Skope ProSpec Series User manual

Page 1 of 4
ProSpec Series
PRN80218 Rev. 2.0 Aug. 2023
User Guide
Thank you for purchasing a SKOPE refrigeration product.
Safety
Always observe safety precautions when using any electrical appliance. Read these instructions carefully and retain them for future
reference.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
•Do not use this appliance for other than its intended use.
•Do not insert fingers/foreign objects into any holes.
•Only use this appliance with the voltage specified on the cabinet rating label.
•Ensure the appliance has adequate ventilation as this is essential to economical, high performance.
•Be careful not to touch moving parts and hot surfaces.
•For your own safety and that of others, ensure that all electrical work is done by authorised personnel.
•If the power supply flexible cord becomes damaged, it must be replaced by an authorised service agent or similarly qualified
person in order to avoid a hazard.
•Ensure all necessary safety precautions are observed during installation or removal of the refrigeration unit.
•The appliance is not designed to be stable while in motion. Use extreme caution when moving or transporting it.
•Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
•Do not exceed a maximum load of 20 kg per shelf.
•If the cabinet is to be scrapped, ensure the cabinet is unplugged from the power supply and cut off the mains flex close to the
back of the cabinet. Be mindful of the risk of animals or children becoming trapped in the appliance – either remove or secure
doors if necessary.
•Refrigerant must be removed by a qualified service person and the cabinet recycled/disposed of in accordance with local
regulations.
Service and Support
We know you will get years of satisfaction from your new SKOPE product when you follow a few simple preventative
maintenance guidelines.
Helpful information is available on the SKOPE website: www.skope.com/serviceandsupport
WARNING
•Ensure the appliance is disconnected from the power supply before performing any cleaning or maintenance.
•Do not cover the grilles or block the entry or exhaust of airflow by placing objects up against the refrigeration unit.
•Should manual defrosting be necessary, turn off the refrigeration system and allow the ice to melt by air circulation. Collect
ice and water during defrost to prevent a slip hazard. Do not use mechanical methods to remove ice, as this may damage
the refrigeration circuit.
•Do not use any electrical devices or appliances inside the food storage compartment.
This cabinet is designed to operate within a specific climatic class environment.
See the cabinet rating label inside the cabinet for climate class number.
The cabinet includes relevant hazard symbols that may be associated with
the cooler. Refer to the information below for symbol description.
Climate class Ambient temperature Relative humidity WARNING
The refrigeration system contains flammable R290
refrigerant. Do not tamper with it.
The refrigeration system must only be serviced by qualified
personnel.
3 25°C 60%
4 30°C 55%
5 40°C 40%
7 (tropical) 35°C 75%

Page 2 of 4
ProSpec Series
PRN80218 Rev. 2.0 Aug. 2023
Installation Guidelines
Ensure the installation guidelines below are considered and met.
Ventilation Requirements
This cabinet must have the following ventilation clearances at all times:
*When installed for continuous duty in climate class 7 environment (35°C ambient/75% relative humidity), it is recommended to
provide 50 mm clearance around the sides and back of the cabinet.
Cleaning Before First Use
The cabinet interior and food contact surfaces such as the worktop must be thoroughly cleaned and sanitised before first use. Ensure
the cabinet is unplugged from the power supply before cleaning, and use only standard stainless steel cleaners suitable for food
preparation areas. If required, the cabinet exterior can be cleaned as instructed on the back page of this user guide.
Ventilation
Ensure all ventilation
requirements below
are met.
Door Opening
Allow adequate space
for the door/s to open
and close properly.
Sunlight
Do not install the
cabinet in direct
sunlight.
Uneven Surface
Do not install the
cabinet on an uneven
surface.
Surface
The installation surface
must be capable of
supporting the loaded
cabinet.
Power Supply
Do not overload the
power supply.
Blocking Ventilation
Do not store boxes or
items in front or on
top of the cabinet.
Climate Class
The cabinet must be installed in an
environment within its climate class.
The climate class is stated on the
cabinet rating label inside the
cabinet, and explained on the front
page of this user guide.
No below clearance required
Min. 300 mm above
No side
clearance
required
No behind
clearance
required
No side
clearance
required
No behind
clearance
required
No below clearance required
No above clearance required
Upright Cabinets Underbench Cabinets
Keep area in front of grille
and doors/drawers clear
Keep area in front
of doors clear
**
**
No below clearance required
Min. 100 mm
left side
Keep area in front of
grille and drawers clear
Chef Base Cabinets
No behind
clearance
required *

Page 3 of 4
ProSpec Series
PRN80218 Rev. 2.0 Aug. 2023
Drawers
Where fitted, remove drawers for cleaning. Pull the drawer out of the cabinet, release the latches at the side of drawer as shown, and
lift the drawer out at an angle. You can also remove the drawer slider by releasing the side catches as shown. Reverse the operation
to refit the drawers to the cabinet after cleaning.
Shelves
Each shelf is held in place with shelf rails, which clip into the shelf support strips. The shelf rails may be positioned at different
heights to suit various product.
The shelf rails are suitable for use with Gastronorm pans.
Loading Product
Let the cabinet cool down to the desired storage temperature before loading it with product. When loading the shelves:
Door Lock/s
The cabinet is fitted with key locks, which can be operated with the supplied key.
Electronic Controller
The electronic controller regulates the cabinet internal temperature, signals alarms and captures
operational information. The internal temperature is factory-set for storage of perishable product.
To customise the settings to your requirements and view historical data, download the SKOPE-connect
app from the Google Play Store or Apple App Store, and connect via Bluetooth wireless technology.
Lights
The interior lights switch on and off automatically depending on use.
ChefBase – Weight Limits
To ensure a safe workplace, carefully examine and make note of how much weight you plan to place on the benchtop of the ChefBase
fridge. SKOPE recommends no greater than 200 kg for the 2-drawer fridge and no greater than 400 kg for the 4-drawer fridge.
Maximum Loading
Do not overload the
shelves.
Shelf Flexing
Remove product if the
shelf is flexing.
Shelf Overhang
Do not let product
overhang the shelves.
Front
Top
Back
MAX
20kg
per shelf
Internal Airflow
Leave 25 mm space between
product and the back and
top of cabinet interior.
Cabinet Floor
Do not load product
on the cabinet floor.
Use the shelves.
Apple App
store
Google Play
store

Page 4 of 4
ProSpec Series
PRN80218 Rev. 2.0 Aug. 2023
ChefBase – Marine Edge
A marine edge on top of a ChefBase helps contain drips and spills. It also discourages items and equipment from slipping off the
top, which increases safety.
ChefBase – Heat Shield
A heat shield is fitted inside the benchtop of ChefBase cabinets which can deflect some of the cooking equipment heat away from
the refrigerated space. It is important to follow the equipment manufacturer’s guidelines to maintain food-safe holding
temperatures and prolong the refrigeration unit’s life.
Routine Cleaning
Ensure the cabinet is unplugged from the power supply before cleaning.
IMPORTANT: Do not use abrasive, corrosive or solvent-based cleaners, as they could damage the protective coating on the door.
Wipe the outside of the cabinet with a damp cloth, and the inside of the cabinet with standard stainless steel cleaners suitable for
food preparation areas. Take care to keep moisture away from electrical parts.
The condenser coil must be kept clean. SKOPE strongly recommends monthly cleaning of the condenser coil and air filter. Do not
use hard or sharp tools to clean the coil as these may cause damage.
Vertical cabinets Underbench cabinets
Clean the air filter Clean the air filter
1. Unplug the cabinet from the mains power. 1. Unplug the cabinet from the mains power.
2. Remove the filter, which is
located on the side of the
condenser coil, on top of the
cabinet by reaching over the top
of the cabinet and sliding the
filter up and off.
2. Remove the filter, which is
located behind the unit bottom
grille by rotating the grille out
and sliding the filter up and off.
3. Clean the filter with a vacuum
cleaner, wash with cold water,
and shake off any excess water
before refitting.
•Do not apply hot water,
blow-dry, or place in a
dishwasher.
•If necessary, discard and
refit a new filter.
3. Clean the filter with a vacuum
cleaner, wash with cold water,
and shake off any excess water
before refitting.
•Do not apply hot water,
blow-dry, or place in the
dishwasher.
•If necessary discard and fit a
new filter.
Clean the condenser coil Clean the condenser coil
1. Unplug the cabinet from the mains power. 1. Unplug the cabinet from the mains power.
2. Remove the air filter (see above). 2. Remove the air filter (see the previous procedure).
3. Brush the condenser coil with a
soft brush to remove any dust
and fluff.
3. Brush the condenser coil with a
soft brush to remove any dust
and fluff.
4. Refit the front panel and
reconnect the cabinet to the
power supply.
IMPORTANT
When refitting, ensure the tabs on
the back of the sign are located in
the notches on top of the cabinet,
and that the sign is pushed fully in
and secure.
4. Refit the filter, close the bottom
grille, and reconnect the cabinet
to the mains power.
Filter
Filter
Grille
Coil
Tab and notch
Coil
