SMART-AVI SDX-XT-2P User manual

NOTICE SDX-XT-2P
Dual DVI, KVM and Audio Extender
Over CAT5e/6 HDBaseT
(245 ft)
Long-range HD Dual DVI-D Video,
USB Keyboard-Mouse, RS232 and
Audio Extender
Quick Start Guide
VIDEO
Format DVI-D Single-link
Max. Pixel Clock 165 MHz
Input (TX) (2) DVI-D 29-pin female
Output (RX) (2) DVI-D 29-pin female
Resolution Up to 1920 x 1200 @ 60 Hz;
Up to 3840 x 2160 @ 30 Hz
DDC 5 Volts p-p (TTL)
Input Equalization Automatic
Input/Output Cable
Length Up to 20 ft
USB
Signal Type OHCI/UHCI (USB 1.1)
Input Interface (TX) (1) USB Type-B (female)
Output Interface (RX) (2) USB Type-B (female)
RS232
Input Interface (TX) (2) DB9 (female)
Output Interface (RX) (2) DB9 (female)
Speed @ 115 Kbps
AUDIO
Input Interface (TX) (1) 3.5 mm jack socket
Output Interface (RX) (1) 3.5 mm jack socket
Frequency Response 30 KHz to 80 KHz
OTHER
Power Supply External 100-240 VAC/
5VDC4A
Dimensions 8.25” W x 1” H x 3.625” D
Weight 1 lb
Operating Temperature 32 to 131 °F (0 to 55 °C)
Storage Temperature -4 to 185 °F (-20 to 85 °C)
Humidity Up to 95%
The information contained in this document
is subject to change without notice. SmartAVI
makes no warranty of any kind with regard
to this material, including but not limited to,
implied warranties of merchantability and
tness for particular purpose.
SmartAVI will not be liable for errors
contained herein or for incidental or
consequential damages in connection with
the furnishing, performance or use of this
material.
No part of this document may be
photocopied, reproduced, or translated
into another language without prior written
consent from SmartAVI Technologies, Inc.
Designed and Manufactured in the USA
800.AVI.2131, 702.800.0005
2455 W Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
SmartAVI.com
Technical Specication

About SDX-XT Installation Diagram
Connecting SDX-XT-2P
What’s in the Box
SDX-RX2P FRONT
SDX-TX2P FRONT
SDX-RX2P BACK
SDX-TX2P BACK
SDX-XT-2P is a dual DVI video, stereo audio, USB KVM, and
dual RS232 control extender capable of sending ultra-HD
signals up to 245 ft away via CAT5e/6 cables.
Features:
• Extends DVI-D up to 245 ft from source
• Data Recover for digital video
• Supports up to 1080p and 4K/2K resolutions
• Automatic DDC learning
• Supports USB Keyboard-Mouse extension
• Supports RS232 command extension
• Can be powered by either TX and RX units with
HDBaseT
• Plug-and-play ready for easy use
1. Turn off connected devices
2. Connect cables between signal source device and TX unit’s input ports
3. Connect cables between the RX unit’s output ports and end-point device
4. Connect TX and RX via CAT5e/6 cable
5. Connect power supply to either TX and RX units
6. Turn on TX and RX units
7. Return power to connected devices
Dual-Head DVI-D, USB 2.0 and Audio Extender – Transmier Unit
PWR LINK FW LINK FW
SDX-XT-2TX
DVI IN
DVI OUT
USB IN
USB OUT
AUDIO IN
AUDIO OUT
CAT5/6
245 ft
Dual-HeadDVI-D, USB 2.0 and Audio Extender – ReceiverUnit
PWR LINK FW LINK FW
SDX-XT-2RX
PART NO. Q-TY DESCRIPTION
SDX-2PS 1 Dual DVI-D , USB 1.1, Dual RS232 ,
Audio, CAT5/5e/6 Extender.
PS5VD4A-WLLMNT 1 PS5VD4A Power Supply
Quick Start Guide 1
