SLC S54001 User manual

SLC DMX Wall Touch RGB Master 230V S54001
Function introduction
Important: Read All Instructions Prior to Installation
Front side
Touch color wheel, touch to
select R/G/B color
R/G/B/W 4channels:Click to turn off/on the channel
Press and hold down to increase/decrease light intensity of each channel
Click to switch on/off
Click to play / pause the
10 built-in effects,
Press and hold down to
speed up/down the
running effects
Press and hold down to save color/effect;
Click to recall the saved
Press and hold down to
increase/decrease light
intensity
Product Data
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.
Safety & Warnings
Wiring diagram
Output Signal DMX512 signal
Power Supply 100-240VAC
Power consumption 15 mA
Operating temperature 0-40°C
Relative humidity 8% to 80%
Dimensions 86x86x29.1mm
• Touch sensitive
• Glass interface(white & black)
• Standard DMX512 Signal output
• Control RGBW color
• Control 1 zone/area
• Waterproof grade: IP20
12V/24V/36V
CV PSU
L
N
G
V+
V-
OUTPU T
INPUT
D1 D1 D2 D 2
DMX5 12 D ec od er
GND
whit e
0-5 0-9 0-9
D1 D1 D2 D 2
DMX5 12 D ec od er
GND
whit e
0-5 0-9 0-9
D1 D1 D2 D 2
DMX5 12 D ec od er
GND
whit e
0-5 0-9 0-9
Connect with RGBW LED Strip
V+ V+
R- R-
G- G-
B- B-
W- W-
Connect with RGBW LED Strip
V+ V+
R- R-
G- G-
B- B-
W- W-
Connect with RGBW LED Strip
V+ V+
R- R-
G- G-
B- B-
W- W-
Set DMX Address
One DMX master controller can control many DMX Decoders, set all DMX decoders' address as 001.
Note: one DMX Decoder has 4 channels, so it occupies 4 DMX addresses 001, 002, 003, 004.
LED indicator
Back side
59.00 mm
31.20 mm
59.00 mm
AC Power input
D+ D-
DMX signal
output
AC100-240V
input
DMX512 Controller
L N
DMX512 signal output
D+ D-
DMX signal
output
AC100-240V
input
DMX512 Controller
L N
AC 100-240V

Installation
The Light Group AS, Sagmyra 2A, 4624 Kristiansand, Norway
