TME650/1000N-3C
SKOPE Top Mount Chiller
Hydrocarbon
Service Manual MAN80216 Rev. 1.5 Jan. 2023

TME650/1000N-3C
SKOPE Top Mount Chiller
Hydrocarbon
Service Manual
MAN80216
Rev. 1.5 Jan. 2023
© 2019 SKOPE Industries Limited. All rights reserved.
SKOPE Industries Limited reserve the right to alter specifications without notice.
is a registered trademark of SKOPE Industries Limited.
SKOPE INDUSTRIES LIMITED
Head Office
PO Box 1091, Christchurch
New Zealand
A.B.N. 73 374 418 306
AU: 1800 121 535
NZ: 0800 947 5673
E-mail: [email protected]
Website: www.skope.com
Trademark Infringement
The SKOPE trademark on this product is infringed if the owner, for the time being, does
any of the following:
• Applies the trade mark to the product after its state, condition, get-up or packaging
has been altered in any manner
• Alters, removes (including part removal) or obliterates (including part obliteration) the
trade mark on the product
• Applies any other trade mark to the product
• Adds to the product any written material that is likely to damage the reputation of the
trade mark
Notice of the above contractual obligations passes to:
• Successors or assignees of the buyer
• Future owners of the product

SKOPE TME650/1000N-3C
Service Manual iii
Contents
1 Servicing Hydrocarbon
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Specifications
Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3 Installation
Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Ventilation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Shelf Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Repositioning a Shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Electronic Controller
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SCS Connect Field App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
SCS Connect Track App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Controller Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Buttons and Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Service Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
SCS Connect Field App and Track App. . . . . . . . . . . . . . . . . . . . . . .10
Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
App Categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Faults and Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
5 Wiring
Model: TME650/1000N-3C Series . . . . . . . . . . . . . . . . . . . . . . . .16
6 Replacement Procedures
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Sign Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Alignment Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Height Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Replacing the Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Removing and Refitting the Door . . . . . . . . . . . . . . . . . . . . . . . . .20
Adjusting Door Tension. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Replacing the Torsion Bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Hinge Reversal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Refrigeration System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Before Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
On-site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Off-site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Refrigeration Cassette Assembly . . . . . . . . . . . . . . . . . . . . . . . . .25
Not Cooling Fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Removing the Cassette. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Replacing the Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Cassette Electrics Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . .28
Cassette Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Condenser Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Evaporator Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Compressor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Compressor Electrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Refrigeration Cassette. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Cassette Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

SKOPE TME650/1000N-3C
Service Manual
iv
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Controller Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
QC Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Replacing the Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Door Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Control Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Evaporator Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Condenser Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Ambient Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Condenser Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7 Spare Parts
Cabinet Assembly – TME650N-3C . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Cabinet Assembly – TME1000N-3C . . . . . . . . . . . . . . . . . . . . . . . . . 42
Glass Door Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Sign Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Cassette Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8 Troubleshooting
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Cabinet and Refrigeration Cassette . . . . . . . . . . . . . . . . . . . . . . . . . 48
Diagnostic Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
On-site Work Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

5
SKOPE TME650/1000N-3C
Servicing Hydrocarbon
Service Manual
1 Servicing Hydrocarbon
Overview
This cooler uses hydrocarbon (HC) R290 propane as its refrigerant. R290 is a natural
refrigerant that has a very low environmental impact.
Special service requirements are needed as hydrocarbon is a flammable refrigerant.
Safety hazards
The main hydrocarbon safety hazards are:
• Flammability
• Venting of R290 and compressor oil
• Asphyxiation
SKOPE does not recommend performing hazardous activities on the refrigeration system.
See “Refrigeration Cassette” on page 33 for more information including examples of
hazardous activities.

6Specifications
Service Manual
SKOPE TME650/1000N-3C
2 Specifications
Models
This service manual is applicable to the SKOPE TME top mount chillers detailed in the table
below. Refer to the relevant product specification sheet (available on the SKOPE website:
www.skope.com) for specifications.
Table 1: Model specifications
Series Model SKOPE ID
TME650N-3 TME650N-3C PH65BYN
TME1000N-3 TME1000N-3C PH10BYN

7
SKOPE TME650/1000N-3C
Installation
Service Manual
3 Installation
Installation Guidelines
When installing this cabinet, ensure the installation guidelines below are considered and met.
Ventilation Requirements
This cabinet must have the following ventilation clearances at all times.
Ventilation
Ensure all ventilation
requirements below are
met.
Door Opening
Allow adequate space for
the door/s to open and
close properly.
Sunlight
Do not install the fridge in
direct sunlight.
Uneven Surface
Do not install the fridge on
an uneven surface.
Surface
The installation surface
must be capable of
supporting the loaded
cabinet.
Power Supply
Do not overload the power
supply.
Blocking Ventilation
Do not store boxes or items in
front or on top of the fridge.
Climate Class
The fridge must be installed in
an environment within its
climate class.
The climate class is stated on
the cabinet rating label inside
the fridge.
No below clearance required
Min. 300 mm above
No side
clearance
required
No behind
clearance
required

8Installation
Service Manual
SKOPE TME650/1000N-3C
Shelves
The cabinet is fitted with five layers of wire shelves which may be positioned at different heights
to suit various products.
Shelf Clips Each wire shelf is held in place with four shelf clips, which clip in the shelf support strips and
slide up and down to the required shelf position.
The support strips are numbered to help place the shelf clips. You can see the numbers in the
bottom left hand corner of the shelf clip.
Repositioning
a Shelf
Procedure 1: To fit a shelf clip
The shelf clip twists onto the shelf support strip.
1. Position the shelf clip with the flat side up
against the shelf support strip and the two
prongs pointing up.
2. Twist the top of the clip anticlockwise onto the
shelf support strip until it locks in place.
Procedure 2: To slide a shelf clip up and down
1. Pull the shelf clip tab up and slide the shelf clip
up or down as required.
2. Once in position, ensure the shelf clip is locked
into place.
Procedure 3: To remove a shelf clip
1. Pull the shelf clip tab up.
2. Twist the top of the clip clockwise off the shelf support strip.
Shelf
support
strip
Prongs
Shelf clip
Shelf clip
Tab
Procedure 4: To reposition a standard shelf
1. Unload the shelf and remove it from the cabinet.
2. Slide each shelf clip to the new position in the shelf support strips.
3. Replace the shelf back in the cabinet, and sit it on the shelf clips.

9
SKOPE TME650/1000N-3C
Electronic Controller
Service Manual
4 Electronic Controller
Overview
The cabinet is fitted with an SCS Connect electronic controller. The controller is located above
the door/s and is visible from the outside of the cabient.
Servicing can be performed via the controller faceplate, or the SCS Connect Field app.
Apps
SCS Connect
Field App
The SCS Connect Field app is designed for service technicians, and provides access to the
controller from mobile devices with Bluetooth capability. The app provides information on data
logging, alarm notification and diagnostic control.
See “SCS Connect Field App and Track App” on page 10 for information on setting up and
using the app.
SCS Connect
Track App
The SCS Connect Track app is used to upload data from chillers fitted with an SCS Connect
electronic controller.
Controller Faceplate
Buttons and
Display
The controller faceplate includes the front display panel and interface buttons.
12 3 4 5
8 7
11
10
96
Table 2: Controller faceplate
No. Description
1Night Mode: Indicator. On during cooler night mode.
2Display: Indicator. Digital display of cabinet air temperature or messages. The temperature is what the sensor
inside the cooler detects, and not necessarily the product temperature. However, they may be very close
depending on how the controller is set to sense temperature.
3Light Switch - Night Mode (back/abort): Button. Press to switch the lights on or off. Press and hold to switch
cooler between day and night mode. Used during programming.
4Up: Button. Used for programming.
5Bluetooth: Indicator. On when ready to connect to a device. Flashing when connected to a device.
6Defrost Cycle (next/enter): Button. Press and hold to initiate manual defrost. Used during programming.
7Down: Button. Used for programming.
8Fault - Alarm: Indicator. On during fault or alarm. Note: Alarm message is also shown on the display during
alarm.
9Compressor: Indicator. On when the compressor is running.
10 Defrost Mode: Indicator. On during defrost cycle.
11 Fan: Indicator. ON when evaporator fan running.

10 Electronic Controller
Service Manual
SKOPE TME650/1000N-3C
Service Mode Service mode can be accessed and used via the SCS Connect Field app (see “SCS Connect
Field App and Track App” on page 10), or the controller faceplate (see below).
Note: A 9 digit pin code is required to access service mode via the controller buttons. Contact
your User Manager to receive your activation code.
There are 5 main service mode categories when accessing and using service mode via the
controller faceplate:
Parameters
Provides access to and editing of individual controller parameters.
It is not recommended that parameters are changed unless absolutely necessary. If incorrect
parameter settings are suspected, reload the complete parameter set.
Reset
Returns the controller back to factory settings. Parameter set must be reloaded after
performing a reset.
Manual test
Allows inspection of input values from sensors, and check the effects of output adjustments to
peripherals, and to run preset test routines.
Statistics
Displays logged values and event counts to assist with fine tuning and diagnostics.
About
Lists the properties of the refrigeration system and the controller, including cooler model
codes, firmware, hardware and software versions.
SCS Connect Field App and Track App
Connecting Follow the procedures below to install and set up the app, and connect to a controller.
Note: The SCS Connect Field app and Track app are separate from the SKOPE-connect app.
Procedure 5: To enable and use service mode via the controller faceplate
1. Press and hold the up and down buttons simultaneously until prompted to enter the 9 digit pin
code.
2. Enter service mode pin code.
3. Use the up, down, back/abort and next/enter buttons to navigate to the desired category.

11
SKOPE TME650/1000N-3C
Electronic Controller
Service Manual
App
Categories
Various options are available in the app menu to provide information about the connected
controller and its cooler. Available menu option depend on the user’s access level.
Home screen
The home screen shows a graphic representation of the current state of the cooler being
controlled.
Procedure 6: To install the SCS Connect Field app
1. Download and install the Connect Field app or Track app from Google Play or Apple Store (search
for “scs wellington”).
2. When you first run the app, you will be requested to enter an activation code. Contact your Service
Manager or SKOPE to receive your activation code (you must be connected to the internet at the
time of activation).
3. Your activation code is unique to you, and determines your personal access level for the app.
NEVER share it with anyone else. The same code will give you access to all SCS apps you are
authorised to use.
4. Once activation is complete, you must define a 4-digit PIN code. This can be any code unique to
you. Each time you start the app, you will be required to enter this same PIN code. This is to
prevent other people accessing the app from unlocked phones.
5. You can see which databases you are activated for from the “Settings” screen. You can be activated
on more than one database at the same time. Simply select ACTIVATE ANOTHER DATABASE,
and enter the new database’s unique activation code, as in Step 2.
Procedure 7: To connect to a controller
1. Check that the Bluetooth logo on the top right of the controller faceplate is lit, indicating that the
controller is ready to connect to a device.
1. Note: A flashing Bluetooth logo indicates that the controller is currently connected to a device.
2. Open the SCS Connect Field app.
3. Select a controller to connect to from the list of visible controllers.
4. Note: This list is filtered by your activation permissions, so devices you are not authorised to
connect to will not be displayed.
5. Select “connect” to connect to the controller.
6. Check that the Bluetooth logo on the top right of the controller faceplate is flashing, indicating that
the controller is connected.

12 Electronic Controller
Service Manual
SKOPE TME650/1000N-3C
Output control
Provides control of the controller input sensors and switches, and output relays.
Edit parameters
Provides access and editing of individual controller parameters.
Note: Parameter changes must be recorded on warranty/job card.
It is not recommended that parameters are changed unless absolutely necessary. If incorrect
parameter settings are suspected, reload the complete parameter set. Note: Updated
parameters are not applied until DISCONNECT has been selected from the menu (after
loading the new parameter set).
Load parameter file
Allows reloading of the default parameter set, or changing to a new parameter set. See
“Replacing the Controller” on page 35 for instructions. Note: Updated parameters are not
applied until DISCONNECT has been selected from the menu (after loading new parameter
set).
Statistics
Information from the past seven days on cooler activity including temperatures, door openings
and alarms.
SCS info
Controller version and cooler asset information.
SCS setup
Add or change SCS info (see above).
Disconnect
Disconnect from currently connected controller.
Settings
Change app general settings.
Faults and Alarms
The following tables explain faults and alarms that the electronic controller may log and
display.
If a fault occurs, the fault - alarm indicator is lit on the controller faceplate, but no message is
displayed. Faults do not affect product temperature, and require no action from the shop
owner.
Alarms are logged and the alarm message is displayed on the controller faceplate. Alarms may
result in abnormal product temperature.
Some faults and alarms can be cleared by the shop owner, and others can only be cleared by
a service technician.
If the cabinet is connected to the power supply and has warm product, check the SCS Connect
Field app for an active fault or alarm, and investigate. If the cabinet does not have an active
fault or alarm, check the app statistics to determine if and when the controller signalled a fault
or alarm.
Refer to the tables below for fault and alarm descriptions and possible causes and actions. The
service tech type column refers to the service technician skill level required to complete a task.
Refer to the SKOPE HC Service Policy for service tech type details.

13
SKOPE TME650/1000N-3C
Electronic Controller
Service Manual
Table 3: Faults
Description Service tech
type
Possible root cause
Door left open
The door has been open for several minutes.
1, 2, 3, 4 • Door not self-closing (torsion fault)
• Door switch / circuit
• Controller
Excessive door open counts
Over-voltage protection
The maximum allowable mains supply voltage has been exceeded. The
cabinet has temporarily shut down to prevent damage and will restart
once the supply voltage decreases.
1, 2, 3, 4 Should be a one off; if continues:
• Line voltage / rural
• Voltage setting parameter
• Controller
Under-voltage protection
The mains supply voltage has dropped below the minimum allowable
level. The cabinet has temporarily shut down to prevent damage and will
restart once the supply voltage increases.
1, 2, 3, 4 Should be a one off; if continues:
• Power supply overloaded / multi-box
• Line voltage / rural
• Voltage setting parameter
• Controller
High condensing temperature protection
The system was operating at an elevated temperature and has
temporarily shut down to prevent damage. Extended operation in this
condition may result in ALARM 15, increased energy consumption and a
reduction in cabinet life. This alarm may be caused by very high ambient
temperature.
2, 3, 4 NO swap cassette required
• Condenser not clean
• Poor installation / ventilation
• Condenser fan motor / blade
• Controller
Excessive compressor cycling protection
The system has been turning on and off too frequently.
2, 3, 4 Take spare cassette in case refrigeration system fault.
• Condenser blocked
• Poor installation / ventilation
• Cabinet / cassette gasket seals leaking
• Door not self -losing / gasket leaking
• Product; hot / blocking cabinet airflow
• Overloaded from excess door openings / ambient
• Fan motor / blade (condenser / evap)
• Controller
• Compressor / gas leak = SWAP cassette
Table 4: Alarms
Code Description Service tech
type
Possible root cause
dor Door left open
The door has been open for several minutes. Will revert to
door left open FAULT after 10 minutes (see Table 3,
“Faults”).
1, 2, 3, 4 • Door not self-closing (torsion fault)
• Door switch / circuit
• Controller
8Estimated product temperature below allowable range
The estimated product temperature has been below the
allowable range for longer than the permissible time.
Potential causes are: an empty or partially filled cabinet, or
low ambient temperature.
1, 2, 3, 4 • Low ambient
• App settings
• Controller
9Estimated product temperature above allowable range
The estimated product temperature has been above the
allowable range for longer than the permissible time.
Potential causes are: excessive door openings, door being
left open, or warm product loaded into cabinet.
2, 3, 4 NO Swap cassette required to be taken (but may be required
as fault could still be with sealed refrigeration system)
• Condenser blocked
• Poor installation / ventilation
• Frozen blocked evaporator coil
• Cassette gasket leaking (to cabinet seal / lid seal)
• Door leaking air (bad gasket / door not self-closing)
• Product hot, or blocking cabinet airflow
• Overloaded from excess door openings / ambient
• Fan motor / blade (condenser / evaporator)
• App settings
• Controller
• Compressor / gas leak = arrange SWAP cassette

14 Electronic Controller
Service Manual
SKOPE TME650/1000N-3C
15 Excessive condensing temperature protection
The system was operating at an excessive temperature
and has shut down to prevent permanent damage. This
alarm may occur due to very high ambient temperature.
2, 3, 4 NO swap cassette required
• Condenser not clean
• Poor installation / ventilation
• Condenser fan motor / blade
• Controller
17 Control probe failure
A critical system sensor has failed and the cabinet can no
longer operate.
2, 3, 4 NO swap cassette required
• Control probe / circuit
• Controller
18 Electrical over-current protection activated
The compressor was drawing too much current and has
shut down to prevent permanent damage.
2, 3, 4 Take spare cassette in case refrigeration system fault.
• Condenser blocked
• Poor installation / ventilation
• Cabinet / cassette gasket seals leaking
• Door not self-closing / gasket leaking
• Product hot, or blocking cabinet airflow
• Overloaded from excess door openings / ambient
• Fan motor / blade (condenser / evaporator)
• Controller
• Compressor / gas leak = SWAP cassette
19 Failed to reach set temperature
The refrigeration system has been operating continuously
for a long period without reaching the set temperature.
2, 3, 4 Take spare cassette in case refrigeration system fault.
• Condenser blocked
• Poor installation / ventilation
• Frozen blocked evaporator coil
• Cabinet seal leaking / door / cassette
• Product hot, or blocking cabinet airflow
• Overloaded from excess door openings / ambient
• Fan motor / blade (condenser / evaporator)
• Controller
• Compressor / gas leak = SWAP cassette
20 Over cooling product
The internal temperature is too low. The system has
temporarily shut down until the temperature has returned to
normal. This can occur if the set temperature has been
raised by a large amount.
1, 2, 3, 4 Confirm if really too cold; change parameters accordingly.
22 Evaporator fan over-current protection
The current supplied to the evaporator fan motor is too
high.
2, 3, 4 NO swap cassette required
• Faulty fan motor
• Fan blade fault (imbalance / debris / blockage)
• Controller
23 Condenser fan over-current protection
The current supplied to the condenser fan motor is too
high.
2, 3, 4 NO swap cassette required
• Faulty fan motor
• Fan blade fault (imbalance / debris / blockage)
• Controller
24 Controller communication error
Controller has lost communication channels.
1, 2, 3, 4 • App
• Controller / circuit
25 Controller update failed
Controller update could not be completed.
1, 2, 3, 4 • App
• Controller / circuit
26 Controller hardware failure
Controller hardware has failed.
1, 2, 3, 4 • App
• Controller / circuit
27 Probe failure
A non-critical system probe has failed. The cabinet will
continue to operate with partial function but requires
service.
2, 3, 4 NO swap cassette required
• Evaporator probe / connections
• Controller
Table 4: Alarms (continued)
Code Description Service tech
type
Possible root cause

15
SKOPE TME650/1000N-3C
Electronic Controller
Service Manual
28 No downward tendency
The temperature is no longer decreasing.
2, 3, 4 Take spare cassette in case refrigeration system fault.
• Condenser blocked
• Poor installation / ventilation
• Cabinet / cassette gasket seals leaking
• Door not self-closing / gasket leaking
• Product hot, or blocking cabinet airflow
• Overloaded from excess door openings / ambient
• Fan motor / blade (condenser / evaporator)
• Controller
• Compressor / gas leak = SWAP cassette
29 Compressor cutting out
The compressor cut out on its internal protection or
pressure switch.
2, 3, 4 Take spare cassette in case refrigeration system fault.
• Condenser blocked
• Poor installation / ventilation
• Cabinet seal leaking / door / cassette
• Product hot, or blocking cabinet airflow
• Overloaded from excess door openings / ambient
• Fan motor / blade (condenser / evaporator)
• Controller
• Compressor / gas leak = SWAP cassette
30 Excessive automatic defrosting
The system is automatically defrosting too frequently.
2, 3, 4 Take spare cassette in case refrigeration system fault.
• Door not self-closing / gasket leaking
• Evaporator probe
• Evaporator motor / fan
• Controller
• Compressor / gas leak = SWAP cassette
31 Compressor stalling
The compressor is stalling on start up.
2, 3, 4 Take spare cassette in case refrigeration system fault.
• Condenser blocked
• Poor installation / ventilation
• Cabinet / cassette gasket seals leaking
• Door not self-closing / gasket leaking
• Product hot, or blocking cabinet airflow
• Overloaded from excess door openings / ambient
• Fan motor / blade (condenser / evaporator)
• Controller
• Compressor / gas leak = SWAP cassette
Table 4: Alarms (continued)
Code Description Service tech
type
Possible root cause

16 Wiring
Service Manual
SKOPE TME650/1000N-3C
5 Wiring
Model: TME650/1000N-3C Series
BU
S18-2 P18-2
S24-4 P24-4
P6-1 S6-1
P3-1 S3-1
P3-4 S3-4
P6-4 S6-4
BN BU
BU
Compressor
RS
C
L
N
Start
Relay
Compressor
Overload
S24-3 P24-3
BN
BU
BN
S21-4 P21-4
S21-2 P21-2
Condenser Fan
BN
S18-4 P18-4
Evaporator Fan
BU
BU
BU
S2-1 P2-1
S2-2 P2-2
S2-3 P2-3
S2-5 P2-5
BK
BK
OG
BK
BK
BK
BK
BK
Cabinet
Probe
Evaporator
Probe
BN
L
BU
N
Inlet-L Inlet-N
BN BU
T1-2
GNYE
E
EMC Filter
BU
BN
P17-2 S17-2
S6-2 P6-2
BU
P4-1 S4-1
Pillar elements
WDTL
SCS
Controller
LN
C
R
R
SSR
S1
S2
SSR
Comp.
0V
+
1 2 3
AD5
DI1
0V AD1
DI2
0V AD2
DI3
0V AD3
DI4
5V 0V
AD4
BK
BK
BN BU
P3-2 S3-2
S19-2 P19-2
S19-4 P19-4
BN
BK
T1-1
BK
RD
BN
WH
S4-2 P4-2
BN
BN
P18-1 S18-1
BU
BU
P21-1 S21-1
P19-1 S19-1
BU
BN
WH
WH
RD
Door Switch
WH
WH
RD
Door Switch
BK
BK
Condenser
Probe
P17-1 S17-1
P16-1 S16-1 P16-2 S16-2
P20-2 S20-2
P20-1 S20-1
S23-4
S23-1 S23-3
P22-1 S22-1
BK
BK
P22-2 S22-2
BK
P7-2 S7-2
S2-4 P2-4
RD
BU
BU
WH
P7-1 S7-1
WH
BK
WH
RD
A
mbient
Probe
RDBK
Programming
Port
BN
BN
BK
S5-2 P5-2
BU GNS BN GNS
BK GNS
BK
OG
S15-1 P15-1 S15-2 P15-2
BU
BN
Lighter shaded areas
only present on two
door cabinet.
GNS indicates a Green
sleeve on the wire
LED Power
Supply
N
L
+
-
S25 P25
S5-1 P5-1
LED Lighting
WIRE COLOURS
BK Black BN Brown RD Red OG Orange GN Green BU Blue GY Grey WH White GNYE Green-Yellow Based upon IEC 757 Standard
LEGEND
Internal Unit Junction Box Sockets/Plugs S9/P9 Not Used S19/P19 Evaporator Motor Unit Socket/Plug (White 4-way) Inlet IEC Cabinet Socket/Plug S10/P10 Not Used S20/P20 Condenser Sensor Socket/Plug (Red 2-way) S1/P1 Not Used S11/P11 Not Used T1 Unit Terminals S2/P2 Unit Junction Box to Controller Signal Socket/Plug (6-way) S12/P12 Not Used External Sockets/Plugs S3/P3 Unit Junction Box to Controller Power Socket/Plug (Blue 4-way) S13/P13 Not Used S21/P21 Evaporator Motor Extension Socket/Plug (White 4-way) S4/P4 Heater Wire Unit Socket/Plug (Black 3-way) S14/P14 Not Used S22/P22 Ambient Sensor Socket/Plug (Blue 2-way) S5/P5 Light Unit Socket/Plug (White 3-way) S15/P15 Compressor Unit Socket/Plug (Blue 4-way) S23/P23 Programming/Comms Port Socket (Blue 4-way) S6/P6 Unit Junction Box to Controller Power Socket/Plug 1 (Red 4-way) S16/P16 Evaporator Sensor Socket/Plug (Black 2-way) S24/P24 Compressor Electrics Plug S7/P7 Door Sensor Socket/Plug (White 2-way) S17/P17 Cabinet Sensor Socket/Plug (White 2-way) S25/P25 LED Driver DC Output Socket/Plug (Red 2-way) S8/P8 Not Used S18/P18 Condenser Motor Unit Socket/Plug (Red 4-way) -

17
SKOPE TME650/1000N-3C
Replacement Procedures
Service Manual
6 Replacement Procedures
Lighting
The cooler is fitted with LED modular interior and sign lights. Ensure the light is replaced with
the same light type. Fluorescent or LED tubes cannot be used in place of LED modular lights.
Refer to the table below for replacement light specifications.
The lighting is made up of three components which are replaceable:
• LED modular light
• Light power supply (1 per cabinet)
• Interior wiring loom (1 per door)
Power is supplied to the lights by the power supply (located in the cabinet electrics panel above
the door/s) via the wiring loom/s which run down the sidelight channel.
Lighting components are all non-serviceable items. If a component is faulty, it should be
removed and a SKOPE OEM new replacement component fitted.
Refer to the diagnostics table below to determine which component may be at fault, and the
procedures over the next few pages for component replacement instructions.
Ensure the cabinet is isolated from the power supply before cleaning or removing parts.
IMPORTANT
Replace the light with the same SKOPE OEM part.
DO NOT use alternative LED strip or tube lights, or fluorescent
tubes.
Table 5: Light specifications
Model Interior light Sign light
Description Part No. Description Part No.
TME650N-3C Interior light ELL11771 Sign light ELL11772
TME1000N-3C 2 × interior light ELL11771 Sign light ELL11773
Table 6: Lighting fault diagnostics
Problem Possible cause Repair
No lights working.
Cabinet is dark.
Lights switched off. Switch lights on at electronic controller
faceplate (see page 9), or the app.
Controller is in Energy Saving
mode.
Open the door to bring the controller into
Normal mode.
Controller alarm. Check controller for alarm code.
Plug not connected properly. Check and clean plugs on top of the cabinet.
Light power supply fault. Replace light power supply.
Light component not
working.
Plug not connected properly. Check and clean plug connection in side light
channel, behind the loom cover.
Faulty light. Replace light.
Segment of light not
working. Faulty light. Replace light.

18 Replacement Procedures
Service Manual
SKOPE TME650/1000N-3C
Procedure 8: To replace an interior light component
1. Unplug the chiller from the power supply.
2. Unplug the light, and remove the light from the
plastic casing.
3. Clip the replacement light into place on the
plastic casing, ensuring the male end of the light
is at the top, and plug the light in.
4. Ensure the light is firmly and completely clipped in.
5. Reconnect to the power supply and check for correct operation.
Procedure 9: To replace the LED driver power supply
1. Disconnect the chiller from the power supply.
2. Remove the sign panel.
3. Detach the refrigeration cassette and carefully
push back or remove to allow access to the
cabinet electrics cover.
Cabinet electrics cover

19
SKOPE TME650/1000N-3C
Replacement Procedures
Service Manual
Sign Light The sign is lit by an LED modular light which can be replaced by following the steps below.
4. Unscrew the cabinet electrics cover.
5. Remove the light power supply.
6. Replace the light power supply and reassemble.
Procedure 10: To replace an interior wiring loom
1. Disconnect the chiller from the power supply.
2. Unplug the light from the wire loom.
3. Gain access to the cabinet electrics panel (see procedure above).
4. Move up to the cabinet roof, and unplug the wiring loom from the light power supply, and if
applicable the sign light.
5. Remove the putty from the loom entry point on the cabinet roof, and pull the loom up through the
cabinet ceiling.
6. Refit the new loom and reassemble. Ensure that:
• All plugs are clean, correctly fitted and plugged in.
• The ceiling and roof hole is completely sealed with putty.
Procedure 9: To replace the LED driver power supply (continued)
Light power supply
Procedure 11: To replace the sign light
1. Unplug the cooler from the power supply.
2. Unplug the sign and remove from the cabinet.
3. Remove one end trim by undoing and removing
the top and bottom black end caps.
4. Slide the front sign panel and decal out from the
sign.
5. Unclip and replace the light.
6. Rout the light plug and cable back through behind the reflector and hole at the back of the sign, and
cable tie in place.
7. Reassemble the sign, reconnect to the power supply and check for correct operation.
End trim
End cap
End cap
Sign panel
and decal

20 Replacement Procedures
Service Manual
SKOPE TME650/1000N-3C
Doors
Alignment
Adjustment
If a door is out of alignment, realign it by loosening the top hinge bracket fixing screws, and
move the top of the door as required.
Height
Adjustment
A height adjustment block is fitted below the bottom hinge. As standard, the notched edges on
the bottom of the hinge and the top of the height adjustment block align to set the door to the
correct level. If the door is not at the correct height when at the standard setting, follow the
steps below to adjust the height.
Note: On three door models, the height of the middle door cannot be adjusted.
Replacing the
Gasket
The one-piece door gasket clips into the door frame and runs around the perimeter of the door.
Remove the gasket by peeling it from the door frame, starting at a corner.
If the gasket is out of shape after refitting, use a hair dryer to heat and reshape it.
Removing and
Refitting the
Door
For ease of servicing and to reverse the hinging, the door can be removed from the cabinet.
Refer to image below for door hinging components.
WARNING
For safe door operation the door bottom hinge bracket must
always be fitted with a split pin.
Procedure 12: To adjust the door height
1. Isolate the chiller from the power supply.
2. Loosen the bottom hinge and remove the height
adjustment block.
3. Set the door to the correct height, rotate and refit the height adjustment block to the most
appropriate setting and tighten up the bottom hinge screws.
Bottom hinge
Height adjustment
block
