SKF LINCOLN P203 User manual

951-171-021-EN
Version 02
21/05/2021
EN
Lubrication pump P203
for multi-line lubrication systems
DC versions without PCB
LINCOLN
LINCOLN
LINCOLN
LINCOLN
LINCOLN
Original Assembly Instructions
following machinery directive 2006/42/EC

- 2 -
951-171-021
Version 02
EN Original EC Declaration of incorporation
Jürgen Kreutzkämper
Manager R&D Germany Stefan Schürmann
Manager PD
Germany South
Original EC Declaration of incorporation following machinery directive 2006/42/EG, annex II, part 1 B
SKF Lubrication Systems Germany GmbH, Heinrich-Hertz-Str. 2-8, DE - 69190 Walldorf hereby declares at its sole responsibility that the partly completed
machinery complies with the essential health and safety requirements of the Machinery Directive 2006/42/EC, Annex I, marked in the Annex to the EC Decla-
ration of Incorporation as applicable and fulfilled at the time of placing on the market.
The special technical documents were prepared following Annex VII part B. Upon justifiable request, these special technical documents can be forwarded
electronically to the respective national authorities. The authorized company for the compilation of the technical documentation is SKF Lubrication Systems
Germany GmbH.
Designation: Electrically driven pump to supply lubricant during intermittent operation within a centralized lubrication system
Types: P203 V DC
Part number: 6440-xxxxxxxx /644-xxxxx-x / 94xxxxxx, 094xxxxxxx
Furthermore, the following directives and standards were applied in the respective applicable areas:
2011/65/EU RoHS II
2014/30/EU Electromagnetic compatibility Industry
Standards
EN ISO 12100:2010 EN 60204-1:2018 EN 60034-1:2010/AC:2010 EN 61000-6-4:2007/A1:2011
EN 809:1998+A1:2009/AC:2010 EN 60947-5-1:2004/A1:2009 EN 61000-6-2:2005/AC:2005
EN IEC 63000:2018 EN 61131-2:2007
The partly completed machinery must not be put into service until the final machinery into which it is to be incorporated has been declared in conformity with
the previsions of machinery directive 2006/42/EC and any other applicable directives.
Walldorf, 21/05/2021

- 3 -
951-171-021
Version 02
EN
Original UK Declaration of incorporation according to the Supply of Machinery (Safety) Regulations 2008
No. 1597 Annex II
SKF Lubrication Systems Germany GmbH, Heinrich-Hertz-Str. 2-8, DE - 69190 Walldorf hereby declares under sole responsibility that the partly completed
machinery complies with the essential health and safety requirements of UK legislation Supply of Machinery (Safety) Regulations 2008 No. 1597Annex I,
marked in theAnnex to the EC Declaration of Incorporation as applicable and fulfilled at the time of placing on the market. The special technical documents
were prepared following Annex VII part B. Upon justifiable request, these special technical documents can be forwarded electronically to the respective na-
tional authorities. The authorized company for the compilation of the technical documentation is SKF (U.K.) Limited, 2 Canada Close, Banbury, Oxfordshire,
OX16 2RT, GBR.
Designation: Electrically driven pump to supply lubricant during intermittent operation within a centralized lubrication system
Types: P203 V DC
Part number: 6440-xxxxxxxx /644-xxxxx-x / 94xxxxxx, 094xxxxxxx
Furthermore, the following regulations and standards were applied in the respective applicable areas:
- The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012 No. 3032
- Electromagnetic Compatibility Regulations 2016 No. 1091
Standards
EN ISO 12100:2010 EN 60204-1:2018 EN 60034-1:2010/AC:2010 EN 61000-6-4:2007/A1:2011
EN 809:1998+A1:2009/AC:2010 EN 60947-5-1:2004/A1:2009 EN 61000-6-2:2005/AC:2005
EN IEC 63000:2018 EN 61131-2:2007
The partly completed machinery must not be put into service until it has been established that the machinery into which it is to be incorporated is in compli-
ance with the provisions of UK legislation Supply of Machinery (Safety) Regulations 2008 No. 1597and all other applicable Directives.
Walldorf, 21/05/2021
Original UK Declaration of incorporation
Jürgen Kreutzkämper
Manager R&D Germany Stefan Schürmann
Manager PD
Germany South

- 4 -
951-171-021
Version 02
EN
Description of the essential health and safety requirements according to 2006/42/EC, Annex I, which have been applied and complied with. Any basic health
and safety requirements not listed here are not relevant to this product.
No.: Basic safety and health requirements Applicable: Complied with:
1.1.1 Definitions YES YES
1.1.2 Principles of safety integration YES YES
1.1.3 Materials and products YES YES
As to 1.1.3 Not fully complied with: The operator has to evaluate the hazards caused by the lubricant on the basis of the safety data sheet (SDS) and take
protective measures, if necessary.
1.1.5 Design of machinery to facilitate its handling YES YES
1.1.6 Ergonomics YES YES
As to 1.1.6 Not fully complied with: The operator has to ensure that the pump is integrated into the superior machine in such a manner that operation and
filling of the pump are ergonomically possible.
1.2 Control systems YES YES
1.2.1 Safety and reliability of control systems YES YES
1.2.3 Starting YES YES
1.2.6 Failure of the power supply YES YES
1.3 Protection against mechanical hazards YES YES
1.3.1 Risk of loss of stability YES YES
1.3.2 Risk of break-up during operation YES YES
As to 1.3.2 Not fully complied with: The operator has to secure the lubrication system against excessive pressure. For this purpose a pressure relief valve with
max. 350 bar opening pressure must be provided on each pump element.
1.3.4 Risks due to surfaces, edges or angles YES YES
1.3.7 Risks related to moving parts YES YES
1.3.9 Risks of uncontrolled movements YES YES
1.5 Risks due to other hazards YES YES
1.5.1 Electricity supply YES YES
1.5.6 Fire YES YES
As to 1.5.6 Not fully complied with: For pumps without control unit, the operator has to take suitable measures to ensure that the relative duty cycle (see
Technical Data) is complied with. Otherwise the motor may generate unacceptably high heat.
Annex to the declaration of incorporation following 2006/42/EC, annex II, no 1 B

- 5 -
951-171-021
Version 02
EN
No.: Basic safety and health requirements Applicable: Complied with:
1.5.8 Noise YES YES
1.5.11 External radiation YES YES
1.5.13 Emission of hazardous materials and substances YES YES
1.5.15 Risk of slipping, tripping and falling YES YES
1.6 Maintenance YES YES
1.6.1 Machinery maintenance YES YES
1.6.2 Access to operating positions and servicing points YES YES
As to 1.6.2 Not fully complied with: The operator has to ensure that the pump is integrated into the superior machine in such a manner that operation of the
pump is possible without risk.
1.6.4 Operator interventions YES YES
1.7 Information YES YES
1.7.1 Information and warnings on the machinery YES YES
1.7.1.1 Information and information devices YES YES
1.7.2 Warning of residual risks YES YES
1.7.3 Marking of machinery YES YES
1.7.4 Instructions YES YES
1.7.4.1 General principles for the drafting of instructions YES YES
1.7.4.2 Contents of the instructions YES YES
1.7.4.3 Sales literature YES YES
Annex to the declaration of incorporation following 2006/42/EC, annex II, no 1 B

- 6 -
951-171-021
Version 02
EN Legal notice
Authorized local distributors
Great Britain
SKF (U.K.) Limited,
2 Canada Close, Banbury, Oxfordshire,
OX16 2RT, GBR.
North America
SKF Lubrication Business Unit
Lincoln Industrial
5148 North Hanley Road, St. Louis,
MO. 63134 USA
South America
SKF Argentina Pte. Roca 4145,
CP 2001 Rosario, Santa Fe
EEU Area
LLC SKF
121552, Russia, Moscow,
Yartsevskaya Street, 19, BlockA Floor 7
Copyright
© Copyright SKF
All rights reserved.
Legal notice
Manufacturer
SKF Lubrication Systems Germany GmbH
e-mail: [e-mail]
www.skf.com/lubrication
Manufacturer's addresses
Walldorf Facilities
Heinrich-Hertz-Straße 2-8
69190 Walldorf
Germany
Phone: [phone]
Fax: [phone]
Berlin Facilities
Motzener Straße 35/37
12277 Berlin
Germany
Phone [phone]
Fax [phone]
www.skf.com/lubrication
Training courses
In order to provide a maximum of safety and
economic viability, SKF carries out detailed
training courses. It is recommended that the
training courses are attended. For more in-
formation please contact the respective SKF
Service address.
Warranty
The instructions do not contain any informa-
tion on the warranty. This can be found in
our general terms and conditions.
Disclaimer
The manufacturer shall not be held respon-
sible for damages caused by:
○Non appropriate use
faulty assembly, operation, setting, main-
tenance, repair or accidents
○Use of inappropriate lubricants
○Improper or late response to
malfunctions
○Unauthorized modifications of the
product
○Intent or negligence
○Use of non-original SKF spare parts
○Faulty planning or layout of the central-
ized lubrication system
Liability for loss or damage resulting from
the use of our products is limited to the
maximum purchase price. Liability for con-
sequential damages of whatever kind is
excluded.

- 7 -
951-171-021
Version 02
EN
Table of contents
Table of contents
Original EC Declaration of incorporation following machinery directive
2006/42/EG, annex II, part 1 B ...................................................................2
Original UK Declaration of incorporation according to the Supply of Ma-
chinery (Safety) Regulations 2008
No. 1597 Annex II........................................................................................3
Legal notice .................................................................................................6
Explanation of symbols, signs and abbreviations..................................... 10
1. Safety instructions...................................................................... 12
1.1 General safety instructions..................................................................12
1.2 General behaviour when handling the product.................................12
1.3 Intended use..........................................................................................13
1.4 Foreseeable misuse..............................................................................13
1.5 Modifications of the product................................................................13
1.6 Prohibition of certain activities............................................................13
1.7 Painting of plastic parts........................................................................13
1.8 Notes related to the CE marking .........................................................14
1.9 Inspections prior to delivery ................................................................14
1.10 Other applicable documents................................................................14
1.11 Markings on the product......................................................................14
1.12 Notes related to the type identification plate.....................................15
1.13 Notes related to the ECE approval mark ............................................15
1.14 Notes related to the UL approval mark...............................................15
1.15 Notes related to the EAC marking.......................................................15
1.16 Notes related to the UKCA marking ....................................................15
1.18 Persons authorized to operate the pump ..........................................16
1.18.1 Operator.................................................................................................16
1.18.2 Specialist in mechanics ........................................................................16
1.18.3 Specialist in electrics ............................................................................16
1.19 Briefing of external technicians...........................................................16
1.20 Provision of personal protective equipment......................................16
1.21 Operation...............................................................................................16
1.22 Emergency stopping.............................................................................16
1.23 Transport, installation, maintenance, malfunctions, repair,
shutdown, disposal...............................................................................17
1.24 Initial commissioning / daily start-up.................................................18
1.25 Cleaning .................................................................................................18
1.26 Residual risks ........................................................................................19
2. Lubricants................................................................................... 20
2.1 General information .............................................................................20
2.2 Selection of lubricants..........................................................................20
2.3 Material compatibility...........................................................................20
2.4 Temperature characteristics................................................................20
2.5 Ageing of lubricants..............................................................................21
2.6 Chisel pastes..........................................................................................22
2.6.1 Solid lubricants .....................................................................................22
3. Overview, functional description ................................................ 23
3.1 Pumps without follower plate..............................................................23
3.2 Pumps with follower plate ...................................................................25
4. Technical data ............................................................................. 27
4.1 General technical data..........................................................................27
4.2 Protection types and classes ...............................................................28
4.3 Hydraulic connection diagram ............................................................28
4.4 Nominal output volumes .....................................................................29
4.4.1 Influencing variables on the output volume ......................................29
4.4.2 Output diagrams of typical NLGI 2 lubricants....................................30

- 8 -
951-171-021
Version 02
EN Table of contents
4.5 Functioning principle of the intermittent low-level indication.........31
4.6 Limits of use of the intermittent low-level indication.......................32
4.7 Processing of the low-level signals in case of external controller
and monitoring of the pump................................................................33
4.7.1 Visualization of a low-level indication ................................................33
4.7.2 Remaining run time of pump in case of a low-level indication........33
4.8 Reservoir variants.................................................................................34
4.9 Useable reservoir volume ....................................................................35
4.10 Lubricant requirement for priming of an empty pump ....................36
4.11 Tightening torques ...............................................................................37
4.12 Type identification code........................................................................38
5. Delivery, returns, and storage .................................................... 42
5.1 Delivery..................................................................................................42
5.2 Returns ..................................................................................................42
5.3 Storage...................................................................................................42
5.4 Storage temperature range.................................................................43
5.5 Storage conditions for parts filled with lubricant ..............................43
5.5.1 Storage period of up to 6 months.......................................................43
5.5.2 Storage period from 6 to 18 months..................................................43
5.5.3 Storage period exceeding 18 months ................................................43
6. Installation.................................................................................. 44
6.1 General information .............................................................................44
6.2 Place of installation...............................................................................44
6.3 Mechanical connection.........................................................................45
6.3.1 Minimum assembly dimensions .........................................................45
6.3.2 Installation bores ..................................................................................48
6.4 Electrical connection ............................................................................50
6.5 Adjusting the output volume on the pump element R......................52
6.6 Mount pressure control valve..............................................................53
6.7 Lubrication line connection .................................................................54
6.8 Filling with lubricant .............................................................................55
6.8.1 Filling via the reservoir lid....................................................................55
6.8.2 Filling via filler fitting.............................................................................56
6.8.3 Filling via the optional filling connection ............................................57
6.8.4 Priming of pumps with follower plate.................................................58
7. Initial start-up ............................................................................ 61
7.1 Inspections prior to initial start-up.....................................................61
7.2 Inspections during initial start-up ......................................................61
8. Operation.................................................................................... 62
8.1 Refill lubricant .......................................................................................62
9. Cleaning ...................................................................................... 63
9.1 Cleaning agents.....................................................................................63
9.2 Exterior cleaning ...................................................................................63
9.3 Interior cleaning....................................................................................63

- 9 -
951-171-021
Version 02
EN
Table of contents
10. Maintenance ............................................................................... 64
11. Troubleshooting.......................................................................... 65
12. Repairs........................................................................................ 66
12.1 Replace pump element and pressure control valve..........................66
13. Shutdown and disposal............................................................... 67
13.1 Temporary shutdown ...........................................................................67
13.2 Final shutdown and disassembly ........................................................67
13.3 Disposal..................................................................................................67
14. Spare parts ................................................................................. 68
14.1 Housing cover assy. ..............................................................................68
14.2 Pump elements.....................................................................................68
14.3 Pressure control valve and adapter ....................................................69
14.4 Adapter D 6 AX 1/8NPT I C ..................................................................69
14.5 Motor 12/ 24 V DC................................................................................69
14.6 Magnetic switch ....................................................................................70
14.7 Adapter with lubrication fitting............................................................70
14.8 Closure screw M22 x 1,5......................................................................70
14.9 Transparent reservoir...........................................................................71
14.10 Fixed paddle...........................................................................................72
14.12 Reservoir lid...........................................................................................72
14.11 Screw cap...............................................................................................72
14.13 Connection sockets and cable .............................................................73
15. Electrical connections................................................................. 74
15.1 Cable colours following IEC 60757.....................................................74
15.2 Legend ...................................................................................................75
15.3 Connection of signal line to reservoir lid ............................................76
15.4 Recommended contact protection measure for
switching inductive loads .....................................................................77
15.5 Connection diagram P203 V DC without control PCB, 1 of 5..........78
15.6 Connection diagram P203 V DC without control PCB, 2 of 5..........79
15.7 Connection diagram P203 V DC without control PCB, 3 of 5..........80
15.8 Connection diagram P203 V DC without control PCB, 4 of 5..........81
15.9 Connection diagram P203 V DC without control PCB, 5 of 5..........82
15.10 Overveiw of cables and connection options.......................................83
16. China RoHS Table........................................................................ 84

- 10 -
951-171-021
Version 02
EN Explanation of symbols, signs and abbreviations
Explanation of symbols, signs and abbreviations
General warning Dangerous electrical voltage Risk of falling Hot surfaces
Unintentional intake Crushing hazard Pressure injection Suspended load
Electrostatically sensitive
components
Potentially explosive
atmosphere
Keep unauthorized persons
away
Wear personal protective
equipment (goggles)
Wear personal protective
equipment (face shield)
Wear personal protective
equipment (gloves)
Wear personal protective
equipment (protective clothes)
Wear personal protective
equipment (safety shoes)
Disconnect product from
mains General obligation
Protective conductor
(protection class I)
Protection y double or rein-
forced insulation
(protection class II)
Protection by extra low volt-
age (protection class III)
Safe galvanic isolation (protec-
tion class III)
CE marking Disposal, recycling Disposal of waste electrical
and electronic equipment
Warning level Consequence Probability Symbol Meaning
DANGER Death, serious
injury imminent lChronological guidelines
WARNING Death, serious
injury possible ¡Lists
CAUTION Minor injury possible Refers to other facts, causes, or consequences
NOTICE Property damage possible
The following abbreviations may be used within these instructions. Symbols within safety notes mark the kind and source of the hazard.

- 11 -
951-171-021
Version 02
EN
Explanation of symbols, signs and abbreviations
Abbreviations and conversion factors
re. regarding °C degrees Celsius °F degrees Fahrenheit
approx. approximately K Kelvin Oz. ounce
i.e. that is N Newton fl. oz. fluid ounce
poss. possibly h hour in. inch
if appl. if applicable s second psi pounds per square inch
incl. including d day sq. in. square inch
min. minimum Nm Newtonmeter cu. in. cubic inch
max. maximum ml millilitre mph miles per hour
min. minute ml /d millilitre per day rpm revolutions per minute
etc. et cetera cc cubic centimetre gal. gallon
e.g. for example mm millimetre lb. pound
kW kilowatt l litre hp horse power
U Voltage dB (A) sound pressure level kp kilopond
R resistance > greater than fpsec feet per second
I current < less than conversion factors
V volt ± plus/minus Length 1 mm = 0.03937 in.
Wwatt Ø diametre Area 1 cm² = 0.155 sq.in
AC alternating current kg kilogram Volume 1 ml = 0.0352 fl.oz.
DC direct current rh relative humidity 1 l = 2.11416 pints (US)
A ampere ≈approximately Mass 1 kg = 2.205 lbs
Ah ampere hour = equal to 1 g = 0.03527 oz.
Hz frequency [Hertz] % per cent Density 1 kg/cm³ = 8.3454 lb./gal. (US)
nc normally closed contact ‰ per mille 1 kg/cc = 0.03613 lb./cu.in.
no Normally open contact ≥greater than Force 1 N = 0.10197 kp
N/A not applicable ≤less than Pressure 1 bar = 14.5 psi
ft. feet mm2square millimetre Temperature °C = (°F-32) x 5/9
rpm revolutions per minute Output 1 kW = 1.34109 hp
áIncreases a value Acceleration 1 m/s² = 3.28084 ft./s²
âReduces a value Speed 1 m/s = 3.28084 fpsec.
1 m/s = 2.23694 mph

- 12 -
951-171-021
Version 02
EN 1. Safety instructions
1. Safety instructions
1.1 General safety instructions
○The owner must ensure that safety infor-
mation has been read by any persons en-
trusted with works on the product or by
those persons who supervise or instruct
the before-mentioned group of persons.
In addition, the owner must also ensure
that the relevant personnel are fully fa-
miliar with and have understood the con-
tents of the Instructions. It is prohibited to
commission or operate the products prior
to reading the instructions
○These instructions must be kept for fur-
ther use
○The described products were manufac-
tured according to the state of the art.
Risks may, however, arise from a usage
not according to the intended purpose
and may result in harm to persons or
damage to material assets
○Any malfunctions which may affect safety
must be remedied immediately. In addi-
tion to these Instructions, general statu-
tory regulations for accident prevention
and environmental protection must be
observed
1.2 General behaviour when handling the
product
○The product may be used only in aware-
ness of the potential dangers, in proper
technical condition, and according to the
information in these instructions
○Familiarize yourself with the functions
and operation of the product. The speci-
fied assembly and operating steps and
their sequences must be observed
○Any unclear points regarding proper
condition or correct assembly/ operation
must be clarified. Operation is prohibited
until issues have been clarified
○Keep unauthorized persons away
○Wear personal protective equipment
always
○Precautionary operational measures and
instructions for the respective work must
be observed
○Responsibilities for different activities
must be clearly defined and observed.
Uncertainty seriously endangers safety
○Safety-related protective and safety
equipment must not be removed, modi-
fied or affected otherwise in its function
and is to be checked at regular intervals
for completeness and function
○If protective and safety equipment has to
be dismantled, it must be reassembled
immediately after finishing the work, and
then checked for correct function
○Remedy occurring faults in the frame of
responsibilities. Immediately inform your
superior in the case of faults beyond your
competence
○Never use parts of the centralized lu-
brication system or of the machine as
standing or climbing aids

1
- 13 -
951-171-021
Version 02
EN
1. Safety instructions
1.3 Intended use
Supply of lubricants within a centralized lu-
brication system following the specifications,
technical data and limits stated in these
Instructions:
The product is intended exclusively for inte-
gration into a different machine.
Usage is allowed exclusively for professional
users in the frame of commercial and eco-
nomic activities.
1.4 Foreseeable misuse
Any usage differing from the one stated in
these Instructions is strictly prohibited, par-
ticularly a usage:
○outside the indicated ambient tempera-
ture range
○with non-specified means of operation
○without adequate pressure control valve
○in continuous operation
○of C3 versions in areas with aggressive
and corrosive materials (e.g. with high
salt concentration)
○of plastic parts in areas with high ozone
levels or in areas with harmful radiation
(e.g. ionising radiation)
○to supply, transport, or store hazardous
substances and mixtures in accordance
with annex I part 2-5 of the CLP regula-
tion (EG 1272/2008) or HCS 29 CFR
1910.1200 marked with GHS01-GHS06
and GHS08 hazard pictograms
○to feed, forward, or store gases, liquefied
gases, dissolved gases, vapours, or fluids
whose vapour pressure exceeds normal
atmospheric pressure of 1013 mbar
[14.69 psi] by more than 0.5 bar [7.25
psi] at the maximum permissible operat-
ing temperature.
○in an explosion protection zone
1.5 Modications of the product
Unauthorized conversions or modifica-
tions may result in unforeseeable impacts
on safety. Therefore, any unauthorized
conversions or modifications are expressly
prohibited.
1.6 Prohibition of certain activities
Due to potential sources of faults that may
not be visible or due to legal regulations
the following activities may be carried out
by manufacturer specialists or authorized
persons only:
○Repairs or changes to the drive
○Replacement of or changes on the pis-
tons of the pump elements
1.7 Painting of plastic parts
Painting of any plastic parts or seals of the
described products is expressly prohibited.
Remove or tape plastic parts completely be-
fore painting the superior machine

- 14 -
951-171-021
Version 02
EN 1. Safety instructions
1.11 Markings on the product
Warning of personal injury from
being drawn in, crushed or
sheared while the pump is run-
ning due to contact with the stir-
ring paddle when the reservoir lid
is open.
Warning of spring tension in case
of pumps with follower plate
Rotational direction of the pump.
Further to the findings of the
workplace risk evaluation the
operating company has to at-
tach additional markings (e. g.
warnings, signs giving orders,
prohibition signs or labelling
as specified by GHS), where
appropriate.
1.8 Notes related to the CE marking
CE marking is effected following the require-
ments of the applied directives:
○2014/30/EU
Electromagnetic compatibility
○2011/65/EU
(RoHS II) Directive on the restriction of
the use of certain hazardous substances
in electrical and electronic equipment
Reference on Pressure Equipment Directive
2014/68/EU
Because of its performance data the product
does not achieve the limit values defined in
Article 4 (1) (a) (ii) and is therefore excluded
from the scope of application of Pressure
Equipment Directive 2014/68/EU following
Article 1 (2) (f).
1.9 Inspections prior to delivery
The following inspections were carried out
prior to delivery:
○Safety and functional tests
○Electrical inspections following EN
60204-1
1.10 Other applicable documents
In addition to these instructions, the fol-
lowing documents must be observed by the
respective target group:
○Operational instructions and approval
rules
○Safety data sheet of the lubricant used
Where appropriate:
○Project planning documents
○Additional information on special ver-
sions of the pump. You will find these in
the special system documentation
○Any documents of other components
required to set up the centralized lubrica-
tion system

1
- 15 -
951-171-021
Version 02
EN
1. Safety instructions
SKF Lubrication Systems Germany GmbH
P203-xxxxx-xxx-xx
644-xxxxx-x
xxxxxxxxxxxx
Made in xxxxxxxxxxxxxxxx Factory address
xxx bar / xxxx psi
xx VDC
72 W
KW/JJ
Factory Automation
Equipment
77MM
Model:
P. No.:
S. No.:
pmax:
U:
P:
SKF Lubrication Systems Germany GmbH
P203-xxxxx-xxx-xx
644-xxxxx-x
xxxxxxxxxxxx
Made in xxxxxxxxxxxxxxxx Factory address
xxx bar / xxxx psi
xx VDC
72 W
KW/JJ
Factory Automation
Equipment
77MM
Model:
P. No.:
S. No.:
pmax:
U:
P:
1.12 Notes related to the type identica-
tion plate
The type identification plate states impor-
tant characteristics such as type designa-
tion, order number, and regulatory char-
acteristics.To ensure that the loss of data
due to an illegible type identification plate is
avoided, the characteristics should be en-
tered in the Instructions.
Model: _______________________________
P. No. ________________________________
S. No. ________________________________
(CW/YY) _______________________________
Calendar week/year of construction
1.13 Notes related to the ECE approval
mark
The ECE approval mark (E1) con-
firms that an ECE design certifica-
tion (ECE R10) was issued for the
product.
1.14 Notes related to the UL approval
mark
The UL approval mark confirms
that the product has UL certifica-
tion of compliance with US and
Canadian safety regulations.
1.15 Notes related to the EAC marking
The EAC conformity marking con-
firms the product’s conformity with
the applicable legal provisions of the
Eurasian customs union.
1.16 Notes related to the UKCA marking
The UKCA conformity marking con-
firms the product’s conformity with
the applicable legal provisions of
Great Britain.
1.17 Notes related to the China RoHS
marking
The China RoHS marking confirms
that there is no danger to persons
or the environment from the regu-
lated substances contained within
the intended period of use (number
in the circle) of the product.

- 16 -
951-171-021
Version 02
EN 1. Safety instructions
1.18 Persons authorized to operate the
pump
1.18.1 Operator
A person who is qualified by training, know-
ledge and experience to carry out the func-
tions and activities related to normal opera-
tion. This includes avoiding possible hazards
that may arise during operation.
1.18.2 Specialist in mechanics
Person with appropriate professional educa-
tion, knowledge and experience to detect
and avoid the hazards that may arise during
transport, installation, start-up, operation,
maintenance, repair and disassembly.
1.18.3 Specialist in electrics
Person with appropriate professional educa-
tion, knowledge and experience to detect
and avoid the hazards that may arise from
electricity.
1.19 Brieng of external technicians
Prior to commencing the activities, external
technicians must be informed by the opera-
tor of the company safety provisions, the
applicable accident prevention regulations
to be maintained, and the functions of the
superordinate machine and its protective
devices.
1.20 Provision of personal protective
equipment
The operator must provide suitable personal
protective equipment for the respective
location of operation and the purpose of
operation.
1.21 Operation
The following must be observed during
commissioning and operation:
○Any information within this manual and
the information within the referenced
documents
○All laws and regulations to be complied
with by the user
1.22 Emergency stopping
In case of an emergency stop the pump sta-
tion by:
○Interrupting the power supply to the
pump
○Where appropriate, using measures
determined by the operator, such as ac-
tuating the emergency stop switch of the
superior machine

1
- 17 -
951-171-021
Version 02
EN
1. Safety instructions
○Carry out electrical connections only ac-
cording to the information in the valid
wiring diagram and taking the relevant
regulations and the local connection con-
ditions into account
○Do not touch cables or electrical compo-
nents with wet or damp hands
○Fuses must not be bypassed Replace de-
fective fuses always by fuses of the same
type
○Ensure proper connection of the protec-
tive conductor in case of products of pro-
tection class I
○Observe the stated type of protection
○Undertake drilling at non-critical, non-
load bearing parts only. Use any available
boreholes. Do not damage lines and ca-
bles when drilling.
○Observe possible abrasion points. Protect
the parts accordingly
○Ensure through suitable measures that
movable or detached parts are immobi-
lized during the work and that no limbs
can be caught in between by inadvertent
movements
○Assemble the product only outside of the
operating range of moving parts, at an
adequate distance from sources of heat
or cold. Other units of the machine or ve-
hicle must not be damaged or impaired in
their function by the installation
○Dry or cover wet, slippery surfaces
accordingly
○Cover hot or cold surfaces accordingly
○Work on electrical components must be
carried out by electrical specialists only.
Observe any waiting periods for dis-
charging, if necessary
○Carry out works on electrical components
only while the system is depressurized
and use voltage isolated tools suitable for
electrical works only
1.23 Transport, installation, maintenance,
malfunctions, repair, shutdown,
disposal
○All relevant persons must be informed
of the activity prior to starting any work.
Observe the precautionary operational
measures and work instructions
○Carry out transport using suitable trans-
port and hoisting equipment on suitable
ways only
○Maintenance and repair work can be
subject to restrictions at low or high tem-
peratures (e.g. changed flow properties of
the lubricant).Therefore, where possible,
try to carry out maintenance and repair
work at room temperature.
○Prior to performing work, the product
and the machine, into which the product
will be integrated, must be depressur-
ized and secured against unauthorized
activation

- 18 -
951-171-021
Version 02
EN 1. Safety instructions
1.24 Initial commissioning / daily start-up
Ensure that:
○All safety devices are completely available
and functional
○All connections are correctly connected
○All parts are correctly installed
○All warning labels on the product are
present completely, highly visible and
undamaged
○Illegible or missing warning labels are to
be replaced without delay
○All components used must be designed
according to the maximum operating
pressure and the maximum respectively
minimum ambient temperature
○No parts of the centralized lubrication
system may be subjected to torsion,
shear, or bending
○Check all parts prior to their usage for
contamination and clean, if necessary
○Lubricant lines must be primed with
lubricant prior to installation. This makes
the subsequent ventilation of the system
easier
○Observe the specified tightening torques.
When tightening, use a calibrated torque
wrench,
○When working with heavy parts use suit-
able lifting tools
○Avoid mixing up or wrong assembly
of dismantled parts. Mark these parts
accordingly
1.25 Cleaning
○Risk of fire and explosion when using
inflammable cleaning agents Only use
non-flammable cleaning agents suitable
for the purpose
○Do not use aggressive cleaning agents
○Thoroughly remove residues of cleaning
agents from the product
○Do not use steam jet and high pressure
cleaners. Electrical components may be
damaged. Observe the type of protection
of the pump
○Cleaning work may not be carried out on
energized components
○Mark damp areas accordingly

1
- 19 -
951-171-021
Version 02
EN
1. Safety instructions
1.26 Residual risks
Residual risk Possible in life cycle Prevention/ remedy
Personal injury/ material damage due to
falling of raised parts A B C G H K Keep unauthorized persons away. No people may remain under suspended loads. Lift parts with adequate lifting devices.
Personal injury/ material damage due to
tilting or falling of the product because of
non-observance of the stated tightening
torques
B C G
Observe the specified tightening torques. Fix the product to components with ad-
equate load-bearing capacities only. If no tightening torques are stated, apply tight-
ening torques according to the screw size characteristics for 8.8 screws.
Personal injury/ material damage due to
electric shock in case of damage to the
connection cable
B C D E F G H
Check the connection cable with regard to damages before the first usage and then at
regular intervals. Do not mount cable to moving parts or friction points. If this cannot
be avoided, use spring coils respectively protective conduits.
Personal injury/ damage to material due
to spilled or leaked lubricant B C D F G H K
Be careful when filling the reservoir and when connecting or disconnecting lubricant
feed lines. Always use suitable hydraulic screw connections and lubrication lines
for the stated pressures. Do not mount lubrication lines to moving parts or friction
points. If this cannot be avoided, use spring coils respectively protective conduits.
Loss of electrical protective function due
to faulty installation of electrical compo-
nents after repair
GAfter replacement of electrical components carry out an electrical safety test accord-
ing to EN 60204-1.
Reservoir with follower plate is subjected
to spring load G
Remove reservoir with follower plate only when the spring is quite released (i.e. the
reservoir is empty). Provide adequate protective measure, e.g. fastening straps, when
loosening the reservoir. Do not work with your head directly above the reservoir.
Warning of personal injury from being
drawn in, crushed or sheared while the
pump is running due to contact with the
stirring paddles when the reservoir lid
is open.
B C D E F G
Never reach into the reservoir while the pump is running.
Remove reservoir lid only, if pump has been disconnected electrically from the mains
beforehand.
Life phases:
A = transport, B = installation, C = initial start-up, D = operation, E = cleaning, F = maintenance, G = fault, repair, H = shutdown, K = disposal

- 20 -
951-171-021
Version 02
EN 2. Lubricants
2. Lubricants
2.1 General information
Lubricants are used specifically for cer-
tain application purposes. In order to fulfil
their tasks, lubricants must fulfil various
requirements.
The most important requirements for lubri-
cants are:
○Reduction of abrasion and wear
○Corrosion protection
○Noise minimisation
○protection against contamination or
penetration of foreign objects
○Cooling (primarily with oils)
○longevity (physical/ chemical stability)
○economic and ecological aspects
2.2 Selection of lubricants
SKF considers lubricants to be an element
of system design. A suitable lubricant is se-
lected already when designing the machine
and forms the basis for the planning of a
centralized lubrication system.
The selection is made by the manufacturer
or operator of the machine, preferably to-
gether with the lubricant supplier based on
the requirement profile defined.
Should you have little or no experience with
the selection of lubricants for centralized lu-
brication systems, please contact SKF.
If required we will be glad to support cus-
tomers to select suitable components for
feeding the selected lubricant and to plan
and design their centralized lubrication
system.
You will avoid possible downtimes through
damage to your machine or system or
damage to the centralized lubrication
system.
2.3 Material compatibility
Lubricants must generally be compatible
with the following materials:
○steel, grey iron, brass, copper, aluminium
○ABS, CR, FPM, NBR, NR, PA, PET, PMMA,
POM, PP, PS, PTFE, PU, PUR
2.4 Temperature characteristics
The lubricant used must be suitable for the
specific ambient temperature of the product.
The viscosity required for proper operation
of the product must be adhered to and must
not be exceeded in case of low temperatures
nor fall below specification in case of high
temperatures. Specified viscosities, see
chapter Technical data.
