Skope SC112N-AC User manual

User Manual MAN80260 Rev. 1.1 Jan. 2022
SC112N-AC
Four Glass Sided Chiller
Type: HSC112NA

SC112N-AC
Four Glass Sided Chiller
Type: HSC112NA
User Manual
MAN80260
Rev. 1.1 Jan. 2022
© 2020 SKOPE Industries Limited. All rights reserved.
SKOPE Industries Limited reserves the right to alter specifications without notice.
is a registered trademark of SKOPE Industries Limited.
SKOPE INDUSTRIES LIMITED
Head Office
PO Box 1091, Christchurch
New Zealand
A.B.N. 73 374 418 306
AU: 1800 121 535
NZ: 0800 947 5673
E-mail: [email protected]
Website: www.skope.com
Trademark Infringement
The SKOPE trademark on this product is infringed if the owner, for the time being, does
any of the following:
• Applies the trade mark to the product after its state, condition, get-up or packaging
has been altered in any manner
• Alters, removes (including part removal) or obliterates (including part obliteration) the
trade mark on the product
• Applies any other trade mark to the product
• Adds to the product any written material that is likely to damage the reputation of the
trade mark
Notice of the above contractual obligations passes to:
• Successors or assignees of the buyer
• Future owners of the product

SC112N-AC
User Manual iii
CONTENTS
1 Installation
Safety First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Positioning the Chiller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Climate Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Levelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 Operation
Automatic Start-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Loading Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Door Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Door Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Controller Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Messages and Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3 Maintenance
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Adjusting the Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4Installation
User Manual
SC112N-AC
1 Installation
Safety First Always observe safety precautions when using any electrical appliance.
Read these instructions carefully and retain them for future reference.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not
play with the appliance.
Do not use this appliance for other than its intended use.
Do not insert fingers/foreign objects into any holes.
Only use this appliance with the voltage specified on the cabinet rating
label.
Ensure the appliance has adequate ventilation as this is essential to
economical, high performance.
Be careful not to touch moving parts and hot surfaces.
For your own safety and that of others, ensure that all electrical work is
done by authorised personnel.
If the power supply flexible cord becomes damaged, it must be replaced
by an authorised service agent or similarly qualified person in order to
avoid a hazard.
Ensure all necessary safety precautions are observed during installation
or removal of the refrigeration unit.
The appliance is not designed to be stable while in motion. Use extreme
caution when moving or transporting it.
Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
If the cabinet is to be scrapped, ensure the cabinet is unplugged from
the power supply and cut off the mains flex close to the back of the
cabinet. Be mindful of the risk of animals or children becoming trapped
in the appliance – either remove or secure doors if necessary.
Refrigerant must be removed by a qualified service person and the
cabinet recycled/disposed of in accordance with local regulations.
WARNING
Always disconnect the chiller from the mains power supply
before cleaning or maintenance.
CAUTION
Never overload the power supply, which could damage the
chiller and product. See the rating label inside the cabinet for
the safe power supply and current draw.

5
SC112N-AC
Installation
User Manual
Positioning the Chiller
Climate Class The chiller is designed to operate within a climate class 3 environment (25°C
@ 60% relative humidity).
Location Select a suitable location for the chiller away from direct sunlight and heat
sources, e.g. radiators, baseboard heaters, cooking appliances.
This chiller is intended to sit on a raised benchtop. Ensure the bench will
support the chiller which could weigh up to 120kg when fully loaded.
The front door (electronic controller side) is fitted with a door switch. Position
the chiller so that the front door opens to the customer side of the benchtop.
This enables the door switch to detect customer door openings.
Ventilation Ensure adequate ventilation is provided around the chiller. The chiller is
designed for free-standing installation only. Do not place the chiller in a
recess or another cabinet.
Installation
Guidelines
When installing the chiller:
Remove all packaging material from the inside and outside the chiller.
Ensure the chiller is positioned on a level surface so the doors shut and
seal correctly, and to prevent the condensate tray from overflowing.
Ensure the installation surface is capable of supporting the fully loaded
chiller.
Allow adequate space for door opening. The self-closing doors have
pre-tensioned internal torsion bars.
Do not overload the power supply (see the rating label inside the
cabinet for power supply and current draw information).
Position the front door (electronic controller side) towards the customer.
Power Cord The chiller is fitted with a 2 metre flexible power cord with a 3-pin plug, which
exits the front of the refrigeration system.
Levelling Adjust the four stabiliser feet (see image below) to ensure the chiller sits on
a level surface so that both doors shut and seal correctly. Turn the stabiliser
foot clockwise to raise and anti-clockwise to lower the cabinet.
Front door
Electronic
controller
IMPORTANT
Ensure the controller faces the customer side of the benchtop.
Stabiliser foot

6Operation
User Manual
SC112N-AC
2 Operation
Automatic Start-up
After the chiller has been positioned in a suitable place, plug it in and check
the following activity.
Loading Product
Let the chiller run for 30 minutes before loading it with product the first time.
When loading the cabinet shelves with product:
Allow adequate air space around each item to ensure even cooling and
efficient operation of the chiller.
Remove some product if the shelves are flexing. The maximum loading
for each shelf is 25kg.
Do not let anything overhang the shelves, this might stop the doors from
shutting or even break something.
Door Lock
The chiller is fitted with security door locks. Use the supplied keys to lock
and unlock the door as necessary.
Item Activity
Condenser fan The condenser fan starts immediately and can be heard.
Evaporator fan
The evaporator fan will start after a few seconds. To verify,
check that the fan light is flashing on the electronic
controller. The evaporator fan turns off when the front door
(electronic controller) is opened and turns on again when
the front door is closed.
Sign and interior LED
lighting
The lights that illuminate the sign and cabinet interior will
come on when the chiller is turned on.
Compressor
The compressor will start after a few minutes. To verify,
check that the compressor light is flashing on the electronic
controller. The compressor turns off when the product
temperature reaches +2°C and turns on when the product
temperature rises to +5°C.
Front panel
Door lock keyhole

7
SC112N-AC
Operation
User Manual
Electronic Controller
Introduction The electronic controller controls and displays the chiller temperature, and
signals temperature alarms. It uses temperature probes and a door switch
to collect data and runs the chiller accordingly. The electronic controller
automatically switches the chiller between ‘Day’ and ‘Night’ modes
depending on chiller usage. The electronic controller is pre-programmed
and requires no initial setup or additional programming. SKOPE does not
recommend that the settings be changed unless it is absolutely necessary.
To ensure efficient operation, the electronic controller forces a defrost cycle
when required.
Faceplate Because the electronic controller plays such an important role, it’s helpful to
know the parts of the faceplate you may use.
Door Switch The front door (electronic controller side) is fitted with a door switch which
tells the electronic controller when the door is opened and closed. If the door
is opened for an extended period an alarm will sound. Press the alarm mute
button on the electronic controller to mute the alarm.
1
2
6
3
5
4
7
8
9
No. Item Description
1Alarm Mute (up): Mutes the audible alarm buzzer.
2Day - Night: Switches the chiller between ‘Day’ and ‘Night’ modes.
3Light (down): Switches the cabinet lights on and off.
4Compressor: ON when the compressor and condenser fan starts.
Flashes when activation of the compressor is temporarily delayed.
5Fan: ON when the internal cabinet fans are activated. Flashes
when activation of the fans is temporarily delayed.
6Defrost: ON when the defrost is activated. Flashes when the
defrost is temporarily delayed due to other procedures in progress.
7AUX: n.a.
8Clock: n.a.
9Alarm: ON when an alarm is signalled.

8Operation
User Manual
SC112N-AC
Controller
Operation
The electronic controller will automatically switch the chiller between ‘Day’
and ‘Night’ modes depending on use. If the front door (electronic controller
side) is not opened for four hours, the chiller will automatically enter Night
mode and the sign and interior lights will switch off. To switch the chiller
between Day and Night modes manually, press and hold the Day - Night
button on the electronic controller faceplate. The chiller can also be bought
into Day mode by holding the front door (electronic controller side) open for
ten seconds.
Lights In Day mode the sign and interior lights are on. In Night mode the sign and
interior lights are off. Press the Light (down) button on the electronic
controller faceplate to manually switch the sign and interior lights on and off.

9
SC112N-AC
Operation
User Manual
Messages and Alarms
The following table explains messages and alarms that the electronic controller displays. If a
warning or alarm persists, contact a service agent.
Messages
Alarms
Display Description
The chiller is cooling warm product.
The chiller is in Day mode and the electronic controller displays the chiller temperature.
The chiller is in Cold Climate Protection (CCP) mode. The chiller enters CCP mode if the ambient
temperature in the room gets too cold. The lights remain on and cannot be switched off.
Defrost cycle in progress.
The chiller is in economical Night mode. In Night mode the temperature inside the chiller is
moderated and the cabinet lights turn off. The chiller can be switched into Day mode by pressing
the Day - Night button on the electronic controller faceplate.
Alarm code Buzzer Alarm LED Description Reset
Off On CO2 condenser high temperature
pre-alarm status Automatic
On On CO2 condenser high temperature alarm
status
• Manual (A14 = 0)
• Automatic (A14 > 0)
On On Open door alarm Automatic
On On Second probe error Automatic
Off On Probe 2 error, or pressure switch fault Automatic
Off On Door switch fault Automatic
Off On
Mitigation algorithm when enabled, if
regulation temperature > /b and
increasing
Automatic
Off On Internal parameters error Not possible
Off On Operating parameters error Manual
On On High voltage condition Automatic
On On Low voltage condition Automatic
On On Refrigerant system failure alarm Automatic
On On High temperature alarm Automatic
On On Low temperature alarm Automatic
On On CO2 high pressure pre-alarm status Automatic
On On CO2 high pressure alarm status Manual

10 Maintenance
User Manual
SC112N-AC
3 Maintenance
Cleaning
Many commercially available cleaning products contain solvents that may
damage the plastic components of the chiller and cause them to crack. Do
not use abrasive or corrosive cleaners or boiling water.
Wash with warm water and wipe down the chiller with a soft cloth or sponge,
then rinse with clean warm water and dry with a soft cloth. If required, lift up
and remove the shelves to help with cleaning. Do not flush the cabinet with
water.
Shelves
Adjusting the
Shelves
The chiller is supplied with three wire shelves which may be positioned at
different heights to suit various products. Each shelf is held in place with four
shelf clips which engage in the shelf support strips.
To adjust the cabinet shelves
Lighting
The chiller is lit by long life LED strip lighting. If any of the lights fail, contact
an authorised service agent to service the lights.
CAUTION
Isolate the chiller from the power supply before cleaning.
1. Remove the shelves from the chiller.
2. Remove the shelf clips from the four shelf support strips at each corner of the
chiller interior.
3. Establish the desired position for the shelves and securely engage a shelf clip
in each of the shelf support strips.
4. Sit the shelves onto the shelf support clips.
Shelf clip
Shelf support strip
Shelf

11
SC112N-AC
Maintenance
User Manual
Troubleshooting
For problems with the chiller refer to the following table.
Problem Possible Cause Suggestions
• Chiller not operating. • Loss of power supply. • Check the mains power
supply.
• Sign and/or Interior
lights not on.
• Electronic controller
displays ECO
indicating the chiller is
in Night mode.
• Switch the light on while
keeping the chiller in Night
mode by pressing the Light
(down) button on the
electronic controller
faceplate.
• Switch the chiller to Day
mode by pressing and
holding the Day - Night button
on the electronic controller
faceplate, or hold the door
open for ten seconds.
• Light is switched off. • Switch the light on by
pressing the Light (down)
button on the electronic
controller faceplate.
• Electronic controller
displays Err, indicating
a refrigeration system
error.
• Arrange a service call.
• Failed LED light. • Arrange a service call.
• Sign and interior lights
will not switch off.
• Chiller is in Cold
Climate Protection
(CCP) mode.
• It is not possible to turn the
lights off when the chiller is in
CCP mode. Wait for the
chiller temperature to rise,
then switch the lights off.
• Product is too warm. • Frequent door
opening.
• Limit door openings.
• Door not closing
properly.
• Check and clean the door
gasket.
• Electronic controller
displays ECO,
indicating the chiller is
in Night mode
• Switch the chiller to Day
mode by pressing and
holding the Day - Night button
on the electronic controller
faceplate, or hold the door
open for ten seconds.
• Moisture build up on
door or exterior.
• High humidity. • Check the ambient operating
temperature and reposition
the chiller if necessary.
• Frequent door
opening.
• Limit door openings.
• Door is not closing
properly.
• Check and clean the door
gasket.
• Chiller door does not
shut properly.
• Chiller is on an uneven
surface.
• Level the chiller.
• Door is obstructed. • Check the shelves and
product.

SKOPE Contacts
SKOPE Industries Limited
ABN: 73 374 418 306
AU: 1800 121 535
NZ: 0800 947 5673
[email protected]
www.skope.com
