smartheart 01-540 User manual

INSTRUCTION MANUAL
ENGLISH AND SPANISH
Please read this instruction manual
completely before operating this unit.
Automatic Digital
Blood Pressure Wrist Monitor
Model # 01-540

2 • ENGLISH
Digital Monitor 2 AAA Batteries Storage Case
Instruction Manual
Quick Start Guide
Blood Pressure Reading Tracking Log
FAQ Information Sheet
STOP!
PLEASE ENSURE YOU HAVE ALL OF THE
FOLLOWING COMPONENTS BEFORE USING
YOUR DIGITAL BLOOD PRESSURE MONITOR
IF YOU ARE MISSING ANY PARTS, INCLUDING INSERTS OR
INSTRUCTION MANUALS, DO NOT RETURN TO PLACE OF
PURCHASE. CONTACT CUSTOMER CARE AT 866-326-1313.

ENGLISH • 3
Care & Safety Information.............................................................4-6
Introduction & Indications for Use..................................................... 7
Blood Pressure Monitor Features ....................................................8-9
Getting Started ............................................................................ 10
Battery Installation ....................................................................... 11
Setting Date & Time..................................................................12-13
Fitting & Applying Your Cuff ......................................................14-15
Taking Your Blood Pressure Reading ...........................................16-17
Interpreting Your Results ............................................................18-19
Memory Function .....................................................................20-21
Care & Maintenance................................................................22-23
Device & Label Symbols................................................................ 24
Display Symbols .......................................................................... 25
Troubleshooting ........................................................................... 26
Error Codes................................................................................. 27
FCC Statement............................................................................. 28
Electromagnetic Compatibility....................................................29-31
Specications .............................................................................. 32
Warranty .................................................................................... 33
Instrucciones en Español ...........................................................35-67
Reference Page............................................................................ 68
INDEX
SmartHeart™
Manufactured for
Veridian Healthcare
1175 Lakeside Drive
Gurnee, IL 60031
Made in China
#93-1081 07/20
©2020 Veridian Healthcare, LLC
Toll-Free Customer Care Help Line: 1-866-326-1313
Monday – Friday 8:30 a.m. – 4:30 p.m. CST

4 • ENGLISH
CARE & SAFETY INFORMATION
NOTE: Read all instructions carefully before use. The following basic precautions
are needed when using an electrical product.
CAUTION: Failure to read and observe all precautions could result in personal
injury or equipment damage.
Improper care or use of your blood pressure monitor may result in injury, damage
to the unit or ineffective treatment. Following these instructions will ensure the
blood pressure monitor’s efcacy and long life.
GENERAL CAUTIONS AND WARNINGS
• Measurement results should be discussed with your physician or healthcare
professional; never self-diagnose or attempt treatment as this may be
dangerous.
• Intended for adult use only; this device is not approved for neonate, infant or
child use. Not for use by pregnant women.
• Keep out of reach of children.
• The patient is the intended operator of this device.
• Do not use the unit if it has any damaged parts (including cuff), if it has been
submersed in water or dropped.
• If any abnormality occurs, discontinue use until the unit has been examined
and repaired.
• Only use included attachments and parts; do not use attachments from other
brands or models as these may not be properly calibrated for use with this
device and may result in measurement error.
• Do not disassemble the unit or attempt to repair it; substitution of a component
different from that supplied may result in measurement error and will void
manufacturer warranty.
• Always follow local regulations for proper disposal of the monitor, cuff and
batteries.

ENGLISH • 5
CARE & SAFETY INFORMATION
• Swallowing batteries and battery uid is extremely dangerous; keep batteries
and unit out of reach of children and disabled persons.
• Do not use this device with other diagnostic monitoring equipment on the same
limb.
• Do not use near active HF Surgical Equipment and the RF shielded room of
an ME system for magneticresonance imaging, where the intensity of the EM
Disturbances is high.
• Do not share this device with infected persons where there may be a risk of
cross-contamination.
• Consult with your physician before if the cuff may be applied over a wound or
inamation diseases.
• It is inappropriate for people with serious arrhythmia to use this Electronic
Sphygmomanometer.
• Consult with your physician before use if any of the following conditions
are present: arrhythmia, common arrhythmias such as atrial or ventricular
premature beats or atrial brillation, arterial sclerosis, poor perfusion,
diabetes, pre-eclampsia, renal diseases. inammatory diseases, intravascular
therapy, arteriovenous shunts or if a mastectomy has been performed.
• Motion, trembling and shivering may affect measurement reading.
• For information regarding potential electromagentic or other interference
between digital monitor and other devices and advice on avoidance of such
interference, consult with the Electromagnetic Compatibility portion of this
manual.
• Monitor should be kept at least 12” from other wireless devices during use.
• If you are allergic to plastic or rubber, consult with your medical professional
before using this device.

6 • ENGLISH
OPERATING CAUTIONS AND WARNINGS
• Prolonged over-ination may cause congestion, swelling or bruising in some
people.
• Too-frequent measurements may cause injury due to blood ow interference.
• Check the circulation of the user before, during and after use.
• If you experience any discomfort or an abnormality occurs, stop using the
device immediately; to stop the device during operation, press the POWER
button and the cuff will automatically deate.
• Operation outside of stated operating temperature may result in measurement
error or device malfunction; operation environment temperature is: 41°F –
104°F (5°C – 40°C); humidity: ≤90% RH.
• Never use this unit while operating a vehicle or in the bathtub or shower.
STORAGE CAUTIONS AND WARNINGS
• Storage outside of stated storage temperature may result in measurement
error or device malfunction; storage environment temperature is: -4°F – 131°F
(-20°C – 55°C); humidity: ≤90% RH.
• Keep the unit out of reach of children.
• Always keep the unit unplugged while not in use; remove the batteries if the
unit will not be used for an extended period of time.
CLEANING CAUTIONS AND WARNINGS
• Never immerse the unit in water to clean as it may damage the unit.
• Follow the ‘Care & Maintenance’ portion of this manual for instruction on how
to clean and care for your monitor.

ENGLISH • 7
INTRODUCTION & INDICATIONS FOR USE
It is recommended that you rst seek the advice and recommendation of your
physician or healthcare professional when using home diagnostic devices,
including blood pressure monitors.
Automatic digital blood pressure monitors use the oscillometric method to
electronically measure your blood pressure. The monitor detects your blood’s
movement through the artery in your arm and converts the movements into a
digital reading. The oscillometric method does not require a stethoscope, making
the monitor ideal for home use.
Blood pressure readings determined with this device are equivalent to
measurements obtained by a trained healthcare professional using the cuff/
stethoscope auscultation method, within the limits prescribed by the American
National Standard for Electronic or Automated Sphygmomanometers.
Thank you for purchasing an Automatic Digital Blood Pressure Monitor. With
proper care and use, your monitor will provide you with many years of reliable
readings.
PLEASE READ THIS INSTRUCTION MANUAL
COMPLETELY BEFORE OPERATING THIS UNIT.

8 • ENGLISH
BLOOD PRESSURE MONITOR FEATURES
Wrist Cuff
Digital Display
DETAILS OF THE DISPLAY AND INTERPRETATION OF THE SYMBOLS ARE
INCLUDED THROUGHOUT THIS MANUAL.
MEMORY
Recall Button
START/POWER
Button (on/off)
Battery
Compartment
(underside)

ENGLISH • 9
BLOOD PRESSURE MONITOR FEATURES
DETAILS OF THE DIGITAL DISPLAY SCREEN AND
INTERPRETATION OF THE SYMBOLS ARE INCLUDED
THROUGHOUT THIS MANUAL.
WHO Indicator
Pressure
Release
Irregular
Heartbeat
Memory
Mode
Date & Time
Low Battery
Memory
Bank View
(Alternates)
Systolic Pressure
Diastolic Pressure
Pulse Rate
(Alternates)
MEM

10 • ENGLISH
GETTING STARTED
Before taking a measurement
1. Your readings should only be interpreted by your physician or healthcare
professional with access to your individual medical history. Regular use of a
home blood pressure monitor will allow you to track and record your readings
for discussion with your physician.
2. Conduct your measurement in a quiet place while seated in a relaxed position.
Rest for 15 minutes before taking your reading. If an error occurs or you desire
to take a second reading, allow 15 minutes between readings for your blood
vessels to return to normal.
3. Avoid smoking, eating, taking medication, alcohol, physical activity or any
other stressful activity for 30 minutes prior to taking a reading.
4. Always remove any jewelry or constrictive clothing that may interfere with the
cuff placement.
5. Keep yourself and the monitor still during measuring; do not talk during the
reading.
6. It is recommended that you take your readings at the same time each day to
better monitor any indications in your results.
7. Record your daily measurement on the included chart or some other written
document to share with your physician.

ENGLISH • 11
1. Press down and lift the cover.
2. Insert or replace 2 AAA batteries into
the battery compartment, ensuring to
match the indicated polarity symbols.
Always use new batteries.
3. Replace the battery cover.
4. Dispose of batteries according
to local disposal and recycling
regulations.
It is recommended to remove the
batteries if the unit will not be used for an
extended period of time.
BATTERY INSTALLATION
The ‘Low
Battery’ symbol
will appear on
the display.
This unit comes complete with 2 AAA
batteries.
It is necessary to replace the batteries when the ‘Low
Battery’ symbol appears on the display or when the
display does not turn on after the START/POWER button
is pressed.
The battery compartment is located on the underside of
this monitor.

12 • ENGLISH
SETTING DATE/TIME
IT IS NECESSARY TO SET THE DATE AND TIME FOR THE
UNIT EVERY TIME BATTERIES ARE INITIALLY INSTALLED OR
REPLACED.
DATE AND TIME WILL DEFAULT TO FACTORY SETTINGS,
12:00/1(M)-1(D), IF YOU DO NOT CHOOSE TO SET THE
CORRECT DATA.
The date/time feature is on the bottom left of
the display screen, Fig 1. The date and time will
alternate every four seconds regardless of the
operating mode.
1. When the unit is off, press and hold the START
and MEM button at the same time. The unit will
beep once and the month will begin to ash,
Fig. 2.
2. Press the MEM button to change until the
desired number appears. To scroll through the
numbers quicker, hold down the MEM button
as the numbers advance.
The MEM and START/
POWER buttons are located
on the right side of the
monitor.
12
Fig. 1
Fig. 2

ENGLISH • 13
SETTING DATE/TIME
3. Press the START button to conrm the month entry.
4. Next, the date will blink. Repeat steps 2 and 3 to set the date, then hours, then
minutes. This unit does not track the year.
5. After setting the minutes, the unit will automatically exit out of the date/time
setting mode.
When the monitor is off, the date and time will still appear on the display.
Time is displayed in 24hr Military Time. This chart explains the time conversion.
MILITARY TIME = REGULAR TIME
1:00 = 1AM 7:00 = 7AM 13:00 = 1PM 19:00 = 7PM
2:00 = 2AM 8:00 = 8AM 14:00 = 2PM 20:00 = 8PM
3:00 = 3AM 9:00 = 9AM 15:00 = 3PM 21:00 = 9PM
4:00 = 4AM 10:00 = 10AM 16:00 = 4PM 22:00 = 10PM
5:00 = 5AM 11:00 = 11AM 17:00 = 5PM 23:00 = 11PM
6:00 = 6AM 12:00 = 12PM 18:00 = 6PM 24:00 = 12AM

14 • ENGLISH
FITTING & APPLYING YOUR CUFF
PROPER CUFF FIT AND PLACEMENT IS CRITICAL IN
OBTAINING ACCURATE BLOOD PRESSURE MEASUREMENTS.
PLEASE READ THESE INSTRUCTIONS CAREFULLY AND
CONSIDER CONSULTING WITH YOUR PHYSICIAN FOR
FURTHER DIRECTION.
Before applying your blood pressure cuff, be sure your wrist is within the
appropriate cuff range:
Wrist Circumference Range Suitable for 5.5” – 7.6” (14 cm – 19.5 cm).
Reminder, it is important to avoid smoking, eating, taking medication, alcohol
consumption or physical activity 30 minutes prior to taking a reading.
If for any reason you are unable to or cannot not use your left wrist, please modify
the instructions for cuff application to your right wrist. Your physician can help you
identify which wrist is best for you to take measurements from.
Applying Your Cuff
1. Remove any constrictive clothing or
jewelry that may interfere with cuff
placement.
2. Be seated at a table or desk with your
feet at on the oor.
3. Hold your left arm in front of you with
your palm facing upward.

ENGLISH • 15
FITTING & APPLYING YOUR CUFF
Fig. 1
Fig. 2
4. Apply the cuff to your left wrist so that the digital
display face is positioned on the inside area of
your wrist facing you, Fig. 1.
5. Adjust the cuff approximately 0.5” from the edge
of the head of the ulna bone, Fig. 2.
6. The cuff should t comfortably, yet snugly around
your wrist.
If you are not comfortable with applying your cuff,
please seek the assistance of another member of your
household or work with your physician to practice the
cuff application. Incorrectly applied cuffs may result in
inaccurate readings.

16 • ENGLISH
TAKING YOUR BLOOD PRESSURE READING
1. Rest your elbow on a solid surface with your
palm facing upward. Elevate your arm so that
the cuff is at the same level as your heart, Fig
1. Be certain that cuff is elevated to the proper
level; you may choose to support your hand
with a folded towel or book. Relax your left
hand. Be seated with your feet at on the oor
and legs uncrossed.
2. Press and release the START/POWER button
to turn on device. The unit will run a self-test,
Fig. 2
3. The display will briey show a ashing arrow
and ‘0’ before the measurement begins, Fig 3.
4. The cuff will automatically inate to
approximately190mmhg or 40 mmhg higher
than the last systolic pressure reading stored in
memory.
5. When the ination has reached optimum level,
the display will begin to show the decreasing
pressure while you feel the pressure of the cuff
decrease.
Fig. 1
Please read the preceding portions of this manual
prior to taking your rst reading.
Reminder: It is important to avoid smoking, eating,
taking medication, alcohol consumption or physical
activity 30 minutes prior to taking a reading.
YOU CAN STOP THE INFLATION OR DEFLATION PROCESS AT
ANY TIME BY PRESSING THE POWER BUTTON.
Fig. 2
Fig. 3
MEM

ENGLISH • 17
TAKING YOUR BLOOD PRESSURE READING
6. When the measurement is complete, your blood
pressure measurement and pulse will display
separately on the screen alternating repeatedly
every 2-3 seconds, Fig 4. The systolic and
diastolic readings will display at the same time.
7. The hypertension Indicator will indicate your
reading range in the right side of the display,
Fig 5. For more information see Interpreting
Your Results.
8. If an irregular heartbeat was detected during
the reading, the Irregular heartbeat Detector
icon will appear ashing on the display for
both the measurement results and pulse results
screens, Fig 6. For more information see
Interpreting Your Results.
9. The reading will automatically be stored in
memory, up to 60 readings.
10. Select START to turn the unit off and
conserve energy and battery life. The unit will
automatically shut-off and revert to time/date
mode after approximately 1 minute.
Fig. 4
Fig. 5
Fig. 6
Systolic/Diastolic Results
Pulse Results

18 • ENGLISH
Irregular Heartbeat Detector
An irregular heartbeat is dened as a heartbeat rhythm that is more than 25%
slower or 25% faster than the average measurement detected while the monitor is
conducting the measurement. When this device detects an irregular rhythm two or
more times during the reading, the IHB symbol will appear on the display screen.
This monitor will operate if the icon appears, but the results may be compromised,
especially if this symbol appears often. Please consult with your physician or
trained healthcare professional for further information regarding an irregular
heartbeat and if this symbol appears frequently.
INTERPRETING YOUR RESULTS
Pulse
Pulse
Irregular Heartbeat
Normal Heartbeat
Blood
Pressure
Blood
Pressure
Short
Beat Long Beat

ENGLISH • 19
INTERPRETING YOUR RESULTS
Hypertension Indicator
This unit features our unique Hypertension Indicator. The color bars on the right
side of the monitor display correspond with an icon on
the digital display, indicating where the measurement
results fall within the World Health Organization
standards.
The World Health Organization has established
globally accepted standards for the assessment of
high or low blood pressure readings. The below chart
should be considered only as a guideline, always
consult with your physician or health care professional to interpret your individual
results. Never adjust your medication(s) dosage, or severely alter your diet or
exercise routine without consulting with your physician.
Stage 3 Hypertension
Systolic pressure: ≥ 180 mmHg
or
Diastolic pressure: ≥ 110 mmHg
Stage 2 Hypertension
Systolic pressure: ≥ 160 ≤ 179 mmHg
or
Diastolic pressure: ≥ 100 ≤ 109 mmHg
Stage 1 Hypertension
Systolic pressure: ≥ 140 ≤ 159 mmHg
or
Diastolic pressure: ≥ 90 ≤ 99 mmHg
High Normal
Systolic pressure: ≥ 130 ≤ 139 mmHg
or
Diastolic pressure: ≥ 85 ≤ 89 mmHg
Normal
Systolic pressure: ≥ 120 ≤ 129 mmHg
or
Diastolic pressure: ≥ 80 ≤ 84 mmHg
Optimal
Systolic pressure: < 120 mmHg
or
Diastolic pressure: < 80 mmHg

20 • ENGLISH
MEMORY FUNCTIONS
Recalling Measurements in Memory
1. Press and release the MEM button. The unit will
show how many measurements are stored within
the bank, Fig 1.
2. Press the MEM button again to scroll through the
saved measurements. Measurements will appear
on the display from most current to oldest.
All results for a given measurement will display,
including measurement results, pulse rate,
hypertension Indicator, Irregular heartbeat alert
(if applicable), and date/time stamp, Fig 2.
The measurement results and pulse results will
alternate, ashing between measurement and
pulse every 2-3 seconds.
3. When the number of readings exceeds 60, the
oldest data will be replaced with the new record.
4. Press START to turn the monitor oFF at any time
during review of the stored measurements.. Fig. 2
Fig. 1
MEM
MEM
You can recall up to 60 total measurements in memory. These measurements can
be shared with your physician or trained healthcare professional.
