smartmi P1 User manual

Smartmi Air Purifier P1
User Manual
Making Appliances that Move People

Making
Appliances
that Move
People

Table of Contents Smartmi Air Purifier P1 User Manual
WARNING
Precautions
Package Contents
Product Overview
Installation
Use
QR Code for Installing "Smartmi" App
Maintenance and Care
Specifications
01
02
03
04
06
07
08
10
11

1
WARNING
When the power adapter is damaged, it must be replaced with a genuine power
adapter purchased from the manufacturer or after-sales service department.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
To reduce the risk of fire or electric shock, do not use this appliance with any
solid-state speed control device.
READ AND SAVE THESE INSTRUCTIONS

2
Do not stick your fingers or foreign objects
into the protective parts, movable parts, air
inlets, or air outlets.
Keep objects such as hairs or fabrics away
from the purifier to avoid blocking the air
inlets or air outlets.
Do not sit on, lean on or tilt the purifier.
When using in conjunction with gas-fueled
appliances (such as gas stoves, gas
heaters), please ventilate sufficiently to
avoid carbon monoxide poisoning.
Do not pour liquids, nor throw powders or
other small substances into the purifier's
air outlet.
Do not use the purifier in the following
circumstances, as they may result in electric
shocks, fire, or other damage:
Near open flames, such as candles,
incense burners, stoves, fireplaces,
cigarettes, firecrackers, lighters,
multipurpose torches, candle lighters, or
fire pans.
Near appliances that generate high
temperatures, such as electric heaters,
fan heaters, electric foot warmers,electric
stoves, electric irons.
Make sure no inflammable objects get into
the purifier.
In unstable locations where the purifier
can easily fall over.
In environments that are extremely hot,
humid, or damp, such as bathrooms.
Turn off and unplug the purifier before
moving it.
The purifier cannot turn on when the fan
grille and the filter compartment cover are
not installed properly.
Maintain a distance of at least 20 cm
between the air inlets and walls or other
objects.
Prior to cleaning or other maintenance, the
appliance must be disconnected from the
supply mains.
Frequently remove dust, hair, and other
particles from the outer mesh screen of
the filter, so as to reduce the chance of
bacteria growth.
Remove dust, hair, and particles from the
purifier's air inlets to prevent a reduction of
air intake.
Cover the air outlet to prevent dust, hair,
and other particles from falling in when the
purifier is left unused for a long time.
To avoid fire, electric shocks, or other
damage, use the power adapter and
electrical outlet as instructed below:
Do not excessively pull, twist or bend the
power adapter, as this may expose or
break the cord's core.
The power adapter must be plugged into a
suitable electrical outlet.
Use the power adapter that is provided
with the purifier, do not use any third party
power adapters.
Always unplug the purifier before carrying
out maintenance to or moving the air
purifier.
Immediately stop using the purifier
when it makes unusual sounds, gives off
bad odors, overheats, or its fan rotates
irregularly.
Precautions

3
Package Contents
Air Purifier
Power Adapter
User Manual
Read this manual carefully before use, and retain it for future reference.
Note: In this manual, the illustrations of the product and its accessories and the user interface are schematic diagrams for reference only.
The actual product may vary from that shown in the schematic diagrams due to product updates and upgrades. Please refer to the actual product.

4
Product Overview
Touch Display Screen
Fan Grille
Laser Particulate
Matter Sensor
Handle
Power Port
Front View Rear View

5
Screen Display
Light Sensor
Pollen Alert Indicator
PM2.5 Level
Wi-Fi Status Indicator
Custom Indicator
PM2.5 Indicator
Timer Mode Selection Button
Power Button
Timer Display
The timer display changes
according to which time
setting has been selected.
Press " " button to cycle
through time settings and to
activate the timer
Press " " button to switch
between purification modes.
Screen brightness will adjust
automatically based on the
surrounding environment,
thus avoiding night-time light
pollution.
After "Custom" mode is selected,
" " will illuminate on the screen.
Mode Display
Purifier operates in ultra-low
noise mode for a favorable
sleeping environment.
Sleep
Purifier operates at its optimal
mode and noise level. Applicable
for daily use.
Normal
Purification rate can be
customized by adjusting the
applicable range within the app.
Custom
Purification rate setting
automatically adjusts depending
on IAQ.
Auto
Green
Yellow
Orange
Red
Very good
Good
Moderate
Unhealthy
Auto Indicator
After "Auto" mode is selected,
" " will illuminate on the screen.

6
Installation
Place the purifier on a flat and stable surface with the touch screen
facing upwards.
Connect power adapter to the power
port at the bottom of the main unit. Then
connect the power adapter to a power
socket.
To allow the purifier to operate as effectively
as possible, maintain a suitable distance
between its air inlet and obstructions such
as walls (see figure above).
Note: For optimal air
purification, keep doors and
windows closed during use.
1 2
20cm or more
20cm or more
Placing the Purifier at an
Appropriate Place

7
Use
After connecting to a
power supply, press
" " button to power
on. Upon initial startup,
the purifier will operate
in "Auto" mode. For
subsequent startups,
it will operate in such
mode that it is shut
down previously.
Press " " button to set shutdown time in advance.
1
Press " " button to set a mode for the purifier.
2
3
Press " " button to turn the purifier off.
4
Note:
After the timer is activated, the indicator will illuminate. Available
time intervals are displayed as follows, "0h, 1h, 2h, 4h, and 8h". If 0h
is selected, the timer will be canceled.
To cancel the timer, press " " button until the timing indicator is
off and "0h" is displayed on the screen.
Once the timer runs out, the purifier will shut down automatically.
Upon startup, the purifier will not have a time setting for shutdown.
The timer will start again only if it has been reset.
CL
1h
2h
3h
4h
Note:
When "Auto" mode is selected, " " will be illuminated on the screen,
and the purifier will adjust the purification level automatically based
on the IAQ.
In "Custom" mode, settings may be adjusted after connecting to
the Smartmi app and adding a device. By default, the purifier can
operate at full capacity in this mode, resulting in slightly noisier
operation but superior results.
After the purifier has been activated, purification levels may be
adjusted at any time.

8
QR Code for
Installing
"Smartmi" App
This product is connected to the
Smartmi app and can be both
controlled and interconnected
with other products through the
Smartmi app.
Scan the QR code to download and
install the Smartmi app. Users who
have already installed the app may
navigate to the product connection
interface. Alternatively, you can
search for "Smartmi" in the app
store and download the app in this
way.
Open the Smartmi app, click "+" on
the home page, and add a device
when prompted.
Note: The Smartmi app may have been
updated. Please use the most current
version of the app.
You can lock/unlock the touch screen by
using the app. After the screen is locked,
you cannot operate the purifier by pressing
" " or " ".
When your phone connects to the purifier for the first time or if your phone fails to
connect, hold down the buttons " " and " " simultaneously for 5 seconds. The Wi-
Fi icon on the screen will flash. When you hear a sound, the Wi-Fi module has been
reset successfully.
Hold down the buttons " " and " " simultaneously for 10 seconds. After you hear a
sound, the purifier has been reset successfully.
Screen Lock
Resetting Wi-Fi
Resetting Purifier
Note:
The purifier can be turned off while in locked
mode.
If you press " " or " " button while in locked
mode, and "LOC" is displayed on the screen,
this indicates the purifier must be unlocked
using the app.

9
Note: Power off purifier and disconnect it from
the power supply before performing the following
operations.
Note: Since it contains activated carbon,
when saturated, the filter will retain
the odor of the harmful gases it has
absorbed. Leaving a used filter in a place
with adequate light and ventilation will
allow the activated carbon to recover,
partially restoring the filter's absorption
capability. Timely replacement of the
filter once the recommended filter life is
over is advised.
After replacing the filter and turning
on the purifier, hold down " " for 5
seconds. When you hear a sound, it
indicates the purifier has restarted
the filter replacement count.
Filters should be replaced every
6–12 months. The app will send a
reminder when the filter's lifespan
reaches 10% or less.
Click on the product page on the
app and check the filter level, which
will be displayed as a percentage.
1. Checking Filter Lifespan
2. Filter Replacement Reminder
Resetting the Filter
Filter Status Reminder Replacing and Resetting the Filter
98% of filter life
remaining
2% of filter life
remaining
Turn over the purifier and remove the filter by
rotating it counterclockwise.
1
Replace the filter by following the instructions
contained in the user manual.
2

10
Maintenance and Care
Power off purifier and disconnect it from the power supply before performing the following operations.
Cleaning the Filter
Housing
Turn over the purifier and
remove the filter by rotating it
counterclockwise.
1
Use a vacuum cleaner
to remove dust from the
ventilation hole and cabin
walls, or wipe them using a
soft cloth.
2
Re-install the filter after it has
been cleaned.
3
Note: Do not spray liquid onto the
purifier's casing, or wipe it using a wet
cloth. This could lead to drops of water
leaking into the base of the device.
Cleaning Laser
Particulate Matter
Sensor
Turn over the purifier and
remove the filter by rotating it
counterclockwise.
1
Use a screwdriver to loosen
the screws on the sensor
cover.
2
Remove the cover and
clean it with a hair dryer or
pneumatic air gun.
3
Once cleaning is finished,
fix the cover back onto
the sensor and tighten the
screws.
4
Note: Do NOT clean with hot air.

11
Specifications
*Tested for particulate matter by third party lab as according to GB/T 18801-2015
Name Smartmi Air Purifier P1 Rated Voltage 120 V~
Model ZMKQJHQP11 / ZMKQJHQP12 Rated Frequency 60 Hz
Item Dimensions φ220 × 362.5 mm Rated Power 30 W
Net Weight Approx. 3 kg Noise Level 50 dB
Suitable Temperature 5°C-40°C Suitable Humidity <85% RH
Recommended
Surface 15–26 m2* Wireless Connectivity Wi-Fi IEEE 802.11 b/g/n 2.4GHz

FCC ID:XXXXXXXX
Contains FCC ID : 2ANDL-TYWE3SE
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that may cause undesired operation.
Caution: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Limited by local law regulations, version for North America does not have region selection option.
To satisfy FCC RF exposure requirements, a separation distance of 20 cm or more should be maintained between the
antenna of this device and persons during device operation.
To ensure compliance, operations at closer than this distance is not recommended.
201120-Y
Manufactured by: Beijing Smartmi Electronic Technology Co., Ltd.
Address:Room 201-203, Unit 6, Building A, No. 66,Zhufang Road, Qinghe, Haidian District, Beijing
