Skope SC112N-AC User manual

Service Manual MAN80302 Rev. 1.2 Jan. 2024
SC112N-AC
Four Glass Sided Chiller
Type: HSC112NA/Z157

SC112N-AC
Four Glass Sided Fridge
Type: HSC112NA/Z157
Service Manual
MAN80302
Rev. 1.2 Jan. 2024
© 2021 SKOPE Industries Limited. All rights reserved.
SKOPE Industries Limited reserves the right to alter specifications without notice.
is a registered trademark of SKOPE Industries Limited.
SKOPE INDUSTRIES LIMITED
Head Office
PO Box 1091, Christchurch
New Zealand
A.B.N. 73 374 418 306
AU: 1800 121 535
NZ: 0800 947 5673
E-mail: [email protected]
Website: www.skope.com
Trademark Infringement
The SKOPE trademark on this product is infringed if the owner, for the time being, does
any of the following:
• Applies the trade mark to the product after its state, condition, get-up or packaging
has been altered in any manner
• Alters, removes (including part removal) or obliterates (including part obliteration) the
trade mark on the product
• Applies any other trade mark to the product
• Adds to the product any written material that is likely to damage the reputation of the
trade mark
Notice of the above contractual obligations passes to:
• Successors or assignees of the buyer
• Future owners of the product

SC112N-AC
Service Manual iii
Contents
1 Servicing Hydrocarbon
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 Specifications
SC112N-AC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3 Electronic Controller
Electronic Controller Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Running the Fridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Compressor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Evaporator Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Condenser Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Temperature Probes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Door Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Defrost Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Messages and Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Controller Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Cold Climate Protection (CCP) . . . . . . . . . . . . . . . . . . . . . . . . . . .10
No-downward Tendency Protection (NDTP). . . . . . . . . . . . . . . . .10
Programming the Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . 11
Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Parameter list – SC112N-AC program 089. . . . . . . . . . . . . . . .12
4 Replacement Procedures
Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Adjusting the Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Interior lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Top Sign Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Bottom Sign Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Replacing Door Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Removing and Fitting Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Adjusting Door Tension. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Refrigeration System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Before Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
On-site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Off-site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Refrigeration Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Refrigeration Cartridge Assembly . . . . . . . . . . . . . . . . . . . . . . . . .21
Refrigeration System Access . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Refrigeration System Dismantling. . . . . . . . . . . . . . . . . . . . . . . . .23
Evaporator Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Condenser Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Power Supply and Surge Protector. . . . . . . . . . . . . . . . . . . . . . . .27

SC112N-AC
Service Manual
iv
Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Compressor Electrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Electronic Controller Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Controller Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Control Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Evaporator Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Door Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
5 Wiring
Model: SC112N-AC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6 Spare Parts
Cabinet Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Refrigeration System Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7 Troubleshooting
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

5
SC112N-AC
Servicing Hydrocarbon
Service Manual
1 Servicing Hydrocarbon
Overview
This cooler uses hydrocarbon (HC) R600a as its refrigerant. R600a is a
natural refrigerant that has a very low environmental impact.
Special service requirements are needed as R600a is a flammable
refrigerant.
Safety hazards
The main R600a safety hazards are:
• Flammable refrigerant.
• Venting of R600a and compressor oil.
• Asphyxiation.
SKOPE does NOT recommend performing hazardous activities on the
refrigeration system.

6Specifications
Service Manual
SC112N-AC
2 Specifications
SC112N-AC Description: Four Glass Sided Fridge
Type: HSC112NA/Z157
Tools required for servicing may include:
• Screwdriver with Pozidriv PZ1 and PZ2 bit
• Slotted screwdriver
• Small slotted screwdriver (for electrical connectors)
Table 1: SC112N-AC specifications
Dimensions
External Internal
Height 1165 to 1180 mm 725 mm
Width 470 mm 382.6 mm
Depth 470 mm 369.5 mm
Floor area 0.22 m2
Refrigeration system Bottom-mounted, integral, electronically controlled refrigeration system
Electronic controller CAREL ECOBOX
Refrigerant R600a/40 g (natural refrigerant)
Operating temperature range 0°C to 5°C
Tested climate 25°C @ 60% relative humidity (climatic class 3)
GEMS energy 3.03 kWh/day
Electrical 220-240 volts a.c. 50 Hz, single phase supply, 1.2 amps
Nominal capacity 250 watts
Sign lighting Top sign: 4 × horizontal LED lights (total 5 W)
Bottom sign: 2 × horizontal LED lights (total 3 W)
Internal lighting 4 × vertical corner LED lights (total 8W)
Doors 2 × double-glazed, single low-e, lockable, toughened glass swing doors
(right hand hinge)
Shelves 3 × adjustable height wire shelves (351 mm × 357 mm)
Product loading 3 layers of bottles (216 mm high): 4 per side, 16 per shelf, 48 per cabinet
Internal volume 109 litres
Total weight 56 kg

7
SC112N-AC
Electronic Controller
Service Manual
3 Electronic Controller
Electronic Controller Operations
Overview The SC112N-AC fridge is fitted with a CAREL ECOBOX electronic
controller. The electronic controller is visible on the front panel and is housed
inside the controller box at the front of the refrigeration system.
The electronic controller controls and displays the fridge temperature and
signals temperature alarms. It uses two temperature probes within the
refrigeration system to collect data and runs the fridge accordingly.
The electronic controller is pre-programmed; SKOPE does not recommend
changing the settings unless it is absolutely necessary. To ensure efficient
operation, the electronic controller automatically forces a defrost cycle when
required.
IMPORTANT
The electronic controller must only be adjusted by an authorised
service agent.
Figure 1: CAREL ECOBOX
electronic controller

8Electronic Controller
Service Manual
SC112N-AC
Faceplate Because the electronic controller plays such an important role, it’s helpful to
know the parts of the faceplate you may use.
1
2
6
3
5
4
7
8
9
Figure 2: Electronic
controller faceplate
Table 2: Controller faceplate
No. Item Description
1Alarm Mute (up): Mutes the audible alarm buzzer.
2Day - Night: Switches the fridge between Day and Night
modes.
3Light (down): Switches the cabinet lights on and off.
4
Compressor: ON when the compressor and condenser fan
starts. Flashes when activation of the compressor is
temporarily delayed.
5Fan: ON when the internal cabinet fans are activated.
Flashes when activation of the fans is temporarily delayed.
6
Defrost: ON when the defrost is activated. Flashes when the
activation of the defrost is temporarily delayed due to
procedures in progress.
7AUX: n.a.
8Clock: n.a.
9Alarm: ON when alarm is signalled.

9
SC112N-AC
Electronic Controller
Service Manual
Running the Fridge
Operating
Modes
The electronic controller will automatically switch the fridge between Day
and Night modes depending on use, and into Cold Climate Protection (CCP)
mode if necessary (see “Cold Climate Protection (CCP)” on page 10).
If the front door (on the electronic controller side) is not opened for
four hours, the fridge will automatically enter Night mode and the sign and
interior lights will switch off. To manually switch the fridge between Day and
Night modes, press and hold the Day - Night button on the electronic
controller faceplate. The fridge can also be bought into Day mode by
opening the front door (on the electronic controller side).
Compressor The compressor cycles on and off during Day and Night modes. It does not
run when the fridge is in defrost mode or when the fridge is in CCP mode. If
the electronic controller displays “Err” there is a fault within the refrigeration
system and the compressor will not run.
Evaporator
Fan
The evaporator fan starts a few minutes after the fridge is turned on and runs
continuously during normal operation defrost and CCP mode, and stops
when the front door is open or if the electronic controller displays “Err”
indicating a fault within the refrigeration system.
Condenser
Fan
The condenser fan runs continuously when the fridge is on except if the
electronic controller displays “Err”, indicating a fault within the refrigeration
system.
Temperature
Probes
Two temperature probes feed data to the electronic controller – the control
probe and the evaporator probe. The control probe controls the fridge
temperature, provides the fridge temperature for the electronic controller to
display, and notifies the electronic controller of any erratic or abnormal
temperatures that could identify a problem within the refrigeration system.
The evaporator probe controls the refrigeration system defrost initiation and
termination.
Door Switch The fridge is fitted with a door switch below the front door (on the electronic
controller side). A small magnet in the door frame activates the switch. The
door switch tells the electronic controller to turn off the evaporator fan motor
(i.e. if the door is opened) during normal run operation, to initiate Night mode
if the door is not opened for four hours, and to reactivate Day mode if the
door is opened during night mode.
Defrost Cycle The defrost cycle will begin after three hours of cumulative compressor run
time or during No-Downward Tendency Protection (see “No-downward
Tendency Protection (NDTP)” on page 10). During the defrost cycle the
compressor stops and the evaporator fan runs continuously. The defrost
cycle will stop when the evaporator probe reaches 6°C or after the defrost
cycle has been running for 60 minutes.
Lighting The fridge is fitted with top and bottom sign lights, and interior pillar lights.
The lights will come on when the fridge is first plugged in. When in Day mode
the sign and interior lights are on. When in Night mode the sign and interior
lights are off. Press the Light button on the electronic controller faceplate to
switch the sign and interior lights on and off manually. The lights will remain
on and cannot be switched off when the fridge is in CCP mode.

10 Electronic Controller
Service Manual
SC112N-AC
Messages and Alarms
Controller
Display
The following table explains messages that the electronic controller
displays, and related alarms. Alarms signal unexpected operational
changes in the fridge and can be muted by pressing the Alarm Mute (up)
button on the electronic controller faceplate (see page 8).
Cold Climate
Protection
(CCP)
The fridge will enter CCP mode if the ambient temperature becomes too
cold. This is detected by the control probe (at the evaporator air out)
measuring a temperature of ≤0°C continuously for 30 minutes. The lights will
stay on and cannot be switched off while the fridge is in CCP mode. The
fridge will return to its previous mode (Day or Night) once the control probe
measures ≥2°C at the evaporator air out.
No-downward
Tendency
Protection
(NDTP)
The electronic controller starts NDTP when the compressor has been
running for ≥30 minutes and the control probe temperature does not
decrease. This will force a standard defrost cycle (see “Defrost Cycle” on
page 9). If the electronic controller is required to force consecutive defrost
cycles due to NDTP, the refrigeration system error alarm will start (Err) and
the fridge will shut down indicating a fault within the refrigeration system.
Table 3: Controller display
Display Description
The fridge is in Day mode and the electronic controller displays
the fridge temperature.
The fridge is in economical Night mode. When in Night mode the
temperature inside the fridge is moderated and the cabinet lights
turn off. The lights can be switched on and off by pressing the
Light button on the controller faceplate, and the fridge can be
switched into Day mode by pressing the Day - Night button on the
electronic controller faceplate.
The fridge is in Cold Climate Protection (CCP) mode. The fridge
enters CCP mode if the ambient temperature gets too cold. The
lights remain on and cannot be switched off.
The front door has remained open for over two minutes. An alarm
sounds, and the compressor and evaporator fan turn off.
There is a refrigeration system error and the controller turns the
fridge off to avoid damage.
Control probe failure. The control temperature probe has failed
and an alarm sounds.
Evaporator probe failure. The evaporator temperature probe has
failed and an alarm sounds.

11
SC112N-AC
Electronic Controller
Service Manual
Programming the Electronic Controller
Parameters The parameter configuration program is set by SKOPE at the factory. A label
on the controller box indicates the parameter configuration program number
(e.g. the SC112N-AC fridge uses program 089).
The electronic controller parameters can be modified using the keypad.
Access to the parameters is protected by a password to prevent accidental
or unauthorised modifications. Only an authorised service agent should
modify the parameters.
Procedure 1: To access the parameters
1. Press and hold the Alarm Mute (up) button for 5 seconds until the display
shows PS (password).
2. Press the Day - Night button. The display shows 0.
3. Use the Alarm Mute (up) and Light (down) buttons to select password 22
(default password).
4. Press the Day - Night button to confirm the password. The display shows PS.
5. Use the Alarm Mute (up) and Light (down) buttons to scroll through the
parameter codes and locate the required parameter.
Parameter categories can be identified by the initial symbol or letter of the code,
and the icon displayed on the electronic controller faceplate:
6. Press the Day - Night button to display the value associated with the
parameter code.
7. Use the Alarm Mute (up) and Light (down) buttons to increase or decrease
the value of the parameter.
8. Press the Day- Night button to temporarily save the new value. The display
shows the parameter code.
Note: If no buttons are pressed for 60 seconds or the power is disconnected
before the temporarily saved values are permanently saved, the temporarily
saved values will be cancelled and the previous setting will be restored.
9. If necessary, repeat steps 5 to 9 to change other parameters as required.
10. Press and hold the Day - Night button for 3 seconds to permanently save the
parameters and exit the parameter menu.
Category Initial Icon
Probe parameters / -
Control parameters r -
Compressor parameters c
Defrost parameters d
Alarm parameters A
Fan parameters F

12 Electronic Controller
Service Manual
SC112N-AC
Parameter list – SC112N-AC program 089
Electronic Controller Parameter Sheet
032 - B600F-3 (CO2) #N/A Revision No. 3.0
Application SC112A-AC
Controller Type ECOBox EVO
Controller Model & Revision PZHBC0H00VK (Rev 1.422)
SKOPE Part Number ELZ10900
Setting Unit Access Description of Parameter
SET0 Level Min Max
Probe Parameters
PS
22 -F0 200
/2 4 -C115
/4
1-C13
/5 0 -C01
/6
0-C01
/8 0.0 °C C 0.0 99.0
/9
0.0 °C C -40.0 /A
/A 199 °C C /9 /b
/b
199 °C C /A 199.0
/E 1 -C050
/C1
3.5 °C C -50.0 50.0
/C2 0.0 °C C -50.0 50.0
Control Parameters
St
3.0 °C C r1 r2
rd 3.0 °C C 0.0 19.0
r1
0.0 °C C -50.0 r2
r2 4.0 °C C r1 150
r4
2.0 °C C -50.0 50.0
r5 3.0 °C C 0.0 19.0
r6
4hrs C 090
r7 8 hrs C 190
CCt 2.0 °C C 0.1 20.0
CCd
30 mins C 0 199
Pt 127 °C C 0.1 127
Pd
12 hrs C 0 250
r9 0 hrs C 024
r10
0hrs C 024
Compressor Parameters
c0
2mins C 0 100
c1 6 mins C 0 100
c2
5mins C 0 100
c3 0 mins C 0 100
c4
15 mins C 0 100
c5 0 -C01
Defrost Parameters
d0
1-C03
dI 3 hrs C 0 199
1dI
1-C01
dt 6 °C C -50.0 130
dP
60 mins C 1 199
d4 0 -C01
d5
0mins C 0 199
d6 1 -C01
dd
3mins C 015
d8 1 hrs C 015
d9
0-C01
d/ - °C C --
d10
-20 °C C -50.0 127.0
d11 127 °C C -50.0 127.0
d12
30 mins C A10 199
Defrost probe reading (read only)
Enabling defrost condition: Control probe threshold
On demand defrost Start Temperature (when d0 = 2 or 3)
No Downward Tendency Defrost - Start Delay
Defrost delay on power-up (when d4=1)
Display during defrost (0 = "dF", 1 = Temperature at start of defrost)
Dripping time (compressor and fans stopped after defrost)
Bypass High and Low temperature alarms (AH,AL) after defrost
Defrost priority over compressor protectors
Defrost start interval time
Run defrost interval timer only when compressor running
Defrost Termination temperature
Maximum defrost duration
Run defrost on power on
Disable mains voltage protection
Type of defrost
Inhibit Night Mode after pull-down ends
Lights ON-Delay after entering day mode
Compressor start delay on power-up
Minimum time between consecutive compressor starts
Minimum compressor off time
Cold Climate Protection Mode Delay
Pull-down Mode - Activation temperature
Pull-down Mode - Maximum Duration
Minimum compressor on time
Compressor on time with duty setting
Night differential
Night Mode Delay (time period with no door openings)
Night Mode Timeout (time period in night mode)
Cold Climate Protection Temperature Delta
Set point
DAY differential
Minimum set point value
Maximum set point value
Night Mode set point delta
036
Full List
SET0
CPS1014-036-SET0
Password
5-Mar-2021
Parameter
Range
Last Revised on:
Probe measurement stability
Select probe displayed
Select °C/°F (0 = °C, 1 = °F)
Disable decimal point
Display Offset (Only if /E > 0)
Minimum Display value (Only if /E > 0)
Maximum Display Value (Only if /E > 0)
Visualization Error Threshold (Only if /E > 0)
Display Filtering Coefficient
Probe 1 off set
Probe 2 off set
Page 1 of 2

13
SC112N-AC
Electronic Controller
Service Manual

14 Replacement Procedures
Service Manual
SC112N-AC
4 Replacement Procedures
Shelves
Adjusting the
Shelves
The fridge is supplied with three wire shelves which may be positioned at
different heights to suit various products. Each shelf is held in place with four
shelf clips which engage in the corner shelf support strips.
Procedure 2: To adjust the cabinet shelves
1. Remove the shelves from the fridge.
2. Remove the shelf clips from the four shelf support strips at each corner of the
fridge interior.
3. Securely engage a shelf clip in each of the shelf support strips at the required
height.
4. Sit the shelves onto the shelf support clips.
Shelf clip
Shelf support strip
Shelf
Figure 3: Shelf detail

15
SC112N-AC
Replacement Procedures
Service Manual
Lights
The fridge is lit by four interior pillar lights, four top sign lights and two bottom
sign lights. All lights are powered by a 12Vdc LED power supply located
within the refrigeration system (see page 21). If one or several individual
light/s fail on a light strip, the remaining lights will still receive power and
should work. If an LED strip is damaged (and the circuit is broken) no lights
will go (including the sign lights). If all the lights are off, check operation via
the light switch on the electronic controller (see page 9) before replacing the
LED strip lighting.
Interior lights The cabinet interior is lit by four vertical corner pillar LED lights. Each corner
pillar light is made up of two LED strip lights (see page 36 for spare parts).
Procedure 3: To replace a single LED interior light strip
1. Disconnect the fridge from the mains power supply by unplugging it from the
wall socket.
2. Remove the shelves from the fridge.
3. Access the fridge interior
via the appropriate door
and unclip the diffuser to
expose the failed LED light
strip.
4. Unplug the failed LED strip
and remove it by
unscrewing it from the
pillar.
5. Fit the new light and plug it into the circuit.
6. Refit the diffuser and the shelves.
7. Test the cabinet for correct operation.

16 Replacement Procedures
Service Manual
SC112N-AC
Top Sign
Lights
The fridge has four lit top signs, one on each side of the fridge. Each sign is
lit by one LED strip light (see page 36 for spare parts).
Bottom Sign
Lights
The fridge has two bottom lit signs, one at the front and one at the back.
Each sign is lit by one LED strip light (see page 36 for spare parts).
Procedure 4: To replace a top sign light
1. Disconnect the fridge from the mains power supply by unplugging it from the
wall socket.
2. Remove the lid from the
fridge by undoing the four
fixing screws (one on each
corner).
3. Slide the top sign panel
and decal from in front of
the failed light strip.
4. Unplug and unclip the LED
strip light, and remove
from the fridge.
5. Fit the new light and plug it into the circuit.
6. Reassemble the cabinet and test for correct operation.
Procedure 5: To replace a bottom sign light
1. Disconnect the fridge from the mains power supply by unplugging it from the
wall socket.
2. Remove the lower bottom
panel by undoing the three
fixing screws.
3. Remove the sign panel
and decal from the sign.

17
SC112N-AC
Replacement Procedures
Service Manual
Doors
The fridge is fitted with a front and a back door. The front door is on the
electronic controller side and is fitted with a door switch to monitor door
openings. The front door should be directed towards the customer. The rear
door is not fitted with a door switch and should face away from the customer.
It is used for restocking product.
Replacing
Door Gasket
The one-piece door gasket clips into the door frame and runs around the
perimeter of the door. You can remove the gasket by peeling it from the door
frame, starting at a corner.
If the gasket is out of shape after you fit it, use a hair dryer to heat and
reshape it.
4. Unplug and unclip the LED
strip light, and remove
from the fridge.
5. Fit the new light and plug it into the circuit.
6. Reassemble the cabinet and test for correct operation.
Procedure 5: To replace a bottom sign light (continued)
Figure 4: Door gasket

18 Replacement Procedures
Service Manual
SC112N-AC
Removing and
Fitting Doors
For ease of servicing the doors can be removed from the fridge.
Adjusting
Door Tension
Each glass door has an internal torsion bar, pre-tensioned at the factory, that
lets the door self-close. If necessary, you can adjust the torsion by rotating
the capstan mounted at the bottom of the door.
Procedure 6: To remove a door
1. Disconnect the fridge from the mains power supply by unplugging it from the
wall socket.
2. Detach the top hinge from
the cabinet by opening the
door and undoing the two
fixing screws.
3. Lift the door up and off the cabinet.
Procedure 7: To refit a door
1. Disconnect the fridge from the mains power supply by unplugging it from the
wall socket.
2. Use a flat hex spanner or
strong 2 mm steel pin to
rotate the capstan about
half a turn in the direction
the door closes.
3. While holding the tension
with the spanner, slot the
capstan into the hole on
the bottom of the door
opening and lock in place.
4. Reattach the top hinge and fix in place with two fixing screws.
5. Check the tension.
Procedure 8: To adjust the door tension
1. Disconnect the fridge from the mains power supply by unplugging it from the
wall socket.
2. Remove the door from the cabinet (see Procedure 6).
3. Refit the door to the cabinet (see Procedure 7), adjusting the tension via the
capstan as necessary.

19
SC112N-AC
Replacement Procedures
Service Manual
Refrigeration System
Before
Servicing
Overview
Ensure you have read and understood this manual before starting any
servicing.
Important
• SKOPE hydrocarbon refrigeration systems must only be serviced by
appropriately skilled and qualified refrigeration mechanics.
• Servicing a sealed refrigeration system must occur at a hydrocarbon
workshop or service area with dedicated hydrocarbon equipment and
personal protective equipment (PPE).
• All local hydrocarbon storage and handling regulations and procedures
must be followed at all times.
Ensure all electronic controller alarms diagnostics and refrigeration system
diagnostics are performed to confirm a refrigeration system fault is present.
Check all components including the electronic controller and electrical
systems.
Ensure your work area is well ventilated.
Safety hazards
The main hydrocarbon safety hazards are:
• Flammability
• Venting of hydrocarbon and compressor oil
• Asphyxiation
Refrigerant identification
Correctly identifying the refrigerant is critical to maintain safety and the
correct functioning of the cabinet.
• The cabinet rating label (located in the upper inside of the cabinet) states
the refrigerant type.
• Warning labels are fitted to hydrocarbon refrigeration cabinets to
indicate the use of hydrocarbon refrigerant.
Personal protective equipment (PPE)
Correctly wear or use all PPE required by local regulations and procedures
during servicing.
Service equipment
Only use dedicated hydrocarbon service equipment which is hydrocarbon-
compliant. Electrical equipment that could be exposed to the refrigerant
must be intrinsically safe.
In addition to standard tools for accessing and removing parts, specialist
tools are required for completing the refrigeration system service tasks in
this manual:
• Intrinsically safe refrigeration vacuum pump, rated by the manufacturer
as suitable for use with hydrocarbon refrigerant
IMPORTANT
Use only dedicated hydrocarbon SKOPE OEM spare parts.
DO NOT use alternative parts.
For safety compliance, use only SKOPE-supplied components
specified for the appliance.

20 Replacement Procedures
Service Manual
SC112N-AC
• Dedicated hydrocarbon gauge set
• Flammable gas detector to warn if flammable refrigerant is present
• Charging scales, rated by the manufacturer as suitable for use with
hydrocarbon refrigerant, accurate to 1 gram
Leak detector
A leak detector is used to track and locate the source of hydrocarbon gas
leaks. It is:
• recommended for servicing hydrocarbon units on-site.
• required for servicing hydrocarbon units off-site.
Service vehicle
• Must be suitable for transporting flammable gas.
• Vehicle cargo area:
• Must be well ventilated to outside the vehicle only.
• Must have no ignition sources, nor any areas where the gas may
pool.
• Must be able to transport swap units.
• Should carry minimum SKOPE hydrocarbon service parts.
On-site Work The service technician must have required knowledge, skills, qualifications,
and tools before beginning any on-site work on the refrigeration sealed
system.
Minimum knowledge and skills
• Qualifications and certifications required by local/state regulatory bodies
to service hydrocarbon refrigeration systems
• Safe working practices, including a safe working environment at all
times
Minimum tools and equipment
• Safety signs and/or barrier – suitable to create a safe work zone 1.5 m
around the cabinet
• Hydrocarbon gas detector
• Dedicated hydrocarbon gauge set
• Bullet valves/line piercing valves suitable for a 6 mm tube
Off-site Work Hydrocarbon workshop
The following tools and equipment are required in the hydrocarbon
workshop:
• Dedicated area for hazardous work – suitable for servicing and
releasing flammable hydrocarbon refrigerant
• Hydrocarbon leak detector
• Refrigeration gauge set – suitable for flammable hydrocarbon
refrigerant
• Dry nitrogen – suitable for purging and high pressure testing
• Intrinsically safe refrigeration vacuum pump, rated by the manufacturer
as suitable for use with hydrocarbon refrigerant
• Charging scales, rated by the manufacturer as suitable for use with
hydrocarbon refrigerant, accurate to 1 gram
• Hydrocarbon refrigerant supply cylinder
