Skoda Infotainment Navigation Columbus User manual

SIMPLY CLEVER
Infotainment Columbus
Operating Instructions


3V0012720FA

Preface
This manual is intended for the Infotainment Navigation Columbus systems (hereinafter referred to
only as Device).
Please read these Operating Instructions carefully, because the operation in accordance with these
instructions is a prerequisite for proper use of the unit.

3V0012720FA

Table of Contents
Operating Instructions 3
Notes 4
Abbreviations
Introductory information
Important notes 6
Equipment overview 6
Device operation and settings
Device operation 9
Voice control 11
Device Settings 15
Radio
Operation 18
Settings 21
Media
Operation 23
Audio sources 25
Images
Image viewer 31
DVD video
Video player 33
TV tuner
TV function 36
Telephone
Introductory information 39
Pairing and connecting 42
Connection using the SIM card in the external
module 46
Dial telephone number 47
Telephone functions 50
Text messages (SMS) 51
WLAN connectivity and data connection
WLAN 53
Data connection 55
MirrorLink
MirrorLink™56
Navigation
Navigation description 59
New destination 60
My Destinations 62
POI 64
Import custom destinations 65
Map 66
Route guidance 69
Tour 73
Traffic reports 74
Settings 76
Vehicle systems
CAR - Vehicle settings 78
Adjustment of the heating and cooling
system 83
Index
2Table of Contents

Operating Instructions
This Owner's Manual describes all possible device functions without identify-
ing them as special equipment, model variants or market-dependent equip-
ment. Consequently, the device on this vehicle does not need to contain all of
the functions described in this Owner's Manual.
The availability of some features described in this manual depends on the
type of external devices (for example, telephone, music player, etc.).
Information on the compatibility of external devices can be found on ŠKODAIn-
ternet pages http://infotainment.skoda-auto.com .
The Images in these Operating Instructions are for illustrative purposes only.
The illustrations can differ in minor details from your vehicle; they are only in-
tended to provide general information.
ŠKODA AUTO a.s. pursues a policy of ongoing product and model development
with all vehicles. Changes in terms of supply scope are possible at any time
with regard to design, equipment and technology. The information listed in
these Operating Instructions corresponds to the information available at the
time of going to press.
It is therefore not possible for legal claims to be made based on the technical
data, illustrations and information contained in these Operating Instructions.
Declaration of conformity
ŠKODA AUTO a.s. hereby declares that the ŠKODA Infotainment systems meet
the basic requirements and additional provisions of Directive 1999/5/EC with
reference to radio equipment and telecommunications devices.
Applies to Nigeria: ŠKODA AUTO a.s. hereby declares that the “connection and
the use of this communication device is granted by the Nigerian Communica-
tions Commission.”
3
Operating Instructions

Notes
Structure of these Operating Instructions
The Operating Instructions are hierarchically divided into the following areas.
■Main chapters (e.g. Introductory information) - the title of the main chapter is
always shown on the lower right side of the page
■Chapter (e.g. Equipment overview)
■ Introduction to the topic - Module overview within the chapter, intro-
ductory information about the chapter content, if necessary, applies to all
chapter notes
■Module (for example, Switching the unit on/off)
Text notes
Note Meaning
“Press” Short press of the button for under 1 s
“Hold” Long press of the button for 2 - 5 s
Text Symbols
Symbol Meaning
Reference to the introductory module of a chapter with im-
portant information and safety warnings
Continuation of the module on the next page
®Registered Trademark
™
→Marker to the next operation step
The text symbol used for the right control dial
WARNING
Texts with this symbol draw attention to threats of a serious accident, in-
jury or loss of life.
CAUTION
Texts with this symbol draw attention to the risk of vehicle damage or possible
non-operability of some systems.
Note
Texts with this symbol contain additional information.
Information search
When searching for information in the Operating Instructions, we recommend
using the Index at the end of the manual.
4Notes

Abbreviations
Abbreviation Definition
2D planar map display
3D spatial map display
A2DP a Bluetooth® profile for the one-sided audio data transmis-
sion
AF Alternative frequencies for the current radio station
AM Identification of the radio-frequency range
TCS Traction Control of the drive wheels
avi Compressed video format
AVRCP A Bluetooth® profile for the operation associated with the
transmission of audio data multimedia functions
BT Bluetooth® - wireless communication for reception and
transmission of voice and data information
DAB Digital radio reception
DRM A system for monitoring or restricting the use of digital me-
dia content
DTMF A dialling tone during a telephone communication
ESC Electronic Stability Control
FM Identification of the radio-frequency range
HFP A Bluetooth® - profile for communication between a mobile
telephone and the Infotainment
GPS Satellite system for determining the position
GPT Method for the division of the areas in the data devices (to
be used for mass storage resources)
GSM Global system for mobile communications
ID3 tag An additional feature of a music file, which allows for the
display of artist, title, album name, etc.
MAP A Bluetooth® - profile for the exchange of text messages
(SMS) between the device and a connected device
mp3 Compressed audio format
mp4 Compressed video format
MSC A communication protocol for a USB device
Abbreviation Definition
MTP A communication protocol for a data device
PBAP A Bluetooth® profile for the download of telephone contacts
to the device memory
PI code A program identification of the radio station, which allows a
group sort of radio stations
PIN Personal identification number
RDS A system for the transmission of additional information for
FM radio reception
rSAP
A Bluetooth® profile for the communication between a mo-
bile telephone and Infotainment in the mode for distance
transmission of SIM data
Messages A service for short text messages
SSP The quick pairing method of a Bluetooth® device
TMC Traffic reports, which may affect the navigation
TP Identification of a traffic information station
UPnP Application for a simple wireless connection of the device to
the device
VIN Vehicle identification number
wav Audio format
WLAN Wireless Local Area Network
wma Compressed audio format
wmv Compressed video format
5
Abbreviations

Introductory information
Important notes
Introduction
This chapter contains information on the following subjects:
Information on use, updating and compatibility 6
Component protection 6
WARNING
■Concentrate fully at all times on your driving! As the driver you are fully
responsible for the operation of your vehicle.
■Only use the device in such a way that you are in full control of your vehi-
cle in every traffic situation – there is the risk of accidents!
■Adjust the volume to ensure that acoustic signals from outside the vehi-
cle, e.g. sirens from emerging vehicles instructing you to give way to, such
as the police, ambulance and fire brigade, can be heard at all times.
■High volumes can cause hearing damage!
CAUTION
In some countries, some unit features can no longer be selected when the ve-
hicle is running faster than a certain speed. This is not a malfunction, but com-
plies with the national legal regulations.
Information on use, updating and compatibility
Read and observe and on page 6 first.
Refer to the ŠKODAInternet pages http://infotainment.skoda-auto.com for in-
formation on the compatibility of external devices as well as software updates
and navigation data.
Component protection
Read and observe and on page 6 first.
Some electronic control units are equipped with protection components, which
serve as protective mechanisms, for example, in cases of theft of the ECUs.


When component protection is enabled, the following message appears on the
display Component theft protection: the infotainment system is not fully
available at present. Please switch on the ignition.
If the component protection does not activate by switching on the ignition,
please contact a ŠKODA specialist garage.
Equipment overview
Introduction
This chapter contains information on the following subjects:
Description of the device 7
External module 7
Touch screen 7
Turn device on/off 8
Unit menus 8
Adjusting the volume 8
This chapter covers the device, the switching on and off and volume control of
the device.
6Introductory information

Description of the device
Fig. 1 Equipment overview
- Control dial for calls and confirmations
 - Left control dial for switching the device on and off; volume adjust-
ment
 - Menu Radio » page 18
 - Menu Media » page 23
 - Menu Telephone » page 39
 - Voice control » page 11
 - Navigation menu » page 59
 - Radio traffic service » page 74
 - Vehicle systems settings » page 78
 - Unit menus display » page 8
Touch screen » page 7

1
2
3
4
5
6
7
8
9
10
External module
Fig. 2 External module
The external module is located in the storage compartment on the front pas-
senger side.
 CD/DVD ejection button
CD/DVD case
SD1 card slot
SD2 card slot
SIM card slot
Touch screen
The unit is equipped with a touch screen which can be operated with a light
touch or swipe of a finger.
The brightness level of the screen can be set » page 15.
CAUTION
Notes on operating the touch screen
■The screen is operated with a light touch of a finger. Do not exert any pres-
sure on the screen - there is a risk of damaging the screen!
■It is not possible to operate the screen with your fingernails or while wearing
gloves. 
1
2
3
4
5
7
