SMART-AVI DV-SW2 User manual

© Copyright 2010 Smart-AVI, All Rights Reserved
NOTICE
The information contained in this document
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
For more information, visit www.smartavi.com.
SmartAVI, Inc. / Twitter: smartavi
11651 Vanowen St. North Hollywood, CA 91605
Tel: [phone] Fax: [phone]
http://www.SmartAVI.com
Display Content From 2 Computers, PC or
Mac on one Display Up To 20 Feet Away
DV-SW2
2-Port Cross-platform DVI-D
with RS-232 and IR Control
www.smartavi.com
Installation
Manual
Technical Specications
VIDEO
Format DVI-D Single Line
Maximum Pixel Clock 165 MHz
Input Interface (2) DVI-D 29-pin female
Output Interface (1) DVI-D 29-pin female
Resolution Up to 1920 x 1200 @60Hz
DDC 5 volts p-p(TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
OTHER
Control RS-232, IR, and Front Panel
Power External 5VDC2A
Dimensions 10.5”W x 1.875”H x 6”D
Weight 5 lbs.
Approvals UL, CE, ROHS Compliant
What’s in the Box?
PART NO. QTY DESCRIPTION
DV-SW2S 1 DVI-D 2x1 Switch
Power Supply 1 PS5VDC2A
User Manual 1
DV-SW2 Front
DV-SW2 Rear

Introduction
The DV-SW2 is a cross-platform DVI-D switch capable of
sharing one DVI-D Monitor between two computers, PC
or Mac. View two computers equipped with DVI-D on a
single screen, saving money and desktop space.
Features
• Supports Mac, PC, Linux and Sun DVI-D
• Supports High Resolution1920x1200 60 Hz WUXGA
• Uses universal DVI Single Link connectors
• Zero pixel loss with TMDS signal correction
• Output DVI up to 20 feet
• Front panel switch with LED indicator
• Saves space on your desktop
Applications
• Home Theater Integration
• Digital Signage Deployment
• Information Kiosks/Displays
• Film/Recording Studios
In the medical or industrial eld, where it may not be
practical (or safe) to have one or more CPUs in the
general vicinity, SmartAVI’s DVI Switch Series is the
perfect solution. allowing for either PC or Mac signals
to be extended to a display (20 feet from computer to
DVI Switch, and then 20 feet from DVI Switch to remote
monitor/display point).
Another practical use for one of our DVI Switches would
be for media recording studios, where soundproong
and space issues come into play. Using a DVI Switch
eliminates the inherent “hum” of a powered CPU and
gives you the freedom of using your keyboard, mouse
and monitor without having to nd room for the
computer itself in the same workspace.
Product - Installation Diagram
Installation
1. Turn o all computers and the display.
2. Connect the DVI extension cables (not included) to the computers and to the“IN” ports on the DV-SW2.
3. Connect the display to the“OUT” connector on the DV-SW2.
4. Connect the power cord and power on the DV-SW2.
5. Power on the computers and the display.
6. Use the front panel buttons, an RS-232 connection or infrared remote control to select the desired input port.
DV-SW2
20 ft. over DVI-D20 ft. over DVI-D
MacPC
Switching Between Ports
There are three ways to switch between inputs on the DV-SW2: via
the front panel buttons, RS-232 connection or IR remote control.
Front Panel Control
To switch ports using the front panel, press either the up or down
button to cycle through the available ports.The selected port number
will be indicated on the LED display.
RS-232 Control
To switch ports using an RS-232 connection, use a male-to-female
serial cable to connect a computer to the DV-SW2’s RS-232 port. Use
Hyperterminal to connect to the DV-SW2, making sure to use the
standard communication mode of 9600bps, 8, N, 1.
To switch ports, use the standard “//M”command prompt.
To select the “IN 1” port, send “//M1 [ENTER]”
To select the “IN 2” port, send “//M2 [ENTER]” etc.
IR Control
To switch ports using an infrared remote control (optional accessory),
connect an IR-EYE (optional accessory) to the DV-SW2 box and the
unit will auto-detect the infrared connection. Once the connection is
made, you may use the IR remote to cycle through the available ports.
DDC Learning
The DV-SW2 is fully capable of “learning” and remembering what
type of display monitor is connected to the unit. Programming the
DDC (Display Data Channel) is accomplished using the two buttons
located on the front panel.
To enter Learning Mode, simply depress both buttons at once until
the display reads “L”. By then pressing the Down/Left button, you
may cycle through the following DDC learning modes:
“P” indicates Personal Computer Mode and automatically selects the
standard display characteristics of a PC display, which typically works
for any PC/Display combination.
“A” indicates Apple Mode and selects the best display mode to
accommodate a Mac.
“S” indicates Screen Mode, which replicates the type of device
connected to the “IN 1” port.
