smartheart 01-5025 User manual

Automatic Digital
Blood Pressure Arm Monitor
Model # 01-5025
INSTRUCTION MANUAL
ENGLISH AND SPANISH
mmHg
Please read this instruction manual
completely before operating this unit.

2 • ENGLISH
Digital Monitor Adult Arm Cuff
Instruction Manual
Quick Start Guide
Blood Pressure Reading Tracking Log
FAQ Information Sheet
Replacement Parts Order Form
STOP!
PLEASE ENSURE YOU HAVE ALL OF THE
FOLLOWING COMPONENTS BEFORE USING
YOUR DIGITAL BLOOD PRESSURE MONITOR
IF YOU ARE MISSING ANY PARTS, INCLUDING INSERTS OR
INSTRUCTION MANUALS, DO NOT RETURN TO PLACE OF
PURCHASE. CONTACT CUSTOMER CARE AT 866-326-1313.

ENGLISH • 3
Care & Safety Information.................................................. 4-5
Introduction & Indications for Use........................................... 6
Digital Blood Pressure Monitor Features .................................. 7
Getting Started .................................................................... 8
Battery Installation ............................................................... 9
Applying Your Blood Pressure Cuff .................................. 10-11
Taking Your Blood Pressure Reading ................................ 12-13
Memory Recall .................................................................. 13
Interpreting Your Results ................................................. 14-15
Care and Maintenance....................................................... 16
Display Symbols ................................................................ 17
Troubleshooting ................................................................. 17
FCC Statement................................................................... 18
Electromagnetic Compatibility......................................... 19-22
Specications .................................................................... 23
Warranty .......................................................................... 24
Instrucciones en Español ................................................ 25-48
INDEX
SmartHeart™
Manufactured for
Veridian Healthcare
1175 Lakeside Drive
Gurnee, IL 60031
Made in China
#93-1229 06/16
©2014 Veridian Healthcare, LLC
Toll-Free Customer Care Help Line: 1-866-326-1313
Monday – Friday 8:30 a.m. – 4:30 p.m. CST

4 • ENGLISH
CARE & SAFETY INFORMATION
NOTE: Read all instructions carefully before use. The following basic precautions
are needed when using an electrical product.
CAUTION: Failure to read and observe all precautions could result in personal
injury or equipment damage.
Improper care or use of your blood pressure monitor may result in injury, damage
to the unit or ineffective treatment. Following these instructions will ensure the
blood pressure monitor’s efcacy and long life.
GENERAL CAUTIONS AND WARNINGS
• Measurement results should be discussed with your physician or healthcare
professional; never self-diagnose or attempt treatment as this may be
dangerous
• Intended for adult use only; this device is not approved for infant or child use
• Keep out of reach of children
• Do not use the unit if it has any damaged parts (including power cord or plug
and cuff), if it has been submersed in water or dropped
• If any abnormality occurs, discontinue use until the unit has been examined and
repaired
• Only use included attachments and parts; do not use attachments from other
brands or models as these may not be properly calibrated for use with this
device and may result in measurement error
• Do not disassemble the unit or attempt to repair it; substitution of a component
different from that supplied may result in measurement error and will void
manufacturer warranty
• Always follow local regulations for proper disposal of the monitor, cuff and
batteries

ENGLISH • 5
CARE & SAFETY INFORMATION
OPERATING CAUTIONS AND WARNINGS
• Prolonged over-ination may cause congestion, swelling or bruising in some
people
• If you experience any discomfort or an abnormality occurs, stop using the
device immediately; to stop the device during operation, press the START/
STOP button and the cuff will automatically deate
• Operation outside of stated operating temperature may result in measurement
error or device malfunction; operation environment temperature is: 41°F –
104°F (5°C – 40°C); Humidity: ≤85% RH max
• Never use this unit while operating a vehicle or in the bathtub or shower
STORAGE CAUTIONS AND WARNINGS
• Storage outside of stated storage temperature may result in measurement error
or device malfunction; storage environment temperature is: 14°F – 131°F
(-10°C – 55°C); Humidity: <95%
• Keep the unit out of reach of small children
• Always keep the unit unplugged while not in use; remove the batteries if the
unit will not be used for an extended period of time
CLEANING CAUTIONS AND WARNINGS
• Never immerse the unit in water to clean as it may damage the unit
• Follow the ‘Cleaning and Maintenance’ portion of this manual for instruction
on how to clean and care for your monitor

6 • ENGLISH
INTRODUCTION & INDICATIONS FOR USE
It is recommended that you rst seek the advice and recommendation of your
physician or healthcare professional when using home diagnostic devices,
including blood pressure monitors.
Automatic digital blood pressure monitors use the oscillometric method to
electronically measure your blood pressure. The monitor detects your blood’s
movement through the artery in your arm and converts the movements into a
digital reading. The oscillometric method does not require a stethoscope, making
the monitor ideal for home use.
Blood pressure readings determined with this device are equivalent to
measurements obtained by a trained healthcare professional using the cuff/
stethoscope auscultation method, within the limits prescribed by the American
National Standard for Electronic or Automated Sphygmomanometers.
Thank you for purchasing a SmartHeart Automatic Digital Blood Pressure Monitor.
With proper care and use, your monitor will provide you with many years of
reliable readings.
PLEASE READ THIS INSTRUCTION MANUAL
COMPLETELY BEFORE OPERATING THIS UNIT.

ENGLISH • 7
BLOOD PRESSURE MONITOR FEATURES
DETAILS OF THE DIGITAL DISPLAY SCREEN AND INTERPRETATION OF
THE SYMBOLS ARE INCLUDED THROUGHOUT THIS MANUAL.
Arm Cuff
Cuff
Connector
Battery
Compartment
(underside)
Digital Display
START/STOP
Button
(power on/off)

8 • ENGLISH
GETTING STARTED
Before Taking a Measurement
1. Your readings should only be interpreted by your physician or healthcare
professional with access to your individual medical history. Regular use of a
home blood pressure monitor will allow you to track and record your readings
for discussion with your physician.
2. Conduct your measurement in a quiet place while seated in a relaxed position.
Rest for 15 minutes before taking your reading. If an error occurs or you desire
to take a second reading, allow 15 minutes between readings for your blood
vessels to return to normal.
3. Avoid smoking, eating, taking medication, alcohol, physical activity or any
other stressful activity for 30 minutes prior to taking a reading.
4. Always remove any jewelry or constrictive clothing that may interfere with the
cuff placement.
5. Keep yourself and the monitor still during measuring; do not talk during the
reading.
6. It is recommended that you take your readings as the same time each day to
better monitor any indications in your results.
7. Record your daily measurement on the included chart or some other written
document to share with your physician.

ENGLISH • 9
BATTERY INSTALLATION
This unit requires 4 AA batteries (not included).
It is necessary to replace the batteries when the Low
Battery symbol appears on the display, Fig 1, or when the
display does not turn on after the START/STOP button is
pressed.
The battery compartment is located on the underside of
this monitor.
1. Depress the clip in the battery
compartment cover and remove the
cover.
2. Insert or replace 4 AA batteries into
the battery compartment, ensuring to
match the indicated polarity symbols,
Fig 2. Always use new batteries.
3. Replace the battery cover.
4. Dispose of batteries according to local
disposal and recycling regulations.
It is recommended to remove the batteries
if the unit will not be used for an extended
period of time.
The ‘Low Battery’
symbol will appear
on the left side
of the display.
Fig. 1
Fig. 2

10 • ENGLISH
FITTING AND APPLYING YOUR CUFF
PROPER CUFF FIT AND PLACEMENT IS CRITICAL IN OBTAINING
ACCURATE BLOOD PRESSURE MEASUREMENTS. PLEASE READ THESE
INSTRUCTIONS CAREFULLY AND CONSIDER CONSULTING WITH
YOUR PHYSICIAN FOR FURTHER DIRECTION.
Before applying your blood pressure cuff, be sure you have
selected the appropriate size cuff.
To determine the proper cuff size, measure the circumference
of your left upper arm at the point midway between inside
bend of your elbow and your shoulder.
Adult Cuff ts arm circumference 8-3/4”—14-1/8” (22—36 cm)
A large adult cuff is (11-7/8” – 16-1/2”) is available for order on the enclosed
order form.
If for any reason you are unable to or should not use your left arm, please modify
the instructions for cuff application to your right arm. Your physician can help you
identify which arm is best for you to take measurements from.
Assembling Your Cuff
Your cuff may need to be ‘threaded’ through the metal bar
to form the cuff cylinder for your arm.
1. Lay the open cuff hook and loop side down, size/
instruction wording side up on a at surface.
2. Keeping the words on the inside of the cuff, thread the
end of the cuff through the metal bar, Fig 1. The end
of the cuff should be able to fold over onto itself for
securing via the hook and loop closure, Fig 2.
Fig. 1
Fig. 2

ENGLISH • 11
FITTING AND APPLYING YOUR CUFF
Applying Your Cuff
Be seated at a table or desk with your feet at on the
oor. To avoid accidentally pulling on or dropping your
monitor, the cuff should not be plugged into the monitor
until after the cuff is applied to your arm.
1. Remove any constrictive clothing or jewelry that may
interfere with cuff placement.
2. Slide the cuff cylinder onto your left arm and align the
artery mark over the main artery on the inside of your
arm, Fig 3.
The tube should follow the inside length of the arm,
Fig 4.
3. The bottom edge of the cuff should be positioned
approximately one inch above the elbow joint, Fig 5.
4. The INDEX mark arrow should be within the range
bar marking as shown, Fig 6; if the INDEX arrow is
outside of the range, a different sized cuff is needed.
The cuff should t comfortably, yet snugly around your
arm. You should be able to insert one nger easily
between your arm and the cuff.
Fig. 3
Fig. 5
Fig. 4
Fig. 6
0.8-1.2”/2-3cm

12 • ENGLISH
TAKING YOUR BLOOD PRESSURE READING
Please read the preceding portions of this manual
prior to taking your rst reading.
Reminder, it is important to avoid smoking,
eating, taking medication, alcohol consumption
or physical activity 30 minutes prior to taking a
reading.
1. Position the monitor on a at, stable surface
with the digital display in view.
2. Insert the cuff tubing connector into the port
on the left side of your monitor.
3. Rest your elbow on a solid surface with your
palm facing upward. Elevate your arm so that
the cuff is at the same level as your heart, Fig
1. Relax your left hand.
4. Press the START/STOP button to turn the unit
on; the unit will briey ash a self-test, Fig 2.
5. The display will briey show a ashing ‘0’
before the measurement begins.
6. The cuff will automatically inate to
approximately 190mmHg; you will see the
numbers go up on the display screen.
7. When the ination has reached optimum
level, the display will begin to show the
decreasing pressure while you feel the
pressure of the cuff decrease.
Fig. 1
mmHg
Fig. 2

ENGLISH • 13
TAKING YOUR BLOOD PRESSURE READING
8. When the measurement is complete, your blood
pressure measurement and pulse will display
simultaneously on the screen, Fig 3.
9. Select START/STOP to turn the unit off and
conserve energy and battery life.
10. The unit will automatically shut-off approximately
3 minutes after use.
11. Disconnect the cuff and tubing prior to storage.
YOU CAN STOP THE INFLATION OR DEFLATION PROCESS AT ANY
TIME BY PRESSING THE START/STOP BUTTON.
mmHg
Fig. 3
MEMORY RECALL
This monitor will save only the last measurement result
for review.
1. When the monitor is OFF, press and hold the
START/STOP button for 3+ seconds.
2. The display will show the last measurement taken.
3. The unit will automatically shut-off approximately
3 minutes after use; press the START/STOP button
to turn the unit off as desired.
NOTE: If the batteries are replaced or expire, the
last measurement will be deleted.
mmHg

14 • ENGLISH
Irregular Heartbeat
An irregular heartbeat is dened as a heartbeat rhythm that is more than 25%
slower or 25% faster than the average measurement detected while the monitor is
conducting the measurement.
If you know you have an irregular heartbeat, please consult with your physician or
trained healthcare professional for further information regarding the best method
for home blood pressure monitoring for your particular health condition.
INTERPRETING YOUR BLOOD PRESSURE READING
Pulse
Pulse
Irregular Heartbeat
Normal Heartbeat
Blood
Pressure
Blood
Pressure
Short
Beat Long Beat

ENGLISH • 15
INTERPRETING YOUR BLOOD PRESSURE READING
Hypertension Indicator - WHO Classications
This chart can help you identify where your blood pressure measurements fall
according to WHO classication standards. This chart should only be considered
as a guideline; always consult with your physician to interpret your individual
results. Never adjust your medication(s) dosage, or severely alter your diet or
exercise routine without consulting with your physician.
Optimal
Systolic pressure: < 120 mmHg
or
Diastolic pressure: < 80 mmHg
Normal
Systolic pressure: ≥ 120-129 mmHg
or
Diastolic pressure: ≥ 80-84 mmHg
High Normal
Systolic pressure: ≥ 130-139 mmHg
or
Diastolic pressure: ≥ 85-89 mmHg
Stage 1 Hypertension
Systolic pressure: ≥ 140-159 mmHg
or
Diastolic pressure: ≥ 90-99 mmHg
Stage 2 Hypertension
Systolic pressure: ≥ 160-179 mmHg
or
Diastolic pressure: ≥ 100-109 mmHg
Stage 3 Hypertension
Systolic pressure: ≥ 180 mmHg
or
Diastolic pressure: ≥ 110 mmHg

16 • ENGLISH
CARE AND MAINTENANCE
Proper care and maintenance of your blood pressure monitor will help ensure long
life for the product; improper use of the monitor may void the included warranty.
Always disconnect the cuff and tubing from the monitor prior to cleaning and
storage.
Monitor Care and Maintenance
• Do not use any liquids on the monitor; use a soft, dry cloth to clean the monitor
as needed
• Storage outside of stated storage temperature may result in measurement error
or device malfunction; storage environment temperature is: 14°F – 131°F
(-10°C – 55°C); Humidity: <95%
• Always keep the unit unplugged while not in use; remove the batteries if the
unit will not be used for an extended period of time
• Do not attempt to disassemble your monitor; disassembling your monitor may
void the manufacturers warranty
• Do not subject the monitor to strong shocks; take care not to drop the monitor
Cuff Care and Maintenance
• The cuff should not be submerged or washed in a washing machine, but may
be spot cleaned with a mild-detergent as needed
• Never attempt to iron or dry the cuff; if the cuff becomes wet, allow the cuff to
air dry completely before use or storage
• Do not attempt to remove the tube and bladder from the nylon cuff as this may
damage the cuff
• Take care not to forcefully bend or kink the tubing during storage

ENGLISH • 17
DESCRIPTION OF DISPLAY SYMBOLS
TROUBLESHOOTING
Low battery
Symbol Meaning
Problem Possible Cause Solution
Symbol Meaning
Cuff position was not correct or
was not tight enough
Speaking, excessive movement,
angry, excited or nervous anxiety
during measurement
Cuff failed to inate properly
Improper operation of the device
Pressurization is over 300mmHg
Batteries may be expired or
installed improperly
Display shows an
abnormal result or
the result is outside
of typical range
Display shows
Display is blank
when power is on
An error has occurred during ination
The measurement has failed
Apply the cuff properly and attempt a
new measurement; consult the applying
your cuff section of this manual for more
information about cuff application
Wait a period of time and attempt a new
measurement after calm has returned; do
not speak or move during measurement
Ensure the air hose is properly connected
to the cuff and monitor
Review the ‘Taking a Measurement’
portion of this manual and attempt a new
measurement
Review the ‘Taking a Measurement’
portion of this manual and attempt a new
measurement
Check the polarity of the batteries and
reinstall if necessary; replace batteries with
new batteries

18 • ENGLISH
FCC STATEMENT
NOTE:
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only)
This product has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. The product generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If the product does cause harmful interference to radio or television
reception, which can be determined by turning the product on and off, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for Canada only)
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the interference-causing equipment
standard entitled “Digital Apparatus”, ICES-003 of the Canadian Department of
Communications.
Cet appareil numérique respecte les limites de bruits radioeléctriques applicables
aux appareils numériques de Clase B prescrites dans la norme sur le materiel
brouilleur:
“Appareils Numériques”, ICES-003 édictée par le minister des communications.
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

ENGLISH • 19
ELECTROMAGNETIC COMPATIBILITY
Table 1
For all ME EQUIPMENT and ME SYSTEMS
Guidance and manufacture’s declaration - electromagnetic emissions
This monitor is intended for use in the electromagnetic environment specied below.
The customer or the user of this monitor should assure that it is used in such an environment.
Emmission Test Compliance Electromagnetic Environment Guidance
Group 1
Class B
Class A
Complies
This monitor uses RF energy only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause any interference in nearby
electronic equipment.
This monitor is suitable for use in all establishments, including domestic
establishments and those directly connected to the public low-voltage power
supply network that supplies buildings used for domestic purposes.
RF emissions
CISPR 11
RF emissions
CISPR 11
Harmonic emissions
IEC 61000-3-2
Voltage uctuations/
icker emissions IEC
61000-3-3

20 • ENGLISH
ELECTROMAGNETIC COMPATIBILITY
Table 2
For all ME EQUIPMENT and ME SYSTEMS
Guidance and manufacture’s declaration - electromagnetic immunity
This monitor is intended for use in the electromagnetic environment specied below.
The customer or the user of this monitor should assure that it is used in such an environment.
Electrostatic discharge
(ESD)
IEC 61000-4-2
Electrical fast
transient/burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
Power frequency
(50/60 Hz)
magnetic eld
IEC 61000-4-8
± 6 kV contact
± 8 kV air
± 2 kV for power supply lines
± 1 kV for input/output lines
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
<5 % UT
(>95 % dip in UT)
for 0.5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
for 25 cycles
<5 % UT
(>95 % dip in UT)
for 5 s
3 A/m
± 6 kV contact
± 8 kV air
± 2 kV for power supply lines
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
<5 % UT
(>95 % dip in UT)
for 0.5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
for 25 cycles
<5 % UT
(>95 % dip in UT)
for 5 s
3 A/m
Floors should be wood, concrete or ceramic tile.
If oors are covered with synthetic material, the
relative humidity should be at least 30 %.
Mains power quality should be that of a typical
commercial or hospital environment.
Mains power quality should be that of a typical
commercial or hospital environment.
Mains power quality should be that of a typical
commercial or hospital environment. If the user of
this monitor requires continued operation during
power mains interruptions, it is recommended that
this monitor be powered from an uninterruptible
power supply or a battery.
Power frequency magnetic elds should be at
levels characteristic of a typical location in a typical
commercial or hospital environment.
Immunity Test IEC 60601 Test Level Compliance Level Electromagnetic Environment Guidance
