Smart Technologies MX-V4 Series Guide

Service Parts
Diagrams
MX-V4/V4N/V4-VO series
For Model:
MX-V4-PW/V4N-PW series

SMART Technologies ULC
3636 Research Road NW
Calgary, AB T2L 1Y1
CANADA
www.smarttech.com
© 2023 SMART Technologies ULC. All rights reserved. SMART Board, smarttech and the SMART logo are trademarks or registered trademarks of SMART
Technologies ULC in the U.S. and/or other countries. All other third-party product and company names are for identification purposes only and may be
trademarks of their respective owners. Contents are subject to change without notice. 02/2023.
Service Parts Diagrams Revision History
Revision 1 - February, 2023
• New document
Standard Warranty Terms
Base product: Three-year limited equipment warranty
First Customer Ship: December, 2022

Service Parts Diagrams for the MX-V4/V4N/V4-VO and MX-V4-PW/V4N-PW series i
Service Parts Diagrams for the MX-V4/V4N/V4-VO and
MX-V4-PW/V4N-PW series
Identifying Your Product Using the Serial Number ................................................................... 1
Service Parts ................................................................................................................................. 2
Optional MX Pen Replacement Nibs - Set of 10 (Part No. 1037955) ........................................ 4

ii Service Parts Diagrams for the MX-V4/V4N/V4-VO and MX-V4-PW/V4N-PW series

Service Parts Diagrams for the MX-V4/V4N/V4-VO and MX-V4-PW/V4N-PW series 1
Identifying Your Product Using the Serial Number
To make sure that you have the correct service parts diagrams, you must verify the serial number of your display. The serial
number of the flat panel display will be located on the left side.
Unique Serial Number
K152OW48G0552
Serial Number Location

5
4
3
6
2
1
2Service Parts Diagrams for the MX-V4/V4N/V4-VO and MX-V4-PW/V4N-PW series
Service Parts
Item Part No. Qty Description
11035668 2Pen, SBID - MX
21033596 3Antenna
31035792 1Assembly, remote control
41028289 1Cable, USB, A-B, 16' (5.0 m)
51022063 1Cable, power, North America, 8' (2.4 m)
593-055 1Cable, power, United Kingdom, 8' (2.4 m)
593-056 1Cable, power, Autstralia, 8' (2.4 m)
593-054 1Cable, power, Europe, 8' (2.4 m)
593-00708-20 1Cable, power, China, 8' (2.4 m)

Service Parts Diagrams for the MX-V4/V4N/V4-VO and MX-V4-PW/V4N-PW series 3
593-00654-20 1Cable, power, Japan, 8' (2.4 m)
593-063 1Cable, power, South Africa, 8' (2.4 m)
51018969 1Cable, power, Singapore, 14' 9" (4.5 m)
51018970 1Cable, power, India, 14' 9" (4.5 m)
51018971 1Cable, power, Saudi Arabia, 14' 9" (4.5 m)
51018972 1Cable, power, Brazil, 14' 9" (4.5 m)
51025597 1Cable, power, Argentina, 14' 9" (4.5 m)
51025603 1Cable, power, Chile and Italy, 14' 9" (4.5 m)
51030859 1Cable, power, Korea, 8' (2.4 m)
6 SBID-ID-1 2 Identification cards for NFC enabled SMART Board interactive displays - Qty 1
NOTE: Not included with any MX-V4 models that begin with "SBID-MX0".
Not shown 1038587 1Kit, packaging, 55"
Not shown 1038615 1Kit, packaging, 65"
Not shown 1038616 1Kit, packaging, 75"
Not shown 1038631 1Kit, packaging, 86"

( 10)
4Service Parts Diagrams for the MX-V4/V4N/V4-VO and MX-V4-PW/V4N-PW series
Optional MX Pen Replacement Nibs - Set of 10 (Part No. 1037955)
NOTE: The replacement nibs are compatible with the version of MX pen shown below.
NOTE: The replacement nibs are NOT compatible with the versions of MX pen shown below.
