to take off your
silk stockings in advance.
If you feel pain around your legs or knees, stop using this
product immediately.
If there is any problem with your skin or legs, please stop
using this product immediately and consult a doctor.
It is recommended not to use the massage function
excessively.
Never use it while sleeping.
Never use it when covered with quilt or blanket.
Do not lie or sit on the product.
The product permits no huge impact or overload.
Do not use the product in the bathroom or shower.
Do not wear the product while doing anything else.
Precautions for maintenance
Do unplug the charging cable and adapter connector.
Please properly handle the packaging bag of this product
and keep it away from infants.
This product contains lithium batteries. Do not disassemble,
modify, immerse the product (controller) in water or throw it
into fire; otherwise, it may be damaged.
Do not store this product within the reach of children and
infants. Moreover, do not let them touch or operate this
product. Otherwise, it may cause burns, electric shock or
personal injury.
Do not modify it at will or bend it forcibly.
This product can promote the blood circulation of the knee joint
and relieve discomfort of muscles and joints by imitating human
hand beating and hot compress. Its various temperature and
massage intensity options are suitable for different people to use
for knee massage and care. Matched with the extension belt, it
can also be used for care of other body parts.
Product Functions
2
32
• People with heart disease.
• Women who are unstable at the beginning of pregnancy or
shortly after giving birth.
• People with perceptual impairment caused by diabetes
• People with scars on their skin.
• People who need to be quiet and people in poor health.
• People with osteoporosis, severe fracture, strain injury, muscle
pain, and acute (head) pain.
• People with a temperature of 38℃ (fever).
• Weak people with such strong symptoms as acute inflammation,
fatigue, aversion to cold, and pressing pain.
• Others treated in medical organizations.

Precautions before use:
1. Absorb the magnetic snap on the back of the battery compart-
ment with the magnetic snap on the bodywork, so that the
battery compartment could be firmly installed on the bodywork
（As shown in figure 1）;
2. Used for knees: place the massager on the knee, let the screen
cloth facing your body, make the heating area aligned with your
knee joint, and then fix the magic tapes on the two straps
respectively（As shown in figure 2）;
Use Directions
4
Parts Names
3
Independent battery
compartment (controller)
Hot area
Massage area
Inner bag
Extension belt
3. Used for elbow: place the massager on your arm, let the screen
cloth facing your arm, make the heating area aligned with your
elbow joint, and then fix the magic tapes on the two straps
respectively（As shown in figure 3）;
4. Used for shoulder: connect the extension belt to one end of the
longer strap, fix it with magic tapes, place the massager on your
shoulder, let the screen cloth facing your body, make the heating
area aligned with your shoulder joint, and then fix the magic
tapes on the two straps respectively（As shown in figure 4）.
（ Figure 1 ）（
Figure 2 ）
54
Wormwood bag

1. When wearing silk stockings, the straps on the product
may tear your silk stockings. It is recommended to take off
your silk stockings in advance.
2. It is recommended to use the first level of force at the
beginning of using this massager. Your knees may turn red
soon, but it can relieve itself after a period of time.
（ Figure 3 ） （ Figure 4 ）
76
Operating Instructions
Vibration function
Screen lock
Hot compress
Vibration shift
display
Power level
Temperature
button
ON/OFF
Temperature
button
Temp. display
15
Press and hold the ON/OFF button for 2 seconds to start the
machine at the default temperature of 50℃ with the vibration
force set at Level 1.
Press the heating button briefly to enable/disable the heating
function.
Press the force key briefly to adjust the vibration force (Level 1,
Level 2, Level 3 and OFF).
Briefly press the temperature “+” and “-” buttons to adjust the
temperature (40℃, 45℃, 50℃, 55℃ and 60℃) and it will display
the current temperature on the display screen.
When power on, press this button briefly to lock/unlock the
screen.
After 15 minutes of operation, the massager will shut down and
enter the standby mode automatically.
The cloth area can be cleaned with clean water or wipe with wet
towel, with no machine wash permitted.
No machine wash

Charging Method
1. Insert the charging plug into the charging hole on the side of
the battery compartment;
2. Connect the USB socket of the power cord with the 5V 1A
adapter and plug it into the power socket; please provide an
adapter on your own;
3. The power indicator will flash when charging; the 3-level power
indicators will all go out after full charge;
4. Full charge takes about 3 hours.
Abandonment Mode
The lithium-ion battery used in this product is a valuable
resource that can be recycled. Please take out the lithium-ion
battery when it is discarded and hand it over to a professional
organization that can recycle rechargeable batteries.
1. Use a screwdriver to pry off the cover along its edge;
2. Remove the four screws on the plastic middle plate;
3. Remove the plastic middle plate and circuit board in turn;
4. Cut the battery wire and you can remove the battery;
5. Use insulating tape to wrap the two wires of the battery.
When the power is less than 10%, the power indicator will
flash. Please charge in time.
Please turn off the machine and recharge it. Do not use it
while charging.
Cleaning Method
1. Battery compartment (controller) care: Properly protect the
battery compartment (controller) display screen with touch
function. Please use a soft cloth to clean it.
2. Cloth area care: The cloth area permits no machine wash.
When necessary, please use alcohol to sterilize and remove sweat
stains or wipe it with a clean wet towel.
Charging socket
Charging plug
Battery
compartment
Adapter
(not included)
Maintenance and Repair
5
During maintenance, unplug the power cord, but never
unplug it with wet hands.
Alcohol Detergent GasolineWater Thinner
98

Cautions:
If the fault cannot be eliminated or the machine still cannot work
satisfactorily, contact the after-sales service personnel, but never
disassemble or attempt to repair it by yourself.
This chapter lists the most common problems about this
product. If you can't find the answer to your question, please
contact customer service or call the service hotline.
Troubleshooting
6
Fault descriptions Possible causes Troubleshooting
Start failure
The product is still
connected to the power
socket
The battery is exhausted Please charge
Reinstall it by aligning to
the magnetic port
The charging indicator
does not light up
The USB charging cable
is not plugged into the
power socket correctly
Please insert the USB
charging cable correctly
into the power plug
The control box is not
fully adsorbed on the
corresponding magnetic
port
Align the magnetic
port again
The machine stops
working during
operation
The battery is exhausted The battery is low.
Please charge
The machine
automatically shuts dow
after 15 minutes
If you need to continue,
please restart it
It can only be used for
a few minutes even after
being charged
The battery life has
ended (about 5 years)
Please contact customer
service (please do not
replace the battery by
yourself)
The heating function
does not work
This product may not
operate normally when
used beyond the
recommended ambient
temperature range
Use it within the operating
temperature range of
0~40℃ as recommended
The indicator lamp
operates normally,
but the touch screen
does not work
The screen is already
locked
Press the screen lock
button briefly to unlock
the screen
Check regularly
Whether there is any fault below
After being unused for a long time, it can not be used again before its
function is ensured normal
Power cord overheat-
ing；The power cord
has deep scars or
deformation. It tastes
burnt；There is
abnormal sound or
vibration during
operation; it doesn’t
work normally or
some other
abnormalities or faults
occur
In case of the above
faults, please
immediately stop
using and cut off the
power supply to
prevent accidents.
Please contact
customer service
Main Technical Parameters
7
Product name
Product model
Working voltage
Working power
Battery capacity
Charging voltage
Product size
Product net weight
Heating knee massager
SY-KE01
5V
7W
2500mAh
5V
510x290x35mm
310g
1110
Website: www.syrebocare.com
Mailbox: [email protected]om
Shanghai Siyi Intelligence Technology Co., Ltd
