SMART Embedded Computing PCIE-8130-HL User manual

1 Box contents
Make sure you receive all items of your shipment:
• One PCIE-8130-HL card
• One printed copy of Quick Start Guide (this document)
• One printed copy of Safety Notes Summary
When installing or servicing the system or accessories,
strictly observe the safety precautions in the Safety Notes
Summary. Ignoring these instructions can void the system
warranty and cause personal injury or property damage.
2 ESD
Electrostatic discharge and incorrect installation or
removal of the card can damage circuit or shorten its life.
Use a properly grounded ESD wrist strap or work in an
ESD-safe environment.
Connect to the ESD connector at the front or the rear of
the system.
3 Site preparation
Note: Consult the installation manual provided by your server
vendor for instruction on how to install the card in a specific server.
1. Make sure that all environmental and power requirements
defined in the PCIE-8130 Installation and Use manual are
met.
2. The PCIE-8130-HL card requires a PCIe x4 connector size. It
can also be installed in a x8 or x16 slot.
3. The PCIE-8130-HL can be installed in a system board PCIe slot
or on a PCIe riser card.
4. Make sure the server can accommodate the full-height, half-
length PCIE-8130-HL card and that it provides snap-in fixation or
screw holes.
5. Verify that the I/O slot can supply power via the 12V supply rail in
accordance with the PCI Express Card Electromechanical
Specification definition for a 75W slot.
4 Install PCIe cards
Note: Consult the installation manual provided by your server
vendor for instructions on how to power down and remove the
housing cover from the system.
1. Shut down and disconnect the system from AC power.
2. Remove the housing cover from the server.
3. Remove the filler cards or filler panels in the PCIe slots, if any.
4. Install the PCIE-8130-HL card(s) in the respective slot(s) by
gently pushing the card along the guide rails till the card is fully
engaged with the connector. Avoid excessive force during this
operation.
Note: If a retainer clip is used in the target server to secure the
card, the clip must be applied for proper operation of the card.
5. Fill any empty PCIe slots with filler cards or filler panels. A slot
adjacent to the component side (primary side) of a high power
card should always contain a filler card for better cooling.
For more information about PCIE-8130-HL card installation, refer to
the PCIE-8130 Installation and Use manual.
5 Power connector info
Power for the PCIE-8130-HL card is supplied via the PCIe card
edge connector. No additional power (via ATX connectors) is used.
For more information about connecting cables and power cords,
refer to the PCIE-8130 Installation and Use manual.
PCIE-8130-HL
Quick Start Guide
P/N: 6806877A03A March 2021

PCIE-8130-HL Quick Start Guide
SMART Embedded Computing, 2900 S. Diablo Way, Suite 190, Tempe, Arizona 85282
For technical assistance or to report product damage or shortages,
contact your local SMART Embedded Computing sales
representative or visit https://www.smartembedded.com/ec/support/.
Technical Assistance
For more information on this product, see the PCIE-8130
Installation and Use manual and other related technical
documentation, which can be found by using the
Documentation Search at
https://www.smartembedded.com/ec/support/.
