SMA SUNNY TRIPOWER 60 User manual

SHP75-10-STP60-10-IA-xx-18 | 139R0183 | Version 1.8
Installation Guide / Installationsanleitung /
Instrucciones de instalación / Instructions d’installation /
Istruzioni per l’installazione
SUNNY HIGHPOWER PEAK1
SUNNY TRIPOWER 60

SMA Solar Technology AG 
Installation Guide SHP75-10-STP60-10-IA-xx-18 3
ENGLISH - Table of Contents
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.1 System Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.2 Purpose of This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.3 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1.4 Inverter Type Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1.5 Installation Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.1 Environment and Clearances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.2 Mounting the Wall Mounting Bracket . . . . . . . . . . . . . . . . . . . . . . . . 22
2.3 Mounting the Inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.4 Disassembling the Inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.5 Access to the Installation Area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.6 AC Grid Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.7 Enclosure opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.8 Ethernet Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.9 PV Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.9.1 External PV Array Junction Boxes. . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.10 Closing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3 Initial Setup and Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.1 User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.1.1 Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.2 Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.2.1 Initial Setup via LCS-Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.2.2 Switching on the PV Load-Break Switch . . . . . . . . . . . . . . . . . . . . . . 32
3.2.3 Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.2.4 Grid Code File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.2.5 Configuring the Fallback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4 Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.1 Troubleshooting and Repair. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

 SMA Solar Technology AG
4 SHP75-10-STP60-10-IA-xx-18 Installation Guide
4.2 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.1 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.2 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.3 Installation Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.4 Torque Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.5 Specifications for Grid Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.6 Technical Data of the Communication Interface . . . . . . . . . . . . . . . . 46
5.7 Ethernet Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.7.1 Network Topology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6 Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

SMA Solar Technology AG 
Installation Guide SHP75-10-STP60-10-IA-xx-18 5
DEUTSCH - Inhaltsverzeichnis
1 Einführung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
1.1 Systemübersicht . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
1.2 Zweck der Anleitung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
1.3 Auspacken. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
1.4 Typenschild des Wechselrichters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
1.5 Installationsreihenfolge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
2.1 Umgebung und Abstände . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
2.2 Montage der Wandhalterung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
2.3 Montage des Wechselrichters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
2.4 Abbau des Wechselrichters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
2.5 Zugang zum Installationsbereich. . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
2.6 AC-Netzanschluss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
2.7 Kabeleinführung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
2.8 Ethernet-Anschlüsse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
2.9 PV-Anschluss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
2.9.1 Externe Generatoranschlusskästen . . . . . . . . . . . . . . . . . . . . . . . . . 63
2.10 Schließen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
3 Ersteinrichtung und Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
3.1 Benutzerschnittstelle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
3.1.1 Betriebsarten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
3.2 Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
3.2.1 Ersteinrichtung über LCS-Tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
3.2.2 PV-Lasttrennschalter einschalten. . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
3.2.3 Inbetriebnahme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
3.2.4 Grid-Code-Datei. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
3.2.5 Fallback konfigurieren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
4 Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
4.1 Fehlersuche und -behebung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

 SMA Solar Technology AG
6 SHP75-10-STP60-10-IA-xx-18 Installation Guide
4.2 Wartung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
5 Technische Daten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
5.1 Spezifikationen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
5.2 Konformität . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
5.3 Installationsbedingungen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
5.4 Drehmomentspezifikationen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
5.5 Spezifikation für die Netzsicherungen. . . . . . . . . . . . . . . . . . . . . . . . 81
5.6 Technische Daten der Kommunikationsschnittstellen . . . . . . . . . . . . . 82
5.7 Ethernet-Anschlüsse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
5.7.1 Netzwerktopologie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6 Kontakt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

SMA Solar Technology AG 
Installation Guide SHP75-10-STP60-10-IA-xx-18 7
ESPAÑOL - Índice
1 Introducción . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
1.1 Vista general del sistema . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
1.2 Fin de las instrucciones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
1.3 Desembalaje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
1.4 Placa de características del inversor . . . . . . . . . . . . . . . . . . . . . . . . . 90
1.5 Orden de instalación. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
2 Instalación. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
2.1 Entorno y espacios libres. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
2.2 Montaje del soporte mural . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
2.3 Montaje del inversor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
2.4 Desmontaje del inversor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
2.5 Acceso al área de instalación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
2.6 Conexión de red de CA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
2.7 Entrada de cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
2.8 Conexiones de ethernet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
2.9 Conexión fotovoltaica . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
2.9.1 Cajas de conexión del generador externas. . . . . . . . . . . . . . . . . . . 99
2.10 Cierre. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
3 Configuración inicial y arranque . . . . . . . . . . . . . . . . . . . . . . 101
3.1 Interfaz de usuario. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
3.1.1 Modos de funcionamiento . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
3.2 Pantalla . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
3.2.1 Ajuste inicial mediante LCS-Tool . . . . . . . . . . . . . . . . . . . . . . . . . . 103
3.2.2 Activación del interruptor-seccionador fotovoltaico. . . . . . . . . . . . 103
3.2.3 Puesta en marcha. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
3.2.4 Archivo del código de red . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
3.2.5 Configuración del procedimiento de emergencia . . . . . . . . . . . . . 103
4 Mantenimiento . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
4.1 Resolución de problemas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

 SMA Solar Technology AG
8 SHP75-10-STP60-10-IA-xx-18 Installation Guide
4.2 Mantenimiento. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
5 Datos técnicos. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
5.1 Especificaciones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
5.2 Conformidad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
5.3 Condiciones de la instalación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
5.4 Especificaciones del par de apriete. . . . . . . . . . . . . . . . . . . . . . . . . 117
5.5 Especificaciones del circuito de la red eléctrica . . . . . . . . . . . . . . . 118
5.6 Especificaciones de las interfaces de comunicación . . . . . . . . . . . . 119
5.7 Conexiones de ethernet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
5.7.1 Topología de red . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
6 Contacto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

SMA Solar Technology AG 
Installation Guide SHP75-10-STP60-10-IA-xx-18 9
FRANÇAIS - Table des matières
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
1.1 Vue d’ensemble du système. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
1.2 Objet des ces instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
1.3 Déballage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
1.4 Plaque signalétique de l’onduleur . . . . . . . . . . . . . . . . . . . . . . . . . . 165
1.5 Ordre d’installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
2.1 Environnement et distances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
2.2 Montage du support mural . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
2.3 Montage de l’onduleur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
2.4 Démontage de l’onduleur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
2.5 Accès à la zone d’installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
2.6 Raccordement au réseau AC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
2.7 Insertion de câbles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
2.8 Raccordements Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
2.9 Raccordement photovoltaïque. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
2.9.1 Boîtiers externes de raccordement pour le générateur
photovoltaïque. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
2.10 Fermeture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
3 Configuration initiale et démarrage. . . . . . . . . . . . . . . . . . . . 176
3.1 Interface utilisateur. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
3.1.1 Modes de fonctionnement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
3.2 Écran . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
3.2.1 Configuration initiale via LCS-Tool . . . . . . . . . . . . . . . . . . . . . . . . . 178
3.2.2 Activation de l’interrupteur-sectionneur PV . . . . . . . . . . . . . . . . . . . 178
3.2.3 Mise en service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
3.2.4 Fichier de codes réseau . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
3.2.5 Configuration du repli automatique. . . . . . . . . . . . . . . . . . . . . . . . 179
4 Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
4.1 Recherche d’erreurs et dépannage . . . . . . . . . . . . . . . . . . . . . . . . . 180

 SMA Solar Technology AG
10 SHP75-10-STP60-10-IA-xx-18 Installation Guide
4.2 Entretien. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
5 Données techniques. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
5.1 Spécifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
5.2 Conformité. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
5.3 Conditions d’installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
5.4 Spécifications de couple . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
5.5 Spécifications pour la protection du réseau . . . . . . . . . . . . . . . . . . 193
5.6 Spécifications de l’interface de communication. . . . . . . . . . . . . . . . 194
5.7 Raccordements Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
5.7.1 Topologie du réseau . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
6 Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

SMA Solar Technology AG 
Installation Guide SHP75-10-STP60-10-IA-xx-18 11
ITALIANO - Indice
1 Introduzione . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
1.1 Panoramica del sistema. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
1.2 Scopo delle istruzioni . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
1.3 Disimballaggio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
1.4 Targhetta di identificazione dell’inverter . . . . . . . . . . . . . . . . . . . . . 127
1.5 Ordine d’installazione . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
2 Installazione . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
2.1 Ambiente e distanze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
2.2 Montaggio del supporto da parete. . . . . . . . . . . . . . . . . . . . . . . . . 130
2.3 Montaggio dell’inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
2.4 Rimozione dell’inverter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
2.5 Accesso all’area di installazione . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
2.6 Collegamento rete CA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
2.7 Introduzione dei cavi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
2.8 Collegamenti Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
2.9 Collegamento dell’impianto FV . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
2.9.1 Quadri di parallelo stringhe esterni . . . . . . . . . . . . . . . . . . . . . . . . 136
2.10 Chiusura. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
3 Setup iniziale e avviamento . . . . . . . . . . . . . . . . . . . . . . . . . . 138
3.1 Interfaccia utente . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
3.1.1 Modalità di funzionamento . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
3.2 Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
3.2.1 Setup iniziale attraverso LCS Tool . . . . . . . . . . . . . . . . . . . . . . . . . 139
3.2.2 Attivazione dell’interruttore del carico FV . . . . . . . . . . . . . . . . . . . 140
3.2.3 Messa in servizio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
3.2.4 File del codice di rete. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
3.2.5 Configurazione del fallback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
4 Servizio di assistenza tecnica SMA. . . . . . . . . . . . . . . . . . . . . 141
4.1 Ricerca degli errori . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

 SMA Solar Technology AG
12 SHP75-10-STP60-10-IA-xx-18 Installation Guide
4.2 Manutenzione . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
5 Dati tecnici. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
5.1 Specifiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
5.2 Conformità. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
5.3 Condizioni di installazione . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
5.4 Specifiche di coppia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
5.5 Specifiche dei fusibili di rete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
5.6 Dati tecnici delle interfacce di comunicazione. . . . . . . . . . . . . . . . . 155
5.7 Collegamenti Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
5.7.1 Topologia della rete. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
6 Contatti . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

SMA Solar Technology AG
Installation Guide SHP75-10-STP60-10-IA-xx-18 13
Legal Provisions
The information contained in these documents is the
property of SMA Solar Technology AG. Any publication,
whether in whole or in part, requires prior written approval
by SMA Solar Technology AG. Internal reproduction used
solely for the purpose of product evaluation or other proper
use is allowed and does not require prior approval.
SMA Warranty
You can download the current warranty conditions from the
Internet at www.SMA-Solar.com.
Trademarks
All trademarks are recognized, even if not explicitly
identified as such. Missing designations do not mean that a
product or brand is not a registered trademark.
SMA Solar Technology AG
Sonnenallee 1
34266 Niestetal
Deutschland
Tel. [phone]
Fax [phone]
www.SMA.de
E-mail: [email protected]
Copyright © 2019 SMA Solar Technology AG.
All rights reserved.
Nomenclature
IMPORTANT SAFETY
INFORMATION
The following symbols are used in this document:
Complete designation Designation in this
document
Sunny Highpower Peak1 Inverter, product
Sunny Tripower 60 Inverter, product
SMA Digital I/O Box I/O Box
Symbol Explanation
Indicates a hazardous
situation which, if not
avoided, will result in
death or serious injury
Indicates a hazardous
situation which, if not
avoided, can result in
death or serious injury
Indicates a hazardous
situation which, if not
avoided, can result in
minor or moderate injury
Indicates a situation
which, if not avoided, can
result in property damage
Indicates that the
following section contains
tasks that must be
performed by qualified
persons only
Information that is
important for a specific
topic or goal, but is not
safety-relevant
☐Indicates a requirement
for meeting a specific goal
☑ Desired result
✖ A problem that might
occur

SMA Solar Technology AG
14 SHP75-10-STP60-10-IA-xx-18 Installation Guide
General Safety
Figure1: PV load-break switch
This manual contains important instructions that must be
followed during installation and maintenance of the
inverter.
Before Installation
Check the inverter and the packaging for damage.
If in doubt, contact the supplier before commencing
installation.
Installation/Service
For optimum safety, follow the steps described in this
document. Keep in mind that the inverter has two voltage
carrying sides, the PV input and the utility grid.
Disconnecting the inverter
Before working on the inverter, disconnect it from the utility
grid by means of the AC breaker and switch off PV using
the integrated PV load-break switch (DC load-break
switch). Ensure that the inverter cannot be unintentionally
reconnected. Use a voltage detector to ensure that the
unit is disconnected and voltage free. The inverter can still
be charged with very high voltage at hazardous levels
even when it is disconnected from utility grid and PV
modules. Wait at least five minutes after disconnection
from the utility grid and PV modules before proceeding.
A PV load-break switch
A
INFORMATION
The PV load-break switch can be secured in the "Off"
position using a padlock.
INFORMATION
Only for SHP 75-10:
The inverter is not intended to be used in living areas
and cannot provide protection of radio reception
against interference signals in such environments.
In accordance with EN55011:2016, the inverter
must only be operated at operation locations where
the distance between the inverter and
radio-communication installations is greater than
30 m and an own power transformer is used.
DC voltages up to 1000 V are present in a PV system
even when the inverter is disconnected from the utility grid.
Faults or inappropriate use may lead to electric arcing.
MAINTENANCE AND MODIFICATION
Only authorized personnel are permitted to repair or
modify the inverter. To ensure personal safety, use only
original spare parts available from the supplier.
INSTALLER
Input and output circuits are isolated from the enclosure.
System grounding is the responsibility of the installer.
RISK OF ELECTRIC SHOCK
This manual is intended for use by qualified personnel
only. To reduce the risk of electric shock, do not perform
any maintenance work other than that specified in the
manual unless you are qualified to do so.

SMA Solar Technology AG
Installation Guide SHP75-10-STP60-10-IA-xx-18 15
Symbols on the inverter
Danger due to ground fault on DC side during
operation
Due to the transform erless topology of the product, the
occurrence of ground faults on DC side during operation
can lead to irreparable damage. Damages to the product
due to a faulty or damaged DC installation are not
covered by warranty. The product is equipped with a
protective device that checks whether a ground fault is
present during the starting sequence. The product is not
protected during operation.
• Ensure that the DC installation is carried out correctly
and no ground fault occurs during operation.
The inverter is not equipped with a transformer and is
intended to be installed with an ungrounded (floating) PV
array.
Input and output circuits are isolated from the enclosure.
System grounding is the responsibility of the installer.
All persons responsible for the installation and
maintenance of inverters must be:
• Trained and authorized in general safety rules for
work on electric equipment.
• Familiar with local requirements, rules and
regulations for the installation.
The inverter does not provide overcurrent protection. This
must be provided by the installer. See table 5.8
The temperature of the cooling elements and components
in the inverter can exceed 70°C. There is a risk of burns.
The inverter is to be installed in such way that hot
components cannot be touched.
Damage to the product due to outgassing of
sealants
Sealants such as silicone, polyurethane foam or sealing
foam can outgas. Outgassing of sealants can damage the
product and impair its functionality.
• Do not use any sealants for sealing.
• Only use the provided material for sealing.
INFORMATION
The symbol for grounding conductors used in this
manual is identified in figure 2.18.
An illustration of the DC disconnector can be found in
Section 3.2.2, page 32.
INFORMATION
For information about the operating temperature
range, see Section 5.3, page 44.
INFORMATION
This manual contains information about field wiring
connections and torque specifications. See Section
5.4, page 45.
Symbol Explanation
Danger to life due to electric shock
The product operates at high voltages.
All work on the product must be
carried out by qualified persons only.
Danger
This symbol indicates that the inverter
must be additionally grounded if
additional grounding or equipotential
bonding is required at the installation
site.
Danger to life due to high voltages in
the inverter; observe waiting time.
High voltages that can cause lethal
electric shocks are present in the live
components of the inverter.
Prior to performing any work on the
inverter, disconnect it from all voltage
sources as described in this document.

1 Introduction SMA Solar Technology AG
16 SHP75-10-STP60-10-IA-xx-18 Installation Guide
Compliance
Further information can be found in the download area of
www.SMA-Solar.com (see also Section 5, page 41).
1 Introduction
The inverter is only designed for operation in grid-connected
PV systems. The inverter converts direct current from PV
modules into grid-compliant three-phase alternating current.
For operation, the inverter must be connected to a utility grid
and with a sufficient number of PV modules. The inverter is
not suitable for other applications (such as operation with
batteries or wind turbine systems).
The PV system consists of four main components:
• Inverter
• PV array junction box
The PV array junction box enables the bundling of the
necessary number of PV strings for the inverter. Each
inverter requires a PV array junction box.
• SMA Inverter Manager
The SMA Inverter Manager is always required for the
operation of the inverter. Up to 42 inverters can be
connection to each SMA Inverter Manager. The
SMA Inverter Manager handles all communication of
the inverters. It serves as central interface for data
acquisition systems, upload to cloud services and
power-plant control.
• Local commissioning and service tool (LCS-Tool)
The LCS-Tool is required for the commissioning and
servicing of the inverter via the SMA Inverter Manager.
The LCS-Tool is the primary user interface for the PV
system.
Risk of burns due to hot surfaces
The product can get hot during
operation. Avoid contact during
operation. Allow the product to cool
down sufficiently before carrying out
any work.
Observe the documentation
Observe all documentation supplied
with the product.
WEEE designation
Do not dispose of the product together
with the household waste but in
accordance with the disposal
regulations for electronic waste
applicable at the installation site.
The product complies with the
Moroccan safety and EMC
requirements for electrical products.
Symbol Explanation

SMA Solar Technology AG 1 Introduction
Installation Guide SHP75-10-STP60-10-IA-xx-18 17
1.1 System Overview
Figure 1.1 System overview
1.2 Purpose of This Manual
The manual contains information on the installation and
commissioning of the inverter.
The following additional materials are available:
• Quick reference guide for the installation of the inverter
- information necessary for commissioning and for
establishing communication.
• Installation manual for the SMA Inverter Manager and
the I/O Box - information necessary for commissioning
and for establishing communication.
• Service manual for replacing the fan – for information
required to replace a fan.
• Service manual for replacing the SPDs – contains
information required to replace surge protection
devices.
These documents are available in the download area at
www.SMA-Solar.com. You can also request these from the
supplier of the inverter.

1 Introduction SMA Solar Technology AG
18 SHP75-10-STP60-10-IA-xx-18 Installation Guide
Figure 1.2 Front view of the inverter
Abbreviation Description
cat5e Category 5 twisted pair cable (enhanced)
for data transmission
DHCP Dynamic Host Configuration Protocol –
enables automatic assignment of the
network address via the DHCP server
DSL Digital Subscriber Line
EMC
(directive)
Electromagnetic compatibility directive
ESD Electrostatic discharge
FRT Fault Ride Through
GSM Global System for Mobile
Communications (standard for digital
cellular mobile network)
HDD Hard Disk Drive
IEC International Electrotechnical Commission
– international standards organization
IT Isolated Terra
LCS Local commissioning and service tool
(LCS-Tool)
LED Light-Emitting Diode
LVD (Directive) Low-voltage directive
MCB Miniature circuit breaker
MPP Maximum Power Point
MPPT Maximum Power Point Tracking
determines the point of optimum PV power
P P is the symbol for active power and is
measured in Watts (W).
PCB Printed circuit board
F1 F3 F4F2
OK
Home Back
Alarm
On
PCC Point of Common Coupling - point of
interconnection
The point on the public electricity network
to which other customers are, or could be,
connected.
Grounding
conductor
Protective grounding
PELV Protected Extra-Low Voltage
PLA Power Level Adjustment = Output power
limitation
Pnom Power [W], Nominal active power
POC Connection point
The point at which the PV system is
connected to the public utility grid.
PSTC Power [W], Standard Test Conditions
PV Photovoltaic, photovoltaic cells
RCD Residual-current device
RCMU Residual Current Monitoring Unit
RISO Insulation resistance
ROCOF Rate of Change of Frequency
Q Q is the symbol for reactive power and is
measured in reactive volt-amperes (VAr).
S S is the symbol for apparent power and is
measured in volt-amperes (VA).
STC Standard Test Conditions
SW Software
THD Total Harmonic Distortion
TN-S Terra Neutral - Separate. AC Network
TN-C Terra Neutral - Combined. AC Network
TN-C-S Terra Neutral - Combined - Separate. AC
Network
TT AC grid with separation between
operational ground of the generator and
ground of the load system
DNO Distribution grid operator
Abbreviation Description

SMA Solar Technology AG 1 Introduction
Installation Guide SHP75-10-STP60-10-IA-xx-18 19
1.3 Unpacking
Check the scope of delivery of each product for
completeness and any externally visible damage.
Contact your distributor if the scope of delivery is
incomplete or damaged.
The delivery may contain parts
that are not required for the installation.
Contents:
•Inverter
•Wall mounting bracket
• Accessories bag containing:
– 6 wall plugs 8 x 50 mm
– 6 mounting screws 6 x 60 mm
– 1 M25 cable gland with sealing grommet for
Ethernet cables
– 1 grounding bolt M6 x 12 mm
• Installation manual
• Quick reference guide for installation
1.4 Inverter Type Label
The type label uniquely identifies the inverter. You will
require the information on the type label to use the product
safely and when seeking customer support from the
SMA Service Line. You will find the following information on
the type label:
• Device type (Model)
• Serial number (Serial No.)
• Date of manufacture
• Device-specific characteristics
1.5 Installation Sequence
1. Pay special attention to the important safety
information at the beginning of this manual.
2. Mount the inverter according to Section 2.1, page 21,
Section 2.2, page 22, Section 2.3, page 23.
3. Open the inverter in accordance with Section
2.5, page 24.
4. Install the AC supply in accordance with Section
2.6, page 25.
5. Install Ethernet in accordance with Section
5.7, page 47.
6. Install the PV module in accordance with Section
2.9, page 28 using a PV array junction box.
7. Close the inverter in accordance with Section
2.5, page 24.
8. Turn on AC.
9. Finalize commissioning by using the Local
Commissioning and Service Tool (LCS-Tool). The tool is
available from the download area at
www.SMA-Solar.com. The hardware requirements for
the LCS-Tool are:
– PC with WindowsTM 7 and later
–1 GB HDD
– 2 GB RAM
The LCS-Tool must be installed on a local PC drive.
The PC must be connected to the system network of the
SMA Inverter Manager. See Section 3.2.1, page 32
for configuring via the LCS-Tool.
10. Switch on the PV system via the PV load-break switch.
11. Verify the installation by:
– Inverter display: LED "On" is permanently green.
– LCS-Tool: In the inverter view, the status is
"On grid".
12. The inverter is in operation now.

1 Introduction SMA Solar Technology AG
20 SHP75-10-STP60-10-IA-xx-18 Installation Guide
Figure 1.3 Overview of the installation area
Table 1.2 Overview of the installation area
BCD
E
F
G
H
A
PELV (safe to touch)
B Device grounding
G Ethernet interface x 2
H RS485 interface (not in use)
Live parts
AAC terminals
EPV terminals
Other
C AC overvoltage protection (SPDs)
D DC overvoltage protection (SPDs)
F PV load-break switch
